GENERAL
For genuine Bendix remanufactured compressors not
equipped with a drive gear, it is necessary to remove the
existing gear from the old compressor and reinstall it on the
new remanufactured compressor.
NOTE: It may be necessary to remove the ttings from the
cylinder head prior to removing the gear to prevent damage.
IMPORTANT
The Bendix remanufactured compressor is equipped with
a new safety valve. Do not reuse the old safety valve.
KIT COMPONENTS
• Genuine Bendix remanufactured BA-921 Compressor
(including safety valve)
GEAR REPLACEMENT PROCEDURE
1. After removing the old compressor from the engine,
place the compressor with drive gear facing upward so
it can be removed safely. NOTE: It may be helpful to
secure the compressor and gear so that the gear does
not rotate and the lock nut can be removed more easily.
See Figure 1.
Figure 1 – Remove the Bendix®BA-921®Compressor
Bendix®BA-921®Compressor Gear Replacement for Detroit®Diesel Corporation (DDC)
Engines DD13®and DD15®
