Bauhn ASCBS-815-S User manual

INSTRUCTION MANUAL
Model Number: ASCBS-815-S
Portable Speakers
with Bluetooth® Wireless Technology
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS

2
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Contents
Warranty Details 3
Welcome 4
General Safety Instructions 5
Product Overview 6
Getting Started 8
Instructions 9
FAQs 10
Other Useful Information 11
Repair and Refurbished Goods or Parts Notice 12

3
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Portable Speaker
with Bluetooth®Wireless Technology
Warranty Details
The product is guaranteed to be free from defects in workmanship and
parts for a period of 12 months from the date of purchase. Defects that
occur within this warranty period, under normal use and care, will be
repaired, replaced or refunded at our discretion. The benefits conferred
by this warranty are in addition to all rights and remedies in respect of the
product that the consumer has under the Competition and Consumer Act
2010 and similar state and territory laws.
Our goods come with guarantees that cannot be excluded under the
Australian Consumer Law. You are entitled to a replacement or refund for
a major failure and to compensation for any other reasonably foreseeable
loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does
not amount to a major failure.

4
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Welcome
Congratulations on choosing to buy a Bauhn®product.
All products brought to you by Bauhn® are manufactured to the highest standards
of performance and safety and, as part of our philosophy of customer service and
satisfaction, are backed by our comprehensive 1 Year Warranty. We hope you will enjoy
using your purchase for many years to come.

5
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
General Safety Instructions
Read this manual thoroughly before first use, even if you are familiar with this type of
product. Keep the manual in a safe place for future reference, along with the completed
warranty card, purchase receipt and carton. If applicable, pass these instructions on to
the next owner of the appliance.
Follow all instructions and heed all warnings in this manual. The safety precautions
enclosed herein reduce the risk of fire, electric shock and injury when correctly adhered to.
• Usageenvironment:In order to prevent environmental factors (dampness, dust, food,
liquid etc.) harming the Bluetooth Speaker, only use the product in well ventilated,
clean and dry environments, away from excessive heat, very low temperatures and
humidity. Keep the product away from direct sunlight, sharp objects, liquids, oils and
other chemicals.
• Protectfromheat:Do not leave the unit near any heat sources, stoves, ovens or other
appliances (including amplifiers) which produce heat.
• WARNING!Protectfromwater:Ensure that this unit does not get wet. Protect it from
splashing water. Do not use it with wet hands, and do not immerse it in water or other
liquids. Do not use it near a sink, bath, shower, or in humid or damp conditions. Do not
place objects filled with water (such as a vase) on top of the product.
• Damage:In case of damage, do not disassemble, repair or modify the product yourself.
Contact our after sales support line or qualified personnel for advice on repair or
replacement.
• Intendedpurpose:Use this product only for its intended purpose. It is intended for
personal use only, not for commercial or industrial use.
• Usagerestriction:This product is not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction concerning use of
the product by a person responsible for their safety.
• Children:Supervise young children to ensure that they do not play with the product.
Close supervision is necessary when the product is used by or near children.
• Packaging:Plastic packaging materials can present a suffocation hazard for young
children and babies. Keep all packaging materials out of the reach of children.
• Voltage:Before connecting the power adaptor and turning on the product, ensure
that the electrical voltage and circuit frequency correspond to those indicated on the
product rating label.
• Inappropriateuse: Only use this product in accordance with the instructions in this
manual.
• Repair:The product has no user-serviceable parts contained inside. Do not attempt to
repair, disassemble or modify it. Any modifications could void your warranty. If the unit
needs service, contact our after sales support line for advice relating to examination,
repair, or return of the product.
• Liability: We assume no liability for any eventual damages or injury caused by misuse
of the product or noncompliance with these instructions.

6
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Product Overview
2
1
3
4
5
6
7
8
9
10
1. Hook: To connect the Carabiner (not pictured)
2. Previous:
• Short press to go to the previous song
• In Memory Card mode, long press to go to the previous folder
3. StatusIndicatorLight: To view the Battery and Connection status
4. ModeSelection:Press to switch between different modes (AUX / Micro SD /
Bluetooth)
5. Pause/Play: Press to Pause or Resume Playback
6. VolumeUp:
• Short press to increase the volume gradually
• Long press to increase the volume quickly
7. Microphone:Built-in Microphone for hands-free calls
8. Next:
• Short press to go to the next song
• In Memory Card mode long, press to go to the next folder
9. VolumeDown:
• Short press to decrease the volume gradually
• Long press to decrease the volume quickly
10. Call: Press once to Answer an incoming phone call. During a call, short press to end
the call

7
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Product Overview (Cont.)
NOTE: To access the following ports, lift up the silicone on the bottom of the unit
11
12
13
14
11. MicroSDSlot:Insert a Micro SD Card
12. AUXinPort: To connect with an external audio input (Standard 3.5mm socket)
13. MicroUSBPort: To charge the built-in rechargeable battery
14. PowerON/OFF: To turn the unit ON and OFF
Indicators
BlueLED: The blue indicator will flash to indicate that it is ready for pairing with
a Bluetooth enabled device. Once paired, the blue LED will stay
illuminated.
OrangeLED: The orange indicator will stay illuminated when an audio cable is
plugged into the LINE IN socket.

8
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Getting Started
Beforerstuse
Read the Safety Instructions provided in this manual before using the appliance.
Charging
The unit has been partially charged at the factory. We recommend you fully charge it
before use via the Micro USB cable provided.
• Plug the Micro USB end into the Portable Speaker and the other end into your
computer. It will take approximately 4-5 hours to fully charge.
• When the battery is full, the battery indicator light will turn blue.
NOTE:
• When the Portable Speaker is running out of battery, the orange (make orange)
indicator light will flash quickly and the volume will decrease.
• You can only play music once paired with an external device via Bluetooth, or by
using the LINE IN jack. The unit will not play music directly via the USB port.
• You can also use a 5VDC/1A adaptor (not supplied) to charge.
PowerON/OFF
In order to turn On or Off your unit, lift up the silicone on the bottom of the unit.
• Slide the ON/OFF switch to the ON position to turn on the Portable Speaker.
• Slide the ON/OFF switch to the OFF position to turn off the Portable Speaker.
ConnectingwithBluetoothWirelessTechnology
To connect to Bluetooth Wireless Technology for the first time, use the following
instructions:
1. The unit will enter search mode automatically when you turn on the power for the first
time. The blue LED indicator will flash and the unit will then enter pairing mode.
2. When pairing, put your device (e.g. a mobile phone) within 3 metres of the unit.
Activate the Bluetooth function of your device (refer your device’s user manual for
instructions). Your device will start searching for nearby Bluetooth enabled units.
3. Select “ASCBS-815-S” from the list of units searched by the device.
4. If the device requests a password, enter “0000” and press OK to start pairing. Once
paired, the unit will enter connection mode and the blue LED will stay illuminated.
5. Make sure the unit is within 10 metres of the device and there is no obstructions
between them (such as a wall). You can now play the device’s music through the
unit’s speaker. You can control the music selection through the device and the
Portable Speaker.
NOTE: Your Portable Speaker must be in Bluetooth Mode in order to pair with your
Bluetooth enabled device.

9
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Instructions
BluetoothConnectionMode
After you have paired your unit for the first time, when you turn the Portable Speaker on
and enable bluetooth on your device, it will automatically connect with the last paired
device.
To disconnect the last paired device and connect to another device, press and hold (M)
button on your Portable Speaker, or unpair Bluetooth on your paired device (refer to your
device’s user manual for further instructions). The Portable Speaker will then enter pairing
mode and the Indicator Light will start flashing blue.
Bluetoothplayback
• Short press / to decrease/increase the volume gradually.
• Long press / to decrease/increase the volume quickly.
• Press to Pause or Resume Playback.
• Short press to go to previous track.
• Short press to go to next track.
Hands-freeoperation
• Your Bluetooth enabled device should be paired and connected in order to be able to
use hands-free operation.
• When a call comes through, music playback will pause and the phone’s ringtone will
start playing. Press to answer the call.
• Once you have finished, press to hang up the call and the Portable Speaker will
return to Playback mode automatically.
AUX-INMode
The AUX-IN port is located underneath teh silicon on the bottom of the Portable Speaker.
• Use the (M) to select AUX-IN mode. The AUX-IN port is located underneath the
silicone on the bottom of the Portable Speaker.
• Connect one end of an audio cable to your Portable Speaker and the other end of
the audio cable to the earphone socket of an external audio source (e.g. iPod, MP3
player) and start playing music from the external source.
• Short press / to decrease/increase the volume gradually.
• Long press / to decrease/increase the volume quickly.
The Bluetooth®word mark and logos are registered trademarks owned by Bluetooth SIG, Inc., and
any use of such marks by Hands (IP) Holdings Pty Ltd is under license. Other trademarks and trade
names are those of their respective owners.

10
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
MicroSDCardMode
The Micro SD Card slot is located underneath the silicone on the bottom of the Portable
Speaker. When you insert your Micro SD Card into the Micro SD Card slot, the Portable
Speaker will start to play music from your Micro SD Card automatically.
MicroSDPlayback
• Short press / to decrease/increase the volume gradually.
• Long press / to decrease/increase the volume quickly.
• Press to Pause or Resume Playback.
• Short press to go to previous track.
• Long press to go to previous folder.
• Short press to go to next track.
• Long press to go to the next folder
1. MicroSDSlot:Insert the Micro SD Card
2. AUXinPort: To connect with an external audio input (Standard 3.5mm socket
3. MicroUSBPort: To charge the built-in rechargeable battery
4. PowerON/OFF: To turn the unit ON and OFF
Indicators
BlueLED: The blue indicator will flash to indicate that it is ready for pairing with
a Bluetooth enabled device. Once paired, the blue LED will stay
illuminated.
OrangeLED: The orange indicator will stay illuminated when a cable is plugged into
the LINE IN socket.
Instructions

11
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
FAQs
If you experience problems with your Portable Speaker, check the table below for
solutions to common problems. If the problem persists after checking the suggested
solutions, please contact our after sales support line for advice. Do not attempt to repair
the product yourself.
Problem Solution
Failure of Bluetooth
pairing
The unit will search and connect to the previously
connected Bluetooth device automatically. To search
and pair a different Bluetooth device, please unpair the
previous Bluetooth device first.
The indicators do not
glow, and Bluetooth
cannot be connected
The unit enters sleep mode after a period of inactivity.
Restart the speaker to pair and resume the Bluetooth
connection.
Low sound
The unit is at the default low level output. Turn up the
volume of the unit.
The output volume of the connected Bluetooth device is
low. Turn up the volume of the Bluetooth device.
Bluetooth connection
range is short
There may be a obstruction between the unit and the
Bluetooth device. Remove the obstruction.
A pause or interruption
occurs during normal
use.
There may be a obstruction between the unit and the
connected Bluetooth device. Remove the obstruction.
The distance between the Portable Speaker and the
connected Bluetooth device may exceed the connection
range. Place the unit closer to the Bluetooth device.

12
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Other Useful Information
Technicalspecications
Bluetoothspecications Bluetooth V4.0
SupportedBluetoothproles AVRCP, HFP
Maximumconnectivityrange 10m
Audiooutput 2 x 3.5W(RMS)
Chargingtime 2-3 Hours
Rechargeablebattery 3.7VDC 2200mAh
Playbacktime up to 8 hours
Inputs AUX, Micro SD Card
Devicessupported Most Bluetooth enabled devices

13
1300 886 649 Model: ASCBS-815-S Product Code: 52076 11/2015
www.tempo.org
AUS
Portable Speaker
with Bluetooth®Wireless Technology
Repair and Refurbished
Goods or Parts Notice
Unfortunately, from time to time, faulty products are manufactured which need to
be returned to the supplier for repair.
Please be aware that if your product is capable of retaining user-generated data
(such as files stored on a computer hard drive, telephone numbers stored on
a mobile telephone, songs stored on a portable media player, games saved on
a games console or files stored on a USB memory stick) during the process of
repair, some or all of your stored data may be lost. Werecommendyousavethis
dataelsewherepriortosendingtheproductforrepair.
You should also be aware that rather than repairing goods, we may replace them
with refurbished goods of the same type or use refurbished parts in the repair
process.
Pleasebeassuredthough,refurbishedpartsorreplacementsareonlyused
wheretheymeetALDI’sstringentqualityspecications.
If at any time you feel your repair is being handled unsatisfactorily, you may
escalate your complaint. Please telephone us on 1300 886 649 or write to us at:
Tempo (Aust) Pty Ltd ABN 70 106 100 252
PO BOX 6056 Frenchs Forest, Sydney, Australia NSW 2086
Tempo Help Desk: 1300 886 649 (Aust)
(Operating Hours: Mon-Fri 08:30AM to 06:00PM EST)
Email: [email protected]g
