Binatone Lyris 710 User manual

1
Lyris 710
Lyris 710

2
- When the instruction simply say 'press' a button, this means you should press it
briefly then release it.
- When the instruction say 'press and hold' a button, this means you should keep
it pressed until the display changes or you hear a tone.
Microphone
machine OGM &
Memo recording.
the answering
With TAM ON is standby mode,press to select OGM1 or OGM2.
- To access the caller
display records, and
UP-DOWN (CDS) Buttons
to scroll through lists
and options.
- Press to delete individual
messages, memos, stored
DEL (DELETE) Button
light - Turns ON
when using the
speakerphone.
SPEAKERPHONE
- Turns ON
when the TAM is on. Flashes
when you have new TAM messages.
MESSAGE light
numbers or Caller Display
records. - Press to enter Options
(MENU) Button
- Press to access the
Phonebook records.
(PHONEBOOK) Button
- Press to access the LNR lists
when in standby mode. Press to
insert a pause when dialing.
(REDIAL)/ P (PAUSE) Button
during a call to mute the microphone or
(MUTE) / STO(Store) Button - Press
- You may need this function if your
phone is connected to a PBX, or if
you use BT Calling Features.
R (RECALL) Button
make, answer,
or end a call using the
speakerphone.
SPEAKERPHONE
- Press and hold to
outgoing messages.
message
current message
to the previous
OGM/ (REWIND)
- Press and hold to record a memo.
Press during message playback to
skip to the next message.
MEMO/ (SKIP) Button
- Press to stop recording or
(EXIT)/ (ANSWER ON/OFF) Button
- Used to adjust the volume
level of the Speakerphone.
SPEAKER Volume control
when the phone is ringing
for an incoming call.
Ringer light
- This flashes
mouthpiece. Press to store the (M1, M2
and M3)one touch memory dialing buttons
M1, M2, M3 one-Touch
Memory Buttons
Menu to set the Date,
Time,Screen Contrast,
phone/TAM settings.
- Press to
Button
Button
record your
Press during
playback to
repeat the
or to go back
message(s).
- Press to play back
message.
(PLAY/PAUSE) Button
messages and memos.
Press to pause
playing of a memo or
playback.
- For speakerphone
use and answering
Press and hold to switch
maching ON or OFF.
Important:

3
Phone You are connected to the telephone line - your
Handset is ‘offhook’.
Time Displays the time.
Date/Month
Speakerphone Appears when the speakerphone function is
turned ON.
Mute Appears when you press the MUTE button to
Message Appears only when viewing a Caller display entry
with a recorded answering machine message.
NEW The NEW icon only appears when viewing
New Caller Display records.
Caller Display
Record
Shows the total number of Caller Display records
when the caller display is being received or when
the call lists is being viewed.
mute the mouthpiece or microphone.

4
2. Installation
1. Locating the Base unit
The Base unit should be placed on a level surface, in a position where:
the mains adapter plug will reach an easily accessible 230-V AC
switch mains supply socket - never try to lengthen the mains power cable.
the telephone line cable will reach your telephone line socket or
extension socket.
it is not close to a sink, bath or shower, or anywhere else where it
might get wet.
it is not close to other electrical equipment - fridges, washing
machines, microwave ovens, TVs, fluorescent lights, etc.
2. Plug the coiled handset cord into the Handset. Plug the other end into
the jack on the left side of the Base unit.
Note: The base unit doesn't
require a battery.
3. Place the Handset on
the Base unit.
4. Plug the telephone line cord into
the PHONE LINE jack at the back
of the Base unit. Plug the other
end into your telephone line socket 5. Plug the power supply cord
into the POWER jack at the
back of the Base unit. Plug
the other end to a 230V AC,
50Hz mains socket, with the
switch on the socket set to OFF
6.Switch ON the mains power at
the socket. Wait while the
7.Lift the Handset and check
for Dial tone in the earpiece.
Always use the telephone
line cord supplied with your
. Other telephone
line cords may not work.
Make sure the plugs click
into place.
or extension socket.
display shows INITIALISATION,
then the announcement
Answering machine on.
Announcement one before
the display changes to the
“
”
standby screen.
Lyris 710
Note:The Lyris 710 Base unit must be
used only with the Switch adapter Shen
Zhen G.EREDIT Electronics Co.,Ltd.
5E-AD070042-B .
Modular
Wall jack

5
3. Desk/Wall mount installation
To place the on a desk, connect
the stand to the bottom of the phone in the
slots near the rear of the base as shown below.
Desk Mount
Insert the rigid clips of the stand into the slots
on the bottom of the phone (nearer the centre of
the base). Press down firmly until the flexible
clips clicks into place.
To remove the stand, (1) pinch the flexible
clips, (2) pull back the stand, and then (3)
slide up and forward (3) as shown below.
To place the on a wall, connect
the stand to the bottom of the phone in the
slots near the front of the base as shown below.
Wall Mount
Binatone Help Line - 0845 345 9677 Calls are charged at Local Call rate.
Lyris 710
Lyris 710

Binatone Help Line - 0845 345 9677 Calls are charged at Local Call rate.
6
Desk/Wall mounting continue...
Insert the rigid clips of the stand into the slots
on the bottom of the phone (nearer the centre of
the base). Press down firmly until the flexible
clips clicks into place.
To remove the stand, (1) pinch the flexible
clips, (2) pull back the stand, and then (3)
slide up and forward as shown below.
Mark two points on the wall that are 92 mm
apart to lay the fixing centers as shown below.
BE CAREFUL to check that there are no
electrical wires hidden in the wall.
Hang the telephone on the screws using the
wall mount slots. You may need to remove the
telephone from the wall and tighten the
screws so that the Telephone is securely fixed and
does not wobble. Place the Handset on the
cradle with the parking hook on the cradle
arranged to fit in the parking recess under the
earpiece on the Handset.
92 mm
Fix two screws (7mm head screws required, not
approximately 7mm between the wall and the screw
leaving
supplied) at the marked locations,
head.

Binatone Help Line - 0845 345 9677 Calls are charged at Local Call rate.
7
4. Setting up the Lyris 710
With the phone in standby mode;
1 Press MENU button.
ÖThe display shows
OPTIONS MENUOPTIONS MENU
OPTIONS MENUOPTIONS MENU
OPTIONS MENU .
2 Press UP button to go to the language setting.
ÖThe display shows
SET LANGUAGESET LANGUAGE
SET LANGUAGESET LANGUAGE
SET LANGUAGE .
3 Press MENU button to confirm.
4 Press UP or DOWN button to select ENGLISH
(default), FRANCAIS, or DEUTSCH.
5 Press MENU button to confirm.
6 Continue with programming, or press EXIT
button to return to standby mode.
SET
LANGUAGE
1 Press MENU button.
ÖThe display shows
OPTIONS MENUOPTIONS MENU
OPTIONS MENUOPTIONS MENU
OPTIONS MENU .
2 Press UP or DOWN button until the display
shows
SET TIME/DATESET TIME/DATE
SET TIME/DATESET TIME/DATE
SET TIME/DATE .
3 Press MENU button to confirm.
ÖThe ‘year’ will be blinking.
SET TIME/
DATE
Note: if you subscribe to the caller display service
(see section 9) the time and date will be set
automatically,but the year may still need to be
adjusted to ensure the answering machine time
stamp gives the correct day.
The following section details how to set up your telephone.
Press the MENU button to enter the Options menu and then use
the UP or DOWN buttons to cycle through the following options:
SET LANGUAGE
SET TIME/DATE
SET FLASH TIME
LCD CONTRAST
MESSAGE LENGTH
RINGS TO ANSWER
REMOTE ACCESS
TAM HD: ON/OFF
Note: The system will time out if you leave more than
10 seconds between key presses.
!
EXIT OPTION
ÖTo set the Answering Machine
recording quality / total recording time.(ON gives up to 8
minutes of higher quality, OFF gives up to 20 minutes of
lower quality.)

Binatone Help Line - 0845 345 9677 Calls are charged at Local Call rate.
Setting up continue...
4 Press UP or DOWN button to set the year.
5 Press MENU button to confirm.
ÖThe ‘month’ will be blinking.
6 Press UP or DOWN button to set the month.
7 Press MENU button to confirm.
ÖThe ‘date’ will be blinking.
8 Press UP or DOWN button to set the date.
9 Press MENU button to confirm.
ÖThe ‘hour’ will be blinking.
10 Press UP or DOWN button to set the hour.
11 Press MENU button to confirm.
ÖThe ‘minutes’ will be blinking.
12 Press UP or DOWN button to set the minute.
13 Press MENU button to confirm the TIME and
DATE setting.
14 Continue with programming, or press EXIT
button to return to standby mode.
1Press MENU button.
ÖThe display shows
OPTIONS MENUOPTIONS MENU
OPTIONS MENUOPTIONS MENU
OPTIONS MENU .
2Press UP or DOWN button until the display
shows
SET FLASH TIMESET FLASH TIME
SET FLASH TIMESET FLASH TIME
SET FLASH TIME .
3Press MENU button to confirm.
SET FLASH
TIME
You may need the Recall function if your phone is
connected to a PBX, or if you use BT Calling Features.
Flash is another name for the R (Recall) button,
4Press UP or DOWN button to select 100MS
(default), 300MS, 600MS or 1000MS.
When setting the 'hour' it is in 24 hour
Ö
mode only.
and the normal UK requirement is for 100ms, but
some PBX may need a longer time, in which case
you can change the setting from the Options Menu.
8

Binatone Help Line - 0845 345 9677 Calls are charged at Local Call rate.
9
5 Press MENU button to confirm.
6 Continue with programming, or press EXIT
button to return to standby mode.
1 Press MENU button.
ÖThe display shows
OPTIONS MENUOPTIONS MENU
OPTIONS MENUOPTIONS MENU
OPTIONS MENU .
2 Press UP or DOWN button until the display
shows
LCD CONTRASTLCD CONTRAST
LCD CONTRASTLCD CONTRAST
LCD CONTRAST .
3 Press MENU button to confirm.
4 Press UP or DOWN button to select your
comfortable display viewing level (1~5). The
default setting is 3.
5 Press MENU button to confirm.
6 Continue with programming, or press EXIT
button to return to standby mode.
To set the maximum recording time for each incoming
message or memo message on the Answering Machine.
1 Press MENU button.
ÖThe display shows
OPTIONS MENUOPTIONS MENU
OPTIONS MENUOPTIONS MENU
OPTIONS MENU .
2 Press UP or DOWN button until the display
shows
MESSAGE LENGTHMESSAGE LENGTH
MESSAGE LENGTHMESSAGE LENGTH
MESSAGE LENGTH .
3 Press MENU button to confirm.
4 Press UP or DOWN button to select 1 or 2
minutes. The default setting is 2 minutes.
5 Press MENU button to confirm the MESSAGE
LENGTH setting.
6 Continue with programming, or press EXIT
button to return to standby mode.
Setting up continue...
LCD
CONTRAST
MESSAGE
LENGTH
To set the number of rings before the machine
answers a call;
1 Press MENU button.
ÖThe display shows
OPTIONS MENUOPTIONS MENU
OPTIONS MENUOPTIONS MENU
OPTIONS MENU .
RINGS TO
ANSWER

Binatone Help Line - 0845 345 9677 Calls are charged at Local Call rate.
10
2 Press UP or DOWN button until the display
shows
RINGS TO ANSWERRINGS TO ANSWER
RINGS TO ANSWERRINGS TO ANSWER
RINGS TO ANSWER .
3 Press MENU button to confirm.
4Press UP or DOWN button to select TOLL SAVER,
2, 3, 4, 5, 6, 7, 8, or 9 rings. The default setting is 5.
ÖUse ‘TOLL SAVER’ when checking your Lyris 710
for messages from a remote location using long
distance service or from a pay phone. The Answering
machine responds after the 2nd ring only if you have
a new message waiting. If there are no new messages,
the phone will answer after the 4th ring. You can then
hang up after the 3rd ring to avoid paying for the call.
5 Press MENU button to confirm.
6 Continue with programming, or press EXIT
button to return to standby mode.
The REMOTE ACCESS is a three-digit code you
your
1 Press MENU button.
ÖThe display shows
OPTIONS MENUOPTIONS MENU
OPTIONS MENUOPTIONS MENU
OPTIONS MENU .
2 Press UP or DOWN button until the display
shows
REMOTE ACCESSREMOTE ACCESS
REMOTE ACCESSREMOTE ACCESS
REMOTE ACCESS .
3 Press MENU button to confirm.
ÖThe first digit of the code will be blinking.
4 Press UP or DOWN button to set the first digit
of the REMOTE ACCESS code.
Setting up continue...
REMOTE
ACCESS
5 Press MENU button to confirm.
ÖThe second digit of the code will be blinking.
6 Press UP or DOWN button to set the second
digit of the REMOTE ACCESS code.
7 Press MENU button to confirm.
ÖThe third digit of the code will be blinking.
need if you call away from home to check
messages.The default is 321. You can change it to
any three digits you want.
