BDI modica User manual

1
D - 37mm
x 8
E - x 4
F - x 4
C-50mm
x4
Placement and Maintenance
Modica™ Office furniture is designed for indoor use on level floors.
Clean steel parts and wood veneer with a moist cloth.
Unpack and Identify
Unpack and identify the components at left. Note that some
components are shipped inside the drawer assembly. The assembly
workspace should be a non-marring surface such as carpet. For
missing hardware pieces, please contact BDI Customer Service at
[email protected]. For all other concerns, please contact
your BDI Retailer.
Component List
Designed by Matthew Weatherly.
These distinctive product congurations are protected by US and international patents,
trade dress, and/or copyright laws.
BDI and Format are trademarks of Becker Designed, Inc.
All Rights reserved. ©2014, BDI
Made in China. 6341REV081214v1
A - x 1
B - x 1
J - x 2
K - x 2
H - x 1
1
G - x 1
I- x 1
L-x 2
L
modica
6341
assembly instructions
bdiusa.com [email protected]

2assembly instructions
bdi
usa.com [email protected]
modica
6341
E x 4
B x 1
2
3
J
K
K
J
I
C x 4
A
I
IE
F
Loosely attach screws.

3assembly instructions
bdi
usa.com [email protected]
modica
6341
2 Person Task
2 Person Task
4
5
H
D x 8
A
K
K
J
J
Fully tighten all screws at this point.
CAUTION: FOLLOW THIS STEP CAREFULLY TO AVOID
DAMAGE TO YOUR FLOOR.
Place the Cardboard Corner Protectors (L) from packaging
underneath the Legs (K). With the help of another person,
carefully tip desk upright onto Legs (K). Slide Cardboard
Corner Protectors (L) from underneath Legs (K).
L
L
K
K

4assembly instructions
bdi
usa.com [email protected]
modica
6341
6
G
G
NOTE: Power Strip not included.
