Bartscher 101923 User manual

1,2kg/7L AS
101923

Bartscher GmbH
Franz-Kleine-Str. 28
D-33154 Salzkotten
Germany
Phone: [phone]
Fax: [phone]
Technical Support Hotline: [phone]
www.bartscher.com
Version: 2.0
Date of preparation: 2023-04-24
EN
2

101923 1 / 20
Original instruction manual
1Safety............................................................................................................2
1.1 Explanation of Signal Words....................................................................2
1.2 Safety instructions....................................................................................3
1.3 Intended Use ...........................................................................................5
1.4 Unintended Use.......................................................................................5
2General information.......................................................................................6
2.1 Liability and Warranty ..............................................................................6
2.2 Copyright Protection ................................................................................6
2.3 Declaration of Conformity ........................................................................6
3Transport, Packaging and Storage................................................................7
3.1 Delivery Check.........................................................................................7
3.2 Packaging................................................................................................7
3.3 Storage....................................................................................................7
4Technical Data...............................................................................................8
4.1 Technical Specifications ..........................................................................8
4.2 List of Components of the Appliance .......................................................9
4.3 Functions of the Appliance.....................................................................11
5Installation and operation ............................................................................11
5.1 Installation..............................................................................................11
5.2 Operation...............................................................................................12
6Cleaning and Maintenance..........................................................................19
6.1 Safety Instructions for Cleaning.............................................................19
6.2 Cleaning.................................................................................................19
6.3 Maintenance ..........................................................................................20
7Disposal....................................................................................................... 20

Safety
2 / 20 101923
EN
Diese Bedienungsa nleitung beschreibt di eI nstallation, Bedienu ngu nd Wartung des Geräts u ndg ilt als wichtige Infor mationsquelle un dN achschlagewer k.Di e Kenntnis aller enthalt enenSic herheitshinw eiseu ndH andlungs anweisungen schafft die V oraussetzung für d as sichere und sac hgerechte Arbeite n mitd emG erät.D arüber hin aus müssen die für den Eins atzbereich des Geräts gelt enden örtlichen Un fallverhütungsvorsc hriften und allgemein en Sicherheitsb estimmungen eingehalt en werden. Diese Bedi enungsanleitung ist Bestandt eild es Produkts und muss i n unmittelbarer Nähe d es Geräts für das In¬stall ations-, Bedienungs- , Wartungs- und Reinigu ngspersonal jederzeit z ugänglich auf¬b ewahrt werden. Wenn das Ger ät an eine dritte Person
weitergegeben wird , muss die Bedienungsa nleitung mit ausgehä ndigt werden.
Read this instruction manual before using and keep it available
at all times!
This instruction manual contains information about installation, operation and
maintenance of the appliance and constitutes an important source of information
and reference guide. The knowledge of all operational and safety instructions
included in this manual is a prerequisite for safe and proper handling of the
appliance. Additionally, accident prevention, occupational health and safety, and
legal regulations in force in the area the appliance is used apply.
Before you start using the appliance, especially before turning it on, read this
instruction manual in order to avoid personal injuries and property damages.
Improper use may cause damage.
This instruction manual forms and integral part of the product and must be stored in
an immediate vicinity of the appliance and be available at all times. The instruction
manual should be transferred together with the appliance.
1 Safety
This appliance has been manufactured in accordance with technical standards
currently in force. However, the appliance may be a source of hazards if used
improperly or contrary to its intended purpose. All persons using the appliance must
consider information included in this instruction manual and observe safety
instructions.
1.1 Explanation of Signal Words
Important safety instructions and warning information are indicated in this
instruction manual with appropriate signal words. You must strictly follow the
instructions, to prevent accidents, personal injuries and property damages.
DANGER!
The signal word DANGER warns against hazards that lead to severe
injuries or death if the hazards are not avoided.

Safety
101923 3 / 20
EN
WARNING!
The signal word WARNING warns against hazards that may lead to
moderate or severe injuries or death if the hazards are not avoided.
CAUTION!
The signal word CAUTION warns against hazards that may lead to
light or moderate injuries if the hazards are not avoided.
,di e
IMPORTANT!
The signal word IMPORTANT indicates possible property damages,
which may occur if safety instructions are not observed.
NOTE!
The symbol NOTE indicates subsequent information and guidelines
for the user on usage of the appliance.
1.2 Safety instructions
Electrical Current
•Too high a mains voltage or incorrect installation may cause electric shock.
•The appliance may be connected only if data on the rating plate correspond with
the mains voltage.
•To avoid short-circuit, the appliance should be kept dry.
•If there are malfunctions during operation, disconnect the appliance from the
power supply.
•Do not touch the appliance’s plug with wet hands.
•Never take hold of the appliance if it has fallen into water. Immediately
disconnect the appliance from the power supply.
•Any repairs or housing opening may be carried out by professionals and
relevant workshops only.
•Do not transport the appliance, holding it by the power cord.
•Do not allow the power cord to come into contact with heat sources or sharp
edges.
•Do not bend, pinch nor knot the power cord.

Safety
4 / 20 101923
EN
•Always completely unwind the power cord.
•Never place the appliance or other objects on the power cord.
•Always take hold of the plug to disconnect the appliance from the power supply.
•Check the power cord regularly for damage. Do not use the appliance if the
power cord is damaged. If this cable is damaged, it must be replaced by
customer service or a qualified electrician in order to avoid dangers.
Safety of planetary mixer operation
•Never touch the rotating parts of the appliance during operation.
•Keep hands, hair, clothes, spatulas, and similar kitchen utensils away from the
mixing bowl and whisk during the appliance operation.
•Whisks should be replaced only after complete stop of the drive which rotates
for a short time after the power supply is switched off.
Operating Personnel
•The appliance may only be operated by qualified personnel and trained
specialist personnel.
•This appliance may not be operated by persons (including children) with limited
physical, sensory or mental capabilities, nor by persons with limited experience
and/or limited knowledge.
•Children should be supervised to ensure that they are not playing with or
switching on the appliance.
Supervised Usage only
•Only supervised appliance may be used.
•Always remain in an immediate vicinity of the appliance.

Safety
101923 5 / 20
EN
Improper Use
•Unintended or prohibited use may cause damage to the appliance.
•The appliance may only be used when its technical condition is flawless and
allows for safe operation.
•The appliance may only be used when all connections are executed according
to rules of law in force.
•The appliance may only be used when it is clean.
•Use only original spare parts. Never attempt to repair the appliance on your own.
•Do not introduce any changes in the appliance nor modify it.
1.3 Intended Use
As described below, every use of the appliance for a purpose differing and/or
diverging from its intended standard use, is prohibited and considered to be an
unintended use.
The following is an intended use:
–Dough kneading for bread and pies
–Dough mixing for pies and cakes
–Whipping of creams, sour cream, and eggs
1.4 Unintended Use
An unintended use may lead to personal injuries or property damages caused by
hazardous voltage, fire or high temperature. The appliance may only be used to
perform tasks described in this instruction manual.
The following is an unintended use:
–Processing of inappropriate food products and other materials

General information
6 / 20 101923
EN
2 General information
2.1 Liability and Warranty
All information and instructions in this instruction manual account for legal
regulations in force, current level of technical engineering knowledge as well as our
expertise and experience, developed over the years. If special models or additional
options are ordered, or state-of-the-art technical solutions were implemented, the
actual scope of delivery of the appliance may, in some circumstances, differ from
descriptions and numerous drawings in this instruction manual.
The manufacturer is not liable for any damages nor faults stemming from:
–failure to observe instructions,
–unintended use,
–technical alterations introduced by the user,
–usage of unapproved spare parts.
We reserve the right to introduce technical modifications to the product, intended for
improvement of the appliance and its performance.
2.2 Copyright Protection
This instruction manual, and texts, drawings and images included in it, as well as its
other components are copyright protected. It is prohibited to reproduce this
instruction manual (including its excerpts), in any form and by any means, and to
use and/or transfer its content to third parties without manufacturer’s written
permission. Violation of the above results in obligation to pay compensation. We
reserve the right to claim further damages.
2.3 Declaration of Conformity
The appliance meets the currently applicable standards and guidelines of the
European Union. We confirm the above in the EC Declaration of Conformity. We
may provide relevant Declaration of Conformity upon request.

Transport, Packaging and Storage
101923 7 / 20
EN
3 Transport, Packaging and Storage
3.1 Delivery Check
Immediately upon reception, check the delivery for completeness and possible
shipping damage. In the case of visible transport damage refuse to accept the
appliance or accept it conditionally. Mark and note the scope of damage in shipping
documents/consignment list of the shipping company and lodge a complaint.
Concealed damage must be reported immediately upon its discovery, as
compensation claims may only be filed within applicable time limits.
If you find that parts or accessories missing, please contact our Customer Service
Department.
3.2 Packaging
Do not dispose of the appliance cardboard box. It may be used to store the
appliance when relocating or when shipping the appliance to our service point in the
case of any damages.
The packaging and its elements are made of recyclable materials. Particularly,
these are: plastic films and bags, cardboard box.
When disposing of the packaging, observe applicable domestic regulations.
Recyclable packaging materials should be recycled.
3.3 Storage
Leave the packaging closed until installation of the appliance; observe external
indications concerning method of placing and storage. Store the packaging in the
following conditions only:
–in closed rooms;
–in dry and dust-free surrounding;
–away from aggressive agents;
–in a location protected against sunlight;
–in a location protected against mechanical shocks.
In the case of extended storage (over three months), make sure you check the
condition of the packaging and the parts regularly. If needed, replace the packaging
with a new one.

Technical Data
8 / 20 101923
EN
4 Technical Data
4.1 Technical Specifications
Name:
Planetary mixer 1,2kg/7L AS
Art. No.:
101923
Material:
steel, enameled
Mixing bowl material:
stainless steel
Amount of dough production in kg/l:
1,2 / 7
Speed control:
5
Time setting, from–to, in min.:
1 - 30
Time setting intervals, in min.:
1
Connected load:
0,65 kW | 220-240 V | 50 Hz
Dimensions (W x D x H), in mm:
440 x 335 x 510
Weight, in kg:
20,6
We reserve the right to implement technical modifications.
Version / Characteristics
•Appliance connection: ready to plug in
•Removable mixing bowl
•Safety switch
•Digital display
•ON/OFF switch
•The set includes:
–1 whisk for beating froth, stainless steel
–1 hook for kneading dough, stainless steel
–1 flat stirrer, stainless steel, aluminium alloy
–protective grating, stainless steel

Technical Data
101923 9 / 20
EN
4.2 List of Components of the Appliance
Fig. 1
1. Housing
2. Control panel
3. Lever for lifting the mixing bowl
4. Holder chuck for mixing elements
5. Mixing bowl bracket
6. Base
7. Protective cover attachment
8. Mixing bowl
9. Mixing bowl protective cover
10. Flat stirrer
11.Dough hook
12.Whisk

Technical Data
10 / 20 101923
EN
Control Elements / Indicator Lights
Fig. 1
13.Speed level LED indicator
14.Digital display
15.ON/OFF switch
16.Time increase key
17.Time decrease key
18.Speed decrease key
19.Speed increase key
Protective Measures
•The planetary dough-kneading machine is equipped with protective devices
preventing start-up when:
–the mixing bowl protective cover is not in place,
–the feed opening in the protective cover is not closed,
–the mixing bowl is not placed on the bracket,
–the mixing bowl holder is not in its highest position.
•For additional safety the appliance is equipped with power supply failure
protection. This means that in the event of a power failure, the appliance can
only be restarted by operating the ON/OFF switch again. That element assures
that after the power supply restoration the appliance would not start
automatically.
•In case of overload the overheating protection is activated which automatically
stops the appliance. It is then required to switch the appliance off with ON/OFF
switch and after complete drive stop reduce the dough amount.

Installation and operation
101923 11 / 20
EN
4.3 Functions of the Appliance
The efficient planetary dough-kneading machine produces up to 1.2 kg of dough in
one cycle. The mixing bowl of volume of 7 litres allows for preparation of various
pies, whipped cream, creams, and much more, using the attached accessories and
the 5-level speed control.
5 Installation and operation
5.1 Installation
CAUTION!
Incorrect installation, positioning, operation, maintenance or misuse of
the appliance may lead to personal injury or property damage.
Positioning and installation, as well as repairs may be performed by
authorised technical service only and in compliance with the applicable
national law.
Unpacking / Positioning
•Unpack the appliance, remove all external and internal packaging elements and
shipment safeguards.
CAUTION!
Choking hazard!
Prevent children from accessing package materials, for instance: plastic
bags and EPS.
•If the appliance is covered with a protective film, remove it. Remove the film
slowly, so no glue residues are left. Remove any glue residues with the use of a
suitable solvent.
•Be careful not to damage the rating plate and warning labels fixed on the
appliance.
•Never place the appliance in humid or wet environment.
•Place the appliance in a way making the connections easily accessible, so that
they may be quickly disconnected if such a need arises.
•The appliance should be placed on surfaces that are:
–even, with sufficient bearing capacity, resistant to water, dry and resistant
to high temperatures;

Installation and operation
12 / 20 101923
EN
–sufficiently large, and thus enabling usage of the appliance with no
problems;
–easily accessible;
–well ventilated.
•Maintain sufficient clearance from table edges. The appliance might turn over
and fall down.
Power supply connection
•Verify if technical data of the appliance (see rating plate) correspond with the
local electric power grid specification.
•Connect the appliance to a single, properly grounded mains socket with
protective contact. Do not connect the appliance to a multi-socket.
•The power cord should be laid in a way preventing anyone from threading on it
or tripping against it.
5.2 Operation
WARNING
Risk of fingers and hands injury by rotating mixing elements!
Hands, fingers, as well as kitchen utensils may get caught by mixing
elements during operation.
Keep hands, hair and clothing away from the mixing bowl and mixing
elements.
Never insert rigid kitchen utensils into the mixing bowl through the feed
opening or through the opening of the protective cover while the appliance
is in operation. Switch the appliance off, wait for the motor to stop and
only then mix or remove ingredients from the mixing bowl.
Inserting or removing mixing elements while the motor is running can
lead to injury to fingers or hands.
Mixing elements should be replaced only after complete stop of the drive
which rotates for a short time after the power supply is switched off.

Installation and operation
101923 13 / 20
EN
Before First Use
1. Prior to first use, thoroughly clean the appliance and equipment according to
instructions in section 6 'Cleaning'.
2. To end with, dry the appliance and accessories thoroughly.
3. Install the mixing bowl and appropriate mixing elements in the appliance
according to the instructions below.
Mixing Bowl Protective Cover Installation
•Attach the mixing bo wlpr otective cover to the protecti ve cover attachment on th e appliance housing. Position the protective c over over the access ory holder chuck and fast en with two mounting scr ews provided.
1. Place the mixing bowl protective cover on
its attachment, located on the body of the
appliance.
2. Position the protective cover over the
accessory holder chuck and fasten with
two mounting screws (a) provided.
Fig. 2
Mixing Bowl Installation
Before the mixing bowl installation the
appliance must be switched off and the
mixing bowl bracket must be in lower
position.
1. Place the selected mixing element in the
mixing bowl and secure it in the holder
chuck.
There are three attachment points for the
mixing bowl:
–locking pin (stud) at the back of the
mixing bowl which is inserted into
appropriate hole in the mixing bowl
bracket;
–two pins on right and left side of the
mixing bowl bracket which must snap in
the holes on the mixing bowl holders.
Fig. 3

Installation and operation
14 / 20 101923
EN
Selection of Mixing Elements
Flat stirrer, whisk, and dough hook are designed only for specific (appropriate)
works.
NOTE!
Do not use the flat stirrer for preparation of heavy dough and the whisk for
other works than whipping, scrambling, or preparation of light mixes.
Flat stirrer
Usually used for light pies, cakes, filling, and
vegetable purée
Recommended speed levels: 2–3
Dough hook
Designed for heavy mixes, e.g. bread dough
Recommended speed level: 1
Whisk
Perfect for light mixes, e.g. whipped cream,
mayonnaise, eggs, egg white foam, pancakes,
souffles
Recommended speed levels: 4–5
Tab. 1
Installation / Removal Of Mixing Elements
1. Slide the selected mixing element's bayonet onto the holder chuck and rotate
counter-clockwise until it locks in.
CAUTION!
Make sure that the mixing element is firmly seated in the holder chuck.
2. To remove the mixing element, press it slightly towards the holder chuck of the
mixing element, rotate clockwise, and then pull it down.

Installation and operation
101923 15 / 20
EN
Filling with Ingredients
•After installation of the selected mixing element, fill the mixing bowl with
ingredients to knead. Do not exceed the maximum filling level.
Capacity (Quantities)
•The following table shows the recommended quantities (weights after kneading
of common mixes) for dough production.
•The appliance might be able to knead larger amounts, but it could lead to
premature wear and possible damage. The appliance overloading also extends
the mixing/kneading time and causes unsatisfactory results.
•In the event of overloading, stop the appliance and immediately reduce the
mixing bowl filling.
Product
Mixing element
Max. filling level
Egg white
Whisk
700 g
Mashed potatoes
Flat stirrer
1,500 g
Mayonnaise
Flat stirrer
3 litres
Meringue
Whisk
1 litre
Whipped cream
Whisk
3 litres
Pancake / waffle batter
Flat stirrer
2 litres
Puff pastry
Flat stirrer
2,000 g
Sponge cake
Whisk
1,000 g
Sweet yeast dough
Flat stirrer
2,500 g
Bread dough or roll dough
(light / 60% moisture)
Dough hook, speed level
1
Water 500
g
Flour
800 g
Tab. 2

Installation and operation
16 / 20 101923
EN
Lever and Mixing Bowl Protective Cover
1. After adding the ingredients lift the mixing
bowl bracket using the handle (right
drawing).
The mixing bowl lever is located on right
side of the appliance.
2. Rotate the mixing bowl lever counter-
clockwise by 180° to lift the mixing bowl
bracket.
3. To lower it, rotate the mixing bowl lever
clockwise by 180°. Pay attention to the
information next to the lever.
Fig. 4
NOTE!
The mixing bowl holder and its protective cover are electrically connected
to each other, so that the appliance only works when the mixing bowl is
placed in its holder, the protective cover is fixed correctly and the mixing
bowl holder is in its maximum raised position. After lifting the mixing bowl
using the lever the appliance may be safely switched on.
Switching the Appliance ON
1. Connect the appliance to a single grounded socket.
2. To switch the appliance on, press the ON/OFF switch on the control panel.

Installation and operation
101923 17 / 20
EN
Settings
1. Select the appropriate speed level and/or run time settings.
Speed levels
The appliance has 5 speed levels:
Level 1
for slow beating, mixing and kneading of yeast dough
Level 2
for light dough, filling and vegetable purée
Level 3
for mixing and whipping dough
Level 4
for whipping cream, egg whites
Level 5
for beating smaller amounts of cream, egg whites
Selection of speed level depends mostly on the amount and consistence of
ingredients to be processed.
1. Use the and keys on the left-
hand side of the control field to select
one of the levels.
2. Always start from the lowest level
and gradually select the higher levels
until reaching the required one.
Fig. 5
The selected speed level is indicated by the corresponding LED indicator light.
The digital display, in the left-hand field, additionally shows the selected speed level
(e.g., 3).

Installation and operation
18 / 20 101923
EN
Time
The duration can be set between 1 and 30 minutes (or no time = 0), in intervals
of 1 minute.
1. Select the required time using the
and keys in the centre of the
operating panel.
The set time is displayed in the right-hand
field of the digital display. If no time is set,
'0' is displayed in this field.
Fig. 6
Adding More Ingredients
During the mixing process, additional
ingredients can be added via the chute (b)
or opening (a) in the mixing bowl
protective cover.
The opening in the protective cover can, if
necessary, be easily opened with the
handle and closed again after the
ingredients have been added.
Fig. 7
NOTE!
Pour ingredients from bags carefully into the mixing bowl. Push the
opening of a bag as far as possible into the chute or into the opening in
the mixing bowl cover, so that dusting of the flour, for example, is
reduced.
