BestScope BS-3030 Series User manual

BS-3030 Series
Zoom Stereo Microscope
Instruction Manual
BS-3030A BS-3030AT BS-3030B BS-3030BT BS-3030C BS-3030CT
This instruction manual is for the stereo microscope BS-3030 series. To ensure the safety and
obtain optimum performance and familiarize yourself fully with the use of this microscope, we
recommend that you read this manual thoroughly before operating the microscope. Please keep
this instruction manual in an easily accessible place near the microscope for future reference.

BestScope International Limited
CONTENT BS-3030
Before use.........................................................................1
1.Nomenclature.....................................................................2
2.Assemblage........................................................................3
3.Operation
3-1.Use the black and white work board...............................4
3-2. Adjust the degree of tightness of the focusing arm.........4
3-3.Set the specimen slide...................................................4
3-4.Adjust the specimen slide..............................................4
3-5.Adjust the interpupillary distance....................................5
3-6.Mount and remove the optional eyepiece micrometer......5
3-7.Use auxiliary objective...................................................5
3-8.Mount C type photo set and TV set.................................5
3-9.Adjust the focus of TV set..............................................5
4.USE Microscope base
(1)Nomenclature..................................................................6
(2)Operation........................................................................6
5.Technical parameter............................................................7
6.Troubleshooting..................................................................8

BestScope International Limited
1
BEFORE USE BS-3030
Operation
1) As microscope is a precision instrument, handle with care, avoiding impact or
abrupt movement during transportation.
2) Microscope ought to be placed in a dry and clean place. Do not expose the
microscope in the sun directly. Avoid high temperature and violent vibration.
Usually, following environment is required indoor temperature: 0°C - 40 °C, Max.
relative humidity:85%.
3) To keep the image clear, do not leave fingerprints or stains on the surfaces of
the lens.
4) Before use, please check the power supply in compliance with the microscope
power required.
5) Never turn the left and right focusing knob in the adverse direction at the same
time, otherwise the microscope will be damaged.
6) When use photo set to capture image, please ensure the stability of microscope,
make sure the main body inclined less than 3°.
7) When use camera with C-mount, the camera sensor size should be less than
2/3”, weight not more than 2.5kg.
Maintenance
1) All lenses must be kept clean. Fine dust on the surface of the lens should be
blown off with hand blower or wiped off gently with a soft lens tissue;
Fingerprints or oil marked on it should be wiped off with a tissue moistened with
a small amount of xylene or a 3:7 mixture of alcohol and ether.
2) Never use the organic solution to clean the other surface (especially the plastic
surfaces). If necessary, please choose the neutral detergent.
3) Do not take the microscope apart for fearing that it is damaged.
4) After using, cover the microscope with the dust-cover provided and store it in a
dry and clean place free from moisture to prevent rust.

BestScope International Limited
2
1. Nomenclature
Eyepiece
Head lock
screw
Zoom control knob
Focusing
Head
Base
Clip
Black and white work board
Lock
screw
C-mount
Focusing ring
PK-mount

BestScope International Limited
3
2. Assemblage
The following diagram for the installation, the number representatives the order.
Before installing, it should ensure that all connections has clean surface, the installation should
be taken to avoid the surface of the lens was dirty or scratched.
C type camera
C type mount
PK-mount
Eyepiece
Head
Head lock screw
Base
Clip
Black and white work board
*1)Connect the C -mount to the camera, Then connect the camera to the PK- Mount.
Fig.3

BestScope International Limited
4
3. Operation
Up
Fig.1
3.1 Use black and white work board
(1) If the specimen is white or transparent, make the black one as
background, to enhance the contrast.
(2) Take off or change the work board, move the work board (Fig.1)
make one side down, then the other side will be up.(Fig. 1)
Adjust the degree of tightness of the focusing arm.
Loose
Fig.2
Tension
(1) If you want to adjust tightness of the focusing arm, you can
hold one of the focusing knobs and turn another one to attain a
suitable tightness. The degree of tightness relies on the
direction to be turned. The reverse direction is tight, otherwise, is
loose.
(2)The suitable position of tightness can make the adjustment
more comfortable and prevent the focusing bracket from slipping
down by its weight during the observation. (Fig.2)
Set the specimen slide
(1) Set the specimen on the center of stage plate. If necessary,
clamp the slide with the clips.
(2)Turn on the light.
Le f t ey ep ie c e
diopter adjustabl e
loop
Righ t eyepiec e
diopter adjustabl e
loop
Fig.3
Adjust the specimen slide
(1) Turn the zoom control knob to the maximum magnification.
(2) Turn the diopter adjusting rings to the zero.
(3) Observe the specimen through the right eyepiece and make
the image clear by turning the focusing knob.
(4) Rotate the zoom control knob to the minimum magnification.
(5) Observe the specimen through the right eyepiece and make
the image clear by turning the right diopter adjusting ring.(Fig.3)
(6) Re-do the step(3)and (5) till the right adjusting ring is more precise.
(7) Do the step (4) and make the image clear which is observed
through the left eyepiece by turning the left diopter adjusting ring.
(Fig.3)

BestScope International Limited
5
Adjust the interpupillary distance
(1) Adjust the prism housing along the direction of arrow of
the Fig.4 till the observation is comfortable.
Fig.4
Fig.5
Wit h scale
Screw in
Screw out
Mount and Remove the Optional Eyepiece
Micrometer
(1) Turn and remove the mounting ring from the eyepiece.(Fig.5)
(2) Clean the eyepiece micrometer and mount it to the mounting
with the inscription side downward.
(3) Gently twist the mounting ring with the eyepiece micrometer
into the eyepiece till tightening securely.
(4) To remove the eyepiece micrometer, take down the mounting
ring by twisting and take out of the micrometer, and then wrap it.
Auxiliary
objecive
Fig.6
Fig.7
Fig.8
Use Auxiliary objective
(1) Connect the Auxiliary objective to the thread at the bottom
of the microscope head.
(2) 0.5x Auxiliary objective has long working distance. When use
0.5x auxiliary objective, release the lock screw on the arm by
a 4mm Allen key, move the focus arm up and fixed in the up
screw hole.(Fig 6)
0.75x auxiliary objective no need to remove arm.
Mount PK-mount and photo set
(1) Screw the PK-mount in the head, M28 screw, tight the
mount.(Fig.7)
(2) Loosen the screw on the PK-mount , take out the mount of C
type camera .
(3) Screw the C type mount in the TV photo set.
(4) Install the TV photo set into the PK-mount and lock the screw.
Focusing the TV photo set
(1) Turn the zoom control knob to the maximum magnification,
meanwhile, observe the TV set, adjust until the image is clear.
(2) Rotate the zoom control knob to the min. magnification. If the
image is not clear enough, adjust the part until the image clear.
(3) Redo the step (1), turn the zoom control knob to the maximum
magnification to check the image is clear or not. If not clear, redo
step(1)and (2), until the image is clear in all the zoom range.


Bestscope International Limited
6
4. Use Microscope stand
J3 base BS-3030 series
Make sure the power is cut off when replace the fuse.
Make sure the earth wire is correctly connected.
Black and white stage plate, glass stage plate, diameter 95mm
4.1 Nomenclatur e
4.2 O peratio n
Fig.10
Fig.11
Fig.9
2.1 Adjust the brightness of the bottom light or
top light
Turn the adjustable light knob , knob control
top light, knob control bottom light, along the
clockwise the brightness will be added, otherwise it
will be weakened. (Fig.10)
2.2 Replace the fuse
(1) Screw the fuse tube out with a screw driver.
(2) Then pull the fuse out of the tube .
(3) Change with new fuse and mount it in an adverse
direction.

Bestscope International Limited
7
5. T echnical P arameter
5.1 Optical parameter
Zoom
magnification
Working
distance
(mm)
Eyepiece
Eyepiece (optional)
WF10X/22mm
WF15X/16mm
WF20X/12mm
magnification
Field of
view(mm)
magnification
Field of
View(mm)
magnification
Field of
view(mm)
0.67X
105
6.7X
32.8
10.05X
23.9
13.4X
17.9
0.7X
7X
31.4
10.5X
22.86
14X
17.1
0.8X
8X
27.5
12X
20
16X
15
1X
10X
22
15X
16
20X
12
1.5X
15X
14.7
22.5X
10.7
30X
8
2X
20X
11
30X
8
40X
6
3X
30X
7.3
45X
5.3
60X
4
4X
40X
5.5
60X
4
80X
3
4.5X
45X
4.9
67.5X
3.6
90X
2.7
5.2 Auxiliary objective standard(optional)
Magnification
Working
distance(mm)
mm
Magnification
Working
distance(mm)
mm
0.3X
287
0.75X
117
0.4X
217
1.5X
47
0.5X
177
2X
26
Working distance is fixed regardless of the magnification factor.
Total mag.= Zoom mag. X Eyepiece mag. X Auxiliary objective mag.
Diameter of field of view(mm)=
Field number of eyepiece
Zoom mag.X Auxiliary objective mag.
5.3 Photo adapter mag.= Zoom mag.(X Auxiliary objective mag.)X Eyepiece mag.
5.4 Photo set zoom mag.= Zoom mag.(XAuxiliary objective mag.) X CTV mag .X C
type photo tube mag.

BestScope International Limited
8
6. T rouble shooting
The performance of the microscope can't be made fully because of unfamiliar using,
this following table will give some advice.
Trouble
Cause
Solution
1. Optical system
(1) Brightness is too bright or too dark
Brightness adjust not well
Make right adjustment
(2)Dirt appears in the field of view
Dirt on the specimen
Clean the specimen
Dirt on the surface of eyepiece
Clean the surface
Dirt on the surface of the objective
Clean the objective
Dirt on the working stage
Clean the working stage
(3)Double image
Interpupillary distance is not correct
Readjust it
Dioper adjustment is not correct
Readjust it
Magnification of each eyepiece is not
the same size
Mount the same size eyepiece
(4)Image is not clear
Dirt on the surface of the objective
Clean the objective
(5)Image is not clear while the focus
changing
Diopter adjustment is not correct
Readjust the diopter
Focus is not correct
Readjust the focus
(6)The image on the monitor is not
clear when the focusing knob is
turned
The focus of video is not correct
Readjust the focus of video to
a correct position
2. Electrical system
(1) Bulb does not work when the
switch is on
The bulb is not inserted correctly
Insert it correctly
Bulb is wrong
Replace bulb
Fuse is broken
Replace fuse
There is something impede the
light
Clean the working stage
(2) bulb is burned out suddenly
The voltage is too high
Use voltage regulator
Use the wrong bulb
Replace with a correct one
(3) fuse always burned out
The voltage is too high
Use voltage regulator
(4) the bulb flickers or the
Brightness is unstable
The bulb will burn out soon
Replace with a new one
The bulb was not inserted
correctly
Insert I correctly
3. Focusing
(1) the focusing knob is not smooth
The focusing knob is too tight
Loosen it to a suitable
(2)the image is obscure because
of the head slipping down by
itself during observation
The focusing knob is too loose
Tight it to a suitable position
