BCP SKY5969 User manual

SKY5969 + SKY6009 + SKY6346Ver. 3
Kitchen Playset
INSTRUCTION
MANUAL

•This product requires adult assembly and supervision when in use.
•This product is intended for indoor use only.
•Do not stand on or use any part of this item as a step ladder.
•Firmly secure all bolts, screws and knobs before use.
•Reconfirm that all bolts, screws, and knobs are secure every 90 days.
•Do not use or store this item in the proximity of open flame or flammable/combustible chemicals.
•If any parts are missing, broken, damaged, or worn, stop using this item until repairs are made and/or
factory replacement parts are installed.
•Do not use this item in a way inconsistent with the manufacturer’s instructions as this could void the
product warranty.
•This product contains small parts. May result in choking hazard for children under 3 years.
•To wipe down item, use a damp cloth. Then, wipe it down once more with a dry cloth.
AGE RANGE: 3 years old and up
HARDWARE
A
28 PCS
SCREW DOWEL
B
38 PCS
SCREW
C
21 PCS
SCREW
D
50 PCS
TOOLS REQUIRED
UP TO 60 MIN.
ASSEMBLY
1 PERSON
ASSEMBLY
PHILLIPS
SCREWDRIVER
HAMMER
(OPTIONAL)
DRILL
(OPTIONAL)
Please retain these instructions for future reference.
2|
NOTICE

| 3
HARDWARE
M
2 PCS
TAPS RIGHT HINGE
PEG
N
5 PCS
SINK
O
1 PC
WALL NAIL
P
1 PC
Q
1 PC
WALL
ANCHOR
WALL
WASHER
R
1 PC
DISK
WASHER
S
7 PCS
OVEN
HANDLE
T
1 PC
U
2 PCS
HANDLE
HOLDER
PHONE
RECEIVER
V
1 PC
PHONE
W
1 PC
Y
2 PCS
BURNERS RIGHT
HOLDING PEG
Z1
1 PC
LEFT
HOLDING PEG
Z2
1 PC
SUPPORTS
X
3 PCS
E
3 PCS
SCREW SCREW
F
22 PCS
MICROWAVE
HANDLE
G
1 PC
LEFT HINGE
PEG
H
5 PCS
I
4 PCS
HANDLE DOOR CATCH
J
5 PCS
DOOR INSERT
K
5 PCS
FAUCET
L
1 PC

4|
PARTS
1
1 PC
PANTRY LEFT 2
1 PC
PANTRY
DIVIDER
3
1 PC
PANTRY RIGHT 4
1 PC
PANTRY BACK
17
1 PC
OVEN DOOR 18
1 PC
OVEN BACK
PANEL
19
1 PC
SINK BACK
PANEL
20
1 PC
PANTRY DOOR
13
1 PC
SKIRT 14
1 PC
MICROWAVE 15
1 PC
SINK/OVEN
DIVIDER
16
1 PC
SINK
CUPBOARD
9
1 PC
COUNTER
PANEL
10
1 PC
UPPER SHELF
BACK
11
1 PC
MIDDLE SHELF
BACK
12
1 PC
BASE
5
1 PC
UPPER SHELF 6
1 PC
SHELF DIVIDER 7
1 PC
LOWER SHELF 8
1 PC
COUNTERTOP

| 5
PARTS
21
1 PC
REFRIGERATOR
DOOR
22
1 PC
OVEN SIDE
PANEL
23
1 PC
PANTRY TOP 24
1 PC
ICE DISPENSER
25
1 PC
SAUCE PAN 26
1 PC
DUTCH OVEN 27
1 SET
UTENSILS 28
4 PCS
ICE CUBE

16
H
I
K
Dx4
Fx2
BEFORE ASSEMBLY
2
1Insert two part B dowels into the part 5
upper shelf.
Insert four part B dowels into the part 6
shelf divider.
4
3Attach one part I handle to the part 16
sink cupboard door with two part
F screws.
Attach one part K door insert and one
part H hinge peg with four part D
screws, two screws each.
Insert four part B dowels into the part
8 countertop.
Attach two part M taps and one part L
faucet with three part E screws, one
screw each.
Attach two part Y burners with eight
part F screws.
6|
Bx2
5
Bx4
6
Bx4
Fx8
Ex3
Yx2
Mx2
L
8

| 7
6
5Insert four part B dowels into the
part 12 base.
Attach three part X supports to the part
11 middle shelf back with three part
C screws.
8
7Attach one part I handle to the part 17
oven door with two part F screws.
Attach one part K door insert and one
part N hinge peg with four part D
screws, two screws each.
Insert four part B dowels into the part 7
lower shelf.
12
BEFORE ASSEMBLY
Bx4
11
Xx3
Cx3
K
I
N
D
x4
Fx2
17
7
Bx4

8|
10
9Insert two part B dowels into the part 9
counter panel.
Attach one part Z2 left holding peg and
one part Z1 right holding peg with four
part D screws, two screws each.
Insert two part B dowels into the part 13 skirt.
12
11 Insert four part B dowels into the part 2
pantry divider.
Insert two part B dowels into the part 22
oven side panel.
Attach two part U handle holders with
two part F screws.
Place the part T oven handle between
the two handle holders.
BEFORE ASSEMBLY
Bx2
Z1
Z2
Dx4
9
13
Bx2
Bx4
2
22
B
x2
Fx2
Ux2
T

| 9
14
13 Attach one part G microwave handle to
the part 14 microwave door with two
part F screws.
Attach one part K door insert and one
part N hinge peg with four part D
screws, two screws each.
Insert four part B dowels into the part 3
pantry right.
Attach the part V phone receiver with
two part F screws.
16
15 Insert two part B dowels into the part 1
pantry left.
Insert four part B dowels into the part 15
sink/oven divider.
BEFORE ASSEMBLY
Dx4
K
G
N
Fx2
Fx2
3
Bx4
V
Bx2
1
14
Bx4
15

10 |
18
17 Attach one part I handle to the part 20
pantry door with two part F screws.
Attach one part K door insert and one
part H hinge peg with four part D
screws, two screws each.
Attach one part I handle to the part 21
refrigerator door with two part F screws.
Attach one part K door insert and one
part H hinge peg with four part D
screws, two screws each.
You have completed the pre-assembly.
2
1Attach the part 13 skirt to the part 12
base with two part A screws.
Attach the part 3 pantry right to the
base with two screws.
BEFORE ASSEMBLY
PRODUCT ASSEMBLY
13
12
Ax2
I20
H
K
Fx2
Dx4 I
H
K
Dx4
21
Fx2
Ax2
12
3

| 11
PRODUCT ASSEMBLY
4
3Locate the part 2 pantry divider and
insert it into the part 3 pantry right.
Attach the part 1 part pantry left with
two part A screws and secure the
divider with four part A screws.
Attach the part 15 sink/oven divider to
the base with one part A screws.
6
5Attach the part 8 countertop to the part
15 divider with one part A screw.
Secure the countertop to the part 3
pantry right with two part A screws.
Attach the part 15 counter panel to
the countertop.
Attach the part 5 upper shelf to the part
6 shelf divider with one part A screw.
Attach the part 7 lower shelf to the part
6 shelf divider with one part A screw.
12
3
Ax6
12
15
A
Ax3
9
8
15 7
6
5
Ax2

12 |
PRODUCT ASSEMBLY
7Insert the part 4 pantry back between the pantry sides.
Attach the shelf assembly to the part 3 pantry right and secure with two part A screws.
8Attach the part 23 pantry top to the pantry sides with four part A screws.
Attach the part 22 oven side and secure with six part A screws.
7
4
5
3
Ax2
Ax10
7
5
8
12
13
3
1
22
23

| 13
PRODUCT ASSEMBLY
10 Attach two part J door catches to the part 3 pantry right with four part D screws.
Attach two part J door catches to the part 15 divider with four part D screws.
Attach one part J door catch to the part 6 shelf divider with two part D screws.
19
18
C
x18
Sx7
10
11
9Secure the part 10, 11, 18, and 19 back panels with eighteen part C screws and seven part S disk washers.
x10
Dx5
J
6
3
15

14 |
PRODUCT ASSEMBLY
12 Attach the part 24 ice dispenser to the part 21 refrigerator door with six part D screws.
11 Insert the hinge peg on the part 20 pantry door into the opening on the part 23 pantry top.
Insert one part N hinge peg into the opening on the part 2 pantry divider, and secure to the
pantry door with two part D screws.
21
24
D
x6
23
2
N20
Dx2

| 15
PRODUCT ASSEMBLY
13 Insert the hinge peg on the part 21 refrigerator door into the opening on the part 2 pantry divider.
Insert one part N hinge peg into the opening on the base and secure to the pantry door with two
part D screws.
12
N
Dx2
21

16 |
PRODUCT ASSEMBLY
14 Insert the hinge peg on the part 16 sink cupboard door into the opening on the part 9 counter panel.
Insert one part N hinge peg into the opening on the part 12 base, and secure to the part 16
cupboard door with two part D screws.
9
N
Dx2
16

PRODUCT ASSEMBLY
15 Insert the hinge peg on the part 17 oven door into the opening on the part 9 counter panel.
Insert one part H hinge peg into the opening on the part 12 base, and secure to the part 17 oven
door with two part D screws.
H
Dx2
17
| 17

PRODUCT ASSEMBLY
16 Insert the hinge peg on the part 14 microwave door into the opening on the part 5 upper shelf.
Insert one part H hinge peg into the opening on the part 7 lower shelf, and secure to the part 14
oven door with two part D screws.
14
H
Dx2
18 |

PRODUCT ASSEMBLY (OPTIONAL)
17 Combine the part P wall nail, part R wall washer, and part Q wall anchor and use a hammer to
drive the nail into the wall through the opening on the part 4 pantry back.
Insert part O sink and part W phone.
P
R
Q
O
W
| 19
