Bio Compression Systems SC 2008 OC User manual

Indicaons for safety use
Biocompression
Pump SC 2008 OC
User Manual
Indications for safe use
This product is intended for use by
health professionals or patients who are
under clinical supervision.

1. Introducon .........................................3
2. Warnings ..............................................4
3. Product Descripon
Device .................................................. 6
Garments ............................................. 8
Accessories .......................................... 9
4. Seng up the Pump ...................... 10
5. Safety Informaon ......................... 11
6. Troubleshoong ............................. 15
7. Maintenance and Storage
............ 16
8. Specicaons
.................................. 17
9. Repair and warranty .................... 20
Contents
Congratulaons on the purchase of your Bio Compression Systems
SC-2008-OC Sequenal Circulator and accompanying garment(s).
The following manual will provide information regarding the technical specications and
use of this device.
INTENDED USE
The Sequential Circulators SC-2008-OC are pneumatic compression devices intended
for either primary or adjunctive treatment of primary or secondary lymphoedema and
lipoedema. The devices are also intended for additional or alternate treatment of venous
insufciency and chronic venous stasis ulcers associated with venous insufciency as well
as general treatment for swelling of the extremities. The devices are intended for both
home and hospital use. These devices provide sequential (distal to proximal) ination and
deation cycles of compressed air at pressures. Sequential gradient compression helps
to increase blood ow and move excess lymph away from the affected area for clearance
from the body.
1. Introducon
3

MEDIRENT.COM.AU © 2020
2. Warnings and Precauons
Warnings:
• The settings navigation guide will provide general information for compression
pump usage that may not apply to each individual's circumstances. Consult with
your treating therapist regarding specic advice regarding your individual treatment
parameter settings of pressure, duration, and treatment frequency.
• Pressure settings should not be changed unless ordered by a clinician. High pressure
should be set with caution.
• Caution must be exercised for patients with sensitive, irritated, sunburned, bruised
or broken skin, or with skin conditions such as skin cancer, dermatitis, eczema, or
psoriasis in/around treatment sites.
• Should changes in skin appearance occur such as blisters, redness, welts,
discoloration or other noticeable changes in the skin, or if burning, itching, increased
swelling should occur, discontinue use and consult with your therapist or doctor.
• Slip and fall hazard. To avoid the risk of tripping or falling, do not stand or walk while
wearing garments.
Precauons:
• This device is not intended for use during SLEEP.
• Do not attempt to modify this device in any way.
Contraindicaons
Compression is NOT recommended in the following conditions:
• Cellulitis or other infection not treated with antibiotics
• The presence of lymphangiosarcoma
• Known or suspected deep vein thrombosis (DVT)
• Inammatory phlebitis or episodes of pulmonary embolism
• Uncontrolled/severe cardiac failure
• Active metastatic disease affecting oedematous region
• Thrombophlebitis
• Pulmonary oedema
Under Clinical Consultaon
Compression pumps may be used with these conditions under clinical consultaon.
Pressure settings may need to be started lower than usual and progressed according to
tolerance.
• Acute infection
• An ABPI less than 0.8 or greater than 1.2
• High arterial blood pressure
• Cardiac arrhythmia or cardiac stenosis
• Controlled heart failure
• Articial material in body e.g. breast implants/tissue expanders
- be guided by comfort levels*
• Lipoedema*
• Acute inammation*
• Scleroderma*
• Chronic polyarthritis*
• Complex regional pain syndrome*
• Peripheral neuropathy*
* Potential to increase pain or discomfort in some cases
4 5

MEDIRENT.COM.AU © 2020
Your clinician should prescribe suggested settings for
your particular condition.
Pressure knob
Air Supply Ports, #1 - 4
3. Product descripon - Device
Please note
3. Product descripon - Device
Air Supply Ports, #5-8
Receptor Ports
(for Tubing Latch
Connector Bars)
Auxiliary Air Supply Ports
(for Bilateral Use)
Power on / off switch
PACKAGE CONTENTS
1 - SC-2008-OC Sequential Circulator (“pump”)
1 - User manual
1- General settings navigation guide
1 - Quick set-up guide
2 - Blocker Bars for use during single garment therapy
1 - Power Cord
Necessary garments ordered
LATCH CONNECTORS
Attach and detach the garment to the pump via the Receptor Ports and Air supply ports
depicted in the illustration to the left. A second garment may be attached to the Auxiliary
Air Supply Ports for bilateral use. (IMPORTANT: Keep the Blocker bars installed for single
garment use).
TUBING
Responsible for delivering air to and from the pump and garment.
COMPRESSION GARMENTS
Garments contain either 8 or 16 chambers, which work in conjunction with the Sequential
Circulator to apply controlled, sequential pressure throughout the chambers.
Blocker Bars (uninstalled)
6 7

MEDIRENT.COM.AU © 2020
Arm Vest
3. Product descripon - Garments / Accessories
16 Chamber Pants
8 Chamber Legs
3. Product descripon - Garments
Oponal Accessories
Your product may have the following accessories:
- Carry bag (addional purchase)
Carry bag
8 9

MEDIRENT.COM.AU © 2020
4. Seng up the Pump
Pressure sensor
The pressure sensor monitors and adjusts the garment pressure throughout ination to
ensure lling of the garment approximates the pressure setting on the device.
The function of the sensor enables appropriate lling regardless of the size or style of garment
attached to the controller or the limb size within the garment.
It is normal for the garment to feel loose during the rst few cycles before the unit lls each
chamber to the selected pressure. This may take longer for the arm-vest.
If the system doesn't reach set pressure, then the device will alarm indicating there is a fault
with either the garment or the controller. Please see 'Troubleshooting Guide' later in this
booklet to determine the cause of the fault and how to rectify it.
Please refer to the Quick Guide and General Settings Guide to set up your pump, apply
garments and congure settings.
*PLEASE NOTE: You should be guided by a clinician regarding what settings you
should apply for treatment including pressure, cycle time and therapy duration.
Biocompression Pump
SC 2008 OC
settings guide:
8 chamber leg garments or biopants
This protocol has been
developed as a guide only.
Please consult with your
therapist for treatment
sengs to suit your
individual needs.
PRESSURE
PRESSURE
25
25
30
30
35
35
40
40
OFF0
ON|
SC-2008-OC
SequentialCirculator
45
45
50
50
55
55
60
60
65
65
70
70
75
75
80
80
20
20
8
8
7
7
6
6
5
5
8
8
7
7
6
6
5
5
4
4
3
3
2
2
1
1
4
4
3
3
2
2
1
1
RxONLY
RxONLY
6
Ensure youare on a non-slip surface. Stand up
with the garment partially zipped up. Lift the
trousers and zip the remainder of the garment
on each side. Adjust the garment to t your
body without rotating, twisting, or large
creasing of the material.
Medi-Rent Pty Limited
ABN: 37 603 454 360
Unit 3, 61 Beauchamp Rd,
Matraville NSW 2036
P: 1300 726 666
F: 02 9316 9998
E: [email protected]
W: www.medirent.com.au
PH: 1300 726 666
© 2019 Medi-RentPty Limited
2
Plug your power lead in, ensuring that it is
not a trip hazard.
(Often youwill need to visit the bathroom
during treatment due to uid evacuation).
4
Find the position where you will be rested
during treatment on a bed or couch where
your legs are elevated and supported.
Place the device somewhere easily
accessible.
Wear lightweight long pants under the Bio
Compression pants.
1
Connect cuff hose to the device, ensuring
the numbers and indicators match.
35
Unzip the pant garment partially and place
it on the couch or bed. If seated, step each
foot into position ensuring the heels are
located to the back of the garment. Zip the
legs up as far as you can.
BIO-COMPRESSION Set-up Guide: pants
7
Sit as far back on the chair or bed as able.
8
Use your upper body as a counter weight to
lift your legs up onto the couch/bed.
This guide is intended as a quick reference once the user manual has been read in-full
8765 4321
This marking shown on the product or its literature, indicates that
it should not be disposed with other household wastes at the end
of its working life. To prevent possible harm to the environment or
human health from uncontrolled waste disposal, please separate this
from other types of waste and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact Local Council about how and where
they can dispose of this item for environmentally safe recycling.
Business users should contact their supplier and check the items
and conditions of the purchase contract. This product should not be
mixed with other commercial waste for disposal.
5. Safety Informaon
WEEE Marking
10 11

MEDIRENT.COM.AU © 2020
• Only use the supplied AC cord. Inspect the cord and plug for
any damage.
• To prevent re or electric shock never plug the device in if any
damage is evident.
• Stop using the device if you smell electrical burning whilst
using the device. In this case, turn off the electric power, pull
out plug from outlet, and then inform the service centre.
• Grip the plug, not the power cord when inserting or removing
the plug from the power outlet.
• Never handle device or power connect with wet hands (Electric
shocks possible)
• Do not bend or twist the power cord.
• To protect device from electrical damage, disconnect it from
the power outlet when not in use or during electrical storms.
prohibited
caution
Electrical Safety
• Never apply garments over bare skin, always apply over light
clothing or cotton disposable boot liners. (Garment life can be
reduced by sweat or cosmetics)
• Do not inate garments with any other device other than the
Biocompression Controller.
• Never expose garments to oil, benzene, alcohol, hydrocarbons
etc. For cleaning refer to the Maintenance and Storage section
of this manual.
• Remove jewellery from limbs before use
(Damage to garment possible)
• Do not expose garments to any heat sources
• Do not keep garments near dangerous sharp objects such as
needles and scissors
prohibited
caution
caution
Regarding Garments
• Always supervise children when near the device. Serious
injuries could be sustained if the unit is used inappropriately.
• Do not apply air hose to nose, mouth or ears (Injuries possible)
• Seek medical approval when in use by individuals with heart
conditions - pacemaker, heart transplant, uncontrolled heart
failure etc
• Never apply garments to bare skin, always use while wearing
thin clothes or liners. Zip the garment the entire way closed to
avoid damage to the skin during application.
• Stop using the device if you feel any abnormal condition
during use and consult your doctor or therapist.
• Use the device under the supervision and guidance of your
health professional.
Safety for Body
12 13

MEDIRENT.COM.AU © 2020
• Use the device indoors between 0-40°C
• Do not use or keep the device near heating equipment or direct
sunlight (Defects and ammable accidents possible)
• Do not use the device in high humidity (Bathroom and sauna
etc).
(Flammable accidents, electric shocks possible)
• Keep the device upright.
(Defects or malfunctions possible)
prohibited
warning
caution
Use and Maintenance
* Stop the operation of the device and seek medical advice if the following occurs:
1. Difculty breathing or dizziness
2. Pain in any body part during compression that continues even when the treatment has
stopped
3. Temporary body paralysis
* Seek advice from your health professional with regard to setup and progression of
pressure, mode, and speed treatment parameters to ensure effective and safe use with
consideration of your specic medical history and presenting condition.
Stop the device during operaon
Recommendaon
6. Troubleshoong
Symptom Possible Cause Correcve Acon
The device is not working.
No electricity
Check the electrical wall
outlet to be sure that the
pump is plugged into the
outlet correctly. Check the
circuit breaker to be sure
there is power to the outlet.
Power cord
Unplug the power cord
and look forany damage or
defects.
One garment inates but the
second one does not.
The second garment is not
receiving air.
Check the garment hoses
for adequate connection to
the device, kinks, punctures,
twists and /or folds.
The device is making strange
and/or loud noises.
Device is on an uneven or
unstable surface.
Move to a more stable
surface.
An internal problem Contact Medi-Rent for
repair or replacement.
Regardless of the pressure
setting the garments are
applying a very low pressure.
Defective garment
Check the garment for
adequate connection to
the device, leaks, kinks,
punctures, twists and /or
folds.
An internal problem Contact Medi-Rent for
repair or replacement.
14 15

MEDIRENT.COM.AU © 2020
7. Maintenance and Storage
Exterior Pump Case Cleaning instrucons:
1. Clean the exterior case and tubing with a damp (not wet) cloth using mild soap and water
solution once per month.
WARNING!
• Only an authorized technician may open the pump
• Before cleaning, unplug power cord from electrical outlet
2. Disconnect garment from device.
3. Open garment to expose all sides either by separating Velcro type hook and loop or by
unzipping (depending on type of garment).
WARNING!
• Do not allow liquids to enter pump, as this can present an electrical hazard
• Always allow the pump to dry before using
• Do not use bleach on the pump
4. Wipe the garments thoroughly with a ph neutral cleaner or Clinell wipes. Solutions with
alcohol should be avoided.
Garment cleaning/disinfecng instrucons:
WARNING!
• Never allow the Latch Connectors to be submerged into the water. If water enters the
inside of the garment, damage may occur to the device.
• DO NOT place garment in washing machine.
• WARNING! DO NOT use the tubing or valves as “handles” for carrying, handing or
storing garment.
The unit contains no user serviceable parts and should only be serviced by a competent
electrical technician or returned to Medi-Rent Pty Ltd or your local authorsied dealer.
All Biocompression products should be serviced regularly by Medi-Rent Pty Ltd or an
authorsied dealer in order to comply with warranty conditions.
NB. Before returning equipment to Medi-Rent Pty Ltd for service, be sure that it has been
properly cleaned and disinfected in accordance with local health service guidelines.
8. Specicaons
Dimensions 11.43 H x 29.86 W
x 19.69 D cm Weight 2.5kg
Ination/Deation 44/5.5 Seconds Cycle Time 5.5 Secs / chamber
Electrical 120 VAC, 60 Hz, 0.5
A (USA) 230 VAC, Applied Part Type B
Protection against
Electrical Shock
CLASS II (USA)
CLASS IIa (EU) Operation Mode Continuous
Operation
General Equipment Specicaons
Environmental Condions
For Operation
Ambient temperature: +10°C - +44°C
Relative humidity: 30% - 75%
Atmospheric pressure: 700hPa to 1060hPa
For Transport and Storage
Ambient temperature: +10°C - +44°C
Relative humidity: 30% - 75%
Atmospheric pressure: 700hPa to 1060hPa
Electrical Specicaons/Equipment Classicaon
The Sequential Circulator SC-2008-OC interior components are “double insulated” and do not
require a “protective ground.” The devices are equipped with 18 gauge, 2-wire, 10’ Power Cords,
secured through the pump casings with a Heyco strain relief brushing, as well as, an additional
“hold-down” clamp for added safety.
• Class of protection against electrical shock: CLASS II EQUIPMENT
• The degree of protection against electric shock: APPLIED PART-TYPE B
• Mode: CONTINUOUS OPERATION WITH INTERMITTENT LOADING
• According degree of protection against ingress of water: IXP0
16 17

MEDIRENT.COM.AU © 2020
Guidance and Manufacturer’s Declaraon — Electromagnec Immunity
The SC-2004-OC/SC-2004FC-OC/SC-2008-OC are intended for use in the electromagnec environment specied below. The customer or the
user of the SC-2004-OC/SC-2004FC-OC/ C-2008-OC should assure that it is used in such an environment.
Immunity
test
IEC 60601 test
level Compliance level Electromagnec environment—guidance
Conducted RF
IEC 61000-4-6
Radiated RF
IEC 1000-4-3
3 Vrms
15 kHz to 80
MHz
3 V/m
80 MHz to 2.5
GHz
3 Vrms
3 V/m
Portable and mobile RF communicaons equipment should be used no closer to any
part of the model SC-2004-OC/SC-2004FC-OC/SC-2008-OC, than the recommended
separaon distance calculated from the equaon applicable to the frequency of the
transmier.
Recommended separaon distance
80 MHz to 800 MHz
800 MHz to 2.5 GHz
where Pis the maximum output power rang of the transmier in was (W) accord-
ing to the transmier manufacturer and dis the recommended separaon distance
in meters (m).
Field strengths from xed RF transmiers, as determined by an electromagnec site
survey,ashould be less than the compliance level in each frequency range.b
Interference may occur in the vicinity of equipment marked with the following sym-
bol:
Note 1: At 80 MHz and 800 MHz, the higher frequency range applies.
Note 2: These guidelines may not apply to all situaons. Electromagnec propagaons is aected by absorpon and reecons from struc-
tures, objects and people.
a Field strengths from xed transmiers, such as base staons for radio (cellular/cordless) telephones and land mobile radios, amateur ra-
dio, AM and FM radio broadcast and TV broadcast cannot be predicted theorecally with accuracy. To assess the electromagnec environ-
ment due to xed RF
transmiers, an electromagnec site survey should be considered. if the measured eld strength in the locaon in which the model SC-
2004-OC/SC-2004FC-OC/SC-2008-OC is used exceeds the applicable RF compliance level above, the model SC-2004-OC/SC-2004FC-OC/SC-
2008-OC should be observed to verify normal operaon. If abnormal performance is observed, addional measures may be necessary,
such as re-orienng or relocang the model SC-2004-OC/SC-2004FC-OC/SC-2008-OC.
bOver the frequency range 150 kHZ to 80 MHz, eld strengths should be less than 3 V/m.
Model SC-2004-OC/SC-2004FC-OC/SC-2008-OC Electromagnec Emissions—Manufacturer’s Declaraon
The SC-2004-OC/SC-2004FC-OC/SC-2008-OC are intended for use in the electromagnec environment specied below. The customer or the
user of the SC-2004-OC/SC-2004FC-OC/SC-2008-OC should assure that it is used in such an environment.
Emissions test Compliance Electromagnec environment— guidance
RF emissions
CISPR 11
Group 1 The model SC-2004-OC/SC-2004FC-OC/SC-2008-OC uses RF energy only for its internal
funcons. Therefore, its RF emissions are very low and are not likely to cause any inter-
ference in nearby electronic equipment.
RF emissions
CISPR 11
Class B
The model SC-2004-OC/SC-2004FC-OC/SC-2008-OC is suitable for use in all establish-
ments, including domesc establishments and those directly connected to the public
low voltage power supply network that supplies building used for domesc purposes.
Harmonic emissions
IEC 61000-3-2
Not applicable
Voltage uctuaons / icker
emissions
IEC 61000-3-3
Not applicable
Recommended separaon distances between portable and mobile RF communicaons equipment
and the SC-2004-OC/SC-2004FC-OC/SC-2008-OC
The SC-2004-OC/SC-2004FC-OC/SC-2008-OC are intended for use in an electromagnec environment in which radiated RF disturbances are
controlled. The customer of user of the SC-2004-OC/SC-2004FC-OC/SC-2008-OC can help prevent electromagnec interference by maintain-
ing a minimum distance between portable and mobile RF communicaons equipment (transmiers) and the SC-2004-OC/SC-2004FC-OC/SC-
2008-OC as recommended below, according to the maximum output power of the communicaons equipment.
Rated maximum output power
of transmier
W
Separaon distance according to frequency of transmier
m
150 kHz to 80 MHz 80 MHz to 800 MHz 800 MHz to 2.5 GHz
0.01 0.12 0.12 0.23
0.1 0.38 0.38 0.73
1 1.2 1.2 2.3
10 3.8 3.8 7.3
100 12 12 23
For transmiers rated at a maximum output power not listed above, the recommended separaon distance d in meters (m) can be esmated
using the equaon applicable to the frequency of the transmier, where p is the maximum output power rang of the transmier in was
(W) according to the transmier manufacturer.
Note 1: At 80 MHz, the separaon distance for the higher frequency range applies.
Note 2: These guidelines may not apply in all situaons. Electromagnec propagaon is aected by absorpon and reecon from struc-
tures, objects and people.
Guidance and Manufacturer’s Declaraon—Electromagnec Immunity
The SC-2004-OC/SC-2004FC-OC/SC-2008-OC are intended for use in the electromagnec environment specied below. The customer or the
user of the SC-2004-OC/SC-2004FC-OC/SC-2008-OC should assure that it is used in such an environment.
Immunity test IEC 60601
test level Compliance level Electromagnec environment— guidance
Electrostac
discharge (ESD)
IEC 61000-4-2
± 2, 4, and6 kV contact
± 2, 4 and 8 kV air
± 2, 4, and6 kV contact
± 2, 4 and 8 kV air
Floors should be wood, concrete or
ceramic le. If oors are covered with
synthec material, the relave humidi-
ty should be at least 30%.
Electrostac
fast transient /
burst
IEC 61000-4-4
± 2 kV for power supply lines
± 1 kV for input / output lines
± 2 kV
Not applicable
Mains power quality should be that of a
typical home use locaon.
Surge
IEC 61000-4-5
± 0.5 and 1 kV line(s) to line(s)
± 2 kV line(s) to earth
± 0.5 and 1 kV dierenal mode
Not applicable, no ground wire
Mains power quality should be that of a
typical home use locaon.
Voltage dips,
short
interrupons and
voltage variaons
on power supply
input lines
IEC 61000-4-11
<5 % U
T
(>95% dip in U
T
) for 0.5 cycles
40 % U
T
(60% dip in U
T
) for 6 cycles
70 % U
T
(30% dip in U
T
) for 30 cycles
<5 % U
T
(>95% dip in U
T
) for 5 s
<5 % U
T
(>95% dip in U
T
) for 0.5
cycles
40 % U
T
(60% dip in U
T
) for 6 cycles
70 % U
T
(30% dip in U
T
) for 30 cycles
<5 % U
T
(>95% dip in U
T
) for 5 s
Mains power quality should be that of a
typical home use locaon. If the user
of the model SC-2004-OC/SC-2004FC-
OC/SC-2008-OC requires connued
operaon during mains power interrup-
ons, it is recommended that the mod-
el SC-2004-OC/SC-2004FC-OC/SC-2008-
OC be powered from an uninterrupble
power supply or a baery.
Power frequency
(50/60 Hz) mag-
nec eld
IEC 61000-4-8
3 A/m 3 A/m The power frequency magnec elds
should be at the levels found in a typi-
cal home use locaon.
NOTE: U
T
is the AC mains voltage prior to applicaon of the test level.
18 19

MEDIRENT.COM.AU © 2020
9. Repair Service and Warranty
Technical Support—please call for all service repairs. Model and Serial numbers are required
for all service inquiries.
Phone AU: 1300 726 666
Internaonal call to AU: 612 9700 1744
Phone NZ: 09 972 3068
CAUTION: Tampering with or dismantling the Sequential Circulator in any way shall void the
warranty on the device.
Warranty repairs or adjustments shall be performed in a timely manner with minimal
inconvenience. For this reason, it is important that you obtain a “Return Material
Authorization” Number (RMA #) when calling Customer Service.
You can feel condent that your product is backed by the best warranty in the industry,
covering any and all malfunctions (including parts and labour) resulting from component and/
or manufacturing defects.
Compression Pump = 3 years from date of purchase / invoice
Sleeves/Garments = 1 year from date of purchase / invoice
Serial Number: ________________________________________________
Date Purchased: _______________________________________________
Repair Service Informaon
Warranty Informaon
20 21

MEDIRENT.COM.AU © 2020
22 23

MEDI-RENT
Unit 3/61 Beauchamp
Rd Matraville, 2067,
NSW
Ph: 1300 726 666
[email protected]
www.medirent.com.au
2020
MEDI-RENT
Unit 3/61 Beauchamp Rd Matraville,
2067, NSW
Ph AU: 02 9700 1744
Ph NZ: 09 972 3068
[email protected]
