Beko SIM7124B User manual

www.beko.com
SIM7124B
01M-8816423200-2619-01
Steam Iron
User Manual
EN

Please read this user manual first!
Dear Customers,
Thank you for selecting a Beko product. We hope that you get the best results
from your product which has been manufactured with high quality and state-
of-the-art technology. Therefore, please read this entire user manual and all
other accompanying documents carefully before using the product and keep
it as a reference for future use. If you handover the product to someone else,
give the user manual as well. Follow all warnings and information in the user
manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
C
Important information and
useful hints about usage.
A
WARNING: Warnings
for dangerous situations
concerning the safety of
life and property.
WARNING: Warning for
hot surfaces.
Risk or burning and scald-
ing due to steam.
This product has been produced in environmentally-friendly, state-of-the-art facilities.
It does not contain PCB.Conforms to the WEEE Directive.

3 / EN
Steam Iron / User Manual
CONTENTS
ENGLISH 4-16

4 / EN Steam Iron / User Manual
This section contains safety instructions that will help
protect from risk of personal injury or property dam-
age.
Failure to follow these instructions invalidates the
granted warranty.
1.1 General safety
• This appliance complies with the international
safety standards.
• This appliance may be used by children who are
at the age of 8 or over and the people whose
physical, perceptive or mental skills are impaired
or who are inexperienced or not knowledgeable
about the appliance as long as they are super-
vised or informed and made understood the
safe use of the appliance and the encountered
dangers. Children should not play with the ap-
pliance. Cleaning and user maintenance pro-
cedures should not be performed by children
unless they are controlled by their elders.
1Important instructions for safety
and environment

5 / EN
Steam Iron / User Manual
1Important instructions for safety
and environment
• Do not leave the product unattended while it is
plugged in.
• Unplug the product before filling the water res-
ervoir with water.
• Operate and store the appliance on a stable sur-
face.
• When the appliance is placed on its base plate,
ensure that the surface beneath the plate is
level.
• Do not use the appliance if the power cable or
the appliance itself is damaged. Contact an au-
thorised service.
• If the appliance is dropped or leaks water or has
other failures, contact the authorised service.
Do not use the appliance until it is repaired.
• When the appliance is not in use or left to cool
down keep the appliance and power cable out
of reach of children under 8 years old.
• The appliance is not suitable for using outdoors.

6 / EN Steam Iron / User Manual
• Only use the original parts or parts recom-
mended by the manufacturer.
• Do not attempt to dismantle the appliance.
• Your mains power supply should comply with
the information supplied on the rating plate of
the appliance.
• The mains supply of the appliance must be se-
cured with a minimum 16 A fuse.
• Use the appliance with a grounded outlet only.
• Do not use the appliance with an extension
cord.
• Do not pull the power cable when unplugging
the appliance.
• Unplug the appliance before cleaning it.
• Do not wrap the cable around the appliance.
• Do not touch the appliance or its plug with wet
or damp hands when the appliance is plugged
in.
1Important instructions for safety
and environment

7 / EN
Steam Iron / User Manual
• The soleplate and its surrounding area can be
extremely hot. Contacting hot surfaces may
cause burns. Therefore while or just after using
the appliance, pay attention not to touch the
hot surfaces.
• Never use the appliance in or near to combusti-
ble or inflammable places and materials.
• If you keep the packaging materials, store them
out of the reach of children.
• For detailed information on cleaning the appli-
ance, please refer to the section Cleaning and
maintenance.
1Important instructions for safety
and environment

8 / EN Steam Iron / User Manual
1.2 Complance wth WEEE Drectve and
Dsposng of the Waste Product
This product complies with EU WEEE Directive (2012/19/EU). This product
bears a classification symbol for waste electrical and electronic equipment
(WEEE).
This symbol indicates that this product shall not be disposed
with other household wastes at the end of its service life. Used
device must be returned to offical collection point for recycling
of electrical and electronic devices. To find these collection sys-
tems please contact to your local authorities or retailer where
the product was puchased. Each household performs important role in re-
covering and recycling of old appliance. Appropriate disposal of used appli-
ance helps prevent potential negative consequences for the environment
and human health.
1.3 Complance wth RoHS Drectve
The product you have purchased complies with EU RoHS Directive
(2011/65/EU). It does not contain harmful and prohibited materials speci-
fied in the Directive.
1.4 Package nformaton
Packaging materials of the product are manufactured from recy-
clable materials in accordance with our National Environment
Regulations. Do not dispose of the packaging materials together
with the domestic or other wastes. Take them to the packaging
material collection points designated by the local authorities.
1Important instructions for safety
and environment

9 / EN
Steam Iron / User Manual
2.1 Overvew
The values whch are declared n the markngs affxed on your applance or the other prnted documents suppled wth t
represent the values whch were obtaned n the laboratores pursuant to the pertnent standards. These values may vary
accordng to the usage of the applance and ambent condtons.
2Your ron
1. Power cable
2. Iron base plate
3. Temperature adjustment knob
4. Soleplate
5. Water spray nozzle
6. Water refill lid
7. Steam setting and lime removal
button
8. Water spraying button
9. Shock steam button
10.Thermostat indicator and Auto-
Off light
2.2 Techncal data
Voltage: 220-240V~ 50-60Hz
Power consumpton :
2020-2400 W
Shock steam amount:
up to 150 g/min
Insulaton class: I
Technical and design modification
rights are reserved.
1
2
3
4
5
6
7
8
910

10 / EN Steam Iron / User Manual
3.1 Intended use
This appliance is intended only for
household use and ironing; it is not
suitable for professional use.
3.2 Intal use
Prior to initial use, fill twice (see
3.3) and vaporize to remove the
manufacturing residues (see 3.6).
Meanwhile, use shock steam button
(9) frequently.
C
You can smell a mild
odour or see white
sediments coming
out of the soleplate
(4) holes. After per-
forming vaporizing
process twice, such
odours and sedi-
ments will disappear.
Also water droplets
may form within the
water reservoir; this is
normal.
3.3 Refllng the water
reservor
1. Unplug the applance.
2. Steam setting button (7) off Set
to “ ” position.
3. Fill the water cup provided with
the appliance.
4. Open the water refill lid (6) and
fill the appliance with water up
to MAX level.
5. Close the water refill lid (6).
C
Your appliance is de-
signed for use with
tap water. If your tap
water is excessively
hard, we recommend
you to use a mixture
of tap water with po-
table water.
3.4 Settng the
temperature
1. After the applance s plugged n,
set the temperature accordng
to the type of your fabrc by
turnng the temperature settng
knob (3) n clockwse drecton
(see. 3.5).
- Thermostat ndcator lght (10)
wll lght up.
2. When the appliance reaches the
set temperature, thermostat in-
dicator light (10) will turn off and
the appliance is ready to use.
3Operaton

11 / EN
Steam Iron / User Manual
3.5 Temperature and
steam settngs table
When setting the temperature of
the appliance, consider the follow-
ing table.
Fabric
Type
Tempera-
ture Setting
Steam
Setting
Synthetic •Without
steam
Silk •Without
steam
Woolen •• Without
steam
Cotton ••• With steam
Linen - Jean Max With steam
AWARNING:
Before
ironing first check the
label of the garment.
C
If you don’t know the
fabric of your gar-
ment, first iron an
invisible part of your
garment and deter-
mine a correct ironing
temperature for it.
C
In order to prevent the
bright stains that may
form on the synthetic
fabrics such as silk,
iron on the reverse
side of the fabric. Do
not use the water
spraying feature in
order to prevent the
stain formation.
3.6 Steam ronng
1. Fll the water reservor (see. 3.3).
2. Set the appropriate temperature
with the temperature setting
knob (see 3.5).
3. Set the steam setting button (7)
to “ ” position.
4. After the thermostat indicator
light (10) switches off you can
start steam ironing.
3Operaton

12 / EN Steam Iron / User Manual
3.7 Shock steam
C
When you start to
iron, shock steam may
not emit in your first
couple of presses. In
order to obtain shock
steam, the tempera-
ture setting knob (3)
should be at or above
the “•••” level.
1. Fll the water reservor (see. 3.3).
2. Set the temperature setting
knob (3) to max. position by turn-
ing it in the clockwise direction.
- Thermostat ndcator lght (10)
wll lght up.
3. When the appliance reaches the
set temperature, thermostat in-
dicator light (10) will turn off.
4. After the thermostat indicator
light (10) turns off, you can iron
the garments with the power-
ful steam by pressing the shock
steam button (9).
A
WARNING: If this
process is maintained
for a prolonged time
water may come
through the soleplate
(4) together with
steam.
C
In order to maintain
ideal shock steam
quality, set the steam
setting button (7) to
the OFF “ ” position.
A
WARNING: In or-
der to use the shock
steam feature the
thermostat indicator
light (10) should be
turned off.
3.8 Vertcal steam
You can also use the shock steam
in upright position (see. 3.7). By
pressing the shock steam button
(9), you can iron your curtains and
your garments on the hanger with
the steam you will get by pressing
the shock steam button. Hold the
appliance 15-30 cm away from the
garment and curtains.
3Operaton

13 / EN
Steam Iron / User Manual
A
WARNING: During
the ironing if the
thermostat indicator
light (10) turns on,
before proceeding
with the shock steam
process wait for the
light to turn off.
AWARNING:
Never
direct this steam to
people or pets.
3.9 Sprayng water
1. Fll the water reservor (see. 3.3).
2. Set the temperature (see. 3.5).
3. Press the water spraying button
(8) to spray water.
C
You can easily remove
creases using the wa-
ter spraying feature.
3.10 Dry ronng
In order to make dry ironing, set the
steam setting button (7) to the OFF
“ ” position.
C
Having water in the
appliance would be
advantageous; you
may use the water
spraying button (8)
when necessary.
3.11 Automatc
Shutdown (Auto-Off)
•If the appliance is hold stationary
for 30 seconds while in horizontal
position, it will be automatically
turned off.
•If the appliance is hold stationary
for 7-10 minutes while in upright
position, it will be automatically
turned off.
•If the appliance is hold stationary
for 30 seconds while in a leaned
(right or left) position, it will be
automatically turned off.
C
In case of automatic
turn off the auto-off
light (10) flashes.
•Iftheapplianceismoved in horizontal
position it will be turned on.
C
It may take 60 seconds
for the soleplate (4) to
reach the previously
set temperature.
3Operaton

14 / EN Steam Iron / User Manual
4.1 Cleanng
A
WARNING: When
you are finished with
ironing, unplug the
appliance. You can
drain the water in the
reservoir by opening
the refill lid (6) and
tilting the iron to the
front.
1. Unplug the applance before
cleanng.
2. Wait for the appliance to cool
down completely.
3. Use a slightly damp cloth to clean
the outer surface of the appli-
ance. Then dry it thoroughly.
4. Wipe the sediments and resi-
dues on the soleplate (4) with
a slightly damp cloth and soft,
nonabrasive liquid cleaner as
necessary.
A
WARNING: Do not
use gasoline, solvent
and abrasive cleaning
agents or hard brush
to clean the appli-
ance.
4.2 Lme removal (Self-
Clean)
Lime removal function cleans the
lime particles accumulated in the
steam generator reservoir of the
appliance.
Use this function once in every 2
to 3 weeks. If the tap water is very
hard (if lime particles fall down from
the soleplate (4) of the appliance),
use the lime removal function more
frequently.
1. Unplug the applance.
2. Refill the appliance with water
(see. 3.3).
3. Steam setting button (7) off Set
to “ ” position.”
4. Plug in the appliance and set the
temperature setting knob (2) to
max. position by turning it in the
clockwise direction.
5. When the thermostat indicator
light (10) turns off, unplug the
appliance.
6. Keep the iron in horizontal posi-
tion over the sink and hold the
lime removal button (7) at self-
clean “ ” position and shake
the iron. Continue until the water
in the reservoir is depleted.
4Cleanng and mantenance

15 / EN
Steam Iron / User Manual
C
It may take some time
for the water to drip
from the holes of the
soleplate.
7. After the reservoir becomes fully
empty, release the lime removal
button (7).
8. If there is still sediment, repeat
this process.
9. Following the lime removal pro-
cess, let the appliance cool in
upright position. After the ap-
pliance cools down, wipe off the
soleplate (4) with a cloth.
4.3 Storage
If you do not intend to use the ap-
pliance for a long time, store it care-
fully.
•Before lifting the appliance un-
plug it and then let it cool com-
pletely.
•Empty the water reservoir.
•Keep the appliance and its acces-
sories in their original packages.
•Store it in a cool, dry place.
•Always keep the appliance out of
the reach of children.
4.4 Handlng and
transportaton
•During handling and transporta-
tion, carry the appliance in its
original packaging. The packag-
ing of the appliance protects it
against physical damages.
•Do not place heavy loads on the
appliance or the packaging. The
appliance may be damaged.
•Dropping the appliance will ren-
der it non-operational or cause
permanent damage.
4Cleanng and mantenance

16 / EN Steam Iron / User Manual
5Troubleshootng
Although the appliance is plugged in, soleplate (4) does not heat up.
The appliance may be connected improperly. >>> Check the plug and power cable (1) of the appliance.
Temperature setting knob (3) may be at the Min. position. >>> Turn the temperature setting knob in
the clockwise direction up to the steam sign.
The appliance does not generate steam.
The water reservoir may not have enough water. >>> Fill the water reservoir with water up to Max
level (see. 3.3).
Steam setting button (7) may be at without-steam position. >>> Switch the steam setting button to
the steam position (see. 3.6).
Shock Steam – Vertical Steam does not function.
These functions may have been used too frequently in a very short period of time. >>> Keep ironing
at a horizontal position and wait for a while before using the shock steam function again. >>>
Soleplate (4) may not be hot enough. Turn the temperature setting knob (3) in the clockwise direction
up to the steam sign. Seat the appliance in a vertical position and wait for the soleplate to heat up.
Water drops fall down onto the fabric during ironing.
You may not have securely closed the water refill lid (6). >>> Close the water refill lid securely.
You may be using the shock steam at temperature level • or ••.
>>> Increase the temperature level (see. 3.7).
During ironing, sediments and residues fall down from the soleplate (4).
If the water you use for your appliance is too hard, such sediments may form. >>> Use the self-clean
function for once or a few times (see. 4.2). For the subsequent ironings fill the water reservoir of the
appliance with a mixture of tap water and potable water.
The appliance drops water after it cools down or stored.
You may have left the appliance on a horizontal position while there is water in its reservoir. >>>
Empty the water reservoir.
Stains at the soleplate (4).
Wet garments might have been ironed and the soleplate (4) has had lime stains. >>> After the
appliance cools enough, wipe the soleplate with a microfiber knitted or cotton cloth soaked in vinegar.

55 Blanck Street, Ormeau Q 4208
P O Box 354, Ormeau Q 4208
p : 5549 3146 f : 5549 3546
ABN : 49 152 055 162
Sensitivity: Public
ORIGINAL MANUFACTURER’S WARRANTY
ADVICE FORM
BEKO SMALL DOMESTIC APPLIANCE
12 months warranty, full parts and labour warranty only.
WARRANTY CONDITIONS
The following conditions apply only in relations to the warranty expressly given on this Warranty Advice Form supplied with the product. This
warranty only applies to appliances purchased and used in Australia or New Zealand and is in addition to (and does not exclude, restrict or
modify in any way) other rights and remedies under a law to which the appliances relate, including any non-excludable statutory guarantees in
Australia and New Zealand. It applies to the original purchaser and for appliances used in domestic applications only.
1. This warranty does not apply:
(a) if the identification number attached to the appliance has been altered, rendered illegible or removed;
(b) to light globes;
(c) to paint and vitreous enamel finishes and glass;
(d) to surfaces damaged by use of aerosols or cleaners;
(e) if the appliance has been –
(i) subject to misuse, abuse, negligence, accident, fire or floods;
(ii) connected or improper, inadequate or faulty electricity, gas, water or drainage services or intake or exhaust
ducts or flues, or operated using incorrect or contaminated fuels or lubricants;
(iii) installed, maintained or operated otherwise than in accordance with the instructions furnished by Beko including the
improper use of detergents, bleaches, cleaners or other additives;
(iv) damaged by foreign objects in the appliance;
(v) serviced, repaired or altered otherwise than by Beko authorised service agents of Beko, or using other than Beko
approved replacement parts.
2. The purchaser shall be responsible for any expenses involved in making the appliances readily accessible for servicing, the purchaser
shall be responsible for any costs of transporting the appliance or parts thereof to and from the nearest Beko authorised service agent.
3. This warranty is the only expressed warranty given by Beko.
4. Beko reserves the right to determine whether or not the fault is caused by faulty workmanship or material or that any part is defective.
5. Where permitted by law, this warranty shall not apply to loss suffered through or resulting from the non-operation or the ineffective
operation of the appliance or any part of the appliance.
6. The purchaser must produce proof of the date of purchase together with this Warranty Advise Form when making a claim.
7. Subject to your statutory rights as to the merchantable quality of the product or accessory. In the event of a product or accessory being
replaced during the guarantee, the guarantee on the replacement will expire at the original date, i.e., 12 months from the original
purchase date.
8. Australia: For Appliances and services provided by Beko in Australia, Beko goods come with a guarantee by Beko that cannot be
excluded under the Australian Consumer Law. You are entitled to a replacement or refund for a major failure and for compensation for
any other reasonably foreseeable loss or damage. You are also entitled to have the Appliance repaired or replaced if the Appliance
fails to be of acceptable quality and the failure does not amount to a major failure. ‘Acceptable quality’ and ‘major failure’ have the
same meaning as referred to in the Australian Consumer Law.
9. New Zealand: For Appliances and services provided by Beko in New Zealand, the Appliances come with a guarantee by Beko
pursuant to the provisions of the Consumer Guarantees Act, the Sales of Goods Act and the Fair Trading Act. Where the Appliance
was purchased in New Zealand for commercial purposes the Consumer Guarantee Act does not apply.
These Warranty Conditions supersedes and excludes all other representations, conditions and warranties, except those implied
by legislation previously referred to.
For Service or Spare Parts: Aust 1300 282 356 NZ 0800 692 356

www.beko.au
