Beko SIM 3122 T User manual

SIM 3122 T -SIM 3124 D - SIM 3126 R
01M-8911013200-0621-01
01M-8911543200-0621-01
01M-8911023200-0621-01
Steam Iron
User Manual
EN - AR

2 / EN Steam Iron / User Manual
CONTENTS
ENGLISH 8-19

3
EN OPERATION SHOCK STEAM AUTOMATIC SHUTDOWN
AR   
EN CLEANING AND CARE SELF-CLEAN
AR  

4
1
267
8
9
10 11
4 35
1 2 3
4 5 6
7 8 9
10 11 12
Auto-Off
30 sec.
Auto-Off
8 min.
Auto-Off
30 sec.
1
2

5
1 2 3
4 5 6
7 8 9
10 11 12
Auto-Off
30 sec.
Auto-Off
8 min.
Auto-Off
30 sec.
1
2

6
13
14
15
1 2 3
1 2 3
4 5 6
1
1
1
2
2
3
2
Max
1 hour
1 hour

This product has been produced in environmentally-friendly, state-of-the-art facilities.
Please read this user manual first!
Dear Customers,
Thank you for selecting a Beko product. We hope that you get the best results from your
product which has been manufactured with high quality and state-of-the-art technology.
Therefore, please read this entire user manual and all other accompanying documents
carefully before using the product and keep it as a reference for future use. If you handover
the product to someone else, give the user manual as well. Follow all warnings and
information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
CImportant information and useful
hints about usage.
AWARNING: Warnings for dan-
gerous situations concerning the
safety of life and property.
WARNING: Warning for hot sur-
faces.
WARNING: Risk or burning and
scalding due to steam.

8 / EN Steam Iron / User Manual
1. Power cable
2. Iron base plate
3. Water tank
4. Thermostat indicator and Auto-Off light
5. Temperature adjustment knob
6. Soleplate
7. Water spray nozzle
8. Water refill lid
9. Steam adjustment / Self- Clean button
10. Water spraying button
11. Shock steam button
Technical data
SIM 3122 T SIM 3124 D SIM 3126 R
Voltage 220 - 240 V~ 50 - 60 Hz
Power consumption 2200 W 2400 W 2200-2600 W
Shock steam amount up to 140 g/min up to 145 g/min up to 150 g/min
Continuous amount
of steam
up to 25 g/min up to 30 g/min up to 35 g/min
Insulation class I
Technical and design modification rights are reserved.
The values which are declared in the markings affixed on your appliance or the other printed documents supplied with it
represent the values which were obtained in the laboratories pursuant to the pertinent standards. These values may vary
according to the usage of the appliance and ambient conditions.

9 / EN
Steam Iron / User Manual
This section contains safety instructions that will
help protect from risk of personal injury or prop-
erty damage.
Failure to follow these instructions invalidates the
granted warranty.
1.1 General safety
•This appliance complies with the international
safety standards.
•This appliance may be used by children who are
at the age of 8 or over and the people whose
physical, perceptive or mental skills are impaired
or who are inexperienced or not knowledge-
able about the appliance as long as they are
supervised or informed and made understood
the safe use of the appliance and the encoun-
tered dangers. Children should not play with the
appliance. Cleaning and user maintenance pro-
cedures should not be performed by children
unless they are controlled by their elders.
1 Important safety and environmental
instructions

10 / EN Steam Iron / User Manual
•Do not leave the product unattended while it is
plugged in.
•Unplug the product before filling the water res-
ervoir with water.
•Operate and store the appliance on a stable
surface.
•When the appliance is placed on its base plate,
ensure that the surface beneath the plate is
level.
•Do not use the appliance if the power cable or
the appliance itself is damaged. Contact an au-
thorised service.
•If the appliance is dropped or leaks water or has
other failures, contact the authorised service.
Do not use the appliance until it is repaired.
•When the appliance is not in use or left to cool
down keep the appliance and power cable out
of reach of children under 8 years old.
•The appliance is not suitable for using outdoors.
1 Important safety and environmental
instructions

11 / EN
Steam Iron / User Manual
•Only use the original parts or parts recom-
mended by the manufacturer.
•Do not attempt to dismantle the appliance.
•Your mains power supply should comply with
the information supplied on the rating plate of
the appliance.
•The mains supply of the appliance must be se-
cured with a minimum 16 A fuse.
•Use the appliance with a grounded outlet only.
•Do not use the appliance with an extension cord.
•Do not pull the power cable when unplugging
the appliance.
•Unplug the appliance before cleaning it.
•Do not wrap the cable around the appliance.
•Do not touch the appliance or its plug with wet or
damp hands when the appliance is plugged in.
•The soleplate and its surrounding area can be
extremely hot. Contacting hot surfaces may
cause burns.
1 Important safety and environmental
instructions

12 / EN Steam Iron / User Manual
Therefore while or just after using the appliance,
pay attention not to touch the hot surfaces.
•Never use the appliance in or near to combusti-
ble or inflammable places and materials.
•If you keep the packaging materials, store them
out of the reach of children.
1.2 Compliance with the WEEE Directive and Disposing of the
Waste Product:
This product complies with EU WEEE Directive (2012/19/EU). This product bears a classifica-
tion symbol for waste electrical and electronic equipment (WEEE).
This symbol indicates that this product shall not be disposed with other
household wastes at the end of its service life. Used device must be returned
to offical collection point for recycling of electrical and electronic devices. To
find these collection systems please contact to your local authorities or re-
tailer where the product was puchased. Each household performs important
role in recovering and recycling of old appliance. Appropriate disposal of used
appliance helps prevent potential negative consequences for the environment and human
health.
1.3 Compliance with RoHS Directive
The product you have purchased complies with EU RoHS Directive (2011/65/EU). It does not
contain harmful and prohibited materials specified in the Directive.
1.4 Package Information
Packaging materials of the product are manufactured from recyclable materials
in accordance with our National Environment Regulations. Do not dispose of the
packaging materials together with the domestic or other wastes. Take them to the
packaging material collection points designated by the local authorities.
1 Important safety and environmental
instructions

13 / EN
Steam Iron / User Manual
1 Important safety and environmental
instructions
1.5 Plug Wiring
The moulded plug on this appliance incorporates a 13 A fuse. Should the fuse need to be
replaced an ASTA approved BS1362 fuse of the same rating must be used. Do not forget to
refit the fuse cover. In the event of losing the fuse cover, the plug must not to be used until
a replacement fuse cover has been fitted. Colour of the replacement fuse cover must be the
same colour as that visible on the pin face of the plug Fuse covers are availabe from any
good electrical store.
• Fiting a different plug
•As the colours of the wires in the mains lead of this appliance may not correspond with the
coloured markings identifying the terminals on your plug, proceed as follows:
•Brown cable = L (Live)
•Blue cable = N (Neutral)
•Green/yellow cable must be connected to ground (E) line
•With the alternative plugs a 13 A fuse must be fitted either in the plug or adaptore
or in the main fuse box. If in doubt contact a qualified electrician.

14 / EN Steam Iron / User Manual
2.1 Intended use
This appliance is intended only for household use and ironing; it is not suitable for profes-
sional use.
2.2 Initial use
Prior to initial use, fill twice and vaporize to remove the manufacturing residues. Meanwhile,
use shock steam button (11) frequently.
CYou can smell a mild odour or see white sediments coming out of the sole-
plate holes. After performing vaporizing process twice, such odours and
sediments will disappear. Also water droplets may form within the water
reservoir; this is normal.
2.3 Refilling the water reservoir
CYour appliance is designed for use with tap water. If your tap water is ex-
cessively hard, we recommend you to use a mixture of tap water with
potable water.
2.4 Setting the temperature
C
•After the appliance is plugged in, set the temperature according to the
type of your fabric by turning the temperature adjustment knob (5) in
clockwise direction (see. 2.5).
- Thermostat indicator light (4) will light up.
•When the appliance reaches the set temperature, thermostat indicator
light (4) will turn off and the appliance is ready to use.
2.5 Temperature and steam settings table
When setting the temperature of the appliance, consider the following table.
Fabric Type Temperature control Temperautre requirement
Silk • Low temperature
Wool •• Medium temperature
Cotton, linen ••• High temperature
Linen - Jean Max High temperature
2 Operation

15 / EN
Steam Iron / User Manual
2 Operation
C•If you don’t know the fabric of your garment, first iron an invisible part of
your garment and determine a correct ironing temperature for it.
•In order to prevent the bright stains that may form on the synthetic
fabrics such as silk, iron on the reverse side of the fabric. Do not use the
water spraying feature in order to prevent the stain formation.
AWARNING: Before ironing first check the label of the garment.
2.6 Steam ironing
AWARNING:
•For ironing with steam, temperature adjustment knob should be between
“ “ and “max” position.
•Turn the steam adjustment button(9) to desired steam level.
2.7 Shock steam
A
WARNING:
•Wait for a few seconds before pressing the shock steam button (11)
again. Pressing the button repeatedly may cause water come through
the soleplate (6) together with steam.
•At the start of ironing, the first few presses may not produce shock
steam. To produce shock steam, temperature knob should be at “
” or higher position.
•In order to use the shock steam feature the thermostat indicator light
(4) should be turned off.
2.8 Vertical steam
A
WARNING:
•Hold the appliance 15-30 cm away from the garment and curtains.
•During the ironing if the thermostat indicator light (4) turns on, before
proceeding with the shock steam process wait for the light to turn off.
•Never direct this steam to people or pets.

16 / EN Steam Iron / User Manual
2.9 Spraying water
CYou can easily remove creases using the water spraying feature.
2.10 Dry ironing
In order to make dry ironing, set the steam setting button (9) to the “ ” position.
CHaving water in the appliance would be advantageous; you may use the
water spraying button (10) when necessary.
2.11 Anti-dripping system
This iron is equipped with drip stop function: the iron automatically stops steaming when the
temperature is too low to prevent water from dripping out of the soleplate.
With the anti-dripping system, you can perfectly iron even the most delicate fabrics.
2.12 Automatic Shutdown (Auto-Off)
C•In case of automatic turn off the auto-off light (4) flashes.
•If the appliance is moved in horizontal position it will be turned on.
•It may take 60 seconds for the soleplate (6) to reach the previously set
temperature.
2 Operation

17 / EN
Steam Iron / User Manual
3.1 Cleaning
A
WARNING:
•When you are finished with ironing, unplug the appliance. You can drain
the water in the reservoir by opening the refill lid (8) and tilting the iron
to the front.
•Do not use gasoline, solvent and abrasive cleaning agents or hard brush
to clean the appliance.
3.2 Anti-Calc system
A special filter inside the water tank softens the water and prevents scale build-up in the
soleplate. The filter is permanent and does not need replacing.
3.3 Self clean
CThe self-cleaning feature cleans inside the soleplate, removing impurities.
We recommend using it every 10-15 days.
3.4 Storage
If you do not intend to use the appliance for a long time, store it carefully.
•Before lifting the appliance unplug it and then let it cool completely.
•Empty the water reservoir.
•Keep the appliance and its accessories in their original packages.
•Store it in a cool, dry place.
•Always keep the appliance out of the reach of children.
3.5 Handling and transportation
•During handling and transportation, carry the appliance in its original packaging. The
packaging of the appliance protects it against physical damages.
•Do not place heavy loads on the appliance or the packaging. The appliance may be
damaged.
•Dropping the appliance will render it non-operational or cause permanent damage.
For commissioning, general use and cleaning, please observe the instructions
on pages 5-6 of this operating manual.
3 Cleaning and maintenance

18 / EN Steam Iron / User Manual
4 Troubleshooting
Problem Possible Reason Solution
Although the appliance is
plugged in, soleplate (6) does
not heat up.
The appliance may be connected
improperly
Check the plug and power cable
(1) of the appliance.
Temperature adjustment knob (5)
may be at the Min. position.
Turn the temperature adjustment
knob in the clockwise direction
up to the steam sign.
The appliance does not gener-
ate steam.
The water reservoir may not have
enough water.
Fill the water reservoir with water
up to Max level.
Steam setting button (9) may be at
without-steam position.
Switch the steam setting button
to the steam position.
Shock Steam – Vertical Steam
does not function.
These functions may have been
used too frequently in a very short
period of time.
Keep ironing at a horizontal posi-
tion and wait for a while before
using the shock steam function
again.
Soleplate (6) may not be hot
enough.
Turn the Temperature adjust-
ment knob (5) in the clockwise
direction up to the steam sign.
Seat the appliance in a vertical
position and wait for the sole-
plate to heat up.
Water drops fall down onto the
fabric during ironing.
You may not have securely closed
the water refill lid (8).
Close the water refill lid securely.
You may be using the shock steam
at temperature level • or ••.
Increase the temperature level.
During ironing, sediments and
residues fall down from the
soleplate (6).
If the water you use for your appli-
ance is too hard, such sediments
may form.
Use the self-clean function for
once or a few times. For the sub-
sequent ironings fill the water
reservoir of the appliance with a
mixture of tap water and potable
water.
The appliance drops water
after it cools down or stored.
You may have left the appliance
on a horizontal position while
there is water in its reservoir.
Empty the water reservoir.
Stains at the soleplate (6). Wet garments might have been
ironed and the soleplate (6) has
had lime stains.
After the appliance cools
enough, wipe the soleplate with
a microfiber knitted or cotton
cloth soaked in vinegar.

12 months breakdown and repair guarantee
Product Guarantee
Guarantor: Beko plc, 1 Greenhill Crescent, Watford, Hertfordshire. WD18 8UF
The guarantee does not in any way diminish your statutory or legal rights.
Your appliance hasthe benefit of our manufacturer’s guarantee which covers the product for 12 months
from the date of original purchase.
This gives you reassurance thatif within that time, your appliance is proven to be defective because of
either workmanship or materials, we will at our discretion either repair or replace your appliance.
The appliance must be correctly installed, located and operated in accordance with the instructions
contained in the user manual.!The guarantor disclaims anyliabilityfor accidental or consequential damage.
The Guarantee is subject tothe following conditions:
Documentary proof of the original purchase date is provided.
The appliance has been installed and operated correctly and in accordance with our operating and maintenance
instructions.
The appliance is used only on the electricity supply on the rating plate.
The appliance has only been used for normal domestic purposes.
The appliance has not been altered, serviced, dismantled or otherwise interfered with by any person.
The appliance is used in the United Kingdom or Republic of Ireland.
Any parts removed during repair work or any product that has been replaced becomes our property.
The guarantee is not transferrable if the product is resold.
The Guarantee does not cover:
Transit, installation or delivery damage.
Accidental damage.
Misuse or abuse.
Replacement of any consumable item or accessories. These include but are not limited to: plugs, cables, light bulbs,
knobs, filters and flaps.
Repairs or replacements required as a result of unauthorised repairs or inexpert installation that failsto meet the
requirements contained inthe user guide or instruction book.
Repairs to products used in commercial or non-residential household premises.
How to obtain after sales service, help or general advice
Please keep your purchase receipt or other proof of purchase in a safe place as you will need to
show us this document if your product requires attention within the guarantee period.
Please also record your product details below, which will allow you to access our services more quickly and
help us identify your product. The model numberis printed on the front of the user guide and the serial and
model number is shown on your products rating plate.
Model number
Serial number
Purchased from
Date of purchase
Please call our UK based Customer Service department if you need help or advice from us:
United Kingdom and Northern Ireland: 0333 207 9710
Republic of Ireland: 01 862 3411
You can also contact us through our website: www.beko.co.uk

Arçelik A.Ş.
Karaağaç Caddesi No: 2-6, 34445,
Sütlüce, İstanbul, Türkiye
www.beko.com
