Barco X 1.2 User guide

X-series
Safety manual
For fixed indoor installation
R5906876/00
24/07/2017

Barco Visual (Beijing) Electronics Co., Ltd
地址：北京市 昌平区 中关村科技园 昌平园 昌盛路 16号
Phone: [phone]
Fax: [phone]
Support: www.barco.com/en/support
Visit us at the web: www.barco.com
Registered address: Barco NV
President Kennedypark 35, 8500 Kortrijk, Belgium
Phone: [phone]
Fax: [phone]
Support: www.barco.com/en/support
Visit us at the web: www.barco.com
Printed in Belgium

1. Safety
1. SAFETY
About this chapter
Read this chapter attentively. It contains important information to prevent personal injury while installing the X-series display. Fur-
thermore, it includes several cautions to prevent damage to the X-series tiles. Ensure that you understand and follow all safety
guidelines, safety instructions and warnings mentioned in this chapter before installing the X-series tiles. After this chapter, addi-
tional “warnings” and “cautions” are given depending on the installation procedure. Read and follow these “warnings” and “cautions”
as well.
Clarification of the term “X-series” used in this document
When referring in this document to the term “X-series” means that the content is applicable for following Barco products:
•X1.2
•X1.5
•X2.5
•X4.0
1.1 Safety guidelines
Personal protection
WARNING:Ensure you understand and follow all the safety guidelines, safety instructions, warnings and
cautions mentioned in this manual.
WARNING:Be aware of suspended loads.
WARNING:Wear a hard hat to reduce the risk of personal injury.
WARNING:Be careful while working with heavy loads.
WARNING:Mind your fingers while working with heavy loads.
Installation personnel
This installation must be performed by authorized and qualified technical personnel only.
Accredited safety officers must ensure the safety of the site, construction, assembly, connection, use, dismantling, transport etc. of
such safety critical systems.
Operator
The products specified in the manual only can be operated and used by the professional who meets the requirements for this work.
The operator shall obey the instruction in this document, especially the safety and warning note herein. Due to the relevant training
and experience, professional have a more in-depth understanding of this product, they can avoid the risk of the process of the
operation.
The non-professional shall not assembly and disassembly at their own discretion, in case of high-voltage electric shock.
R5906876 X-SERIES 24/07/2017 1

1. Safety
Caution
Installation should be performed only after you are thoroughly familiar with all of the proper safety checks and installation instructions.
To do otherwise increases the risk of hazards and injury to the user.
Assembly parts are designed for intended use only in conjunction with X-series displays.
Do not modify and/or replicate any component. Barco uses specific materials and manufacturing processes in order to achieve part
strength. Consult Barco for assistance with custom applications.
Always follow Barco installation instructions. Contact Barco if you should have any question regarding the safety of an application.
The manufacturer assumes no liability for incorrect, inadequate, irresponsible or unsafe assembly of systems. The system must
comply with the local safety regulations regarding environmental conditions, solidity final construction, etc…
Notice on safety
This equipment is built in accordance with the requirements of the international safety standards IEC60950-1, EN60950-1,
UL60950-1 and CAN/CSA C22.2 No.60950-1, which are the safety standards of information technology equipment including
electrical business equipment. These safety standards impose important requirements on the use of safety critical components,
materials and insulation, in order to protect the user or operator against risk of electric shock and energy hazard and having access
to live parts. Safety standards also impose limits to the internal and external temperature rises, radiation levels, mechanical stability
and strength, enclosure construction and protection against the risk of fire. Simulated single fault condition testing ensures the
safety of the equipment to the user even when the equipment’s normal operation fails.
Product care
Structural & mounting components should be kept dry, clean, lubricated (only if recommended), coated properly, and otherwise
maintained in a manner consistent with part design. Barco products must be used in a manner consistent with their design and
inspected on a routine basis for security, wear, deformation, corrosion and any other circumstances that may affect the load handling
capability of the part.
Barco recommends inspections at regular intervals for all installations and increasing in frequency for more critical installations. If
a part is found to have damage, which may cause a decrease in load capability, the part must be removed for service or replaced
immediately.
Under no circumstances are Barco parts repairable by anyone other than Barco.
1.2 Important safety instructions
Instructions:
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Clean only with materials or chemicals that are inert, nonabrasive, noncorrosive and non-marking. Consult the manufacturer
for further advice should any doubts exist regarding any cleaning procedure.
• Do not block ventilation openings. Install in accordance with the manufacturers instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the polarized or grounding type plugs/sockets. If the provided sockets/plugs are damaged
then replacement of the defective parts must be undertaken immediately.
• Protect the power/data cords from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus. Replace damaged power/data cords immediately.
• Only use attachments/accessories specified by the manufacturer.
• Disconnect the power to this apparatus during lightning storms or provide suitable additional lightning protection. Unplug this
apparatus when unused for long period of time.
• Refer all servicing to qualified service technicians/personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, the apparatus does not operate normally, or has been dropped.
• Use only with systems or peripherals specified by the manufacturer, or sold with the apparatus. Use caution during lifting/moving
or transporting to avoid damage by possible tipping.
• Do not use damaged LED tiles. Replace damaged parts immediately.
2R5906876 X-SERIES 24/07/2017

1. Safety
1.3 Important safety instructions
Instructions:
• Read these instructions.
• Keep these instructions.
• Heed all warnings.
• Follow all instructions.
• Clean only with materials or chemicals that are inert, nonabrasive, noncorrosive and non-marking. Consult the manufacturer
for further advice should any doubts exist regarding any cleaning procedure.
• Do not block ventilation openings. Install in accordance with the manufacturers instructions.
• Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that
produce heat.
• Do not defeat the safety purpose of the polarized or grounding type plugs/sockets. If the provided sockets/plugs are damaged
then replacement of the defective parts must be undertaken immediately.
• Protect the power/data cords from being walked on or pinched particularly at plugs, convenience receptacles, and the point
where they exit from the apparatus. Replace damaged power/data cords immediately.
• Only use attachments/accessories specified by the manufacturer.
• Disconnect the power to this apparatus during lightning storms or provide suitable additional lightning protection. Unplug this
apparatus when unused for long period of time.
• Refer all servicing to qualified service technicians/personnel. Servicing is required when the apparatus has been damaged in
any way, such as power-supply cord or plug is damaged, the apparatus does not operate normally, or has been dropped.
• Use only with systems or peripherals specified by the manufacturer, or sold with the apparatus. Use caution during lifting/moving
or transporting to avoid damage by possible tipping.
• Do not use damaged LED tiles. Replace damaged parts immediately. Ensure that the spring of each locking mechanism (latch)
is functioning properly. If not, replace immediately.
1.4 Important warnings
Important warnings:
Risk of electric shock:
Do not open. To reduce the risk of electric shock, do not remove LED board from tile. No user-serviceable parts inside. Refer
servicing to qualified service personnel.
Maximum and minimum ambient temperature:
The maximum ambient temperature for the LED wall is 40°C (104°F), the minimum temperature is -10°C (14°F).
Low Voltage Surge Protection Device required
Due to the damaging effects of lightning, utility switching and switching electric motors of other users on the mains, this product
needs to be protected by means of a Surge Protection Device. This product is connected to the mains through a power distribution
box from party, please verify that a Low Voltage Surge Protection Device according EN61643-11 or UL 1449 is in place.
High leakage current:
The combination of multiple tiles in an installation results in increased levels of leakage current. In order to avoid risk of electric
shock due to high leakage current, proper grounding of the installation is required.
Flammable materials:
Keep flammable materials away from the installation (such as curtains). A lot of energy is transferred into heat. The installation
should be such that the amount of air flow required for safe operation of the equipment is not compromised. Proper ventilation must
be provided.
Risk of electric shock / Risk of fire:
Each power source cable should be protected by a circuit breaker or fuses rated 16 A / 250 VAC (15 A / 250 VAC in the USA and
Canada). Note that one tile requires 100-240 VAC, 50-60 Hz.
To protect against risk of fire caused by overloading of power cables, the number of tiles connected in parallel is limited. See table
below.
Tile Power source Maximum number of tiles per power source cable
X 1.2 110-180Vac
180-240Vac
10 tiles
14 tiles
X 1.5 110-180Vac
180-240Vac
10 tiles
14 tiles
R5906876 X-SERIES 24/07/2017 3

1. Safety
X 2.5 110-180Vac
180-240Vac
10 tiles
14 tiles
X 4 110-180Vac
180-240Vac
10 tiles
14 tiles
The power limits of the used power connectors needs to be followed. A C13/C14 connector is limited to 10A. An Amphenol connector
is limited to 16A.
ESD and LED’s:
LED components used in X-series tiles are ESD (Electro-Static Discharge) sensitive. To prevent the possibility of destroying LED
components do not touch either in operation or while switched off. Always use ESD-gloves.
Disconnect device:
When the appliance inlets of the individual tiles are not accessible, the socket outlets supplying the rack shall be installed near the
equipment and be easily accessible, or a readily accessible general disconnect device shall be incorporated in the fixed wiring.
This equipment MUST be earthed:
In order to protect against risk of electric shock, the installation should be properly grounded. Defeating the purpose of the grounding
type plug will expose you to the risk of electric shock.
Power system:
It is recommended to use a TN-S power distribution system (a power distribution system with a separate neutral and grounding
conductor) in order to avoid large ground current loops due to voltage differences in the neutral conductor. The total electrical
installation should be protected by an appropriately rated disconnect switch, circuit breakers, over voltage protector and Ground Fault
Current Interrupters. The installation shall be done according to the local electrical installation codes. In Europe special attention
should be given to HD 60364, Harmonization Document for electrical installation of buildings. In Germany VDE 0100 should be
adhered to. In America, special attention should be given to the National Electrical Code, ANSI/NFPA 70.
Mains cords:
The power cords delivered with this system have special properties for safety. They are not user serviceable. If the power cords are
damaged, replace them only with new ones. Never try to repair a power cord.
LEDs:
The LEDs used on the X-series tiles are fragile. Never push with a hard or sharp object onto the lens of the LED as this may cause
damage to the LED. The maximum allowed load upon the lens of the LED is 300 gram/LED. Be careful when installing a shader
upon the X-series tiles. Shaders only fit in one direction and this should be verified before pushing into final position. Use your bare
fingers (not nails) to press the shader over the LEDs. Use your finger nails to press upon the framework of the shader between the
LEDs (not upon the LEDs) to push the shader in its final position.
Do not hot plug:
Do not hot plug any cables. Damage to the connector pins may occur. Resulting damage is not covered under warranty.
Maximum allowed display height:
The maximum height of a X-series display in:
In a hanging configuration:
• with traditional truss : 25 tiles
• with auto balancing truss in combination with X1.2 or X1.5: 20 tiles
• with auto balancing truss in combination with X2.5 or X4.0: 24 tiles
In base stand setup configuration:
• with traditional beam: 25 tiles
• with auto balance truss: 20 tiles
When using back mounting, the maximum height is unlimited.
1.5 Proper usage
Proper usage of X-series tiles
• No part of the X-series tile can come in contact with any type of moisture.
• No part of the X-series tile can come in contact with any type of abrasive.
• No part of the X-series tile can come in contact with any type of dust.
• No part of the X-series tile can come in contact with any type of corrosive substance.
• Using the LED product in an environment with high corrosive gasses (e.g. Sulphur) can lead to discoloration of the materials.
This discoloration gives a change in brightness of the product. This could lead to uniformity differences and possibly also to
failures. Each use of the product in this kind of environment needs to be checked up-front with the supplier.
4R5906876 X-SERIES 24/07/2017

1. Safety
• X-series tiles are to be used in environments meeting the operating specifications.
• X-series tiles are not to be used in environments that are subject to airborne contaminants such as that produced by smoke
machines (cracked oil) or similar (these deposit a thin layer of greasy residue upon the LEDs optics, degrading performance).
• X-series tiles are not to be exposed to extreme localized heat or cold exceeding the temperature specifications.
• X-series tiles are not to be exposed to any element or situation that will cause any part of the display to heat beyond what occurs
during normal operation. Such situations include but are not limited to lasers, ultrasonic vibration, or any type of substance that
prevents proper ventilation and heat radiation of the X-series tiles.
• X-series tiles are not to be exposed to circumstances where moisture can condense or collect on any components.
• Power connected to the X-series tiles must meet the specifications outlined in the installation manual.
• Avoid any accidental bumping of the tile corners while installing or removing the X-series tiles. Since LED’s of the X-series tiles
are mounted near by the edges of the LED boards, which is unavoidable in the design of a high resolution LED-wall, the corners
of the X-series tiles become sensitive for mechanical damage. Because of that it is required to handle the X-series tiles with
care at all times.
• Never place an X-series tile upon a surface with the LED’s facing downwards without protection. This to prevent damage to the
LEDs and the soft lens of the LEDs.
• While removing or installing the X-series tile always keep the LED side of the X-series tile parallel with the LED side of the
remaining neighboring X-series tiles. This to avoid any mechanical stress upon the corners of the X-series tiles.
• No force can be applied to the LEDs. Any LEDs damaged due to mechanical stress are not covered by the warranty.
• Safety and functional features of the display cannot be defeated.
• It is not allowed to climb or hang any additional equipment on the back of an X-series wall. Nothing is to be allowed to hang
from the cables of an X-series tile.
• Any failures must be immediately and appropriately dealt with (equipment returned to Barco). Failing equipment cannot be left
to run in a wall.
• No additional tools (hammers, pry-bars, etc.) are to be used to force handles or locks into place. All moving parts should be
managed by hand.
• Only Barco cables specified to be used with the X-series display are to be used to connect components in the X-series wall.
Further, care must be taken to connect signal only according to the installation manual.
• X-series tiles are not to be used in the vicinity of any equipment that is not CE and UL/ETL certified.
• When reconnecting components in an X-series tile, care must be taken to ensure that cables are carefully routed according to
the installation manual to prevent damage to the cables or other parts of the X-series tile.
• X-series tiles can be cleaned only in accordance to the procedures defined in the installation manual.
• The X-series display is an indoor product. Use the X-series tiles only in a dry area away from direct sunlight, dust and moisture.
Never install and use the X-series tiles in an outdoor environment.
• Ensure rigging hardware is able to handle the weight of the entire X-series with appropriate safety factors.
• External rigging hardware must be properly installed prior to hanging X-series tiles.
R5906876 X-SERIES 24/07/2017 5

1. Safety
6R5906876 X-SERIES 24/07/2017

2. Environmental information
2. ENVIRONMENTAL INFORMATION
2.1 Disposal information
Disposal Information
Waste Electrical and Electronic Equipment
This symbol on the product indicates that, under the European Directive 2012/19/EU governing waste from electrical and
electronic equipment, this product must not be disposed of with other municipal waste. Please dispose of your waste equipment by
handing it over to a designated collection point for the recycling of waste electrical and electronic equipment. To prevent possible
harm to the environment or human health from uncontrolled waste disposal, please separate these items from other types of waste
and recycle them responsibly to promote the sustainable reuse of material resources.
For more information about recycling of this product, please contact your local city office or your municipal waste disposal service.
For details, please visit the Barco website at: http://www.barco.com/en/AboutBarco/weee
2.2 RoHS compliance
中国大陆RoHS (Chinese Mainland RoHS)
根据中国大陆《电器电子产品有害物质限制使用管理办法》（也称为中国大陆RoHS）， 以下部分列出了Barco产品中可能包含的有毒
和/或有害物质的名称和含量。中国大陆RoHS指令包含在中国信息产业部MCV标准：“电子信息产品中有毒物质的限量要求”中。
According to the “Management Methods for the Restriction of the Use of Hazardous Substances in Electrical and Electronic Prod-
ucts” (Also called RoHS of Chinese Mainland), the table below lists the names and contents of toxic and/or hazardous substances
that Barco’s product may contain. The RoHS of Chinese Mainland is included in the MCV standard of the Ministry of Information
Industry of China, in the section “Limit Requirements of toxic substances in Electronic Information Products”.
零件项目(名称)
Component name
有毒有害物质或元素
Hazardous substances and elements
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr6+)
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
印制电路配件
Printed Circuit Assemblies
OOO O OO
外接电(线)缆
External Cables
OOO O OO
內部线路
Internal wiring
OOO O OO
电源供应器
Power Supply Unit
OOO O OO
塑胶外壳
Metal Enclosure
OOO O OO
塑胶外壳
Plastic Enclosure
OOO O OO
R5906876 X-SERIES 24/07/2017 7

2. Environmental information
零件项目(名称)
Component name
有毒有害物质或元素
Hazardous substances and elements
铅
(Pb)
汞
(Hg)
镉
(Cd)
六价铬
(Cr6+)
多溴联苯
(PBB)
多溴二苯醚
(PBDE)
螺帽,螺钉(栓),螺旋(钉),垫圈,紧固件
Nuts, bolts, screws, washers, Fasteners
OOO O OO
本表格依据SJ/T 11364的规定编制
This table is prepared in accordance with the provisions of SJ/T 11364.
O: 表示该有毒有害物质在该部件所有均质材料中的含量均在 GB/T 26572 标准规定的限量要求以下.
O: Indicates that this toxic or hazardous substance contained in all of the homogeneous materials for this part is below the limit
requirement in GB/T 26572.
X: 表示该有毒有害物质至少在该部件的某一均质材料中的含量超出 GB/T 26572 标准规定的限量要求.
X: Indicates that this toxic or hazardous substance contained in at least one of the homogeneous materials used for this part
is above the limit requirement in GB/T 26572.
在中国大陆销售的相应电子信息产品（EIP）都必须遵照中国大陆《电子电气产品有害物质限制使用标识要
求》标准贴上环保使用期限（EFUP）标签。Barco产品所采用的EFUP标签（请参阅实例，徽标内部的编号使用
于指定产品）基于中国大陆的《电子信息产品环保使用期限通则》标准。
10 All Electronic Information Products (EIP) that are sold within Chinese Mainland must comply with the
“Marking for the restriction of the use of hazardous substances in electrical and electronic product” of
Chinese Mainland, marked with the Environmental Friendly Use Period (EFUP) logo. The number
inside the EFUP logo that Barco uses (please refer to the photo) is based on the “General guidelines of
environment-friendly use period of electronic information products” of Chinese Mainland.
Turkey RoHS compliance
Türkiye Cumhuriyeti: AEEE Yönetmeliğine Uygundur.
[Republic of Turkey: In conformity with the WEEE Regulation]
2.3 Production address
Manufacturing address
Barco Visual (Beijing) Electronics Company Limited
No. 16 Changsheng Road, Changping Science & Technology Park
Changping District 102213 Beijing,
PEOPLE’S REPUBLIC OF CHINA
8R5906876 X-SERIES 24/07/2017
