Actuator
Power
120 V ac, single-phase, 60 Hz (Standard), 50 Hz (Optional) Allowable Tolerance +10%
-15%
Operating Conditions -20° to 85°C (-4° to 185°F) - Standard.
-20° to 120°C (-4° to 248°F) - Optional (High Temperature).
-50° to 85°C (-58° to 185°F) - Optional (Low Temperature).
0 to 100% relative humidity.
Feedback Signal with 4–20 mA
Contactless Position Sensor
(CPS-4)
Output Stability 0.25% of span from 102 to 132 V ac
±0.03% of span/°C for 0 to 50°C, ±0.05% of span/°C for -40° to 85°C
Linearity ±1% of span, max. independent error
Hysteresis 0.25% of span at any point
Isolation Max. leakage of 10 µA at 60 V rms, 60 Hz from output to ground
Film Potentiometer 1,000 ohms
Max. Voltage 40 V
Wattage 2 W max.
Linearity ±0.5%
Max. Wiper Current 1 mA
Action on Loss of Power Stays in place.
Limit Switches Two SPDT, one for CW and one for CCW limit of travel. Actuators
having position sensing capability (Options 6 & 5), have over-travel
limit switches set 1/2° outside the CW and CCW travel range (typically,
–0.5° and 100.5°). Actuators without position sensing (Option 3), have
end-of-travel limit switches set at the CW and CCW travel range
(typically, 0° and 100°).
Auxiliary Switches Up to four 3 A, 120 V ac switches available (.5 A @ 125 V dc, .25 A @
250 V dc).
See page 21 for switch setting diagram.
Handswitch Permits local electrical operation, independent of controller signal.
Standard on all units. An auxiliary contact is available as an option for
remote auto indication (rated 3 A at 120 V ac).
Handwheel Provides manual operation without electrical power.
GENERAL SPECIFICATIONS
