Batribike Sprint User manual

Owner
Manual
High Spec Models
SPRINT

2
Sprint
MODEL:-
SERIAL NUMBER:-
PURCHASE DATE:-
DAY MONTH YEAR
IMPORTANT PLEASE READ THIS MANUAL FULLY
PRIOR TO ASSEMBLY AND USE
For your safety and to ensure a long and trouble free life of your Batribike
bicycle, check the operation of brakes, lights, bell and gears,
and check tyre pressures are correct.
Also check all fasteners, including quick release mechanisms,
before every ride.
DEALERSTAMP
S
B
B
/
/

3
Thank you for purchasing a BATRIBIKE Electric Bicycle
With care and correct usage your bicycle
will give many years of service.
Important
PLEASE CHARGE THE BATTERY
BEFORE FIRST USING THE BICYCLE
Even though the battery indicator will show charge this cannot be
relied upon until the battery has had the initial full charge.
PACKAGE CONTENTS
1 ELECTRIC BICYCLE
1 BATTERY
1 BATTERY CHARGER with UK Mains Lead
1 MANUAL
Contents
Parts Identification ............................................ PAGE 4
Battery Charging ............................................... PAGE 6
Using the Power Assistance ............................. PAGE 8
Cycle Computer Functions ............................... PAGE 16
Standard Bicycle Functions .............................. PAGE 18
Maintenance Schedule ..................................... PAGE 22
Warranty ........................................................... PAGE 24
Specifications ................................................... PAGE 26

4
Detail view of
Battery Charging Socket
beneath cover
13
14
5
3
7
5
4
1
6
2
LCD
1
Twist Grip Throttle
2
Rear Brake Lever
3
Front Brake Lever
4
Motor Cutout Switch
5
Gear Selector
6
Bell
7
-
8
Battery Security Lock
9
Battery "Ignition" Lock
10
Suspension Forks
11
Battery
12
Charging Socket
13
Charging Socket Cover
14
Rear Hub Motor
15
Controller Box
16
-
17
8 Spd MicroShift Gears
18
Front Tyre 26 x 1.75
19
-
20
Rear Tyre 26 x 1.75
21
Suspension Pre-Load
22
Chain Guard
23
Seat Height Adjuster
24
Suspension Seat Post
25
Front LED Light
26
Rear LED Light
27
Pedals
28
-
29
Rear Vee Brake
30
Front Disc Brake
31
Chainwheel
32
Suspension Adjuster
33
PARTS IDENTIFICATION
We continually strive to ensure that we provide you with the best possible products, therefore
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

5
30
12
27
18
32
23
21
15
28
16
25
24
26
11
19
Detail view of
Battery "Ignition" Lock
Detail view of
Battery Security Lock
9
10
31
33
22
Left Side
Right Side

6
WARNING
Ensure that the battery is
switched off at the key switch
before charging the battery.
USE ONLY THE CHARGER SUPPLIED
Power
Charge
CHARGING THE BATTERY
The battery can be charged on or off the bike.
To remove the battery, remove the saddle,
unlock the battery with one of the two keys
provided and slide upwards and out of the
frame.
Insertion is the reverse of the above
procedure. Ensure that the battery is fully
seated and locked back into position using the key.
The charging lead is plugged into the
charging socket located behind the cover on
the upper right side of the battery.
IMPORTANT
It is important to plug the charger into the
battery before switching on at the mains.
Similarly, switch off at the mains before
unplugging the charger from the battery.

7
If your BATRIBIKE is not in use for an extended period it is
imperative that you charge the battery before storage and then
charge the battery once a month to prevent deterioration.
When not in use, store the battery in a warm, dry place.
If Lithium batteries are left flat for an
extended period then they may no
longer be functional and a new
replacement will be required.
With correct User Care as outlined above your battery should have a lifetime of
around 1000 charges.
FAILURE TO FOLLOW
THIS PROCEDURE WILL
INVALIDATE YOUR
BATTERY WARRANTY
Plug the charger into the mains socket and switch on at the wall outlet.
The lights on the charger will illuminate after a few seconds.
The RED light indicates that mains power is applied. The
other light will show ORANGE/RED whilst charging is taking
place. This may take up to six hours for a flat battery.
When the battery is charged the ORANGE/RED light will
change to GREEN.
Once charged, switch off at the wall outlet and unplug. Unplug the charging lead
from the battery and slide the cover back over the charging socket.
NOTE: If the battery is charged and the charger left switched
on for an extended period the charger will enter a low power
state, indictaed by both the RED and ORANGE/GREEN LEDs
flashing slowly. Switch off and unplug as above.
Alternative Charger Type
An alternative type of charger may be supplied with one light instead of the two
described above. In this case the light is RED when Charging, and GREEN
when the charge cycle is complete.
The battery does not have to be completely discharged before it is recharged.
The Lithium battery has no "memory" and therefore can be charged at any time.
It is perfectly acceptable to recharge the battery after a short ride so that the
battery is fully charged before the next ride.
Power
Charge
Power
Charge
Power
Charge
CHARGE
CHARGING IN
PROGRESS
CHARGE
COMPLETE
Power
Charge
CHARGING
CHARGED

8
Your BATRIBIKE Electric
Bicycle can be used as a normal
pedal cycle by simply not
switching on the battery.
(or using in Assist
Level 0 - see below)
Usage
Buttons
Display Information Areas
UP
POWER
DOWN
ASSISTANCE
LEVEL
BATTERY STATUS
CYCLE
COMPUTER
SPEED
Display Information Areas

9
To use under electric power, Switch on the
battery with the key located on the top left
side of the battery Then press the POWER
button on the handlebar LCD display.
Control Buttons
By means of the three buttons, UP, POWER and
DOWN, on the handlebar mounted display unit,
the various functions of the power controller and
Cycle Computer can be utilised.
See the following sections for details.
To turn off the LCD and the power to the
bike, press and hold the POWER button for
2 seconds.
If the power is left on for an extended period
and the bike is not used, then the power will
automatically be turned off.
Switching Off
Switching On
ELECTRIC BICYCLE FUNCTIONS

10
The LCD has a backlight
for night time use. This is
switched on by pressing
and holding the UP button.
To turn the backlight off,
again press and hold the
UP button.
The LCD shows the charge remaining in the
battery in the upper left of the display. The
indicators will gradually go out as the battery
power is used up. Refer to the table below
for details.
Battery Meter
Display Backlighting - Night Mode
70 - 100%
SYMBOL
DISPLAYED
CHARGE
REMAINING
BATTERY METER DISPLAYS THE CHARGE REMAINING IN THE BATTERY
BATTERY IS
EXHAUSTED AND
SHOULD BE
RECHARGED AS
SOON AS POSSIBLE
50 - 70%
30 - 50%
15 - 30%
0 - 15%
FLASHING
This function will also operate the
front LED light

11
The centre large digits will normally display the current speed of
the bicycle. For the UK market this is set to show miles per hour
(MPH). The display is accurate to about 10% when the wheel size
is correctly calibrated and the tyre inflated as per the
manufacturers recommendations.
Speed Display
The display can be changed by your dealer to show kilometres
per hour (Km/H)

12
PEDAL ASSISTANCE FROM THE MOTOR
28 miles
15.5 MPH
35 miles
12 - 15 MPH
40 miles
10 - 15 MPH
60 miles
9 - 12 MPH
untested
6 MPH
LEVEL
PERFORMANCE
Provides maximum power when
negotiating hills and head winds.
Great when needing to simply get from
A to B as fast as possible.
Great for commuting to work.
EXAMPLE OF USAGE
Normal Use Mode.
These are the levels to use for everyday
cycling. Gives good performance whilst
maximising usable range per charge.
Best for Leisure Use.
Use these lower power levels when
negotiating busy cycle paths and
crowded areas. Also use when setting
off and gradually increase through the
levels for a smoother performance.
Ideal for negotiating obstacles.
There are 5 levels of pedal assistance
available from the motor. Using the Up and
DOWN buttons you can select from level 1
(LOW) to 5 (HIGH). The motor will then be
activated upon pedalling. There is a rotation
sensor located near the crank which senses
when the pedals are being used.
Pedal Assistance
Please remember that the above values are provided as a guide.
Due to manufacturing tolerances the speeds & distances may vary.

13
Weather and terrain will affect the performance. In hilly areas or
when the bike is heavily loaded there will be a significant increase
in the power used from the battery and hence the range will
decrease accordingly. A lightly loaded bike will achieve higher
performance levels. (These results were ontained by test riders in
optimal conditions - 75kg rider, level ground, no wind).
Other Functions
The Display can also
show diagnostic
information in the
event of a malfunction.
If an error occurs the
display will show a
code as in the example
shown. Make a note of
the error number and
turn off the bicycle
power. After 2 minutes turn on the power again. If the code re-
occurs contact your dealer for assistance.
If the assistance level is set to 0, (ZERO) then the
motor will not be turned on. Your BATRIBIKE will now
act and feel like a normal bicycle. This is useful when
you are feeling fit at the start of a journey or using
your bike for exercise purposes. Power is still only a
button press away.
No Assistance - Normal Pedal Bicycle

14
To activate the throttle, select level 6. "Assist 6" will
be displayed on the LCD panel. In this mode the
throttle on the left handlebar, (twist-grip), is now live.
In all other assistance levels the throttle is not
functional.
You can still pedal the bike but power will not be
applied until the throttle is activated. To activate, twist
the left grip towards the rider.
Use the throttle control gently. A small twist will apply a small
amount of power. Twisting more will increase the power until the
control is fully rotated at which point full motor power will be
applied.
Throttle assistance can also be used without pedalling.
A handy way to use the throttle is to pull away from junctions, or
when starting on inclines as the rider will pull away easier and is
less likely to wobble. It can also be very useful for pulling out and
overtaking slower cyclists smoothly and quickly.
Using the Throttle - Country Specific
PLEASE NOTE:
The throttle control is not activated for some countries due to legal
restrictions. Please refer to your dealer for help and advice.

15
If you want help in setting off on inclines or to
get a smooth getaway at junctions and traffic
lights, there is a system available whereby
the motor can be applied even when no
assistance is selected. This is known as
Launch Assist and is activated by holding
down the DOWN button for 2 seconds.
Launch Assist
The motor will be switched on in low speed
and will continue on until the DOWN button
is released. The bicycle will be powered at
approximately 4 MPH, (6 KMH). Whilst the
motor is activated the running man sysmbol
will be displayed. (Flashing).
The system is designed for intermittent use
and should not be used for more than a few
seconds at a time. If you want continuous
power then one of the Assist modes should
be selected.
BS EN15194 Compliance
The BATRIBIKE SPRINT conforms to BS EN15194.
For the British market, the addition of a throttle control has
rendered this not compliant in some countries.
●You are recommended to seek advice from the relevant
authorities in the country you are visiting before travelling.

16
CYCLE COMPUTER
The LCD models have useful Cycle Computer functions built in. There is a built
in sensor and pickup located in the rear hub which activates the speed and
distance readings.
When first turned on
the display shows the
Trip Time (TM) in the
top right and the Trip
Distance (DST) in the
bottom right. The
Speed is always shown
in the centre right
section of the display.
Normal Display
To change the display to show the Total Time
(TTM) and Odometer Distance (ODO), simply
press the POWER button momentarily.
Total Time and Distance
NOTE
The Trip Time (TM) and Trip Distance (DST) will be reset to zero when the
power is turned off. This will also happen if the bicycle is not used for an
extended period and the power is turned off automatically.

17
When Total Time and Odometer have
been selected, clicking the UP or DOWN
buttons sets the display to show Average
Speed (AVS) or Maximum Speed (MXS)
in the centre section.
Average Speed
Momentarily pressing the POWER button will
return the display to Normal showing the Trip
Time (TM) and Trip Distance (DST).
Maximum Speed
EITHER
Average Speed

18
STANDARD BICYCLE FUNCTIONS
Gears
The SPRINT is provided with 8 speed MicroShift gears.
To change gear you use the right handlebar mounted
selector levers. Gear number 1 is low for hills and
rough terrain and gear 8 is high for normal road use. To
increase the gear simply push the upper lever with your
right thumb. To decrease the gear push the larger
lower lever away from you with your thumb. You must
be pedalling forwards as you change gears.
Lights
Lights are provided on your BATRIBIKE bicycle. These are power efficient
LED units which achieve a long life on each set of batteries.
SAFETY FEATURE - The power for the
rear light is kept separate from the main
power supply so that in the event that the
battery is exhausted you will still have a rear
light for safety.
The front light is powered by the main bike battery
and is switched on by pressing and holding the UP
button on the handlebar mounted LCD unit.
Press again to turn off the light.
The backlighting to the LCD unit is also switched at the same time.
An auto-sensing function is built in to the lamp unit which will deactivate the front
light in bright conditions to save power.

19
The rear light requires 2 AA batteries. You will require a small screwdriver to
take off the red lens for battery replacement. It is switched on and off by the
small red push button switch on the rear of the unit.
Either of the types shown above may be fitted.
Braking
To stop, release the throttle and pull the brake levers.
Side Stand
To put the bicycle on its stand:-
1) While holding the bicycle upright, push the stand to its full
extent.
2) Lean the bicycle over onto the stand.
Make sure bicycle is on solid ground.
Do not sit on the bicycle whilst the stand is down. It is
designed to take the weight of the bicycle and not the
additional weight of the rider.

20
Quick Release fittings for Seat Height Adjustment
With the locking lever in the loose position, tighten the nut until finger tight. The
final tightening is done by moving the lever to the locked position. To undo move
the lever to the loose position to enable height adjustment.
Loose Locked
Adjusting the Front Suspension
The front suspension can be adjusted for
softness and preload by using the adjusters
on the top of the forks.
To adjust the preload,
locate the tab on the
top of the left fork
tube. Lift the tab and
turn in the direction
shown with the +(PLUS) to increase the preload. Turn in
the direction of the -(MINUS) to decrease the preload.
Fold the tab flat again after use.
The softness of the suspension can
be adjusted with the red dial located
on the top of the right fork tube.
Turn the lever clockwise to choose the softer settings and
anti-clockwise to stiffen the ride. Turning the lever fully
anti-clockwise will "lock" the suspension.
Suspension setting is a matter of personal preference and
may need to be adjusted for a comfortable ride depending
on the terrain.
PRELOAD
ADJUSTMENT
on left fork
SUSPENSION RIDE
SETTING
on right fork
