BDI Fin Table 1110 User manual

Fin TableTM1110 & 1106
Assembly Instructions
7/2007
HIGH PERFORMANCE
FURNITURE FOR YOUR
HOME
End Table (Model 1110) and Coffee Table (Model 1106)

2
B- Small Hex Wrench with
Ball End x 1
Your Fin Table™is designed and engineered for easy assembly.
Carefully follow this procedure to prevent any damage.
Placement and Maintenance
Fin Table™is designed for indoor use on level floors. Clean
glass with glass cleaner, and steel parts and wood veneer with
a moist cloth.
Fin Table™
Step 1 - Unpack and identify parts listed.
The assembly workspace should be a non-marring surface such as carpet.
For missing hardware pieces, please contact BDI Customer Service at:
[e-mail] For all other concerns please contact your
local BDI Retailer.
www.bdiusa.com
customerser[email protected]
F- Glide x 3
C- Large Hex Wrench x 1
D- Set Screw x 3
A- Phillips Screwdriver x 1
E- Cap Screw x 6
G- Plastic Set Screw for
Glass Shelf x 3
H- Glass Support Tube x 3
Glass support tubes have
small set screw just below
open end.
I- Leg x 3
Step 2
Wood direction/orientation is critical.
After locating the “BOTTOM SIDE” label on wood base, attach legs (I) to bottom side
with Cap Screw using the Large Hex Wrench (C) and then snap in Glides (F). Install
Glass Support Tube (H) to top edge of wood part using the Large Hex Wrench (C).
NOTE: The Glass Support Tubes have a small set screw just below the open end.
C
H
I
I
F
I
F
Wood Base
Glass Shelf
Glass Top

3
Step 4 - Using the Small Hex Wrench (B) and Set Screw (D), install table top to the Glass Support Tubes (H) as shown below.
Designed by Cristian Wicha.
‘Fin Table’ is a trademark of Becker
Designed, Inc. All rights reserved.
©2006 Becker Designed, Inc.
Step 3 - Install glass shelf
Using the Phillips Screwdriver (A), fasten glass shelf with Plastics Screws (G) to the pre-installed shelf supports as shown below.
G x 3
HH
B
D
