  9. Beghelli PRATICA MODULA AT User manual

Beghelli PRATICA MODULA AT User manual

PRATICA MODULA AT
334.902.373 C
B
15x10mm
Max Ø10mm
15x7mm
M20
A
D
B
B
C
83,5mm
60mm
6
D
SETTINGS
1h
2h
3h
1,5h
SE/NM SA/M *
booster battery connector
BIADHESIVE
RESET
booster battery
Batteria già collegata - Battery already connected
Max M20
60mm
119mm
265mm
39mm
50mm
C
www. eghelli.com
BEGHELLI S.p.A. - Via Mozzeghine 13/15 - località Monteveglio 40053 Valsamoggia (BO) - Tel. +39 051 9660411 - Fax +39 051 9660444 - N° Verde 800 626626
IP65IK07
230Vac - 50/60Hz
0<ta<40°C
230Vac 230Vac
2730
230Vac
2730
230Vac
2730
+/- Basic insulation
SE
Not Maintained
SE
Not Maintained
SA con comando
Maintained with control
SA permanente
Maintained without control
*
Jumper
*
Jumper
*
Jumper
8mm
Ø 0,33mm
2
(AWG22)÷2mm
2
(AWG14)
2730
230Vac
SA Lamp SE Lamp
503
EASY BOX basso -Low EASY BOX
EASY BOX alto - High EASY BOX
18598
(cornice per EASY BOX basso inclusa-
frame for low EASY BOX included)
+ cod. 18580
scatola incasso -
flush-mounted box
+ cod. 18590
staffa 45° - 45° bracket
+ cod. 18591
griglia protettiva - protective grille
+ cod. 18597
tegola antipioggia - rainproof tile
+ cod. 18585
staffa parete bandiera - flag wall bracket
+ cod. 18581-18582-18583
+ cod. 4127-4128-4129
+ cod. 18581
+ cod. 18581
+ cod. 18583
+ cod. 18582
Schermo bandiera serigrafato - Printed screen flag
Schermo serigrafato con molla - Screen printed with spring
Adesivi (inclusi nelle versioni SA)
Stickers (included in SA versions)
cod. 18584
Schermo serigrafato - Screen printed
+ cod. 18593
+ cod. 18594
+ cod. 18596
+ cod. 18595
+ cod. 4127
+ cod. 4127
+ cod. 4129
+ cod. 4128
+ cod. 18586
staffa per controsoffitto - ceiling bracket
+ cod. 18587
staffa blindoluce -
blindoluce bracket
+ cod. 4319
kit binario trifase -
three-phase track kit
Adesivi (inclusi nelle versioni SA) -
Stickers (inclu e in SA versions)
+ cod. 3723
gancio sospensione -
suspension hook
A1 A2
A1
A2
A1
A2
+ cod. 18592
**A-B-D IP40
C IP65 (+ cod. 18592)
*60
*60 180 480
120
90
COLLEGA ENTI - CONNECTIONS
INSTALLAZIONE EASY BOX - EASY BOX INSTALLATION
SETTAGGI - SETTINGS
AONTAGGI - OUNTING
La impostazioni da App sono
prioritarie rispetto alle impo-
stazioni sul circuito.
The settings from the App
have priority over the set-
tings on the circuit.
RESET
La pressione del pulsante
RESET per 15 secondi ripristi-
na le impostazioni sul circuito
Pressing the RESET button
for 15 secon s resets the
circuit settings
er approfondimenti e aggiornamenti inquadra il codice QR sul prodotto
For further information an up ates, scan the QR co e on the pro uct
24h < 1 - 2 - 3h
12h < 1 - 1,5 - 2 - 3 - 8h
9
8
battery connector
E
1
3
4
2A
2B Clack
2
La staffa non utilizzata serve come coperchio
di protezione
The unused bracket serves as a protective
cover
RA11= LiFe 3,2V 1,5Ah
Utilizzo batteria booster cod. RA11:
- per ottenere un flusso maggiore
- per sostituire la batteria interna esausta (se equi-
valente) senza aprire il prodotto (VEDI SOTTO)
Booster battery cod. RA11 usage:
- to obtain a higher flow
- to replace the exhauste internal battery (if
equivalent) without opening the pro uct (SEE
BELOW)
230V
50HzCOSϕLED
1870042mA0,4236 LEDLiFe 3,2V 1,5Ah1h/1,5h/2h/3h/8h
1870158mA0,4536 LEDLiFe 3,2V 1,5Ah1h/1,5h/2h/3h/8h
1871042mA0,4236 LEDLiFe 3,2V 1,5Ah1h/1,5h/2h/3h/8h
1871158mA0,4536 LEDLiFe 3,2V 1,5Ah1h/1,5h/2h/3h/8h
1872158mA0,4536 LEDLiFe 3,2V 3Ah1h/1,5h/2h/3h/8h
1873158mA0,4536 LEDLiFe 3,2V 3Ah1h/1,5h/2h/3h/8h
SE
SE-SA-PS
SE-SA-PS
SE-SA-PS
SE-SA-PS
SE
CHIUSURA PRODOTTO - PRODUCT CLOSURE
SOSTITUZIONE E S ALTI ENTO BATTERIA - BATTERY REPLACE ENT AND DISPOSAL
Vite antivandalica
Vandal-proof screw
1
2
3
4
5
6
7
remove old battery
1
connect booster battery
3
2BIADHESIVE
booster battery
*
*er la gestione dell'autonomia fare riferimento alla tabella
For autonomy management refer to the table
CONFIGURAZIONI E CO ANDI - CONFIG RATION AND COMMANDS senza APP
without APP con APP
Autonomia-Duration 1h • Default • Default
Autonomia-Duration 1,5h • con jumper •
Autonomia-Duration 2h • con jumper •
Autonomia-Duration 3h • con jumper •
Autonomia-Duration 8h •
Settaggio SE/SA (solo su lampade SA)
Setting Non-maintaine /Maintaine (only on Maintaine Luminaire) • con jumper •
Settaggio S (solo su lampade SA)
Setting Non-maintaine /Maintaine (only on Maintaine Luminaire) •
Settaggio pari/dispari AT / Setting even/o AT •
Durata Test 1h/ pari all'autonomia scelta / Test uration 1h or autonomy set • Durata Test 1h • Test uration 1h •
Reset / Reset • con pulsante RESET •
Start/Stop Test Funzionale / Start/Stop functional Test •
Sync Test automatico / Sync automatic Test •
CONFIGURAZIONI
CONFIG RATION
CO ANDI E
FUNZIONI -
CO ANDS
AND
FUNCTIONS
• opzione disponibile - available option Azione locale su singolo apparecchio
Local action on a single evice
Settaggio con App B.connect - Setting with App B.connect
APERTURA CO UNICAZIONE VIA BLUETOOTH®IN 2 DIVERSE ODALITÀ
- Con lampada NON ALIMENTATA da rete, premere il pulsante RESET; finestra di
programmazione di 15 minuti;
- Alla prima alimentazione della lampada si attiva una finestra di programmazione di
2 ore.
N.B. Dopo le 2 ore il Bluetooth®si spegne (impostazione modificabile tramite App).
COMM NICATION OPENING VIA BL ETOOTH®IN 2 DIFFERENT MODES
- With lamp NOT POWERED by the mains, press the RESET button; 15 minute sche-
uling win ow;
- When the lamp is powere up for the first time, a 2-hour programming win ow is
activate .
N.B. after 2 hours the Bluetooth®turns off (setting can be change via the App).
A- Aprire App B.connect (scaricabile su App Store e
Google lay).
B- Tramite il menu “lampa a/Bluetooth” si accede alle
impostazioni e ai Test.
A- Open App B.connect (available for ownloa on the
App Store an Google Play).
B- The settings an Tests are accesse via the
"lamp/Bluetooth" menu.
SCHE I DI COLLEGA ENTO
er porre l'apparecchio in “modo riposo”, fare riferimento alle
istruzioni del telecomando Inibit (Cod. Ordine 2730).
PERIODICITA’ DEI TEST AUTO ATICI:
TEST FUNZIONALE (30 sec)= ogni 28 giorni
TEST DI AUTONOMIA (1h)= ogni 26 settimane
Le lampade pari eseguono il Test di autonomia 1 settimana
dopo quelle dispari.
(0,2,...,8,A,C,E)= pari; (1,3,...,9,B,D,F)= dispari.
SEGNALAZIONI LED
VERDE FISSO BATTERIA CARICA
VERDE LAM EGGIANTE BATTERIA IN RICARICA
UN LAM EGGIO ROSSO ERRORE BATTERIA AUTONOMIA
DUE LAM EGGI ROSSI ERRORE LED DI ILLUMINAZIONE
TRE LAM EGGI ROSSI BATTERIA SCOLLEGATA
CARATTERISTICHE TECNICHE
- Banda di frequenza: 2,4GHz-2,4835GHz
- otenza RF: <100mW e.i.r.p.
AVVERTENZE - GARANZIA
- Questo apparecchio dovrà essere destinato solo all'uso per
il quale è stato costruito. Ogni altro uso è da considerarsi
improprio e pericoloso.
- Batteria Ricaricabile e sorgente LED sono di tipo non sosti-
tuibile. er eventuali riparazioni rivolgersi ad un centro di
assistenza tecnica autorizzato e richiedere l'utilizzo di ricam-
bi originali. Il mancato rispetto di quanto sopra può com-
promettere la sicurezza dell'apparecchio.
Beghelli S.p.A. dichiara che il dispositivo ricetrasmettitore radio
è conforme alla direttiva 2014/53/UE.
Il testo completo della Dichiarazione di Conformità UE del
dispositivo è disponibile al seguente indirizzo internet:
www.beghelli.it/it/area-tecnica/strumenti/download
Il suddetto dispositivo radio può essere utilizzato in regime di
“libero uso”.
WIRING DIAGRA S
To set the device in rest-mode, refer to the instructions of the
Inibit remote controller (Order code 2730).
AUTO ATIC TESTS PERIODICITY:
FUNCTIONAL TEST (30 sec)= every 28 days
AUTONOMY TEST (1h)= every 26 weeks
Even lamps carry out the autonomy test 1 week after the odd
lamps.
(0,2,...,8,A,C,E)= even; (1,3,...,9,B,D,F)= odd.
LED SIGNALS
FIXED GREEN BATTERY CHARGED
FLASHING GREEN BATTERY CHARGING
ONE RED FLASH BATTERY ERROR DURATION
TWO RED FLASHES LIGHTING LED ERROR
THREE RED FLASHES BATTERY DISCONNECTED
TECHNICAL CHARACTERISTICS
- Frequency band: 2.4GHz-2.4835GHz
- RF power: <100mW e.i.r.p.
WARNINGS - GUARANTEE
- This device shall be used exclusively for the purpose for whi-
ch it has been designed. Any other use is considered impro-
per and therefore dangerous.
- Rechargeable battery and LED source are non-replaceable
type. Contact an authorised technical service centre for any
repairs possibly required use only original spare parts.
The lacked respect of the above conditions may compromi-
se the safety of the device.
Beghelli S.p.A. declares that the radio transceiver is in confor-
mity with Directive 2014/53/EU.
The full text of the EU Declaration of Conformity of the device
is available at the following Internet address:
www.beghelli.it/en/technical-area/tools/download
The aforementioned radio device can be used under "free use"
*La selezione dell'autonomia da App è prioritaria rispetto alle impostazioni sul circuito.
*The selection of autonomy from the App takes priority over the settings on the circuit.
RESET

Other Beghelli Lighting Equipment manuals

Beghelli Nova Eco User manual

Beghelli

Beghelli Nova Eco User manual

Beghelli 84-00 Series User manual

Beghelli

Beghelli 84-00 Series User manual

Beghelli Maxima User manual

Beghelli

Beghelli Maxima User manual

Beghelli Pluraluce Mini User manual

Beghelli

Beghelli Pluraluce Mini User manual

Beghelli Lyra W LED User manual

Beghelli

Beghelli Lyra W LED User manual

Beghelli SR User manual

Beghelli

Beghelli SR User manual

Beghelli 86 Series User manual

Beghelli

Beghelli 86 Series User manual

Beghelli GDE-SP User manual

Beghelli

Beghelli GDE-SP User manual

Beghelli Fortezza Combo RM User manual

Beghelli

Beghelli Fortezza Combo RM User manual

Beghelli OL2-CT User manual

Beghelli

Beghelli OL2-CT User manual

Beghelli Cyclone User manual

Beghelli

Beghelli Cyclone User manual

Beghelli Esco Unit User manual

Beghelli

Beghelli Esco Unit User manual

Beghelli Formula 65 LED User manual

Beghelli

Beghelli Formula 65 LED User manual

Beghelli ATX-RE User manual

Beghelli

Beghelli ATX-RE User manual

Beghelli Protegga User manual

Beghelli

Beghelli Protegga User manual

Beghelli Cyclone User manual

Beghelli

Beghelli Cyclone User manual

Beghelli Stella Exit User manual

Beghelli

Beghelli Stella Exit User manual

Beghelli Pluraluce Mini User manual

Beghelli

Beghelli Pluraluce Mini User manual

Beghelli LOGICA LED LG FM User manual

Beghelli

Beghelli LOGICA LED LG FM User manual

Beghelli Bravado Unit User manual

Beghelli

Beghelli Bravado Unit User manual

Beghelli IP65 User manual

Beghelli

Beghelli IP65 User manual

Beghelli MPL Series User manual

Beghelli

Beghelli MPL Series User manual

Beghelli STELLA EXIT User manual

Beghelli

Beghelli STELLA EXIT User manual

Beghelli GDE Combo User manual

Beghelli

Beghelli GDE Combo User manual

Popular Lighting Equipment manuals by other brands

LITESHEET BriteCor AC Direct BCO installation manual

LITESHEET

LITESHEET BriteCor AC Direct BCO installation manual

STL K-FORCE MICRO 21 instruction manual

STL

STL K-FORCE MICRO 21 instruction manual

SOLAR VISION TX360 installation manual

SOLAR VISION

SOLAR VISION TX360 installation manual

American DJ Galaxian Sky User instructions

American DJ

American DJ Galaxian Sky User instructions

Kessil A160WE owner's manual

Kessil

Kessil A160WE owner's manual

Vector 0 Owner's manual & warranty information

Vector

Vector 0 Owner's manual & warranty information

Linergy SELFIE Instructions for installation and use

Linergy

Linergy SELFIE Instructions for installation and use

Uni-bond E-905A installation manual

Uni-bond

Uni-bond E-905A installation manual

Catellani & Smith Medouse F Assembly instructions

Catellani & Smith

Catellani & Smith Medouse F Assembly instructions

Southwire T60100 operating instructions

Southwire

Southwire T60100 operating instructions

Elation Eled Light User instructions

Elation

Elation Eled Light User instructions

Laserworld RB-1.5 manual

Laserworld

Laserworld RB-1.5 manual

McLED Space 30 instruction manual

McLED

McLED Space 30 instruction manual

Blizzard Lighting mikrokassette manual

Blizzard Lighting

Blizzard Lighting mikrokassette manual

Lupo Dayled Series user manual

Lupo

Lupo Dayled Series user manual

IKEA MITTLED L1910 manual

IKEA

IKEA MITTLED L1910 manual

Omron MiniSafe 4800 Series Installation and operating manual

Omron

Omron MiniSafe 4800 Series Installation and operating manual

Amada AMLS02 instruction manual

Amada

Amada AMLS02 instruction manual

manuals.online logo
manuals.online logoBrands
  • About & Mission
  • Contact us
  • Privacy Policy
  • Terms and Conditions

Copyright 2025 Manuals.Online. All Rights Reserved.
