Read this instruction manual before using and
keep them available at all times!
This instruction manual contains information about the installation, operation
and maintenance of the device and should be consulted as an important source
of information and reference guide.
Awareness of the safety instructions and instructions for use in this manual will ensure
the safe and correct use of the device.
In addition to the information given here, you should comply with any local Health and
safety Controls and generally applicable safety regulations.
The instruction manual forms part of the product and should be kept near the device
and easily accessible for anyone carrying out the installation, servicing, maintenance
or cleaning.
Please keep these instructions and give them to future owners of the device.
1.Safety
This device is designed in accordance with the presently applicable technological
standards. However, the device can pose a danger if handled improperly and
inappropriately.
All persons using the device must follow the recommendations and instructions
in this instruction manual.
1.1 Key to symbols
In this manual, symbols are used to highlight important safety instructions and any
advice relating to the device. The instructions should be followed very carefully to avoid
any risk of accident, personal injury or material damage.
DANGER!
This symbol highlights hazards which could lead to injury.
WARNING!
This symbol highlights dangerous situations which could lead to injury or death.

- 19 -
HOT SURFACE!
This symbol is a warning that the device surface is hot when in use.
Ignoring this warning may result in burns!
CAUTION!
This symbol highlights dangerous situations which could lead to light
injuries, or damage, malfunction, and/or destruction of the device.
NOTE!
This symbol highlights recommendations and information aimed for effective
and trouble-free device operation.
1.2 Safety instructions
The device is not intended for use by individuals (including
children) with physical or mental disabilities, insufficient
experience, and/or insufficient knowledge unless such persons
are under the care of a person responsible for their safety or
have received instructions regarding appropriate use of the
device.
Children should be observed to ensure that they are not playing
with or starting the device.
Prevent access of children to the package materials like plastic
bags and foamed polystyrene elements. Suffocation hazard!
Never leave the device unattended when in use.
Only use the device indoors.

- 20 -
The device must be operated in correct and safe technical
condition only. In case of operational problems disconnect the
device from the power supply (pull the plug from the socket) and
contact the service company.
Only a qualified technician and using original spare parts and
accessories should carry out repairs and maintenance of the
device. Do not attempt to repair the device yourself.
Do not use any accessory or spare parts that have not been
recommended by the manufacturer. These can be dangerous
for the user or lead to damages of the device or personal injury,
and further, the warranty expires.
To prevent hazards and to ensure optimum efficiency, no
modifications or alterations to the device that are not explicitly
approved by the manufacturer may be undertaken.
DANGER! Electric shock hazard!
To avoid the hazard results please follow the instructions below.
Never allow the power cable to come into contact with heat
sources or sharp edges. The power cable should not hang over
the side of the working surface. Ensure that no one can step
on or trip over the cable.
The power cable must not be folded, bent or tangled, and must
always remain fully unrolled. Never place the device or other
objects on the power cable.
Do not cover the cable. Keep away the cable from operating
range.

- 21 -
Check the power cord regularly for damage. Do not use the
appliance if the power cord is damaged. If this cable is damaged,
it must be replaced by customer service or a qualified electrician
in order to avoid dangers.
The supply cable must be disconnected from the socket
only by pulling the plug.
Never carry or lift the device by the supply cable.
In any case do not open the device housing. In case of
electrical or mechanical modifications the electric shock
hazard will occur.
Never immerse the appliance, the power cord and the power
plug in water or other liquids.
Do not use any acid agents and make sure no water ingresses
the device.
Never operate the device with moist hands or standing on wet
floor.
Remove the plug from its socket:
-when the device is not used,
-in case of anomalies during operation,
-before cleaning.
HOT SURFACE! Burn hazard!
To avoid the hazard results please follow the instructions below.
The frame and heating tube handle become hot during operation!
Do not touch hot elements of the device.
The device stays hot still for some time after it has been switched
off, use protective gloves to remove the food.

- 22 -
Before you start cleaning or moving the device elsewhere, let it
cool down completely.
During the heat maintaining process the GN container with food
becomes hot. When lifting the GN container always use
protective gloves or a dish cloth!
WARNING! Fire or explosion hazard!
To avoid the hazard results please follow the instructions below.
To avoid the fire hazard and damage to the device never place
the kitchen utensils, towels, paper, etc. on the food warmer.
Never use the device near flammable or inflammable materials
(such as alcohol, spirits, petrol, etc). High temperature may
cause their evaporation and due to contact with the
ignition sources the explosion may occur, and it may result in
personal injuries and material damage.
In case of fire and before taking relevant fire extinguishing action,
disconnect the device from the electric power supply (unplug!).
Caution: Never use water for fire extinguishing when the
device is connected to the power supply. Electric shock
hazard!
When the fire has been extinguished ensure sufficient fresh air
inflow.

- 23 -
1.3 Use as intended
Every use of the device for a different purpose and/or in a way that diverges from the
intended use is not allowed and is assumed as the use against the intended purpose.
Any claims against the manufacturer or their authorized representatives as a consequence
of experiencing damage resulting from the use against the intended purpose are
inadmissible.
The liability for damage occurred during the use of the device against its intended
purpose is borne solely and exclusively by the user.
Safety operation of the device is guaranted only when it is used for its intended purpose
and according to the instructions included in this manual.
The food warmer is intended for keeping food warm using appropriate
GN 1/1 container.
1.4 Use against the intended purpose
Any use other than those mentioned in point “1.3 Use as intended“ is assumed as the
use against the intended purpose and is not allowed.
The use against the intended purpose may lead to severe injury or damage caused by
hazardous voltage, fire or high temperature. It is allowed to use the device to perform
only the work described in the instruction manual. Improper use may cause the device
damage.
Any manipulation with the device, assembly or maintenance work may be performed
exclusively by the authorized service staff.

- 24 -
2. General information
2.1 Liability and Warrantees
All the information and instructions in this manual take into account standard safety
regulations, current levels of technical engineering as well as the expertise and
experience we have developed over the years.
The instruction manual was translated with all due care and attention. However, we do
not accept liability for any translation errors. The German version of this instruction
manual is definitive.
If the delivery consists of a special model, the actual scope of delivery may differ from
the descriptions and illustrations in this manual. This is also the case for special orders
or when the device has been modified in line with new technology.
CAUTION!
Read this manual carefully and thoroughly before any operation of the device,
and especially before turning it on!
Manufacturer is not liable for any damages or faults caused by:
-violation of advice concerning operation and cleaning;
-use other than designed;
-alterations made by user;
-use of inadequate spare parts.
We reserve the right to make technical changes for purposes of developing and improving
the useful properties.
2.2 Copyright protection
The instruction manual including any texts, drawings, images or other illustrations
is copyright. No part of this publication may be reproduced, transmitted or used in any
form or by any means without permission in writing from the manufacturer. Any person
who commits any unauthorized act in relation to this publication shall be liable to claims
for damages. All rights reserved.
NOTE!
The contents, texts, drawings, pictures and any other illustrations are
copyright and subject to other protection rights. Any person unlawfully
using this publication is liable to criminal prosecution.
2.3 Declaration of conformity
The device complies with the current standards and directives of the EU.
We certify this in the EC declaration of conformity. If required we will be
glad to send you the according declaration of conformity.

- 25 -
3. Transport, packaging and storage
3.1 Delivery check
Please check the delivery upon completeness and transport damage immediately
after receipt. In case of visible damage do not accept or accept the delivery with
reservation only.
Note the extent of damage on the carrier’s bill of delivery. Trigger off the complaint.
Hidden damages should be reclaimed immediately after notice, as claims for damages
can only be asserted within the effective period for complaints.
3.2 Packaging
Please do not throw away the covering carton of your device as it might be useful for
storage purposes, when moving or, in case of damages, when the device must be sent
back to a repair center. The outer and inner packing material should be removed
completely from the device before installation.
If you liked to dispose the packing, consider the regulations applicable
in your country. Supply re-usable packing materials to the recycling.
Please inspect the device upon completeness. In case any part is missing please
contact our customer service center immediately.
3.3 Storage
Keep the package closed until installation and under consideration of the outside
indicated positioning- and storage markings.
Packages should be stored under consideration of the following:
-do not store outdoors,
-keep it dry and dust-free,
-do not expose it to aggressive media,
-do not expose it to direct sunlight,
-avoid mechanical shocks and vibration,
-in case of longer storage (> 3 months) make sure you check the state
of the packaging and the parts regularly, if required refresh or renew.

- 26 -
4. Technical data
4.1 Overview of parts
1
Heating tube handle
2
ON/OFF switch
3
Frame
4
Feet
5
Surface with cut-out for GN container
6
Power supply cable
7
Sneeze screen
8
Heating tube
3
1
2
5
8
6
7
4

- 27 -
4.2 Technical specification
Description
Food warmer IHR650 1/1 GN
Code-No.:
114265
Material:
Stainless steel, aluminium, glass
Model:
Heat source
-Type: heating tube
-Number: 1
-Power per heat source: 0.65 kW
Designed for GN basins / GN tray
Cut-out for GN containers
W 507 x D 300 x H 50 mm
Basin size, GN GN 1/1 format
Max. GN container depth: 40 mm
Sneeze guard
ON/OFF switch
State at delivery: assembled for ready to use
Temperature range:
max. 70°C
Power:
0.65 kW / 230 V 50/60 Hz
Clear height:
340 mm
Dimensions:
W 775 x D 430 x H 457 mm
Weight:
9 kg
We reserve the right to make technical changes!
Important tip: delivery without GN containers!

- 28 -
5. Installation and operation
5.1 Installation
Positioning
Unpack the device, remove and dispose of all package material according to
the environment protection regulations.
CAUTION!
Never remove the nameplate and warning signs from the device.
Put the device on an even, stable, dry and waterproof surface which is resistant to
high temperature.
Never place the device on an inflammable surface.
Do not place the device near open flame, electric heaters or other heat source.
Never place the device at the edge of a table to avoid tilting or falling.
Never put the device in a moist or wet area.
Never locate the device in the direct vicinity of walls, low wall, kitchen furniture, or
other objects. Make sure there is enough distance (at least 30 cm) from walls and
other flammable or prone to discolouration objects. Follow the valid fire protection
regulations.
When it is not possible to leave the recommended distance, use appropriate
protection means (e.g. heat-resistant foil that will ensure keeping the wall
temperature within the safe range (up to 60 °C).
Always keep the working area around the device clean and dry.
When locating the device, make sure the power plug is easily accessible to
immediately unplug the device, if necessary.

- 29 -
Connection
DANGER! Electric shock hazard!
The device can cause injuries due to improper installation!
Before installation and connecting the local power grid
specification should be compared with that of the device
(see rating plate). Connect the device only in case of
compliance!
The power supply circuit with the socket must be protected by the fuse of at least 16A.
Connect the device directly to a single grounded socket. Do not use any power bar or
multiple socket.

- 30 -
5.2 Operation
Make sure the device is disconnected from the power supply.
Before use, clean the device according to the instructions set out in point 6
“Cleaning”.
Place the required warm food in the appropriate GN 1/1 container into the cut-out
in the surface under the heating tube.
Connect the device to the single grounded socket.
Turn on the heating tube with the ON/OFF switch by setting it to “ON“ position.
The food is kept warm from the top during the required time due to the heating tube.
The heating tube is responsible for even heat distribution.
Remove the food products when needed and serve.
HOT EXTERNAL SURFACE! Risk of burns!
The device is very hot during operation. Do not touch hot
surfaces to avoid burns. Use protective gloves or a kitchen
towel to remove the GN container from the cut-out in
surface.
When the device is not in use, set the ON/OFF switch to “OFF” position and
remove the plug from the power supply.

- 31 -
6. Cleaning
WARNING!
Before starting cleaning, switch the device off with the
ON/OFF switch (set to “OFF” position) and disconnect it
from the power supply (unplug!).
Leave the device to cool down completely.
The device is not suited for direct washing via water jets!
Protect the device from water penetration.
CAUTION!
Do not use any aggressive or bleaching cleaning agents containing active
oxigen, chlorine or corrosive components.
Do not use any abrasive or scouring cleaning agents, such as steel wool, steel
wool containing soap, metal / plastic sponges or similar agents with abrasive
surface
oClean the device regularly.
oClean the frame, heating tube handle, sneeze screen and the surface for the
GN container with a soft, damp cloth and mild cleaning agent.
oWipe the cleaned surfaces with a cloth moistened in clean water. After cleaning use
a soft and dry cloth to dry and polish the device surfaces.
oAfter use, empty the GN container and wash it regularly with running water, a soft
cloth and mild cleaning agent. Rinse the GN container with clean water and dry
thoroughly.
Storing of the device
oIf the device is not used for a longer time, clean it thoroughly according to the
instructions above and store it in a dry, clean place, protected from cold, sunlight,
and children. Do not place any heavy objects on the device.

- 32 -
7. Waste disposal
Old devices
The electric devices are marked with this symbol. You must not
dispose of electric devices with household waste. When the
device may not be longer used each consumer is obliged to
dispose of the device at the dedicated local collection point,
separately from household waste.
NOTE!
Electric devices should be used and disposed of properly to prevent the impact on
the environment.
Disconnect the device from the power supply and remove the power cord from
the device.
Bartscher GmbH phone: [phone]
Franz-Kleine-Str. 28 fax: [phone]
33154 Salzkotten Service-Hotline: [phone]
Germany www.bartscher.com
