BARRON TRACE-LITE TL101 User manual

INSTALLATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS!
READ CAREFULLY AND FOLLOW ALL INSTRUCTIONS FOR YOUR OWN SAFETY
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
•Installation and servicing of this equipment should be performed by qualified service personnel only.
•Ensure the electricity connections conform to the National Electrical Code and local regulations if applicable.
•Do not mount near gas or electrical heaters.
•Equipment should be mounted in locations and at heights where it will not readily be subjected to tampering by
unauthorized personnel.
•The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition. Any
modification or use of non-original components will void the warranty and product liability.
•Do not use this equipment for other than intended use.
800 533.3948 •www.barronltg.com
1
INSTALLATION INSTRUCTIONS
1. REMOVE FRONT HOUSING (Fig. 1) Loosen two (2) screws “A”. Remove front housing.
2. REMOVE REFLECTOR (Fig. 2) Loosen two (2) screws “B” enough to allow reflector to slide upward until key hole
in reflector releases two screws “B” to remove reflector.
3. MOUNTING WITH TWO (2) BOLTS (Fig. 3) Knock out two (2) slugs “C” in rear housing. Mount with two (2) lag
screws
TL101/TL102
20070032 REV 1 - 09/13

TL101/TL102
INSTALLATION INSTRUCTIONS
800 533.3948 •www.barronltg.com
2
20070032 REV 1 - 09/13
4. MOUNTING ON OUTLET BOX
Knock out appropriate holes around outlet hole in rear housing. Fasten the rear housing to the outlet box using the
screws supplied with the outlet box.
5. ELECTRICAL CONNECTIONS
Electrical connections should be made inside junction box. Cap all unused leads to prevent shorting.
a. Connect the line fixture lead to the black supply lead.
b. Connect the common fixture lead to the white supply lead
c. Connect the ground lead from the service by hooking it around the green
grounding screw “F” between the screw head and brass terminal washer.
6. INSTALL LAMP
Replace reflector, retightening screw “B” Install lamp securely into lamp socket until it seats firmly.
7. REPLACE FRONT HOUSING
Replace front housing, retightening screw “A”
BOTTOM CONDUIT HOLE (Optional)
With front housing and reflector off either drill or tap out recessed indention in bottom of rear housing. Pull service wires
through bottom of conduit hole and make electrical connections. Replace reflector and front housing
by reversing procedures used to remove.
IMPORTANT
To weather-proof your outdoor installation, be sure to seal all holes in fixture housing. (Mounting, conduit, plugs, and
photo controls, etc) with silicone sealant. Apply sealant across top edge of wall pack to prevent water from reaching
the back of the housing.
TROUBLESHOOTING CHECKLIST
If the light does not work:
1. Check your power source.
2. Check to ensure proper seating of lamp.
3. Check electrical connections.
4. Check if lamp is burned out.
