Baumatic BGS460SS User manual

1 I
BGS460SS 46 cm
Steam oven with
grill

2
User Manual for your Baumatic
BGS460SS
46 cm Steam oven with
grill function
NOTE: This User Instruction Manual contains important
information, including safety & installation points, which will
enable you to get the most out of your appliance. Please keep it
in a safe place so that it is easily available for future reference; for
you or any person not familiar with the operation of the appliance.
GS 08/08/11

3
Contents
Environmental note 4
Important safety information 5 – 7
Specifications 8 - 9
Product and aperture dimensions 8
Product specifications 8
Standardaccessories 9
Electricaldetails 9
Description of the oven and accessories 10-11
Oventimer 10
Timersymbols 11
Using your oven for the first time 11-16
Before first use 11-12
Switching on the appliance 12
Settingthetimeofday 12
Setting the minute minder function 12-13
Setting the duration function 13
Setting the end cook function 14
Setting the start and end time function 15-16
Cancelling a timer function 16
Adjusting the audible signal 16
Steam oven cooking function 17
Grill cooking function 18
Cookingguidelines 18
Warnings 19
Accessories 19-20
Cookingcharts 20-21
Cleaning and maintenance 21-25
Oven cavity cleaning cycle 22
Removing the side racks 23
Replacing the light bulb 24
Removing the oven door for cleaning 24-25
Installation 25-28
Electricalconnection 25-26
Installing the oven into the kitchen cabinet 27
Ventilationrequirements 28
My appliance isn’t working correctly 29-31
Errorcodeschart 29
Contact details 32

4
Environmental note
oThe packaging materials that Baumatic uses are environmentally
friendly and can be recycled.
oPlease discard all packaging material with due regard for the
environment.

5
IMPORTANT SAFETY INFORMATION
Your safety is of the utmost importance to Baumatic.
Please make sure that you read this instruction booklet
before attempting to install or use the appliance. If you
are unsure of any of the information contained in this
booklet, please contact the Baumatic Advice Line.
General Information
oThis appliance is designed for domestic household use and can
be built into a standard kitchen cabinet or housing unit.
oIMPORTANT: The adjacent furniture or housing and all
materials used in the installation must be able to withstand a
minimum temperature of 85°C above the ambient temperature
of the room it is located in, whilst in use.
oCertain types of vinyl or laminate kitchen furniture are
particularly prone to heat damage or discolouration at
temperatures below the guidelines given above.
oAny damage caused by the appliance being installed in
contravention of this temperature limit, or by placing adjacent
cabinet materials closer than 4mm to the appliance, will be the
liability of the owner.
oThe use of this appliance for any other purpose or in any other
environment without the express agreement of Baumatic Ltd.
will invalidate any warranty or liability claim.
oYour new appliance is guaranteed against electrical or
mechanical defects, subject to certain exclusions that are noted
in Baumatic’s Conditions Of Guarantee. The foregoing does not
affect your statutory rights.
oRepairs may only be carried out by Baumatic service
engineers or their authorised service agent.

6
Warning and safety instructions
oThis appliance complies with all current European safety
legislation. Baumatic do wish to emphasise that this compliance
does not remove the fact that the appliance surfaces will
become hot during use and retain heat after operation.
Child Safety
oBaumatic strongly recommend that babies and young children
are prevented from being near to the appliance and not allowed
to touch the appliance at any time.
oIf it is necessary for younger family members to be in the
kitchen, please ensure that they are kept under close supervision
at all times.
General Safety
oDo not place heavy objects on the oven door or lean on the
oven door when it is open, as this can cause damage to the oven
door hinges.
oDo not leave heated oil or fat unattended, as this is a fire risk.
oDo not place pans or baking trays directly on the base of the
oven cavity, or line it with aluminium foil.
oDo not allow electrical fittings or cables to come into contact
with areas on the appliance that get hot.
oDo not use the appliance to heat the room it is located in or to
dry clothing.
oDo not install the appliance next to curtains or soft furnishings.
oDo not attempt to lift or move cooking appliances by using the
oven door or handle, as this may cause damage to the appliance
or result in injury to the person lifting the appliance.
Cleaning
oCleaning of the oven should be carried out on a regular basis.
oGreat care should be taken whilst using this appliance and when
following the cleaning procedure.
oIMPORTANT: The appliance must be disconnected from the
mains before following the cleaning procedure.

7
Installation
This appliance must be correctly installed by a
suitably qualified person, strictly in accordance
with the manufacturer’s instructions.
oBaumatic Ltd. declines any responsibility for injury or
damage, to person or property, as a result of improper
use or installation of this appliance.
oHeat, steam and moisture will be created during use of the
appliance, take care to avoid injury and ensure that the room is
adequately ventilated. If the appliance is going to be used for
prolonged periods of time, then additional ventilation may be
required.
oPlease consult with your qualified installer if you are in any doubt
about the amount of ventilation that you will require.
Declaration of conformity
This appliance complies with the following European Directives:
-2006/95/EC regarding “low voltage”
-2004/108/EC regarding “electromagnetic disturbances”
-Regulation (EC) N° 1935/2004 regarding “materials in contact
with food”
oThe above directives comply with 93/68/EEC regarding CE
marking.
oThe manufacturer declares that the oven is built using certified
materials and requires the appliance to be installed in
accordance with the standards currently in force. This appliance
must be used by a trained person for domestic purposes only.

8
Specifications
Product Dimensions
Height: 460 mm
Width: 597 mm
Depth: 550 mm (without front panel)
Aperture Dimensions:
Height: 445 mm (built-in)
460 mm (built under)
Width: 560 mm
Depth: 560 mm
Product specifications
oEnergy efficiency class: A
oGross oven capacity: 31 litres
oNet oven capacity: 27 litres
oSteam cooking function
oGrill cooking function
oTouch control / knob operation
oMechanically controllable thermostat
oThermostatically controlled grill

9
oLED full programmer
oSafety lock
oDouble-glazed removable door
Standard accessories
oRemovable side racks
o1 x Inox perforated deep tray
o1 x Inox baking tray
oSafety shelf
Electrical details
Rated Voltage: 220 - 240 Vac 50 - 60 Hz
Supply Connection: 13 A (double pole switched fused
outlet with 3mm contact gap)
Max Rated Inputs: 1.30 – 1.55 kW
Mains Supply Lead: 3 x 1.2mm²
For future reference please record the following information which can
be found on the rating plate and the date of purchase which can be
found on your sales invoice. The rating plate for your oven can be
located by opening the oven door and looking on the right hand side of
the oven chassis.
Model Number ……………………………….
Serial Number ……………………………….
Date of Purchase ……………………………….

10
Description of the oven and accessories
1) Control panel
2) Water jug compartment
3) Water jug
4) Safety shelf
5) Oven door
6) Oven door glass
7) Oven cavity
8) Side racks
Oven timer
1) Automatic cooking symbol
2) Oven in use symbol
3) Decimal point symbol
4) Minute minder symbol
5) Minus button
6) Programme button
7) Plus button

11
The symbols on the timer display
1 A Automatic program is working.
2 The appliance is ready for manual use (not automatic).
3 When blinking, the programmer is in setting the hour mode.
4 Timer function set.
5 - Decreasing numbers when setting the timer. Also for selecting your
desired sound level.
6 M “Mode” button to access the programming options.
7 + Increasing numbers when setting the timer.
Using your oven for the first time
Before first use
oThe appliance should be disconnected from your mains
supply before commencing any cleaning process.
oTo remove any residue from the oven that may have been left
from the manufacturing process, you should select the steam
oven function and set the thermostat to its maximum
temperature setting.
oIt is perfectly normal for a smell to be produced during this
process.
oYou should make sure that any windows in the room are left
open during this process.
oIt is advisable for you not to remain in the room whilst the
burning off process is taking place.
oYou should leave the oven on maximum setting for 30 – 40
minutes.
oAfter the oven cavity has cooled, it should then be cleaned with
warm soapy water, using either a sponge or soft cloth. No
abrasive cleaners should be used.
oOuter parts of the oven should be cleaned with warm soapy
water, using either a sponge or soft cloth. No abrasive cleaners
should be used.

12
oWe would recommend that an appropriate stainless steel cleaner
and polish is regularly used on the stainless steel surfaces of this
appliance.
Switching on the appliance
oWhen the oven is switched on for the first time, or after a power
cut, the numbers and the automatic cooking symbol (1) on the
LCD display will flash.
oYou will then need to set the time of day before you can use the
appliance.
Setting the time of day
After turning on the oven for the first time, you should set the
time of day.
oAfter pressing the program button (6) for about two seconds,
use the minus button (5) and plus button (7) to adjust the time
that appears in the display. After getting the display to the
correct time, release the minus and plus buttons. After a few
seconds the time will fix in the display and you will be able to
use your oven.
Setting the minute minder function
You are able to set the minute minder at any time, regardless
of whether an oven function has been selected. You can set a
period of time using the minute minder function and an alarm
will sound when this period of time has elapsed.
oPress the program button (6) for two seconds, the minute
minder symbol (4) will flash. Set the period of time that you
wish the minute minder to countdown for, by using the minus
(5) and plus (7) buttons.
oOnce the display has got to your desired countdown time, let go
of the minus and plus buttons. The minute minder symbol will
appear on the timer display.
oOnce a countdown time has been set, it is possible to shorten or
lengthen the time by using the minus or plus buttons.
oAn alarm will sound when the countdown time has elapsed. This
alarm can be silenced by pressing any button on the timer. The
alarm will turn off automatically after 7 minutes.

13
oImportant: If the oven is in use, then it will continue to heat
once the alarm has been silenced. If you have finished cooking,
then you should turn the relevant thermostat knob to the off
position.
Setting the duration function
This function will allow you to set a countdown time similar to
the minute minder function. However the oven will no longer
continue to heat, once the countdown period has elapsed.
oUse either the oven thermostat knob or grill thermostat knob to
set the temperature that you require.
oIt is then possible to set the duration of the cooking time that
you require.
oPress the program button (6) for two seconds and the display
will show a value of 00:00. Set the period of time that you wish
the duration function to countdown for, using the minus (5) and
plus (7) buttons. The maximum time available is 10 hours.
oOnce the display has got to your desired countdown time, let go
of the minus and plus buttons. The countdown will start
immediately and the automatic cooking symbol (1) and oven in
use symbol (2) will appear on the timer display.
oOnce a countdown time has been set, it is possible to shorten or
lengthen the time by using the minus or plus buttons.
oAn alarm will sound when the countdown time has elapsed and
the oven will switch off.
oTo silence the audible signal and return the oven to manual
operation mode, you should press the program button (6).
oImportant: If you do not turn the relevant thermostat control
knob to the off position, then the appliance will continue to
operate as soon as you press the program button.

14
Setting the end cook function
This function is similar to the duration function, however
instead of selecting a period of time that you wish the oven to
switch off after. You select the time of day that you wish the
oven to switch off at.
oUse either the oven thermostat knob or grill thermostat knob to
set the temperature that you require.
oPress the program button (6) for two seconds and the display
will show the minute minder symbol (4). Press the program
button again so the automatic cooking symbol (1) flashes. Press
the program button again so the word “END” appears on the
timer display.
oSet the time of day you wish the cooking function to switch off
at using the minus (5) and plus (7) buttons. The maximum
time available is 10 hours later.
oOnce the display has got to the time of day that you want the
oven to stop cooking at, let go of the minus and plus buttons.
The countdown will start immediately and the automatic cooking
symbol (1) and oven in use symbol (2) will appear on the
display.
oWhen the time is set, it can be modified by pressing the minus
and plus buttons.
oWhen the time of day reaches the end of cooking time that you
set, the oven will switch off and an alarm will sound.
oTo silence the audible signal and return the oven to manual
operation mode, you should press the program button.
oImportant: If you do not turn the relevant thermostat control
knob to the off position, then the appliance will continue to
operate as soon as you press the program button.

15
Setting the start and end time function
This function will allow you to set a time in the future that the
oven switches on at and a time that the oven will switch off at.
oUse either the oven thermostat knob or grill thermostat knob to
set the temperature that you require.
oIt is then possible to set the length of cooking time that you
require.
oPress the program button (6) for two seconds and the display
will show a value of 00:00. Set the period of time that you wish
the oven to be operating for, using the minus (5) and plus (7)
buttons.
oOnce the display has got to your desired countdown time, let go
of the minus and plus buttons.
oPress the program button (6) for two seconds and the display
will show the minute minder symbol (4). Press the program
button again so the automatic cooking symbol (1) flashes. Press
the program button again so the word “END” appears on the
timer display.
oSet the time of day you wish the cooking function to switch off
at using the minus (5) and plus (7) buttons. The maximum
time available is 10 hours later.
oOnce the display has got to the time of day that you want the
oven to stop cooking at, let go of the minus and plus buttons.
oThe oven will calculate what time it needs to switch on at, so
that your food will cook for the length of time that you selected.
It will automatically switch itself on, once it reaches the time of
day that it has calculated.
oWhen the time of day reaches the end of cooking time that you
set, the oven will switch off and an alarm will sound. The alarm
can be silenced by pressing any timer button or will turn off
automatically after 7 minutes.
oYou will need to return the oven to manual operation mode, once
the start and end time function has been used. To do this you
should press the program button (6).

16
oImportant: If you do not turn the thermostat control knob and
oven function selector knob to zero. Then the appliance will
continue to operate as soon as you press the manual operation
button.
Cancelling a timer function
oTo delete a semi-automatic or automatic cooking program, press
the plus (7) and minus (5) buttons together for two seconds.
The automatic cooking symbol (1) will disappear from the timer
display.
Cancelling the minute minder function
oTo delete the countdown of the minute minder, press the
program button (6) for about two seconds. Then press the plus
(7) and minus (5) buttons together so the minute minder
symbol (4) disappears from the timer display.
Adjusting the audible signal and time of day
There are 3 levels of audible signal available; to adjust it you should
do the following:
oWhen the time of day is shown on the timer display, press the
plus (7) and minus (5) buttons together for approximately two
seconds.
oTo change the time of day you can continue using the plus or
minus buttons.
oTo adjust the audible signal sound level, press the program
button (6). Use the minus button (5) to select a sound level.

17
Steam oven cooking function
This cooking function uses steam to cook the food. During steam
cooking, the steam flows from the boiler into the oven cavity. The
steam heats the oven cavity and cooks the food.
This type of cooking is ideal for cooking any type of vegetables and
fish, preserving the colour, taste and goodness of the food.
IMPORTANT: This process MUST be followed when you are using the
steam oven cooking function.
oFill the water jug with distilled water, or if this is unavailable cold
drinking water. IMPORTANT: You may get scale building up in
the steam boiler if you use tap water.
oFill the water jug up to the 1.2 l mark. DO NOT fill the jug right
to the top. Otherwise the water that is pumped back into the jug
at the end of a cooking cycle may overflow.
oInsert the water jug into the water jug compartment.
oPush the water jug down completely, this ensures a perfect seal
between the tube located in the jug and the hydraulic circuit
inside of the oven.
oALWAYS ensure that the inox baking tray is inserted underneath
the perforated deep tray. This will catch any condensation, juice
or food that falls from the perforated deep tray.
oTurn the oven thermostat knob to the temperature that you
require.
oThe oven operating light will switch on to confirm that the oven
is heating. When you finish cooking and switch the oven
thermostat knob to the off position, the oven operating light will
switch off.
oThe oven operating light should be green in colour. If it turns
red, then there is a problem with the operation of the oven (see
the error code table on page 28).
oAfter cooking is completed, turn the oven thermostat knob to the
off position.
oWhen the oven cavity is sufficiently cooled, you should use a soft
cloth to dry any liquid that remains in the oven cavity.

18
oIMPORTANT: The water jug should be emptied after cooking.
Grill cooking function
This cooking function uses the upper heating element to cook the food.
This type of cooking is ideal for grilling medium to large portions of
sausages, bacon, steaks etc.
oIf you are using the grill function, whilst this doesn’t involve
steam, you can leave the water jug inside of the water jug
compartment. It will not affect the cooking abilities of the oven.
oTurn the grill thermostat knob to the temperature that you
require.
oThe grill operating light will switch on to confirm that the grill is
in use. When you finish cooking and switch the grill thermostat
knob to the off position, the grill operating light will switch off.
Cooking guidelines
oPlease refer to the information given on food packaging for
guidance on cooking temperatures and times. Once familiar with
the performance of your appliance, temperatures and times can
be varied to suit personal preference.
oMake sure that frozen foods are thoroughly thawed before
cooking, unless the instructions on the food packaging advise
that you can “cook from frozen”.
oYou should pre-heat the oven and not place food inside of it until
the pre-heating period is over.
oBefore cooking, check that any unused accessories are removed
from the oven.
oTry to open the door as little as possible to view the dishes.

19
Warnings
oKeep the oven door closed when using any cooking function.
oDo not use aluminium foil to cover the trays supplied with the
oven.
oYou should also never line the base of your oven with aluminium
foil.
oDuring cooking, never place pans or cookware directly onto the
bottom of your oven. They should always be placed on the
shelves provided.
oImportant: Be careful when opening the door, to avoid contact
with hot parts and steam.
oThe inox baking tray handle should only be used to reposition
the baking tray and NOT for removing it from the oven cavity.
When removing the baking tray, you should ALWAYS use an
oven glove.
oThe baking tray handle should not be left in position when the
appliance is switched on.
Accessories
The accessories supplied with the oven, allow you to get the optimum
performance from your appliance on the various cooking modes that
are available.
oThe drip pan and shelf accessories
can be placed on various levels by
positioning them in the side racks
located inside of the oven.
oThis allows you to select the most suitable level for cooking,
depending on what you are cooking and what cooking mode you
are using.

20
oThe inox baking tray has raised edges, which can be used as a
support surface for any single level cooking container.
oIt can also be used as a drip tray, for collecting cooking juices or
fat that may be generated during the steam cooking function.
oThe shelf should be used as a support surface; it should normally
be placed in positions 2, 3 or 4.
Cooking charts
The cooking times below are intended as a guide only; you must
adjust them depending on your own personal preferences and the size
of the dishes that you are cooking.
Fish recipes
DISH Oven cavity
temperature
°C
Cooking
time Cooking function
Mussels and clams MAX. 30 minutes Steam
Scorpion fish fillet 80 30 minutes Steam
Prawns and flat
lobster MAX. 30 minutes Steam
Trout MAX. 35 minutes Steam
Vegetables recipes
DISH Oven cavity
temperature
°C
Cooking
time Cooking function
Asparagus MAX. 35 minutes Steam
Broccoli MAX. 30 minutes Steam
Carrots MAX. 35 minutes Steam
Brussel Sprouts MAX. 35 minutes Steam
Cauliflower MAX. 40 minutes Steam
