BestScope BS-3015 Series User manual

Stereo Microscope
BS-3015 Series
User Manual
It is recommended strongly that you study this manual thoroughly before using the
microscope. Retain this manual in an easily accessible place near the work desk for future
reference.

BestScope International Limited
1
CONTENT BS-3015
User notice..................................................................2
1. Components ...........................................................4
2. Assembly ................................................................5
2.1 Assembly Diagram ...........................................5
2.2 Detailed Assembly Procedure ..........................6
3.Adjustment and Operation .......................................8
3.1 Adjusting Binocular Viewing Head....................8
3.2 Focus Adjusment..............................................9
4. Main specifications ...............................................10
5. Troubleshooting ....................................................11
6. Outfit .....................................................................12
BS-3015 系列 体视显微镜
使用说明书

BestScope International Limited
2
User notice BS-3015
1. Application
This microscope is ideal for science educators, industrial enterprise, scientists and
practitioners.
2. Safety Precaution
1. Carefully open the box, avoid the accessories, like lens, dropping to ground and
being damaged.
2. Check the input voltage, be sure the input voltage which signed on the microscope is
consistent with the power supply voltage, or it will bring a serious damage to the
instrument.
3. Do keep the instrument out of direct sunlight, high temperature or humidity, dusty and
easy shaking environment. Make sure the stage is smooth, horizontal and firm
enough.
4. To prevent the microscope body from turning over, its pivot angle must be limited to
30°.
5. .A microscope is a precision instrument. Handle it with care and avoid subjecting it to
sudden or severe impact.
6. Make sure the instrument is earthed, to avoid lighting strike.
7. Do not disassemble any part of the microscope, especially the electrical parts on the
bottom side as this may result in electric shock.
8. Use the factory supplied power cord, please.
9. Warning against electric shock.
10. Warning: before use, carefully read the manual .improper use could result in
personal injury to the user and/or damage to the equipment.
3. Maintenance and Storage
1. All the lenses have been well checked and adjusted. It is forbidden to disassemble
them yourself.
2. The binocular viewing head and focusing unit have a compact and precise frame;
please don’t disassemble them as possibly as you can.
3. Keep the instrument clean, wipe dust regularly, and be attention to avoid
contaminating the optical elements especially.
4. The contaminations on the prism, as fingerprint and oil, could be gently wiped with a
piece of soft cloth or tissue paper, gauze which has been immersed in pure alcohol or

BestScope International Limited
3
ether. (Note that the alcohol and ether are highly flammable, do keep them away
from the fire or potential sources of electrical sparks, and use them in a drafty
room as possible as you can.)
5. Do not attempt to use organic solvents to clean the microscope components other
than the glass components. To clean them, use a lint-free, soft cloth slightly
moistened with a diluted neutral detergent.
6. If the microscope is splashed by liquid during using, cut off the power at once, and
wipe up the moisture.
7. Do not disassemble any parts of the microscope, which will affect the function or
decline the performance of the microscope.
8. Place the instrument in a cool, dry position. When not using the microscope, keep it
covered with a dust cover.

BestScope International Limited
4
Stereo Microscope BS-3015
1. Components
2. 安装 BS-3015
Stereo microscope BS-3015
WF10×eyepieces
Diopter ring
Clamping knob
Standard base
Glass stage
Stand
Focusing knob
Power cord
Brightness adjusting knob
Binocular head and zoom body

BestScope International Limited
5
2. Assembly
2.1 Assembly Diagram
The diagram below shows how to assemble the various modules. The numbers indicate the
order of assembly.
★When assembling the microscope, make sure that all parts are free of dust and dirt, and
avoid scratching any parts or touching glass surfaces.
Microscope Main Body
③
双目变倍镜体
10×目镜
①
电源线
④
②
Binocular head and zoom body
WF10×eyepieces
Power cord

BestScope International Limited
6
BS-3015
2.2 Detailed Assembly Procedure
2.2.1 Mounting binocular head
(Fig.1)
Loose the clamping bolt③on the
pillar④and insert the binocular head and
zoom body assembly②into the bracket of
the pillar, then screw down the bolt③.
2.2.2 Mounting eyepieces (Fig.1,
Fig.2, Fig.3)
Remove the eyepiece dust caps①and
gently insert two adjustable eyepieces ⑤
into the eyepiece sleeves until they stops,
as in Fig.3.
2.2.2 安装目镜(图1、图 2、图 3)
请拆除双目变倍镜体②上的防护盖①，
将2个10 倍大视场视度可调目镜⑤插入目镜
管中，直插到端面靠上。装好后如图 3所示。。
Fig.2
⑤
Fig.1
④
③
①
②
Fig.3
Note:
Working Environment Requirement:
1. Ambient temperature: 5℃to 40℃. (41℉
to 104℉), Maximum R.H: 85%.
2. High Temperature will result in a
mildewing, dew and even ruinous
instrument.
3. Avoid placing the instrument in a dusty
environment. When ending your
microscope operation, please cover it
with the dust cover.
4. Lay the microscope horizontally in a
stable place please.
Fig .1

BestScope International Limited
7
BS-3015
2.2.3 Connecting the power cord (Fig.4)
1. Rotate the left and right brightness adjusting
switches①clockwise until the off state before
connecting the power cord②.
2. Insert the power plug②into the power jack of
the microscope; make sure the connection is
well.
3. Plug the power cord③into the power supply
receptacle safely. Make sure the connection is
well.
Adjustable illumination for both LEDs (top
and bottom).
Input Rating:110V～240V.
Trinocular head is optional if video or
photography function is needed.
2.2.4 Video (Photography) accessories
assembly (Fig.5, Fig.6)
1. Installing the video set: Remove the dust cap
of the trinocular viewing tube, revolve the camera
set ⑤into the screw thread end of the video
adapter④with C mount, and insert the other end
into the tri-through port and screw down the bolt⑥.
2. Installing the photography set: Remove the dust
cap of the trinocular viewing tube, install the
photography accessories⑦into the tri-through
port, and screw down the locking bolts⑥, change
the camera⑨gun with digital photography
adapter⑧, and insert the adapter into the
accessories, as in Fig 6.
2.2.5 Built-in digital accessories
Connect the built-in digital accessories with the
USB port of the computer by USB cable and
install the driver and software to use it.
Fig.4
①
③
②
Fig.6
⑥
⑦
⑨
⑧
Fig.5
⑤
⑥
④

BestScope International Limited
8
3. Adjustment and Operation BS-3015
3.1 Adjusting Binocular
Viewing Head
3.1.1 Adjusting interpupillary
distance (Fig.7)
Different users have different
interpupillary distances. So when users
change, re-do the interpupillary distance
adjustment.
Looking through the eyepieces, hold the
left and right side of the binocular
assembly①and adjust the eyepieces by the
direction shown in Fig.7until the left and right
fields of view coincide completely.
3.1.2 Adjusting diopter ring (Fig.8)
1. Set the dioptor rings of both eyepieces to
“o” point. (Do this when users change,
because different users have different
diopters.)
2．Place an easy-to-observe specimen on the
stage plate.
3．Rotate the zoom body knob③to get the
highest magnification, and turn the
focusing knob④to focus the specimen.
4．Rotate the zoom body knob③to get the
lowest magnification, looking only into
the left eyepiece, adjust the diopter
ring②on left eyepiece to focus the
specimen. Then do the same adjustment
for the right one.
5．Repeat steps 3 and 4 until the specimen
image can always focus without any
adverse effect of the changes of
magnification on the definition of the
image.
Fig.7
①
Fig .8
②
⑤
④
③

BestScope International Limited
9
3.2 Focus Adjustment
3.2.1 Adjusting the rotation tension of
the focusing knob (fig.9, fig.10)
1．Rotate the focusing knob①to move the
slider②to a lower position for fear that the
zoom body drops down suddenly if the
tension is decreased too much.
2．Hold the focusing knobs①with both hands,
stop the left knob and rotate the right knob
to increase or decrease the focus knob
tension.
3. Rotate both the focusing knobs in the same
direction (otherwise it will get loose) to
move the zoom body up and down to focus
on the specimen.
3.2.2 Changing the magnifications
1. The zooming knobs located at two sides of
the zooming body could change the
magnification of the specimen image.
2. Total Magnification = Magnification of
zoom body magnification of eyepiece.
Note: While using the auxiliary objective, it
should be multiplied by its magnification
in addition.
3.2.3 Illumination
1. Use LED lamps for both top and bottom
illumination.
2. Brightness adjustment (Fig.10): the right
brightness adjustment knob③is used to
adjust the bottom illumination, and the left
brightness adjustment knob④is used to
adjust the top illumination. Each knob has
its own on-off. Rotate anticlockwise to open
the power and increase the brightness,
keeping rotating clockwise would decrease
the brightness until it is power off.
③
Fig.10
④
Fig.9
②
①

BestScope International Limited
10
4. Main specifications BS-3015
4.1 Electrical parameters:
Input Voltage: AC 110V~240V 50HZ/60HZ
Power rating: 15W
Top Illuminator: 1W Bottom illuminator: 0.5W
4.2 Binocular viewing head: Inclined at 45, interpupillary distance range: 55～75mm
4.3 Illumination system: LED lamps for both top and bottom illumination
Eyepiece
10×
Field Number 23mm
15×
Field Number 14mm
20×
Field Number 11mm
Auxiliary
objective
Working
distance
(mm)
Magnification
Actual
field
Magnification
Actual
field
Magnification
Actual
field
None
100
10×, 30×
Φ2.3
Φ0.77
15×, 45×
Φ0.93
Φ0.31
20×, 60×
Φ0.55
Φ0.18
0.5×
180
5×, 15×
Φ4.6
Φ1.53
7.5×, 22.5×
Φ1.87-
Φ0.62
10×, 30×
Φ1.1
Φ0.36
0.75×
120
7.5×, 22.5×
Φ3.06
Φ1.02
11.3×, 33.8×
Φ1.24
Φ0.41
15×, 45×
Φ0.73
Φ0.24
2×
30
20×, 60×
Φ1.15
Φ0.38
30×, 90×
Φ0.47
Φ0.16
40×, 120×
Φ0.28
Φ0.09
Eyepiece
10×
Field Number 23mm
15×
Field Number 14mm
20×
Field Number 11mm
Auxiliary
objective
Working
distance
(mm)
Magnification
Actual
field
Magnification
Actual
field
Magnification
Actual
field
None
100
20×, 40×
Φ1.15
Φ0.58
30×, 60×
Φ0.47
Φ0.23
40×, 80×
Φ0.28
Φ0.14
0.5×
180
10×, 20×
Φ2.3
Φ1.15
15×, 30×
Φ0.93-
Φ0.47
20×, 40×
Φ0.56
Φ0.28
0.75×
120
7.5×, 30×
Φ1.53
Φ0.78
22.5×, 45×
Φ0.62
Φ0.31
30×, 60×
Φ0.37
Φ0.18
2×
30
40×, 80×
Φ0.58
Φ0.29
60×, 120×
Φ0.23
Φ0.12
80×, 160×
Φ0.14
Φ0.07
BS-3015/13
BS-3015/24

BestScope International Limited
11
5. Troubleshooting
Under certain conditions, performance of this unit may be adversely affected by factors
other than defects. If a problem occurs, please review the following list and take remedial
action as needed. If you cannot solve the problem after checking the entire list, please contact
your local franchiser for assistance.
PROBLEM
CAUSE
SOLUTION
Interpupillary distance is
not correctly adjusted.
Adjust it correctly
1. Incomplete binocular vision.
Diopter adjustment is
incomplete.
Complete diopter adjustment
Dirt on specimen
Clean specimen
2．Dirt is visible in field of view
Dirt on eyepiece
Clean eyepiece
3．The visibility of the image is
poor.
Dust on objective front
lens.
Clean lens surface
Diopter ring is not
correctly adjusted.
Adjust it correctly.
4. Specimen image blurs
when zoom magnification is
changed.
Not in complete focus on
specimen.
Focus specimen correctly at a high
magnification.
5．Coarse focus adjustment
knobs rotate with too much
resistance.
Tension adjustment ring
is too tight.
Loosen it properly.
6．Zoom microscope body
drops or specimen goes out
of focus during observation.
Tension adjustment ring
is too loose.
Tighten it properly.

BestScope International Limited
12
6. Outfit
Components
Specification
Quantity
Outfit
Main body
Main body
1
●
Binocular head and zoom body
1
●
Trinocular head and zoom body
1
○
Observation
system
Built-in digital zoom body
1
○
Transmitted illuminator (LED)
1
●
Illuminator
Reflected illuminator (LED)
1
●
10×/ Ф23mm Eyepiece
2
●
10× Eyepiece with reticle inside
1
○
15×Eyepiece
2
○
Eyepiece (diopter
adjustable)
20×Eyepiece
2
○
0.5×objective
1
○
0.63×objective
1
○
0.75×objective
1
○
Auxiliary objective
2×objective
1
○
Digital camera
1
○
Camera adapter
1
○
Stage plate
Glass plate
1
●
Power cord
Power cord
1
●
●: Standard Outfit; ○: Optional
