BARRON Exitronix TPXC Series User manual

IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
• DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount near gas or electrical heaters.
• Do not use outdoors.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
• Allow battery to charge for 24 hours before first use.
• For use with metal enclosed wiring systems.
SAVE THESE INSTRUCTIONS!
Technical Support ■ [phone] ■ [email protected]
TPXC Series
Installation Instructions
XXXXXXXX REV 1 - 07/23 1
800-533-3948 www.barronltg.com

Fig. 1
Fig. 2
Fig. 3
Fig. 4
Fig. 5
TPXC Series
Installation Instructions
XXXXXXXX REV 1 - 07/23 2
800-533-3948 www.barronltg.com
Wall Mount Installation (Fig. 2)
1. Open front cover by blade of screwdriver. (Fig. 1)
2. Knock out center and appropriate mounting screw holes on the
back plate.
3. Remove side hole plug from housing, snap lamp heads on the unit
and connect to PC board (Fig. 5)
4. Route the AC supply wires through center hole inside of housing.
5. Install fixture on the J-Box.
6. Make correct electrical connections inside of fixture according to
wiring diagram (Fig. 6)
7. Push excess wire into J-Box.
8. Snap chevron to EXIT panel if required.
9. Attach battery connector to PC board, restore front panel on unit,
adjust direction of lamp heads as needed.
Ceiling Mount Installation (Fig. 3)
1. Attach crossbar to junction box, set the crossbar so that the short
blade is touching the J-Box.
2. Open front cover by blade of screwdriver. (Fig. 1)
3. If double face is desired, replace back plate with additional face
plate provided.
4. Remove the mounting hole cover on the top and side of the unit,
assemble the canopy unit. (Fig. 4)
5. Snap lamp heads on the unit and connect to PC board. (Fig. 5)
6. Route the proper wires through the mounting hole out of housing.
7. Make electrical connections inside the J-Box according to wiring
diagram (Fig. 6)
8. Fasten crossbar on J-Box by screws provided, fasten canopy to
crossbar and against the wall.
9. Snap chevron to EXIT panel if required.
10. Attach battery connector to PC board, restore front panel on unit,
adjust direction of lap heads as needed.

Fig. 7
TPXC Series
Installation Instructions
XXXXXXXX REV 1 - 07/23 3
800-533-3948 www.barronltg.com
Wiring Diagram (Fig. 7)
Operation
The battery in this unit may not be fully charged. After electricity is connected to the unit for at least 24 hours, then normal
operation of this unit should take effect. To check, press the “TEST” button. The EXIT sign should stay illuminated by
battery backup and the LED indicator will be turned off. Release the “TEST” button, LED indicator will be turned on.
In accordance with NFPA 101, your emergency lighting system must be tested monthly for a minimum of 30 seconds and
annually for 90 minutes. Refer to your local codes for any additional requirements that may apply.
Testing and Reporting Instructions (-G2 and -G3 models)
1. When AC power is supplied to fixture, the unity will automatically initiate a self-test and self-diagnostic test as follows:
• Verifies battery disconnection, charger board failure at every 5 seconds.
• 1 minute self-testing every month.
• 30 minutes self-testing on every 6 months after installation.
• 90 minutes self-testing on every 12 months after installation.
2. Dual color LED lamp indicator shows the following status:
• Green color: On / Ready
Blinking: Testing
• Red color: (Service Alert)
• Service Alert LED Code (Red color LED lamp indicator)
Note: After solving the fault of emergency equipment, please press test button for 2 seconds then release to
reset. LED indicator will show green.
2. “-G2” and “-G3” models also have a manual test function, press test button as follows:
Press test button once (within 2 seconds)
Press test button twice (within 2 seconds)
30 seconds discharge test
Press test button 3 times (within 2 seconds)
Press test button 4 times (within 2 seconds)
*Press and hold test button for 8 seconds
3 minutes discharge test
30 minutes discharge test
90 minutes discharge test
Fixture will leave network and reset itself
*Note: only applies to “-G3” models. If you have proplem to initiate provisioning or if you know
the unit belongs to other Guardian Network
One blink ON/pause (4 seconds)
Two blinks ON/pause (4 seconds)
Battery is not connect
Three blinks ON/pause (4 seconds)
Four blinks ON/pause (4 seconds)
Five blinks ON/pause (4 seconds)
Battery voltage too low
Charger board circuit fault
Transfer function failure
Integral lamp fault
Six blinks ON/pause (4 seconds)
Seven blinks ON/pause (4 seconds)
Remote head’s emergency lamp fault (option)
Exit LED strip failure

TPXC Series
Installation Instructions
XXXXXXXX REV 1 - 07/23 4
800-533-3948 www.barronltg.com
Networking Operations for “-G3” Models
Model with "-G3" suffix is our world winning design equipped with "wireless testing and reporting" features. Unit that
has "-G3" suffix in its model number is capable of joining Guardian emergency lighting management system. It will be
part of a large testing system to be tested and report result wirelessly.
Once powered up and commissioning allowed, unit will automatically join Guardian network and get provisioned. Upon
the completion of the commissioning,unit will perform testing and report based on set schedules.
For more information about commissioning, configurations and testing, please visit website, https://www.barronltg.com
for details.
Remote Heads Connection Instructions (Fig. 8) (Option)
1. Remove jump connector from the female connector on PCBA.
2. Attach the remote male connector into the female connector on PC board.
3. Connect extended remote head wires to the remote wires using wire nuts. Yellow is positive (+) and the purple is
negative (-).
Fig. 8
