BCP SKY2856 User manual

SKY2856 + 2857 + 2858
Ver. 4
INSTRUCTION
MANUAL
12V Ride-On Truck
with Remote

Please retain these instructions for future reference.
SAFETY
BATTERY WARNINGS
Pg. 2
This vehicle must be assembled by an adult who has read and understood the instructions in this manual.
Keep the packaging and bags away from children and dispose of all packaging before use. Always use
common sense and safe practices when operating this vehicle. This product contains or emits chemicals
known in the state of California to cause cancer or birth defects or other reproductive harm.
NOTE: For best performance, only use this vehicle on flat and hard surfaces.
Age Range: 3 to 9 years old
Weight Capacity: 65 lbs.
The following safety hazards may result in serious injury or death:
• This product contains small parts. Keep children away during assembly. Make sure to remove all
packaging material and parts from underneath the vehicle body.
•Never open the battery. Batteries contain lead and lead compounds (acids) that are toxic and corrosive,
and known to the state of California to cause cancer and reproductive harm.
•Limbs, hair, and clothing can get caught in moving parts. Always wear shoes, keep limbs away from
moving parts, and do not wear loose clothing while operating this vehicle.
•This vehicle does not have brakes or braking capability. Do not leave a child unattended during
operation. Do not use this in a location that may require braking capability, as this could result in loss of
control, which may cause serious injury or death.
•Use of this vehicle near streets, motor vehicles, steps, bodies of water, sloped surfaces, hills, wet areas,
flammable vapors, in alleys, at night, or in the dark could result in an unexpected accident.
•Use of this vehicle in unsafe conditions such as snow, rain, loose dirt, mud, sand, or gravel may result in
an unexpected accident such as tipping over, and could damage the electrical system or battery.
•Do not operate this vehicle in an unsafe manner. Examples include but are not limited to:
- Pulling the vehicle with another vehicle or similar device
- Allowing more than one rider
- Pushing the user
- Traveling at an unsafe speed
The following safety hazards may result in serious injury or death:
•Use of a battery or charger other than the supplied 12V rechargeable battery and charger may cause a
fire or explosion. Only use the supplied battery and charger.
•Use of the 12V rechargeable battery and charger for any other product may result in overheating, fire, or
explosion. Never use the supplied rechargeable battery and charger with another product.
•Explosive gases are created during charging. Charge the battery in a well-ventilated area. Do not charge
the battery near heat or flammable materials.
•Contact between the positive and negative terminals may result in fire or explosion. Avoid direct contact
between the terminals. Picking up the battery by the wires or charger can cause damage to the battery
and may result in a fire. Always pick up the battery by its case or handles.
•Liquids on the battery may cause fire or electric shock. Always keep all liquids away from the battery and
keep the battery dry. Contact or exposure to battery leakage (lead acid) may cause serious injury. If
contact or exposure occurs immediately call your physician. If the chemical is on the skin or in the eyes,
flush with cool water for 15 minutes. If the chemical was swallowed, immediately give the person water or
milk. Do not give water or milk if the patient is vomiting or has a decreased level of alertness. Do not
induce vomiting.
•Battery posts, terminals, and related accessories contain lead and lead compounds (acid) – chemicals
known to the State of California to cause cancer, reproductive harm, and are toxic and corrosive. Never
open the battery.
•Tampering or modifying the electric circuit system may cause a shock, fire or explosion and permanently
damage the system. Exposed wiring and circuitry in the charger may cause electric shock. Always keep
the charger housing closed.

USER WARNINGS
SPECIFICATIONS
Pg. 3
The following safety hazards may result in serious injury or death:
•Never leave a child unattended.
•Always sit in the seat when using this vehicle.
•Keep your hands, hair, and clothes away from moving parts.
•Always wear shoes when operating this vehicle.
•Only one rider is allowed on the vehicle at a time.
•Children under 3 years of age cannot use the vehicle.
•Only drive on level ground.
•Do not go near swimming pools or other bodies of water, drop-os, or up and down steep inclines.
•Do not drive the vehicle into loose dirt, mud, sand, fine gravel, or on wet surfaces.
•Do not drive the vehicle on streets or near cars.
Overall Dimensions
Weight
Weight Capacity
Age Range
Max Speed
Charging Time
Run Time
Battery Type
Electric Motor
Charger
Materials
45”(L) x 31”(H) x 31”(H)
45 lbs.
65 lbs.
3 – 8 years old
3.75 mph.
8 – 12 hours
Initial Charge Time 12 hours
1 – 2 hours
12V 7AH, Recoverable fuse: 15A
Double drive
Input: 120v | Output: DC12v 1000MA
PP plastic, metal

Pg. 4
65 LBS
CAPACITY
LBS
APPROXIMATELY
1 HR.
ASSEMBLY
1 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER
SMALL
WRENCH
NEEDLE NOSE
PLIERS
TOOLS REQUIRED
PARTS
HARDWARE
1
12 PCS
4 x 10mm 3 x 12mm 10 x 20x 2mm 12 x 22x 2mm 2.5 x 16mm
2
2 PCS
3
2 PCS
4
6 PCS
5
5 PCS
A
D
BC
1 PC
4 PCS
2 PCS 2 PCS
REAR AXLE
E
2 PC
FRAME F
1 PC
BAR LIGHT
REAR WHEEL FRONT WHEEL
HUB CAP

Pg. 5
PARTS
G
J
H I
1 PC
1 PC
1 PC 2 PCS
HOOK
SEAT K
1 PC
FRONT AXLE L
1 PC
STEERING WHEEL
WINDSHIELD SIDE MIRROR
N
1 PC
REMOTE CONTROL O
1 PC
CHARGER
M
2 PCS
FRONT REFLECTOR
P S

Pg. 6
2
1
PRODUCT ASSEMBLY
Flip the vehicle over and lay it on a level surface. Slide out the part A rear axle from underneath the vehicle.
FRONT REAR
A
A
A
Remove the nut and bolt from the stabilizer near the rear gear box. Slide the part A rear axle through the
gear box, metal stabilizer, and shocks. Repeat this on the other side to slide the axle through both gear
boxes. Once the rear axle is in place, replace the nuts and bolts on the stabilizers to secure the axle.

3
Slide on a part B rear wheel and secure it with a part 4 large washer
and part 5 pin. Use needle nose pliers to bend the pin and lock the wheel
in place. Repeat on the other side. Snap a part D hub cap onto each wheel.
K
D
D
4
5
BB
1 1
Pg. 7
TOOLS REQUIREDPRODUCT ASSEMBLY
4
5
4
Slide the part K front axle into the steering column. Secure the axle with a part 3 small washer and part
5 pin. Note: an extra washer is included for adjustment.
Place the front axle into the designated slots, and secure it with eight part 1 screws, four on each side.
3
5

Pg. 8
TOOLS REQUIREDPRODUCT ASSEMBLY
6
5
Insert the two part E frame pieces
into the designated holes on the rear
of the vehicle.
D
E
D
45
C C
54
Slide on a part 4 large washer, part C front wheel,
another part 4 large washer, and secure it with a part 5 pin.
Use needle nose pliers to bend the pin and lock the wheel in
place. Repeat on the other side. Snap a part D hub cap onto
each wheel.
4

Pg. 9
7
8
Secure the part G hook to the rear
of the vehicle with two part 1 screws.
Slide the part F bar light into the
holes located on the frame pieces
and secure it with two part 2 screws.
TOOLS REQUIREDPRODUCT ASSEMBLY
G
1
2
2
F

Pg. 10
9
10
TOOLS REQUIREDPRODUCT ASSEMBLY
L
Join the connector from the part L steering wheel to the connector from the steering mount, then snap
the steering wheel into place.
Snap on the part H windshield.
H

Pg. 11
11
12
TOOLS REQUIREDPRODUCT ASSEMBLY
I
J
I
Snap on part I side mirrors.
Attach the part J seat with two
part 1 screws.
1

14
Slide the two part M front reflectors onto the front of the vehicle and they will snap in place.
Under the hood, connect the red wire to the red terminal on the battery
M
Pg. 12
13
TOOLS REQUIREDPRODUCT ASSEMBLY
SPEAKER
BATTERY
CONTROL
MODULE
STEERING
SHAFT

DASHBOARD DIAGRAM
PEDAL
LIGHT SWITCH
BATTERY CHARGING
SOCKET
POWER SWITCH
REVERSE: DRIVE IN REVERSE
PARK: PARK VEHICLE
(PEDAL IS DISABLED)
FORWARD: DRIVE FORWARD
Push down on the pedal to drive forward/reverse. Release the pedal to slow down and stop.
Pg. 13
TF
(MICROSD)
PORT
MP3 FUNCTIONS
• USB port: play music from a USB drive
• AUX input: plug in a music player to play music
• TF (MicroSD) port: play music from a MicroSD card
• : play/pause music
• : short press to play to the next song, long press to increase volume
• : short press to play the previous song, long press to decrease volume
• MODE: press to toggle between USB, MicroSD, FM radio, and AUX input
• FM Radio: press the to automatically seek a radio station. Press the to seek the next radio
station. Press the to return to the previous radio station
USB PORT
AUX INPUT
PREVIOUS/VOLUME –
PLAY/PAUSE
NEXT/VOLUME +
MODE

FREQUENCY KEY
TURN LEFT
TURN RIGHT
EMERGENCY
BRAKE
REVERSE
FORWARD
SPEED
HIGH-SPEED LED
MEDIUM-SPEED LED
LOW-SPEED LED
P S
TOOLS REQUIREDREMOTE CONTROL FUNCTIONS
•Insert 2 AAA batteries into the remote control
•After 10 seconds of non-operation, the indicator light will turn o and the remote will go into
power-saving mode.
Linking the remote control:
1. Press and hold the frequency key for 2 to 4 seconds. The low speed LED lights will flash.
2. Turn the vehicle on. The low speed LED lights will stop flashing and remain on to indicate a
successful link.
3. If the low speed LED lights continue to flash (indicating an unsuccessful link), remove the battery on the
remote and repeat steps 1 and 2.
Pg. 14
TROUBLESHOOTING
Reason
Low battery
Electrical protection
Switch not in the correct position
Battery connectors disconnected
Low battery
Overloaded vehicle
Uneven or sloped road
Loose connection to motor
Steering wheel is not properly
connected
Battery connectors disconnected
Charger not connected to socket
or outlet
Battery does not have a full charge
Normal
Problem
Battery is warm and
makes a slight noise while
charging
Slow speed
Vehicles shakes while
driving
Vehicle is silent
Battery does not last
Battery does not recharge
Vehicle does not move
Solution
Fully charge the battery
Stop use for several minutes and restart
Completely press in switches
Plug in battery connectors
Fully charge the battery
Reduce the weight on the vehicle
Drive on flat pavement
Ensure the motor is properly connected to
the battery
Properly connect the steering wheel
connector
Plug in battery connectors
Completely plug in the charger
Fully charge the battery
Normal

CHARGING INSTRUCTIONS AND WARNINGS
Pg. 15
CARING FOR YOUR RIDE-ON
•Charging socket is located under the dashboard on the left side. Insert one end of the part O charger into the
charging socket and plug the other end into a wall outlet (see Dashboard Diagram).
•Charge the battery at least 12 hours before initial use.
•On average, you will need to charge the battery between 8 and 12 hours. Do not charge the battery for more
than 20 hours. Failure to charge the battery as directed could cause permanent damage to the battery and
void the warranty.
•Damage to the battery may occur if it is allowed to drain completely. Do not allow the battery to drain
completely.
•Check the battery and charger (supply cord, connector) for wear and damage before charging.
•Do not charge the battery if damage has occurred.
•Only an adult who has read and understood the safety warnings should handle, charge and recharge the
battery.
•Park the vehicle indoors or cover it with a tarp to protect it from wet weather.
•Do not leave the vehicle in the sun for long periods of time or fading may occur. Store in shade or cover
with tarp.
•Do not wash the vehicle with a hose.
•Do not wash the vehicle with soap.

ASSEMBLY IS COMPLETE!
All items can be returned for any reason within 60 days of the receipt and will receive a full refund as long as the
item is returned in its original product packaging and all accessories from its original shipment are included. All
returned items will receive a full refund back to the original payment method. All returned items will not be charged
a re-stocking fee.
All returned items require an RA (Return Authorization) number, which can only be provided by a Best Choice
Products Customer Service Representative when the return request is submitted. Items received without an RA
may not be accepted or may increase your return processing time. Once an item has been received by Best Choice
Products, refunds or replacements will be processed within 5 business days.
All returns must be shipped back to the Best Choice Products Return Center at the customer’s expense. If the
reason for return is a result of an error by Best Choice Products then Best Choice Products will provide a pre-paid
shipping label via email. Boxes for return shipping will not be provided by Best Choice Products, and is the
customer’s responsibility to either use the original shipping boxes or purchase new boxes.
Pictures may be required for some returns to ensure an item is not damaged prior to its return. Items returned are
not considered undamaged until they are received by Best Choice Products and verified as such. All damages to
items are the customer’s responsibility until the item has been received by and acknowledge by Best Choice
Products as undamaged.
CONTACT US; WE’RE HERE 7 DAYS A WEEK TO HELP YOU!
WARNING
Manufacturer and seller expressly disclaim any and all liability for personal injury, property damage or
loss, whether direct, indirect, or incidental, resulting from the incorrect attachment, improper use,
inadequate maintenance, or neglect of this product.
PRODUCT WARRANTY INFORMATION
bestchoiceproducts.com customerservice@
bestchoiceproducts.com 844.948.8400 LEARN MORE!
