stable comfort StableWall System User manual

1
T H E L E A D E R I N A N I M A L C O M F O R T
LASTING COMFORT FOR LASTING HEALTH
STABLEWALL INSTALLATION GUIDE
This guide is to inform the installer on the proper installation of the
Stable Comfort: StableWall System. This system is simple to install
and offers top line comfort for the horses that will be enjoying this
system.

2
T H E L E A D E R I N A N I M A L C O M F O R T
LASTING COMFORT FOR LASTING HEALTH

3
T H E L E A D E R I N A N I M A L C O M F O R T
LASTING COMFORT FOR LASTING HEALTH
Clear the stall of any debris, including sharp edges,
dirt & organic materials.
Remove any obstacles from the wall such as feeders.
Measure the height of the wall of the stable and
record the number.
Measure the length of the stall and record it as well.
2.
Mark the height of the cover PLUS 6” (15cm) to
add leeway for the foam. Do this on both vertical
ends also.
3.
Use a chalk line to connect the marks made in Step
3.
4.
Step-By-Step Installation Instructions:
1.

4
T H E L E A D E R I N A N I M A L C O M F O R T
LASTING COMFORT FOR LASTING HEALTH
Cut the cover along the chalk-line.
5.
Pre-drill the plastic strips every 6” (15cm) as this
will make it easier to install the strips. Drill the
holes in the following pattern:
Measure the length of the wall, then cut the
plastic strip. This is best done by scoring one side
of the strip with a knife, then snap the strip
backwards.
6.
Place the cover against the wall and have a
helper hold it in place.
Hold it so that there is 6” (15cm) of extra material
on each side.
Anchor the bottom of the cover to the wall with
screws and the plastic strip.
7.
Using adhesive, tack the first layer of foam to the
wall (3/4”(2cm)-1 layer of foam, 1.5”(4cm)-2 layers
of foam). If you are installing the double layer,
stagger the foam pieces so the seams are not in top
of each other.
You may also use temporary screws with large
washers to tack Stable Wall pads to the wall. These
fasteners MUST be removed prior to Step 9, as
they may PUNCTURE the top cover. Damage from
these fasteners is NOT covered by Stable Wall
warranty.
8.

5
T H E L E A D E R I N A N I M A L C O M F O R T
LASTING COMFORT FOR LASTING HEALTH
Once your foam is in place, pull your top cover up
and over the foam. Using an EZ-Grip or vise grips,
pull tightly upwards, having a helper follow behind
installing the top plastic strip using the appropriate
fasteners. Make sure the cover is being pulled as
tightly as possible. The cover’s tightness will
ensure longevity of the product.
9.
10.
11.
To promote the waterproof characteristic of
StableWall, it is recommended that a bead of
caulking be added along the edge of the plastic
strip.
Repeat the Steps 1-9 for each wall. Once your top
strip is attached, install the vertical side strips by
fastening them tightly.
12.
Remove the excess top cover around the top of
the stall by using a sharp knife and cutting along
the top of the plastic strip.

6
T H E L E A D E R I N A N I M A L C O M F O R T
LASTING COMFORT FOR LASTING HEALTH
Any feeders or other wall features may be
installed over the Stable Wall.
Clean the stall area up. The system is now ready
to use!
12.
13.
