BEA FLY User manual

FLY
1
2
5
6
7
3
4
* Other use of the device outside of the permitted purpose can not be guaranteed by the manufacturer.
TECHNICAL SPECIFICATIONS
DESCRIPTION
ENGLISH
PASSIVE INFRARED SENSOR FOR AUTOMATIC DOORS*
Specifications are subject to changes without prior notice.
Measured in specific conditions.
Technology :
Optical characteristics:
Maximum Detection area (mounting height: 2.2m):
Minimum Detection area (mounting height: 2.2 m)
Detection mode:
Detection speed:
Light indicator:
Warm up time:
Hold time:
Response time:
Power supply:
Frequency:
Power consumption:
Connection:
Recommended cable section (terminal block):
Standard output:
Max. contact voltage:
Max. contact current:
Max. switching power:
Mounting height:
Temperature range:
Dimensions:
FLY:
FCA:
FSA:
Color (FLY-FCA-FSA):
Length of cable:
Conformity:
passive infrared and microprocessor
P.I.R. with 4 elements, 15 lenses with full independent masking possibilities
2.5 m (W) x 1.5 m (D)
0.5 m (W) x 0.5 m (D)
motion
0.1 to 1.5 m/s
1 red LED:flashes for a few seconds after power-on
LED lights up: sensor detects motion
10 s
0.5 s ou 2 s
< 200 ms
12 VDC - 10% to 24VDC +30% /12 to 24 V AC ±10%
50/60 Hz
< 1 W
terminal block
< 0.5 mm²
relay (free potential contact)
60 V DC / 42 V AC
1A (resistive)
30W (DC) / 42 VA (AC)
3 m max
from -30 °C to +55 °C
101 mm (W) x 41 mm (H) x 27 mm (D)
91 mm (W) x 40 mm (H) x 40 mm (D)
121 mm (W) x 51 mm (H) x 40 mm (D)
anthracite grey
2.5 m
EN 61000-6-2; EN 61000-6-3; EN 50581
User’s Guide for product version 0202 and higher
See product label for serial number.
PLEASE KEEP FOR FURTHER USE
DESIGNED FOR COLOUR PRINTING
1. Sensor fixing
screw BLACK
2. LED
3. DIP-switch
4. Lens
5. Terminal block
6. Bracket
7. bracket fixing
screw ALU

1
2
FLY
FLY
FSA -FLYCATCHER
FCA-FLYUP
FLY FSA
OPENING AND CLOSING THE SENSOR
MOUNTING THE SENSOR
To open the Fly sensor, insert a screwdriver in the
hole under the bracket cam..
Consider the position of the guide pin when
closing the sensor. Insert the bottom of the front cover to the bottom
clip of the base and push to close the FSA.
To open the FSA insert a screwdriver as shown (left)
or pinch off both sides of the front cover (right).
1. Stick the template to the internal profile.
2. Drill the 2 holes.
3. Fix the brackets to both sides of the sensor with the 2 aluminum screws and washers.
4. Fix the sensor, with the connector facing you, to the profile with the 2 black screws.
5. Make the cut-out in the door profile.
6. Connect the sensor using the cable (See p. 1 for wiring).
7. Adjust the tilt angle using the brackets.
1. Stick the template to the wall.
2. Drill the 2 holes to fix the FSA and the hole for the cable.
3. Open the FSA and cut out a wire opening footprint.
4. Fix the sensor to the FSA base with the 2 aluminum screws sup-
plied with the Fly.
5. Connect the sensor using the cable.
6. Fix the sensor with the 2 black screws and close the FSA.
1. Stick the template to the ceiling and cut out the hole.
2. Clip the sensor on the FCA and fix it with the 2 washers and the 2
aluminum screws.
3. Connect the sensor using the cable.
4. Insert the complete assembly into the ceiling and fix it using the 2
long, black screws.

3
4
FLY
ON
1
2 3
1
2
DIP SWITCH SETTINGS
ON
OFF
DIP SWITCH #1 DIP SWITCH #2 DIP SWITCH #3
Sensitivity high
Sensitivity low
(mounting height< 2.2m)
Passive output (NC)
Active output (NO)
Hold time: 2 s
Hold time: 0.5 s
The drawings show the maximum sensing field dimensions. If you install the FLY without accessories (FCA or FSA),
you can move the sensing field position by tilting the sensor to select the required vertical tilt angle. Otherwise, this
adjustment is not possible.
To adjust the sensing field, use the
masking lens. To tailor the sensing
field, cut the segments.
Use the guide pins to insert the
masking lens on the front cover.
Position the screwdriver as shown
to remove the masking lens.
SENSING FIELD SETTINGS
EXAMPLES: door threshold
door threshold
DETECTION AREA
NO DETECTION
NO DETECTION
DETECTION AREA
FRONT VIEW
FLAT VIEW
Door threshold
height

1
1
1
1
1
BEA SA | LIEGE Science Park | Allée des Noisetiers, 5 - 4031 ANGLEUR [BELGIUM] | T [phone] | F [phone] | [email protected] | www.beasensors.com
©BEA | Original instructions | 47.0028 / V3 - 04.21-D0
BEA hereby declares that the FLY is in conformity with the basic requirements and the other relevant provisions of the
directives 2014/30/EU and 2011/65/EU.
The complete declaration of conformity is available on our website.
TROUBLESHOOTING
Only for EC countries: According to the European Guideline 2012/19/EU for Waste Electrical and Electronic Equipment (WEEE)
INSTALLATION TIPS
The sensor must be firmly
fastened in order to avoid
vibrations!
When mounting the Fly,
make sure you apply the
brackets before tightening
the screws.
When clipping the sensor
on the FCA, make sure you
apply the washers before
tightening the screws.
Always use the aluminium
screws to fasten the
accessories and the black
screws to fix the sensor!
Using the wrong screws
could damage the sensor!
PRODUCT RANGE & ACCESSORIES
The door remains
closed. The LED is OFF.
The door will not open
and the LED lights up.
The door opens when
no detection occurs
and closes during
detection.
The sensing field does
not correspond to your
requirements.
The detection is very
bad.
The sensor power is off.
The mode of the relay output
is not correct.
The cut of the masking lens
is wrong.
The sensor might be installed
upside down.
The wiring of the relay
output is not connected
correctly.
Check the wiring and the power supply. check the
supplied voltage.
Check the relay wiring.
Change the position of dip-switch 2.
Cut out a new lens to meet the required sensing
field size.
Check if the sensor is installed with its connector
facing you.
Main cable 2.5m
FLY FCA: Fly Ceiling Accessory
FSA: Fly Surface Accessory F LY C AT C H E R :
Kit for mounting on wall
F LY U P : Kit for mounting in ceiling
FLY
