Billion BiGuard 10 User manual

• Supports up to 10 IPSec VPN connections
• IPSec VPN performance is up to 20 Mbps+
• Supports up to 4 PPTP VPN connections
• PPTP VPN throughput is up to 10 Mbps
• SIP pass-through for Voice over IP protocol
• Robust firewall security to protect office
network
• E-mail alert and logs of attack
• Policy-based bandwidth management
• Quality of Service (QoS) control
• DMZ support for public servers to be visible
to the outside world
• Easy-to-use web interface for administrator
to manage network security
• Rack-mounted support
• Supports IPTV application*
• Ideal for small and medium sized business
iBusiness Security Gateway Small-office
BiGuard 10 is a rack-mountable device integrated with cutting-edge security technology including VPN and
Firewall that enable you to connect your network to the Internet securely without worrying about intruders'
attacks. This security gateway is perfectly designed for small offices requiring application-based network
solutions with low-capital investment to communicate with headquarters and mobile workers. Robust VPN
functions support office users to create remote access of multiple site-to-site encrypted private connections
over the public Internet. The complete firewall features are built in to protect your network from intruders and
Internet attacks. With the growing demand for Voice over IP and multimedia applications such as video
broadcasting from SMB and SOHO users, the device features SIP pass-through and IGMP Snooping to
facilitate the needs. The Quality of Service feature ensures a smooth net connection for inbound and
outbound data with minimal traffic congestion. A rich-featured set in one compact unit makes BiGuard 10 the
best and most affordable choice for small offices.
Virtual Private Network Support
BiGuard 10 supports comprehensive and robust IPSec & PPTP VPN protocols for business users to
establish private encrypted tunnels over the public Internet to ensure that data is transmitted securely among
multiple sites, such as branch office or remote dial-up. The VPN feature supports up to 10 simultaneous
IPSec VPN connections with throughput up to 20 Mbps+, and 4 simultaneous PPTP VPN connections with
throughput up to 10 Mbps.
Rich Firewall Security to Protect Your Network
BiGuard 10 is an intelligent broadband sharing gateway with integrated firewall protection, while simultaneously
offering features such as Stateful Packet Inspection (SPI), Denial of Service (DoS) prevention and filtering.
Built with Stateful Packet Inspection (SPI), the router enables users to determine whether or not a given data
packet is allowed to pass through the firewall to the private LAN. The SPI feature protects against hackers'
attacks from Denial of Service to allow private LAN connected to the Internet. Furthermore, the firewall
function provides e-mail alert service to notify you whenever attacks occur.
Traffic Prioritization and Bandwidth Management
The Quality of Service (QoS) feature helps users to manage the bandwidth and prioritize data transfer
effectively. It gives one full control over the traffic of any type of data, ensuring important data and
bandwidth-consuming applications such as video conferencing, customer information or FTP sharing, can
move through the router at instantaneous speed, even when under heavy tasking. The speed for inbound
and outbound data passed through the router can be controlled to ensure that users do not saturate the
bandwidth with their browsing activities.

Billion Electric Co., Ltd.
8F, No.192, Sec.2, Chung Hsing Road,
Hsin Tien City, Taipei County, 23146 Taiwan
www.billion.com
TEL : [phone]
FAX : [phone]
E-mail : [email protected]
Virtual Private Network
• IPSec VPN: support up to 10 IPSec tunnels
• IPSec VPN performance is up to 20 Mbps+
•PPTP VPN: support up to 4 PPTP tunnels
• PPTP VPN performance is up to 10 Mbps
•Manual key, Internet Key Exchange (IKE)
authentication and Key Management
•Authentication (MD5 / SHA-1)
•DES / 3DES encryption
•AES 128 / 192 / 256 encryption
•IP Authentication Header (AH)
•IP Encapsulating Security Payload (ESP)
•IPSec VPN concentrator
•Dynamic IPSec VPN support
•IPSec NAT Traversal (IPSec NAT-T)
•IPSec DPD (Dead Peer Detection)
•Supports remote access and office-to-office
IPSec connections
•PPTP server
•Netbios over VPN
Firewall
• Stateful Packet Inspection (SPI) and Denial
of Service (DoS) prevention
•Packet filter un-permitted inbound (WAN) /
outbound (LAN) Internet access by IP address,
port number and packet type
•E-mail alert and logs of attack
•Mac address filtering
Quality of Service Control
• Supports the DiffServ approach
•Traffic prioritization and bandwidth
management based-on IP protocol,
port number and address
•Policy control based on IP address or
Mac address
Content Filtering
• URL Filter settings prevent user access to
certain keyword / domain on the Internet
•Java Applet / Active X / Web Proxy / Surfing
of IP Address / Cookie Blocking
Web-Based Management
• Easy-to-use web interface
•Smart VPN setup wizard
•Firmware upgrade via web interface
•Local and remote management via HTTP
and HTTPS
Network Protocols and Features
• System log
•PPPoE, PPTP, Big Pond and DHCP client
connection to ISP
•NAT, static routing and RIP-2
•Dynamic Domain Name System (DDNS)
•Virtual server and DMZ
•DHCP server
•NTP
•SMTP client
•SNMP
•SIP pass-through
• IGMP snooping & IGMP proxy
• Port based VLAN bridge mode
•Multiple NAT (multiple LAN and multiple WAN)
IPTV Application*
• IGMP Snooping
• Virtual LAN (VLAN)
• Quality of Service (QoS)
Hardware Specifications
Physical Interface
•Ethernet WAN 1 port (10 / 100 Base-T, MDI / MDIX)
•Ethernet LAN 8 ports (10 / 100 Base-T, MDI / MDIX)
Physical Specifications
• Dimensions: 19" x 6.54" x 1.65"
(482mm x 166mm x 42mm)
Power Requirements
• Input: 12V DC, 1A
Operating Environment
• Operating temperature: 0 - 40°C
•Storage temperature: -20 - 70°C
•Humidity: 20 - 95% non-condensing
Features & Specifications
VPN Tunnel
VPN Tunnel
VPN Tunnel
Internet
iBusinessSecurityGateway
iBusinessSecurityG ateway
2
iBusinessSecurityGateway
1
0
ISP1
ISP2
ISP
ISP
ADSL/Cable
ADSL/Cable
ADSL/Cable
Modem
Modem
Modem
Modem
Server 2 Server 1
Server
VPN Tunnel
V.073108
VPN Tunnel
Installed with
IPSec VPN
Client Software
Copyright © Billion Electric Co., Ltd. All rights reserved.
Head Office
Branch Office
Branch Office
Mobile Users
BiGuard 30
BiGuard 10
BiGuard 2
*Note:
1. IPTV application may require subscribing to IPTV services from a Telco/ISP.
2. Users are strongly recommended to register at www.biguard.com for updated firmware.
3. Specifications in this datasheet are subject to change without prior notice.
