BIEMMEDUE TITAN 750 User manual

L-L 261.00-BM 1 / 25
INSTRUCTIONS MANUAL
MANUEL D'INSTRUCTIONS
SPACE HEATER
GENERATEUR D'AIR CHAUD
TITAN 750 – TITAN 1000
FR
EN

L-L 261.00-BM 2 / 25
WARNING
BEFORE USING THE HEATER, READ AND UNDERSTAND ALL INSTRUCTIONS AND FOLLOW
THEM CAREFULLY.
THE MANUFACTURER IS NOT RESPONSIBLE FOR DAMAGES TO GOODS OR PERSONS DUE
TO IMPROPER USE OF THE UNITS.
GENERAL HAZARD WARNING
FAILURE TO COMPLY WITH THE PRECAUTIONS AND INSTRUCTIONS PROVIDED WITH THIS
HEATER, CAN RESULT IN DEATH, SERIOUS INJURY AND PROPERTY LOSS OR DAMAGE
FROM HAZARDS OF FIRE, EXPLOSION, BURN, ASPHYXIATION, CARBON MONOXIDE
POISONING, AND / OR ELECTRICAL SHOCK.
ONLY PERSONS WHO CAN UNDERSTAND AND FOLLOW THE INSTRUCTIONS SHOULD USE
OR SERVICE THIS HEATER.
IF YOU NEED ASSISTANCE OR HEATER INFORMATION SUCH AS AN INSTRUCTION
MANUAL, LABEL, ETC., CONTACT THE MANUFACTURER.
WARNING: FIRE, BURN, INHALATION AND EXPLOSION HAZARD
KEEP SOLID COMBUSTIBLES, SUCH AS BUILDING MATERIALS, PAPER OR CARDBOARD, AT
SAFE DISTANCE AWAY FROM THE HEATER AS RECOMMENDED BY THE INSTRUCTIONS.
NEVER USE THE HEATER IN SPACES WHICH DO OR MAY CONTAIN VOLATILE OR
AIRBORNE COMBUSTIBLES, OR PRODUCTS SUCH AS GASOLINE, SOLVENTS, PAINT
THINNER, DUST PARTICLES OR UNKNOWN CHEMICALS.
WARNING
NOT FOR HOME OR RECREATIONAL VEHICLE USE. INSTALLATION OF THIS HEATER IN A
HOME OR RECREATIONAL VEHICLE MAY RESULT IN A FIRE OR EXPLOSION, PROPERTY
DAMAGE, PERSONAL INJURY OR LOSS OF FIRE.
WARNING
IMPROPER INSTALLATION, ADJUSTMENT, ALTERATION, SERVICE OR MAINTENANCE CAN
CAUSE INJURY OR DEATH.
READ THE INSTALLATION, OPERATING AND MAINTENANCE INSTRUCTIONS THOROUGHLY
BEFORE INSTALLING OR SERVICING THIS EQUIPMENT.
FOR YOUR SAFETY
IF YOU SMELL GAS:
1. OPEN WINDOWS
2. DO NOT TOUCH ELECTRICAL SWITCHES
3. EXTINGUISH ANY OPEN FLAME
4. IMMEDIATELY CALL YOUR GAS SUPPLIER
FOR YOUR SAFETY
DO NOT STORE OR USE GASOLINE OR OTHER FLAMMABLE VAPOURS AND LIQUIDS IN
THE VICINITY OF THIS OR ANY OTHER APPLIANCE.

L-L 261.00-BM 3 / 25
WARNING
The heater is designed and approved for use as a construction heater in accordance with Standard
ANSI Z83,7 CGA 2.14.
CHECK WITH YOUR LOCAL FIRE SAFETY AUTHORITY IF YOU HAVE QUESTIONS ABOUT
APPLICATIONS.
Other standards govern the use of fuel gases and heat producing products in specific
applications.Your local authority can advise you about these.
WARNING
This heater can be washed, provided that:
A. The heater is disconnected from the electrical supply.
B. All access panels are securely closed.
C. Water spray nozzle shall not discharge within 6 feet of the heater.
D. The heater is not reconnected to electrical supply until thoroughly dried.
Improper cleaning of the heater can cause severe personal injury or property damage due to water
and/or cleaning solutions:
A. In electrical components, connections and wires causing electrical shocks or component
failure.
B. On gas control components causing corrosion which can result in gas leaks and fire or
explosion from the leak.The hose assembly must be protected from the traffic, building
materials and contact with hot surfaces both during use andwhile in storage.
WARNING
Proper gas supply must be provided to the inlet of the appliance.
Refer to rating plate for proper gas supply pressure.
Gas pressure in excess of maximum inlet pressure specified at the appliance inlet can cause fire or
explosions, leading to serious injury, death, building damage or loss of livestock.
Likewise, gas pressure below the minimum inlet pressure specified at the appliance inlet may cause
improper combustion,leading to asphyxation, carbon monoxide poisoning and therefore serious
injury or death to humans and livestock.
Position heater properly before use.
For either indoor or outdoor use adequate ventilation must be provided.
Minimum clearance from combustible materials and propane containers: 10 ft.
Do not operate heater with panels removed.
Not for use with ductwork.
To avoid injury from moving parts, disconnect all electrical power to equipment before opening
doors or removing panels.
WARNING
RETAIN THIS INSTRUCTION FOR FUTURE REFERENCE..

L-L 261.00-BM 4 / 25
CONTROL BOARD - SCHÉMA DE FONCTIONNEMENT
1 HOT AIR OUTFLOW
SORTIE AIR CHAUD
2 CHIMNEY
CHEMINEE
3 COOLING FAN
VENTILATEUR REFROIDISSEMENT
4 COMBUSTION CHAMBER
CHAMBRE DE COMBUSTION
5 BURNER
BRULEUR
6 THERMOSTATS L2 BOX
BOITIER THERMOSTATS L2
7 HOISTING BRACKETS
ÉTRIERS DE LEVAGE
8 SUPPORT/HANDLE
SUPPORT/POIGNEE
9 WHEEL
ROUE
10 BURNER BOX
BOÎTIER BRÛLEUR
11 ELECTRICAL PANEL BOX
BOÎTIER TABLEAU ÉLECTRIQUE
1
4
11
5
9
10
5
3
2
6
7
8
8

L-L 261.00-BM 5 / 25
CONTROL PANEL - TABLEAU DE COMMANDE
a HEATING-VENTILATION SWITCH
INTERRUPTEUR CHAUFFAGE-VENTILATION
b VOLTAGE LAMP
TEMOIN TENSION
c OVERHEAT THERMOSTATS CONTROL LAMP, L2
TEMOIN THERMOSTATS DE SURCHAUFFE, L2
d ROOM THERMOSTAT PLUG
PRISE THERMOSTAT D’AMBIANCE
e INTAKE FOR PRE-HEAT FILTER
PRISE POUR FILTRE PRÉCHAUFFAGE
f CABLE CLAMP FOR POWER CABLE
PRESSE-CÂBLES POUR CÂBLE D'ALIMENTATION
g TEMPERATURE CONTROLLER
THERMORÉGULATEUR
h BURNER LIGHT
VOYANT BRÛLEUR
i SAFETY THERMOSTAT RESET BUTTON, L2
POUSSOIR DE RÉARMEMENT THERMOSTAT DE SÉCURITÉ, L2
m BURNER RESET BUTTON / LAMP
TÉMOIN / POUSSOIR DE RÉARMEMENT BRÛLEUR
n ELECTRICAL PANEL BOX PANEL
PANNEAU BOÎTIER TABLEAU ÉLECTRIQUE
o ELECTRICAL PANEL
TABLEAU ÉLECTRIQUE
a b
d
c
f
g
i
h
e b m
n
o
