Beacon Assist Call BACM User manual

Assist Call BACM
Emergency Assistance Kit
Installation and Operation Manual

Page 2 of 8
Table of Contents
1Introduction..........................................................................................................................3
1.1 What is an Emergency Assistance Alarm ..........................................................................3
1.2 Suitability ......................................................................................................................3
2Product Overview ..................................................................................................................3
3Design Guidelines..................................................................................................................3
3.1 Ceiling Pull Cord location ................................................................................................3
3.2 Overdoor Indicator location.............................................................................................3
3.3 Cancel/reset point location..............................................................................................3
4Important Safety Information .................................................................................................4
4.1 Unpacking the Beacon BACM...........................................................................................5
Installation ....................................................................................................................................5
4.2 Connecting the Beacon BACM Assist Call emergency assistance alarm kit ............................5
4.2.1 Beacon BACM Kit connection to BA4ZM Controller.....................................................5
4.2.2 Beacon BACM Kit connection to a Beacon Master Station, System Expander Panel and
Assist Call Master Station .......................................................................................................6
4.2.3 Beacon BACM Kit connection to Beacon BTB type B Outstation...................................6
4.3 System Operation ..........................................................................................................7
4.3.1 Raising the Alarm inside the WC..............................................................................7
4.3.2 Indication outside the WC.......................................................................................7
4.3.3 Acknowledging the alarm........................................................................................7
4.3.4 Resound Feature....................................................................................................7
4.3.5 Resetting the system..............................................................................................7
5Maintenance .........................................................................................................................7
Notes............................................................................................................................................8

Page 3 of 8
1Introduction
1.1 What is an Emergency Assistance Alarm
An emergency assistance alarm is used by disabled people to summon assistance.
The system generally consists of a ceiling mounted pull cord, a cancel plate, and an overdoor indicator
plate. These are connected back to an Assist Call controller or Beacon master station depending on
the chosen configuration.
1.2 Suitability
An Emergency assistance alarm must be provided to all accessible toilets, accessible bathrooms,
accessible bedrooms, accessible showers and accessible changing areas.
The Assist Call system is designed to fully comply with BS8300- 2018, emergency assistance alarms are
called for in all new buildings other than dwellings in the following “Building Regulations Approved
Document M:2020”.
2Product Overview
The Assist Call Beacon BAKIT Emergency Assistance Alarm kit is a 2 wire system consisting of a
ceiling pull cord located near to the WC, cancel plate also located near to the WC and over door
indicator plate located above the door outside of the WC .
The Beacon kit is intended to be utilised with a Beacon BA4ZC 4 Zone controller whereas the BAKIT kit
is utilised with a Beacon Master Station either Beacon BM2/4/8, or Beacon BMNET, System expander
panel Beacon BMNETEX or Assist Call Master Stationich should be located in a permanently
staffed area.
Additional assist call devices can be connected to the circuit however this is dependent upon
configuration, please see the installation section for exact details and recommended cabling. of either
one additional cancel plate or overdoor indicator and up to 5 additional ceiling pull cords. All Assist call
devices can be wired in any order so wiring runs can be kept to a minimum.
The Assist Call system wired from a Beacon master station or controller features BS8300
“acknowledge” function, this requires that ”visual and audible feedback should beprovided to indicate
that, when the alarm has been operated, the emergency assistance call has been acknowledged and is
being actioned.
Note an indication that assistance is on its way will reassure those in distress.”
All Assist Call devices utilise blue halo indication so that they will not confused with fire alarm devices.
3Design Guidelines
Before designing an emergency assistance alarm the guidelines in BS8300:2018 and “Building
Regulations Approved document M :2020” should be consulted first.
3.1 Ceiling Pull Cord location
The ceiling pull cord should be located ideally within the grab rail such that it is reachable from the WC
and from the floor close to the WC
Ceiling pull cords should consist of 2 red bangles of 50mm diameter one set at a height of between
800mm and 1000mm and the other set at a height 100mm above the floor.
3.2 Overdoor Indicator location
The overdoor indicator should located so that it is easily seen and heard by those able to give
assistance.
3.3 Cancel/reset point location
The cancel point should be located such that it is reachable from the wheelchair, WC, tip up seat in a
shower facility or bed within an accessible bedroom. The cancel point bottom edgeshould be between
800mm and 1000mm above the floor.

Page 4 of 8
Please see diagram attached for more information
4Important Safety Information
This Equipment must only be installed and maintained by a suitably skilled and competent person.
This Equipment is defined as Class 2 in EN60950 (Low Voltage Directive) and must be EARTHED.
The Beacon 1 Zone controller requires a 3A switched fuse spur.
Caution
Indoor Use Only
Warning Shock Hazard-
Isolate Before Opening
Warning
TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS UNIT TO RAIN
OR MOISTURE
Warning
THIS UNIT MUST BE EARTHED
Warning
NO USER SERVICEABLE PARTS

Page 5 of 8
Anti-static handling guidelines
Make sure that electrostatic handling precautions are taken immediately before handling PCBs and other
static sensitive components.
Before handling any static-sensitive items, operators should get rid of any electrostatic charge by
touching a sound safety earth. Always handle PCBs by their sides and avoid touching any components.
4.1 Unpacking the Beacon BAKIT
Remove the equipment from its packing, and check the contents against the following list:
•BAPCM Ceiling Pull Cord.
•BAM Overdoor Indicator Plate.
•BACM Cancel Plate
•Accessible WC Sticker.
•Instruction Sticker (to be located within the WC).
•Installation and operation manual.
•Accessory pack with the following contents:-
o6 no device 2 part terminals.
o6 no device mounting screws.
Installation
4.2 Connecting the BAKIT Assist Call emergency assistance
alarm kit
The BAPCM, BAM and BACM device plates mount onto a 25mm UK single gang back box.
4.2.1 BAKIT Kit connection to BA4ZM Controller
The devices are wired to the terminals marked 0 and +, the devices are polarity sensitive, however
there are no in or out terminals and devices can be wired in any order. The cabling between the
controller and the devices is 2 core 1 mm csa flex, wired in a radial circuit up to150 m length. The circuit
is fully monitored for open and short circuit and a 10K EOL resistor should be fitted across the terminals
in the last device.

Page 6 of 8
Additional assist call devices can be connected to the circuit of either one additional cancel plate or
overdoor indicator and up to 5 additional ceiling pull cords.
All system wiring should be installed to meet the appropriate parts of BS 7671 (Wiring Regulations).
Other national standards of installation should be adhered to where applicable.
Extra Low Voltage (ELV) Wiring:- Always segregate low voltage wiring from the main wiring.
4.2.2 BAKIT Kit connection to a Beacon Master Station, System
Expander Panel and Assist Call Master Station
The devices are wired to the terminals marked 0 and +, the devices are polarity sensitive, however
there are no in or out terminals and devices can be wired in any order. The cabling between the
controller and the devices is 2 core 1 mm csa flex, wired in a radial circuit up to150 m length. The circuit
is fully monitored for open and short circuit and a 10K EOL resistor should be fitted across the terminals
in the last device.
ACS Change Diagram please
Additional assist call devices can be connected to the circuit of either one additional cancel plate or
overdoor indicator and up to 5 additional ceiling pull cords.
All system wiring should be installed to meet the appropriate parts of BS 7671 (Wiring Regulations).
Other national standards of installation should be adhered to where applicable.
Extra Low Voltage (ELV) Wiring:- Always segregate low voltage wiring from the main wiring.
4.2.3 BAKIT Kit connection to BTB type B Outstation
There is the facility to connect a BAKIT kit to a type B outstation however please see below
as the wiring details are different from those previously mentioned.
The devices are wired to the terminals marked 0 and +, the devices are polarity sensitive, however
there are no in or out terminals and devices can be wired in any order. The cabling between the
controller and the devices is 2 core 1.5 mm csa fire resistant cable to match that of the type B
outstation circuit. The circuit is extended from the terminals marked EOL Out in the type B outstation.
ACS To Alter diagram

Page 7 of 8
The circuit is fully monitored for open and short circuit and a 10K EOL resistor should be fitted across
the terminals in the last device.
Please note only additional pull cords can be added in this configuration up to 5.
All system wiring should be installed to meet the appropriate parts of BS 7671 (Wiring Regulations).
Other national standards of installation should be adhered to where applicable.
Extra Low Voltage (ELV) Wiring:- Always segregate low voltage wiring from the main wiring.
4.3 System Operation
4.3.1 Raising the Alarm inside the WC
The person in distress raises the alarm by pulling on one of the red pull cord bangles, the blue indicator
on the ceiling plate will indicate steady blue and the blue indicator flash and sounder will activate on the
cancel plate.
4.3.2 Indication outside the WC
The overdoor indicator plate will flash and sounder will activate to show the location of the alarm, the
ViAC-1ZC controller should be located within a permanently staffed area. The blue indicator will flash
and the sounder will activate on the controller to alert staff of an alarm.
4.3.3 Acknowledging the alarm
A member of staff acknowledges the alarm bypressing the button adjacent blue indicator on the
controller, the blue indicator will change state from flashing to steady and the internal sounder will
sound intermittently every 15 seconds. The ceiling pull cord indication will extinguish, the blue indicator
on the cancel plate and the overdoor indicator changes state from flashing to steady with intermittent
sounder operation every 15 seconds to confirm to the occupant that help is on the way.
4.3.4 Resound Feature
If the assist call alarm is not reset within 2 minutes of being acknowledged it will automatically resound
causing the master station and all of the devices within the alarm circuit to flash and sound mentioned
above.
4.3.5 Resetting the system
When the call has been attended to the alarm is reset by pressing the cancel button within the WC.
5Maintenance
It is a requirement of BS 5839-9:2021 that a maintenance agreement be in place for the EVCS. The
maintenance schedule should be as follows:
Frequency
Test
Monthly Test the system monthly by operating a pull cord, acknowledge the call using the
controller, check all indicators and reset from the cancel plate within the WC . Record
these results in the site log.

Page 8 of 8
Notes
For more product information please visit www.espuk.com
E&OE - Errors and omissions excepted.A22
Elite Security Products UK, Unit 7 Target Park, Shawbank Road, Lakeside, Redditch, Worcestershire, B98 8YN
Tel [phone], Fax [phone]; Email [email protected]
Registered in England Number Company Registration No: 02769392, VAT Registration GB614686525
