BARRON Trace-Lite AXL2 User manual

AXL2 (15-50W)
INSTALLATION INSTRUCTIONS
800.533.3948 • www.barronltg.com
Knuckle Mount 15W, 30W, 50W
1. Feed wire lead from 1/2” NPT knuckle into weatherproof box cover or post top fitter, then secure threaded knuckle
into place.
2. Electrical connections should be made at this time (see Wiring section).
3. To adjust AXL2 angle loosen screw on the center of the knuckle, adjust to desired position and retighten screw.
20070137 REV 1 P-9 - 2/19
New image
IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations if applicable.
• Do not mount near gas or electric heaters.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering by
unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
SAVE THESE INSTRUCTIONS!
1

INSTALLATION INSTRUCTIONS
800.533.3948 • www.barronltg.com
Yoke mount
1. Mount fixture’s bracket to surface using expansion bolts or appropriate hardware (provided by others).
2. Allow for proper line cord slack for adjusting angle.
3. Electrical connections should be made at this time (see Wiring section).
4. Set desired fixture angle by loosening positioning screws and rotating the Yoke to desired angle, then retighten
positioning screws.
Yoke Templates
Wiring
Make electrical connection as follows:
Black - Line
White - Neutral
Green/Yellow Green - Ground
Note: This fixture auto adjusts for voltages from 120VAC-277VAC.
Cap all unused leads to prevent shorting.
IMPORTANT: Weatherproof your outdoor installation, be sure to seal
all holes in the AXL2 housing such as the mounting, conduit, plugs,
sensors, photocontrols, etc. with silicone sealant.
20070137 REV 1 - 2/19
NEUTRAL
NEUTRAL
LINE
15W
1.480.47
1.4
Ø0.82
4-R0.13
30W
2.540.59
4-R0.2 Ø0.82
1.4
3.51
2-0.78
4-R0.2 Ø0.82
1.4
50W
AXL2 (15-50W)
2
