Bayside Furnishings CORC-8B User manual

Bayside Furnishings
®
Factory No. 16187
Page 1
Date 2015-08-10Rev. 1 Factory: YIZHUA
E
Mesh Chair - Black
ITM. / ART. 189338
Model # CORC-8B
ASSEMBLY INSTRUCTIONS
IMPORTANT, RETAIN FOR FUTURE REFERENCE:
READ CAREFULLY
If you have any questions regarding assembly or if parts are missing, DO NOT return this item to the store
where it was purchased. Please call our toll-free customer service number and have your instructions and parts
list ready to provide the model name, part name or factory number:
1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In US, Canada, and Mexico only)
Or visit our website www.baysidefurnishings.com
Or e-mail your request to [e-mail]
LOT NUMBER:
DATE PURCHASED: / /

ITM. / ART. 189338
Bayside Furnishings
®
Page 2
E
INFORMATION FOR USE
1. This is the type C office chair for commercial or home use. Please use it only on smooth, even
flooring.
2. The height of the seat can be raised up and down by adjusting the right side handle of the
mechanism. The back can tilt after you pull the side handle all the way out.
3. Please check all bolts, screws and knobs are tight at least every 3 months or as needed.
4. If parts are missing, broken, damaged or worn, please stop using this product until repairs are
done by a trained person.
5. Only a trained person may replace or repair seat height adjustment components.
Choking hazard – It contains small parts. Keep all hardware out of reach of children!
Do not stand on this chair, do not use chair as a stepladder.
Use this product only for seating one person at one time.
Do not use this chair unless all bolts, screws and knobs are securely tightened.
Dispose of packing material properly. Do not use plastic cover as head covering. It may cause
suffocation.
Use this chair for its intended purpose only.
Use mild detergent only for cleaning.
Failure to follow these warnings could result in serious injury.
Maximum load weight on chair is 136.1 kg /300 lb.
This unit is intended for use only within the maximum weights
indicated. Use with load than the maximum weights indicated may result in instability,
causing possible injury.
Please read the Assembly Instructions prior to assembling this product.
This product contains small parts, which are for adult assembly only. Keep small children away when
assembling.
To avoid damage, assemble the product on a non-abrasive surface such as a carpet surface.
Please make sure you have all parts before beginning assembly. Please wait until all steps are
completed before tightening bolts. We recommend using two people for assembly.

ITM. / ART. 189338
Bayside Furnishings
®
Page 3
E
Parts and Hardware List
PART # PART DESCRIPTION PART FIGURE QUANTITY
A Back Assembly 1
B Seat 1
C Mechanism 1
D Gas Lift with Telescoping
Cover 1
E 5 Star Base 1
F Caster 5
AA Bolt 4+1 extra
BB Bolt 4+1 extra
Allen Wrench 1
Tools required: Allen wrench (included).

ITM. / ART. 189338
Bayside Furnishings
®
Page 4
E
Assembly Instructions
1. Place 5 Star Base (E) upside down
and press the Casters (F) into the
holes at the end of each leg.
2. Turn the Star Base (E) upright and
insert the thick end of the Gas Lift
(D) into the center hole of Star Base.
Make sure the Telescoping Cover is
over the Gas Lift (D) and rests on the
Base (E).
3. Place the Seat (B) upside down onto
the carton with the threaded holes
facing up. Align and attach the
Mechanism (C) to the Seat (B) using
4 Bolts (AA). Tighten the bolts with
the enclosed Allen wrench.
NOTE: Place a protective cover (like
the bubble wrap packing material)
over the carton to prevent from
scratching the chair material.

ITM. / ART. 189338
Bayside Furnishings
®
Page 5
E
Assembly Instructions
4. Pick up the Back Assembly (A) and
fit the back support under the
Mechanism (C) properly. Insert 4
Bolts (BB) through the mounting
holes on the Mechanism (C) and
securely screw into the threaded
holes on the Back Assembly (A),
using the enclosed Allen wrench.
5. Turn the assembled seat upright and
locate the centre hole of Mechanism
(C) over the Gas Lift (D). Press
down firmly until the seat locks in
place.

ITM. / ART. 189338
Bayside Furnishings
®
Page 6
E
OPERATING INSTRUCTIONS
1. To adjust seat height:
While seated, lean forward and reach under the right side of the chair to find the handle. Lift the handle
and raise your body up slightly to allow the chair to rise to the desired height. To lower the seat, lift the
handle while applying more weight downward on the seat. The chair will descend until the handle is
released or the chair reaches the bottom position.
2. To operate tilt lockout:
While seated, reach under the right side of the chair to find the height adjustment handle. Pull the handle
all the way out (away from the gas lift) to allow the chair to tilt backwards. To lock the chair in the upright
or vertical position, sit upright and push the handle in towards the gas lift.
3. To adjust tension on the tilt:
Reach under the front center of the chair, grasp the round knob and turn it counter-clockwise to stiffen the
tilt mechanism. Turn the knob clockwise to loosen the tilt mechanism. Turn the knob until the desired
resistance is reached.
4. To adjust height of the armrest:
Press the buttons on the armrests to allow the armrests to move up or down freely. Release the buttons
once the desired height is reached.

ITM. / ART. 189338
Bayside Furnishings
®
Page 7
E
QUALITY GUARANTEE
We are confident that you will be delighted with your Bayside Furnishings®purchase.
Should this product be defective in workmanship or materials or fail under normal use, we will repair
or replace it for up to one (1) year from date of purchase. Every Bayside Furnishings®product is
designed to meet your highest expectations. We guarantee that you will immediately see the value of
our fine furniture.
This warranty gives you specific legal rights and you may also have other rights which vary from State
to State.
AUSTRALIA: Our goods come with guarantees that cannot be excluded under the Australian
Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation
for any other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
Customer Service: 1-877-494-2536 (English, French and Spanish)
Pacific Standard Time: 8:30 a.m. - 4:30 p.m., Monday to Friday
(In US, Canada, and Mexico only)
www.baysidefurnishings.com
MADE IN CHINA / FABRIQUÉ EN CHINE / HECHO EN CHINA
Retailer: Costco Wholesale UK Ltd,
UK Home Office, Hartspring Lane, Watford, Herts WD25 8JS
United Kingdom
01923 213113
Model: CORC-8
