BEA MS51W User manual

MS51W
BATTERY-POWERED, TOUCHLESS ACTIVATION
WITH BUILT-IN, 900 MHZ TRANSMITTER
75.0068.01 MS51W 20230512 Page 1 of 8
EN
Visit website for available
languages of this document.

Page 2 of 8 75.0068.01 MS51W 20230512
TECHNICAL SPECIFICATIONS
TECHNOLOGY / PERFORMANCE
Technology Active infrared
number of IR sensors 2
Radio control type Digital
Frequency 908 – 918 MHz (frequency hopping)
Emitted radio power -25 dBm (transmitter)
Detection range 8" max.
Battery life 3 years (at 150 activations per day)
Product temperature range -22 – 158 °F
ELECTRICAL
Power supply 3 VDC (2 AA batteries, each ~1.5 V max.)
Power consumption < 0.5 mW (when idle)
< 25 mW (upon RF transmission)
PHYSICAL
Dimensions (overall)
single gang 2 ¾" (W) × 4 ½" (H) × 1 ¼" (T)
double gang 4 ½" (W) × 4 ½" (H) × 1 ¼" (T)
round 6" (H/W) × 1 ¼" (T)
jamb 1 ¾" (W) × 4 ½" (H) × 1 ¼" (T)
Material Stainless steel 304 and PC
Weight Single gang: 0.34 lb
Double gang: 0.55 lb
Round: 0.71 lb
Jamb: 0.29 lb
COMPLIANCE
IP rating IP65
FCC certification FCC: 2ABWS-10TD900PB
IC: 4680A-10TD900PB
Specifications are subject to change without prior notice.
All values measured in specific conditions, using lithium batteries..
For best performance, BEA recommends using lithium batteries.

75.0068.01 MS51W 20230512 Page 3 of 8
PRECAUTIONS
ASSEMBLY DIAGRAM
!
CAUTION
If needed, wipe the sensor
window with a non-abrasive
and lint-free cloth.
Only trained and qualified
personnel are recommended
to install and set up the sensor.
The warranty is invalid if
unauthorized repairs are
made or attempted by
unauthorized personnel.
Always test the proper
operation of the installation
before leaving the premises.
The door control system and
the header cover profile must
be correctly grounded.
Shut off all power going to header before attempting any wiring procedures.
Observe battery polarity when inserting batteries.
Maintain a clean and safe environment when working in public areas.
Constantly be aware of pedestrian traffic around the door area.
Always stop pedestrian traffic through the doorway when performing tests that may result in
unexpected reactions by the door.
ESD (electrostatic discharge): Circuit boards are vulnerable to damage by electrostatic discharge.
Before handling any board, ensure you dissipate your body’s ESD charge.
Always check placement of all wiring before powering up to ensure that moving door parts will not
catch any wires and cause damage to equipment.
Ensure compliance with all applicable safety standards (i.e. ANSI A156.10 and 156.19) upon
completion of installation.
DO NOT attempt any internal repair of the components. All repairs and/or component replacements
must be performed by BEA, Inc. Unauthorized disassembly or repair:
1. May jeopardize personal safety and may expose one to the risk of electrical shock.
2. May adversely affect the safe and reliable performance of the product resulting in a voided
warranty.
face plate sensor
assembly gasket

Page 4 of 8 75.0068.01 MS51W 20230512
PREPARE INSTALLATION SITE
PREPARE MS51W ASSEMBLY
1. For new installation, install the
appropriate mounting box or
electrical box.
For retrofitting an existing installation, remove the
previous plate and transmitter.
2. Insert 2 AA lithium batteries (provided).
3. Make necessary DIP switch adjustments.
To ensure system performance,
BEA recommends using only plastic
electrical boxes.
Observe battery polarity when inserting batteries.
DIP FUNCTION OFF (default) ON
1 Detection
distance
long range (dependent on DIP 3 setting)
DIP 3 ON = 5 – 6”
DIP 3 OFF = 7 – 8”
short range (2 – 3”)
2 LED
indicator
(applicable
to alkaline
battery
replacements
only)
battery life - multicolor battery life - unicolor
green
1x flash = full battery
green
1x flash = full battery
orange
1x flash = change batteries
green
2x flash = change batteries
red
1x flash = end of battery life
green
3x flash = end of battery life
3 Immunity Low immunity High immunity
When installing jamb version, cutout
dimensions are
1 1⁄2” (W) x 2 7⁄8”(H) × 1” (D min)

75.0068.01 MS51W 20230512 Page 5 of 8
INSTALL MS51W ASSEMBLY
4. Install MS51W assembly on box. Observe the orientation of the assembly as well as each
individual component.
5. Secure with the provided screws (#6-32 flathead) and test functionality.
Be sure to remove the plastic film
from the face plate before testing.
flat portion
toward wall
LED hole
on top
text upright

Page 6 of 8 75.0068.01 MS51W 20230512
6. If retrofitting, ensure that the current
application is equipped with a 900 MHz
receiver. If not (or if new installation),
install a 900 MHz receiver.
7. Pair the transmitter and receiver:
a. Press and release desired learn button.
The red LED on the receiver will
illuminate.
b. Activate the MS51W twice.
The blue LED on the receiver will
illuminate.
See 900 MHz Family User’s Guide
(75.5937) for more information.
COMPLETE THE INSTALLATION
RED 12-24V
RD900
900MHz Receiver
BLK AC/DC WH COM GRN NO YEL NC
PUL |TOG
ACTIVATION LEARN SIGNAL STRENGTH
0.5s |10s STD |EH
DELAY NO
DELAY
1s 30s
LEARN
12345
Typically not used
Control ACT
Control COM
Control / Transformer Power
Control / Transformer Power

75.0068.01 MS51W 20230512 Page 7 of 8
TROUBLESHOOTING
MS51W does not detect
when waving in front of it
Dead batteries Check battery life by placing your
hand in front of the MS51W. If
there is no LED indication, replace
batteries.
Detection range is too short Check DIP 1 Position (see page 4)
and ensure DIP 3 is in OFF position
for indoor applications.
Incorrect battery orientation Ensure batteries are installed
properly with the right polarity (see
label on product).
Incorrect MS51W assembly, causing
water to leak into the assembly
Ensure all components of the
assembly have been placed in the
correct orientation (see page 6,
step 6).
Ensure silicone is applied to the
holes in mounting boxes to prevent
water intrusion.
Door does not open when
waving hand in front of the
MS51W
Incorrect receiver wiring/connection Check wiring and relay connection.
Improper receiver pairing Check receiver pairing with
transmitter.
Incorrect transmitter or receiver
frequency
If using wireless transmitters and
receivers, ensure that the operating
frequencies are the same.
Door safety system is holding the
door closed
Clear the safety system to ensure
that nothing is in detection.
Transmitter interference Ensure that a plastic junction box
is used.
MS51W stays in detection
• LED will remain solid
• LED color will depend on the
DIP 2 setting
Window pollution Check sensor window for any dirt
and debris. Wipe sensor window
with a non-abrasive, lint-free cloth
if necessary.
Cracked or damaged window Replace the MS51W.
LED flashes orange or red
upon activation
Low battery indication See page 4, step 3.
orange = replace soon
red = replace immediately
MS51W causes door
activation without waving
hand
Environmental conditions
influencing sensor
Increase immunity settings (see
page 4, step 3).
Remove moving or reflective objects
in front of the MS51W.
Ensure that door movement is not
causing detection.
Detection range is too long. Switch
to short range (see page 4, step 3).

Page 8 of 8 75.0068.01 MS51W 20230512
