Bartscher 500830 User manual

1/1 2200 E - 2x4L 2200 E
500830 - 500840

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Technical Support Hotline: [phone]
www.bartscher.com
Version: 3.0
Date of preparation: 2023-02-10
EN
2

500830 1 / 18
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended Use ...........................................................................................6
1.4 Unintended Use.......................................................................................6
2General information.......................................................................................7
2.1 Liability and Warranty ..............................................................................7
2.2 Copyright Protection ................................................................................7
2.3 Declaration of Conformity ........................................................................7
3Transport, Packaging and Storage................................................................8
3.1 Delivery Check.........................................................................................8
3.2 Packaging................................................................................................8
3.3 Storage....................................................................................................8
4Technical Data...............................................................................................9
4.1 Technical Specifications ..........................................................................9
4.2 List of Components of the Appliance .....................................................11
4.3 Functions of the Appliance.....................................................................12
5Installation and operation ............................................................................13
5.1 Installation..............................................................................................13
5.2 Operation...............................................................................................14
6Cleaning ......................................................................................................17
6.1 Safety Instructions for Cleaning.............................................................17
6.2 Cleaning.................................................................................................17
7Disposal....................................................................................................... 18

Safety
2 / 18 500830
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle un dN achschlagewer k.Die Ke nntnis aller enthalten enSic herheitshinweis eu ndH andlungsan weisungen sch afft die Voraussetzu ngf ürd as sichere und sachg erechte Arbeiten mit d emG erät.D arüber hin aus müssen die für den Eins atzbereich des Gerät sg eltenden örtlichen Un fallverhütungsvorsc hriften und allgemein en Sicherheitsb estimmungen eingehalt en werden. Diese Be dienungsanleitung is t Bestandteil des Prod ukts und muss in unmitt elbarerN ähe des Geräts für d as In¬stallations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn das Ger ät an eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
500830 3 / 18
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical Current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.

Safety
4 / 18 500830
EN
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.
•Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Flammable Materials
•Never subject the appliance to contact with high temperature sources, e.g.:
oven, furnace, open flame, heat generating devices, etc.
•To avoid fire hazard, clean the appliance regularly.
•Do not cover the appliance with, e.g., aluminium foil or cloths.
•Use the appliance only with materials designated to this end and with correct
temperature settings. Materials, groceries and left-overs remaining in the
appliance may catch fire.
•Never use the appliance near flammable or inflammable materials, e.g.: petrol,
spirit, alcohol, etc. High temperature triggers evaporation of these materials,
and, as a result of contact with sources of ignition, an explosion may occur.
•In case of fire, disconnect the appliance from the power supply before
attempting suitable fire-extinguishing actions.
•Never attempt to extinguish fire with water if the appliance is connected to the
power supply. Following extinction of fire, ensure sufficient fresh air inflow.
Hot Surfaces
•Surfaces of the appliance become hot during operation. Burning hazard! High
temperature remains for some time after switching the appliance off.
•Do not touch any hot surfaces of the appliance. Use the provided handling
elements and holders.
•You may transport and clean the appliance after it cools down entirely.
•It is prohibited to sprinkle hot surfaces with cold water or flammable liquids.

Safety
500830 5 / 18
EN
Supervised Usage only
•Only supervised appliance may be used.
•Always remain in an immediate vicinity of the appliance.
Operating Personnel
•The appliance may only be operated by qualified personnel and trained
specialist personnel.
•This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Improper use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used in a technically flawless condition, providing for
safe use.
•The appliance may only be used with connections in a technically flawless
condition, providing for safe use.
•The appliance may only be used clean.
•Use only original spare parts. Never attempt to repair the appliance on your
own.
•Do not attempt to modify nor alter the appliance.

Safety
6 / 18 500830
EN
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Keeping the prepared food warm in GN containers and inserts.
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–Food preparation.

General information
500830 7 / 18
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
8 / 18 500830
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
500830 9 / 18
EN
4 Technical Data
4.1 Technical Specifications
Name:
Chafing dish 1/1 2200 E
Art. No.:
500830
Material:
chrome-nickel steel, plastic
Lid material:
chrome-nickel steel
Handles material:
chrome-nickel steel
Temperature range, min.–max., in °C:
10 - 85
Volume, in l:
13,5
Gastronorm:
1/1
Max. GN container depth, in mm:
100
Connected load:
2,2 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
636 x 357 x 287
Weight, in kg:
6,2
We reserve the right to implement technical modifications.
Version / Characteristics —Chafing-Dish 500830
•Heating type: electric
•Control: electronic, knob
•Temperature control: 8 levels, thermostatic
•Functions: warm-keeping
•Lid features: removable, with handle
•Indicator lights: heating
•The set includes: 2 support legs to hold the lid
<Endergebnis>

Technical Data
10 / 18 500830
EN
Name:
Hot-pot station 2x4L 2200 E
Art. No.:
500840
Material:
chrome-nickel steel, plastic
Lid material:
chrome-nickel steel
Handles material:
chrome-nickel steel
Temperature range, min.–max., in °C:
10 - 85
Number of inserts:
2
Capacity of each insert, in l:
4
Connected load:
2,2 kW | 230 V | 50 Hz
Dimensions (W x D x H), in mm:
636 x 357 x 460
Weight, in kg:
7,0
We reserve the right to implement technical modifications.
Version / Characteristics —Hot-Pot Station 500840
•Heating type: electric
•Control: electronic, knob
•Functions: warm-keeping
•Lid properties:
–removable, with handle
–spoon recess
•Indicator lights: heating
•The set includes:
–2 lid holders
–2 soup ladles
<Endergebnis>

Technical Data
500830 11 / 18
EN
4.2 List of Components of the Appliance
500830
Fig. 1
1. Lid handle
2. Lid
3. GN container
4. Base holder (2 pcs)
5. Base
6. Temperature controller
7. Heating up indicator light
8. Power cord
9. Appliance plug-in socket
10.ON/OFF switch
11.Water tank with heating element
12.Lid holder (2 pcs)

Technical Data
12 / 18 500830
EN
500840
Fig. 2
1. Soup ladle (2 pcs)
2. Lid handle (2 pcs)
3. Lid (2 pcs)
4. Insert (2 pcs)
5. Intermediate plate
6. Base holder (2 pcs)
7. Base
8. Temperature controller
9. Heating up indicator light
10.Power cord
11.Appliance plug-in socket
12.ON/OFF switch
13.Water tank with heating element
14.Lid holder (2 pcs)
4.3 Functions of the Appliance
The appliance is designed to keep prepared food warm at a set temperature and is
suitable for serving hot food in buffets, catering or event service.

Installation and operation
500830 13 / 18
EN
5 Installation and operation
5.1 Installation
Unpacking / Positioning
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
•If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
•Be careful not to damage the rating plate and warning labels fixed on the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on surfaces that are:
–even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
•Leave at least 20 cm clearance from flammable walls and items.

Installation and operation
14 / 18 500830
EN
Power supply connection
•Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
•Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
•The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
•Do not use the appliance with an external timer or remote control.
5.2 Operation
WARNING!
The appliance may only be used to store already prepared food products!
Remember to keep food products warmed for a maximum of 2 hours
(including preparation, storage and serving) in order to ensure food
safety!
Appliance Preparation
1. Prior to the first use clean the appliance and its components thoroughly
observing instructions in section 6 'Cleaning'.
2. Dry all cleaned elements and surfaces thoroughly.
Fig. 3
3. Next, place the water tank in the base.
4. Fit the enclosed lid holders onto the appliance.
5. Pour water into the water tank up to the water level marker.

Installation and operation
500830 15 / 18
EN
ATTENTION!
Never use the appliance without water!
Ensure that the water level does not drop below the max. mark so that
containers with dishes do not float.
NOTE!
Pour warm water into the tank —it will save time and energy!
6. Fit the intermediate plate on the 500840 appliance.
7. Place warm dishes in appropriate GN containers or inserts and then place them
in the water tank.
WARNING!
During operation, spilled liquids and food can cause burns.
Never overfill food containers.
8. Always connect the power cord first to the appliance plug-in socket and then to
appropriate single socket.
The appliance is now ready for maintaining the food temperature.
Switching the Appliance ON
1. Place the lid on a GN container or an insert.
2. Switch the appliance on with the ON/OFF switch.
The red power indicator light in the ON/OFF switch lights up.
Temperature Control
The temperature is adjusted using the temperature controller (levels 1–8). The
maximum temperature setting is achieved by turning the temperature controller
clockwise, into position '8'. At such setting water in the tank is heated up to approx.
85°C. The heating indicator light next to the temperature controller is switched on
during heating. The indicator light goes off after reaching the pre-set temperature.
When temperature in the water tank drops by approx. 10°C, the indicator light
comes on again and water in the tank is reheated to pre-set temperature.
If a lower dish temperature is required, rotate the temperature controller counter-
clockwise to a setting below '8'.

Installation and operation
16 / 18 500830
EN
Keeping Food Warm / Serving
Food in a GN container or in inserts is kept warm by heating the water in the
water tank.
1. To take warm food from a container, remove the lid and set it down on the lid
holder.
WARNING! Risk of burns!
When removing the lid and taking dishes out, hot steam may escape,
leading to burns.
Take extra care when removing the lid and serving dishes.
Fig. 4
2. Serve warm food and replace the lid to avoid temperature drop.
Switching the Appliance OFF
1. When the appliance is not to be used any more, it should be switched off with
the ON/OFF switch.
2. First, unplug the appliance from the socket outlet and then remove the power
cord from the appliance plug-in socket.
3. Before pouring the water out, leave the appliance and water in the water tank to
cool down.

Cleaning
500830 17 / 18
EN
6 Cleaning
6.1 Safety Instructions for Cleaning
•Before cleaning, disconnect the appliance from the power supply.
•Leave the appliance to cool down completely.
•Make sure water does not enter the appliance. Do not immerse the appliance in
water or other liquids during cleaning. Do not clean the appliance with a
pressurized water jet.
•Do not use any sharp or pointed, nor metal implements (knife, fork, etc.). Sharp
or pointed implements may damage the appliance, and when in contact with live
parts, they may cause electric shock.
•For cleaning, do not use any scouring agents that contain solvents nor corrosive
cleaning agents. They may damage the surface.
6.2 Cleaning
1. Clean the appliance regularly after end of each working day, or more frequently
if needed.
2. Remove the lid(s).
3. In the case of the 500830 appliance, pull out the GN container.
4. In the case of the 500840 appliance, pull out the inserts with soup ladles and
remove the intermediate plate, too.
5. Remove the lid holder.
6. Remove the water tank from the base.
7. Clean the removed elements thoroughly in warm water, using a mild washing
agent and a soft cloth or sponge.
8. Rinse cleaned elements in fresh water.
9. Clean the base with a soft, damp cloth.
10.Dry the appliance and cleaned parts thoroughly with a soft cloth.
11.Wipe the power cord with a slightly damp soft cloth only.
12.In the case of intensive use periodically remove the scale deposits from the
water tank bottom. To this end, use vinegar or a special descaling agent. Follow
the manufacturer's instructions of such an agent.

Disposal
18 / 18 500830
EN
7 Disposal
Electrical Appliance
Electric appliances are marked with this symbol. Electrical
appliances must be disposed of and recycled in a correct
and environmentally friendly manner. You must not dispose
of electric appliances with household waste. Disconnect the
appliance from the power supply and remove power cord
from the appliance.
Electrical appliances should be returned to designated collection points.
