BARRON TRACE-LITE WTA Series User manual

IMPORTANT SAFEGUARDS
READ AND FOLLOW ALL SAFETY INSTRUCTIONS.
When using electrical equipment, basic safety precautions should always be followed including the following:
•DISCONNECT AC POWER SUPPLY BEFORE SERVICING.
• Installation and servicing of this equipment should be performed by qualified service personnel only.
• Ensure that the electrical wiring conforms to the National Electrical Code NEC® and local regulations
if applicable.
• Do not mount near gas or electrical heaters.
• Equipment should be mounted in locations and at heights where it will not be readily subjected to tampering
by unauthorized personnel.
• The use of accessory equipment not recommended by the manufacturer may cause an unsafe condition.
• Any modification or use of non-original components will void the warranty and product liability.
• Do not use this equipment for other than intended use.
SAVE THESE INSTRUCTIONS!
Technical Support ■ [phone] ■ [email protected]
WTA Series
Installation Instructions
20070162 REV 1 - 04/20 1 800-533-3948 www.barronltg.com

WTA Series
Installation Instructions
20070162 REV 1 - 04/20 2 800-533-3948 www.barronltg.com
1. Open the Back Box by loosening the Locking Screw.
2. Verify and remove only necessary EVA Gasket material where Back Box will mount.
3. Knock-out Back Box material for necessary mounting location.
4. Mount Back Box to Junction Box securely, using hardware supplied by others.
5. Connect electrical connections with fixture wiring.
6. Seal Back Box to Housing by pushing on front of Housing while tightening
Locking Screw to ensure that screw is fully seated in the Housing Recess. Ensure
wiring remains within Back Box and wires do not get pinched.
NOTE: Weatherproof your outdoor installation, be sure to seal all holes in the
housing such as the mounting, conduit, plugs, sensors, photocontrols, etc. with
silicone sealant.
MOUNTING TO A WALL
Body
Wall Mount Box
Photocontrol 1/2 Close Up Plugs (both sides top)
EVA Gasket
Glass (27W & 40W Only)
Sealing ring
Wall
Mount
Box
5.31
5.96
5.9
Leveling
Bubble
Locking Screws

WTA Series
Installation Instructions
20070162 REV 1 - 04/20 3 800-533-3948 www.barronltg.com
0° 60° 90°
Serrated Safety
Washers
Screw
Adjusting angle screw
Screw
ANGLE ADJUSTMENT
If the light output angle needs to be adjusted, loosen screw to rotate the fixture to desired light output angle.
Tighten screw once desired light output angle is achieved.

WTA Series
Installation Instructions
20070162 REV 1 - 04/20 4 800-533-3948 www.barronltg.com
1. Check incoming voltage to the LED driver. Must be at least a minimum
of 120VAC and no greater than 277VAC.
2. Are all the LEDs on the light engine “OFF”? If so, LED driver may be defective. Using a voltmeter, check to see if voltage
is present at the output of the power supply. If low or no voltage, then replace the power supply.
3. If any individual LEDs are “OFF” the LED light engine is defective. Please contact technical support.
4. If the unit is equipped with a photocell, check the photocell to make sure it’s functioning properly.
Standard
Photocontrol
Black
White Neutral
Green/Yellow Green
Ground
Line
Purple DIM+
Gray DIM-
Wiring
Electrical connections should be made inside J-box.
Cap all unused leads to prevent shorting.
Make electrical connections as follows:
Black - Line
White - Neutral
Green/Yellow Green - Ground
Note: This fixture auto adjusts for voltages from
120VAC-277VAC
Important: Weatherproof your outdoor installation, be sure to seal all
holes in the housing such as the mounting, conduit, plugs, sensors,
photocontrols, etc. with silicone sealant.
Note: If dimming wires are not used, make sure they are capped.
Troubleshooting
If unit does not turn “ON”
LED DRIVER
CONTROL
LINE
NEUTRAL
LOAD
HOT
BLACK
WHITE
COMMON
