Tot Mate TM2224R User manual

1
#0964-3132
3594.TM2224/TM2226.11/1/18
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.
CAUTION – CHOKING HAZARD
Adult assembly required due to presence
of small parts and sharp edges.
ATTENTION
Please unpack and assemble in an area away from children's activities. Remove all tools
and excess materials from work area after assembly of unit is complete. Dispose of pallet
and packaging materials in an environmentally friendly manner. If any parts are missing
or damaged, please call Stevens for immediate parts replacement (1-800-350-3270).
When ordering parts, give the Model Number and Color of the unit.
by Stevens Industries, Inc.
704 West Main St.
Teutopolis, IL 62467
P: 800.350.3270
P: 217-857-7100 • F: 217-857-7101
www.totmate.com
TM2224R
TM2226R
TM2224R
Toddler Shelf Storage – Double Sided
NOTE: ASSEMBLY INSTRUCTIONS REFERENCE
ILLUSTRATIONS AND PART NUMBERS FOR THE TM2224R.
076,QYHQWRU
\
3DUWV/LVW3DUWV/LVW
3$5747<,7(0
;;
;;
;;

'(6&5,37,21
7RS%RW
(QG8
%DFN
6FUHZ&RQQ+['F1LPP[PP
TM2226R
Preschool Shelf Storage – Double Sided
076,QYHQWRU
\
3DUWV/LVW3DUWV/LVW
3$5747<,7(0
;;
;;
;;

'(6&5,37,21
%DFN
7RS%RW
(QG8
6FUHZ&RQQ+['F1LPP[PP

TM2224R – TM2226R
STEP-BY-STEP ASSEMBLY
2#0964-3132
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2224/TM2226.11/1/18
076,QYHQWRU
\
3DUWV/LVW3DUWV/LVW
TM2224R
3$5747<,7(0
;;
;;
;;

'(6&5,37,21
7RS%RW
(QG8
%DFN
6FUHZ&RQQ+['F1LPP[PP
ILLUSTRATIONS AND PART NUMBERS ARE FOR TM2224R.
BASIC ASSEMBLY INSTRUCTIONS ARE THE SAME FOR BOTH MODELS.
2-PERSON ASSEMBLY RECOMMENDED.
IMPORTANT!
Be sure to keep all parts supported during assembly to avoid damage.
Do not over-tighten screws or it will damage the pre-drilled holes;
snug fit is adequate.
HARDWARE / TOOLS INCLUDED
Confirmat Bolt (4)
(Screw Conn HxDc Ni 7mmx50mm)
Hex Wrench
edgebanding
seam
hole
not used

TM2224R – TM2226R
STEP-BY-STEP ASSEMBLY
3
#0964-3132
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice.3594.TM2224/TM2226.11/1/18
Lay one End (2) flat on floor, with side having the
most holes facing up. IMPORTANT: Edgebanding
seam must be on the bottom of the unit when
assembly is complete.
STEP
1
Insert dowels on Top-Bottoms (1) into the upper,
lower and center sets of holes on End (2). Press
firmly into place.
STEP
2
Insert dowels on Backs (3) into the remaining
holes on End (2), between Top-Bottoms (1).
Press firmly into place.
STEP
3
Position other End (2) on top of assembly, so
dowels on Top-Bottoms (1) and Backs (3) align
with holes on End (2). Make sure edgebanding
seam on End (2) is facing bottom of unit.
Edgebanding seam on both Ends (2) must be
facing same direction. Press firmly into place.
STEP
4
Secure End (2) to Top-Bottoms (1) and Backs (3)
with eight Confirmat Bolts (4), using the included
Hex Wrench.
STEP
5

TM2224R – TM2226R
STEP-BY-STEP ASSEMBLY
4#0964-3132
©2018 Stevens Industries, Inc.
Due to continuing product development, Stevens reserves the right to change specifications without notice. 3594.TM2224/TM2226.11/1/18
Carefully stand unit upright. Make sure
edgebanding seams on Ends (2) are on bottom of
unit.
STEP
9
Ensure that all joints and bolts are tight.
STEP
10
This completes the assembly.
Repeat Step 5 to secure End (2) to Top-Bottoms
(1) and Backs (3).
STEP
8
Secure upper and lower Top-Bottoms (1) to
Backs (3) with two Confirmat Bolts (4).
STEP
6
Carefully turn unit over, so other End (2) is facing
up.
STEP
7
edgebanding
seam
