Stryker Secure 3000 User manual

Modular Patient System (MPS) 3000 Bed
OPERATIONS MANUAL

Table of Contents
DINTRODUCTION 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSPECIFICATIONS 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DWARNING / CAUTION / NOTE DEFINITION 2. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSET–UP PROCEDURES 3. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DBED ILLUSTRATION 4. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DBASE
Brake Pedal Operation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Steer Pedal Operation 5. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DLITTER
CPR Emergency Release Usage 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Foley Bag Hooks Usage, Standard And Isolated (Isolated Optional Equipment) 6. . . . . . . . . . . . . . . . . . .
Foot Prop Usage 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Fracture Frame Usage 6. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
I.V. Poles 7. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Night Light Usage (Optional Equipment) 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Patient Restraint Strap Locations 8. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DFOOT BOARD/HEAD BOARD
Chart Rack Usage, Foot Board (Optional Equipment) 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
CPR Board Usage, Head Board (Optional Equipment) 9. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Panel Guide, Foot Board 10,11. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
LED Display Panel Guide, Foot Board 12. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSIDERAILS
Positioning Siderails 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Control Panel Lights 13. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Inside Siderail Function Guide 14. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Outside Siderail Function Guide 15. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DSYSTEMS
Weigh System Usage (Optional Equipment) 16,17. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Weigh System Control Panel Guide (Optional Equipment) 18,19. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
BED EXIT SYSTEM Usage (Optional Equipment) 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DYNAMIC MATTRESS SYSTEM Usage (Optional Equipment) 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Function Lockout System Usage 20. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
DLIMITED WARRANTY
Obtaining Parts and Service 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Supplemental Warranty Coverage 21. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Return Authorization 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
Freight Damage Claims 22. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

Introduction
2
INTRODUCTION
This manual is designed to assist you with the operation of the Modular Patient System (MPS) 3000 Bed.
Read it thoroughly before using the equipment. There is a separate maintenance manual for the 3000 bed
that contains information on preventative maintenance, troubleshooting, repair procedures, parts lists, etc.
SPECIFICATIONS
Maximum Weight Capacity 500 pounds
Overall Bed Length/Width 93”/41–1/2”
Patient Sleep Surface 84”/35”
Minimum/Maximum Bed Height 15 3/8”/31”
Knee Gatch Angle 0_to 40_
Fowler Angle 0_to 60_
Trendelenberg/Reverse Trendelenberg –12_to +12 _
Weigh System Accuracy (optional equipment) + / – 1% of total patient weight
Electrical Requirements – all electrical requirements
meet UL 544 specifications. 110 VAC, 60 Hz, 10.0 Amp
WARNING / CAUTION / NOTE DEFINITION
The words WARNING, CAUTION and NOTE carry special meanings and should be carefully reviewed.
WARNING
The personal safety of the patient or user may be involved. Disregarding this information could result in injury
to the patient or user.
CAUTION
These instructions point out special procedures or precautions that must be followed to avoid damaging the
equipment.
NOTE
This provides special information to make important instructions clearer.

Set–Up Procedures
3
SET–UP PROCEDURES
It is important that the MPS 3000 Bed is working properly before it is put into service. The following list will
help assure that each part of the bed is tested.
SPlug the bed into a properly grounded, hospital grade wall receptacle and assure the ”Power”LED light
at the foot end of the bed comes on.
WARNING
The 3000 is equipped with a hospital grade plug for protection against shock hazard. It must be plugged di-
rectly into a properly grounded three–prong receptacle. Grounding reliability can be achieved only when a
hospital grade receptacle is used.
SPlug the optional interface cable into the 37 pin connector under the litter frame at the head end of the
bed, and into the ”Patient Station”, ”Head Wall”, ”Docker Station”, or equivalent (whichever applies).
SAssure the siderails raise, lower and store smoothly and lock in the up and intermediate positions (page
13).
SAssure that all four casters lock when the brake pedal is engaged (page 5).
NOTE
Assure that the ”Brake Not Set”LEDs located on the outside of the head end siderails and on the foot board
control panel come on when the brakes are disengaged.
SRun through each function on the foot board control panel to assure that each function is working properly
(page 10 & 11).
SRun through each function on both head end siderails to assure that each is working properly (page 14
& 15).
SActivate the motion stop system to assure it is functioning properly: press and hold down the BED DOWN
key. As the bed lowers, lift up on the motion interrupt pan (page 4) and assure the downward motion
stops. Release the pan and allow the downward motion to continue.
NOTE
The bed’s upward motion or other functions are not disrupted by the motion stop system.
If any problems are found during bed set–up, contact Stryker Customer Service at 800–327–0770.
Damaged Merchandise
ICC Regulations require that claims for damaged merchandise must be made with the carrier within fifteen
(15) days of receipt of merchandise. DO NOT ACCEPT DAMAGED SHIPMENTS UNLESS SUCH DAMAGE
IS NOTED ON THE DELIVERY RECEIPT AT THE TIME OF RECEIPT. Stryker Customer Service must be
notified immediately. Stryker will aid the customer in filing a freight claim with the appropriate carrier for dam-
ages incurred. Claim will be limited in amount to the actual replacement cost. In the event that this information
is not received by Stryker within the fifteen (15) day period following the delivery of the merchandise, or the
damage was not noted on the delivery receipt at the time of receipt, the customer will be responsible for pay-
ment of the original invoice in full.
Claims for any short shipment must be made within thirty (30) days of invoice.

Bed Illustration
4
Brake Pedal
CPR Release
HEAD END
Footboard
Handle
Siderail Release
Handle
FOOT END
Control
Panel
Steer
Pedal
Foley Bag Hooks
(Standard)
Motion
Interrupt
Pan
I.V. and
Fracture Frame
Mount
I.V. and
Fracture Frame
Mount
Chart
Rack
Foley Bag Hook
(Isolated)
Night
Light
(Optional Equip.)
(Optional Equip.)

Base Operation Guide
5
BRAKE PEDAL OPERATION
WARNING
Before putting a patient on the bed, be sure the brakes are fully engaged.
To activate the brakes, push down once on the pedal
identified by the label at right (located at both sides of
the bed). To disengage, push down once.
NOTE
There are LED lights on the outside of the head end siderails and on the foot end control panel that will blink
when the brakes are not engaged only if the bed is plugged into a wall socket (see pages 12 &15). The brakes
will still operate properly when the bed is not plugged in.
STEER PEDAL OPERATION
The purpose of the steer caster is to help guide the bed along a straight line and to help with pivoting at corners
when the bed is moved.
To activate the steer caster, move the pedal located
at the head end of the bed to your left as shown on
the label.
NOTE
For proper ”tracking”of the steer caster, push the bed approximately 10 feet to allow the wheels to face the
direction of travel before engaging the steer pedal. If this is not done, proper ”tracking”will not occur and the
bed will be difficult to steer.

Litter Operation Guide
6
CPR EMERGENCY RELEASE USAGE
When quick access to the patient is needed, and the Fowler is raised, squeeze one of the two red release
handles (see illustration, page 4) and the Fowler can be guided down to a flat position.
NOTE
The handle can be released at any time to stop lowering the Fowler.
FOLEY BAG HOOKS USAGE, STANDARD AND ISOLATED (Isolated Optional
Equipment)
The standard Foley bag hooks are found at two locations on both sides of the bed, under the frame rail below
the seat section and the extreme foot end of the bed.
NOTE
The patient weight reading on the bed scale system will be affected by using the standard Foley bag hooks.
The optional isolated Foley bag hooks are located under the litter frame at the top of the foot end bellows.
CAUTION
The Foley bag hooks move when the Fowler is raised or lowered. Fowler motion must be locked out when
using these hooks, and great care must be taken by the clinician to avoid inadvertent movement of the hooks.
NOTE
The patient weight reading on the bed scale system will not be affected by usage of the isolated Foley bag
hooks.
FOOT PROP USAGE
To prop the foot end of the Knee Gatch up, grasp
the handle (A) at the end of the Knee Gatch and
lift upward, allowing the latch arm to engage at the
desired height. To release the prop, lift up slightly
on the handle (A) and swing the foot prop handle
(B) toward the head end of the bed to disengage
the hinge and allow the foot end to lower.
FRACTURE FRAME USAGE
A standard fracture frame can be mounted on the bed using the I.V. sockets located on all four corners of
the bed. I.V. poles can be used in conjunction with a fracture frame if I. V. pole adaptor sockets are purchased.
A
B
FOOT END

Litter Operation Guide
7
I.V. POLES
To use the Permanently Attached I.V. pole (optional equipment):
1. Lift and pivot the pole from the storage position and push down
until it is locked into receptacle (D).
2. To raise the height of the pole, turn the lock actuator (A) counter–
clockwise and pull up on the telescoping portion (B) of the pole to
raise it to the desired height.
3. Turn the lock actuator (A) clockwise to lock the telescoping portion
in place.
4. Rotate the I.V. hangers (C) to desired position and hang I.V. bags.
CAUTION
The weight of the I.V. bags should not exceed 40 pounds.
To use the ”Removable”I.V. pole:
1. Remove the pole from its storage position located at the foot end of the
bed, under the foot board.
2. Install the pole at any of the six receptacles on the bed top (located on
all four corners of the bed and halfway down the bed, on both sides.)
3. To raise the height of the pole, turn knob (A) counterclockwise and pull
up on the telescoping portion (B) of the pole and raise it to the desired
height.
4. Turn knob (A) clockwise to tighten the telescoping portion in place.
CAUTION
The weight of the I.V. bags should not exceed 40 pounds.
A
B

Litter Operation Guide
8
NIGHT LIGHT USAGE (Optional Equipment)
The bed may be equipped with
an optional night light (A) that will
illuminate the floor area around
the bed. The light has three set–
tings: LOW–OFF–HIGH.
PATIENT RESTRAINT STRAP LOCATIONS
The bed is equipped with 12 separate locations for installing patient restraint straps. The ”cutouts”in the bed
top are located directly across from each other (on both sides of the bed).
WARNING
Improperly adjusted restraint straps can cause serious injury to a patient. The clinician must use her/his
judgement to determine proper use of restraint straps and restraint strap locations.
A
FOOT END

Foot Board/Head Board Operation Guide
9
CHART RACK USAGE (Optional Equipment)
If the bed is equipped with the optional
chart rack, it is located on the foot
board. To use, pull handle rod (A)
downward. To store, push the handle
back to its storage position until it
locks in place.
CAUTION
Do not use handle rod (A) as a
device for pulling the bed. Doing
so may cause damage to the chart
rack and foot board.
CPR BOARD USAGE (Optional Equipment)
If the bed is equipped with the optional CPR board, it is stored on the bed’s head board. To remove, pull
away from the head board and lift out of storage position. If the CPR board option was not purchased,
the head board can also be removed and used as an emergency CPR board.
A
FOOT END

Foot Board/Head Board Operation Guide
10
FOOT BOARD CONTROL PANEL GUIDE
ON
OFF
ON
OFF
12345
6
7
8
9
1. Push to turn on siderail control panel lights. Push again to turn off (see page 13).
2. Push to lock out all bed motions. Push again to unlock (see page 20).
3. Push to lock out Fowler. Push again to unlock (see page 20).
4. Push to lock out Knee Gatch. Push again to unlock (see page 20).
5. Push to lock out bed height movement. Push again to unlock (see page 20).
6. Push to raise bed height.
7. Push to lower bed height.
8. Push to lower head end/raise foot end of bed (Trendelenberg position).
9. Push to lower foot end/raise head end of bed (Reverse Trendelenberg position).
1. Push to raise Fowler.
2. Push to raise Knee Gatch.
3. Push to lower Fowler.
4. Push to lower Knee Gatch.
"This panel is optional equipment.
1. Push to activate Bed Exit function (see page 20).
2. Push to deactivate Bed Exit function (see page 20).
"This panel is optional equipment.
12
34
ARM DISARM
12

Foot Board/Head Board Operation Guide
11
FOOT BOARD CONTROL PANEL GUIDE (Continued)
1. Push to turn the Dynamic Mattress system on or off (see page 20).
2. Push to activate automatic or manual modes (see page 20).
"This panel is optional equipment.
1. LCD –displays patient weight.
2. Push to zero bed (see page 16 & 18).
3. Push when changing equipment on the bed (see page 16 & 18).
4. Push to change weight from pounds to kilograms or back (see page 17 & 18).
5. Push to turn weigh system on (see page 16 –18).
6. Push to decrease numerical value of displayed weight (see page 17 & 19).
7. Push to increase numerical value of displayed weight (see page 17 & 19).
"This panel is optional equipment.
NOTE
See page 12 for explanation of LED’s.
ON
OFF
1
AUTO
MAN
2
123 4
567
SCALE
ON

Foot Board/Head Board Operation Guide
12
LED DISPLAY PANEL GUIDE
The LED Display Panel is located at the foot end of the bed, under the Control Panel.
POWER BED MOTION LOCKED BRAKE NOT SET BED EXIT ON AIR LOSS
”POWER”–will light when the bed is plugged into the wall receptacle.
”BED MOTION LOCKED”–will light when the Bed Motion Lock has been activated.
”BRAKE NOT SET”–will blink when the brakes have not been set.
”BED EXIT ON”–will light when the Bed Exit function has been activated (optional equipment).
”AIR LOSS”–will light when there is a possible air leak in the Dynamic Mattress System (optional equipment).

Siderail Operation Guide
13
POSITIONING SIDERAILS
NOTE
The siderails can be locked at two heights (intermediate & full).
The siderails can be tucked away under the bed when not in use.
To remove the rail from the tucked position, grasp at the top of the
rail and pull outward.
To engage the siderail, grasp the rail and push it
upward until it rests in the ”intermediate”position.
To continue to the full height, pull the brown
release handle (A) until full height is
reached.
WARNING
Be sure rail is locked securely
into position. Siderails are not
intended to keep patients from
exiting the bed. They are
designed to keep a patient
from inadvertently rolling off the
bed. Proper restraint methods
should be utilized to ensure the
patient remains in bed.
To disengage the rail, pull the brown release handle and pivot rail down to desired height. Tuck away siderails
by pushing the rails under the bed. Rails must be in the full down position before they can be tucked.
SIDERAIL CONTROL PANEL LIGHTS
The bed is equipped with lights that will illuminate the head end siderail control panel and can be activated
at the foot board control panel (see control panel guide page 10).
A

Siderail Operation Guide
14
INSIDE SIDERAIL FUNCTION GUIDE
(Patient’s Right Rail)
1. Push to raise Knee Gatch.
2. Push to raise Fowler.
3. Push to lower Knee Gatch.
4. Push to lower Fowler.
(Patient’s Left Rail)
1. Push to raise Fowler.
2. Push to raise Knee Gatch.
3. Push to lower Fowler.
4. Push to lower Knee Gatch.
Push to activate Nurse Call.
NOTE
Yellow LED will light when button is pushed. Red LED will light with
Nurse Station acknowledgment.
"This panel is optional equipment.
Push to turn TV or radio on and to select a channel.
Push to increase volume.
Push to decrease volume.
"This panel is optional equipment.
Push to increase firmness of mattress.
Push to decrease firmness of mattress.
LED will light when the ”Manual”mode has been set at the foot
end of the bed.
"This panel is optional equipment.
Push to turn the room light on.
Push to turn the bed overhead light on.
"This panel is optional equipment.
12
34
12
34

Siderail Operation Guide
15
OUTSIDE SIDERAIL FUNCTION GUIDE
(Patient’s Right Rail)
1. Push to raise Fowler.
2. Push to raise Knee Gatch.
3. Push to lower Fowler.
4. Push to lower Knee Gatch.
"This panel is optional equipment.
(Patient’s Left Rail)
1. Push to raise Knee Gatch.
2. Push to raise Fowler.
3. Push to lower Knee Gatch.
4. Push to lower Fowler.
"This panel is optional equipment.
Push to raise bed height.
Push to lower bed height.
LED will blink when the brakes are not set.
Push to activate Nurse Call.
"This panel is optional equipment.
12
34
12
34

Weigh System Usage
16
OPERATING THE SCALE BEFORE PUTTING A NEW PATIENT IN BED
SPrepare bed for patient stay (linens, pillows, etc.).
SPress and release ”SCALE ON”. The scale monitor will read:
”WEIGHING”
”XXX.X LB”
SPress and hold ”ZERO”. The scale monitor will read:
”HOLD TO ZERO WT.”
”RELEASE TO ZERO”
SRelease ”ZERO”. The scale monitor will now read:
”DO NOT TOUCH BED”
”0.0 LB”
The bed is now ready for the patient.
NOTE
Do not zero the bed while a patient is in bed. If this should occur, remove the patient and zero the bed.
OPERATING THE SCALE IF PATIENT IS ALREADY IN BED
SIf it is necessary to add or remove special equipment (monitors, pumps, etc.) during the patient’s
stay, press and release ”SCALE ON”to activate the weigh system. After the scale monitor reads
”XXX.X LB”, press and hold . The scale monitor will read:
”HOLD TO START”
”RELEASE TO START”
SRelease . The scale monitor will read:
”DO NOT TOUCH BED”
”ADD/REMOVE EQUIP”
SAdd or remove the equipment and press . The scale monitor will read:
”RELEASE TO FIN.”
SRelease . The scale monitor will read:
”DO NOT TOUCH BED”
”XXX.X LB”
The weight displayed will be that of the patient only.

Weigh System Usage
17
CONVERTING THE PATIENT’S WEIGHT
STo convert the patient’s weight from pounds to kilograms, press and release ”SCALE ON”to activate
the weigh system. After the scale monitor reads ”XXX.X LB”, press and release the ”LBS/KGS”but-
ton. The scale monitor will read: ”WEIGHT NOW KGS”
”XXX.X KG”
SRepeat the procedure to return to pounds. The display will read:
”WEIGHT NOW LBS”
”XXX.X LB”
CHANGING THE NUMERICAL VALUE OF DISPLAYED WEIGHT
STo decrease the numerical value of the displayed weight, press and hold ”–”. The scale monitor will
read: ”HOLD TO DEC. WT.”
”XXX.X LB”
SHold ”–”until desired value is achieved.
STo increase the numerical value of the displayed weight, press and hold ”+”. The scale monitor will
read: ”HOLD TO INC. WT.”
”XXX.X LB”
SHold ”+”until desired value is achieved.
NOTE
The weigh system will shut off approximately one minute after a function has been used, if another function
is not activated. Display light will shut off and display will read ”SCALE OFF”.
The weigh system will retain all patient weight information in its memory even when the scale monitor is off
or when the bed is unplugged from the wall socket.

Weigh System Control Panel Guide
18
SYMBOL ACTION DISPLAY
To prepare bed for new patient:
Press and release ”SCALE ON””WEIGHING...”
to activate the scale system, begin ”XXX.X LB”
a new function and to display patient
weight.
Press and hold ”ZERO””HOLD TO ZERO WT.”
”RELEASE TO ZERO”
Release ”ZERO””DO NOT TOUCH BED”
”0.0 LB”
To add or remove equipment
during patient stay without
affecting registered patient
weight:
Press and release ”SCALE ON””WEIGHING...”
”XXX.X LB”
Press ”HOLD TO START”
”RELEASE TO START”
Release ”DO NOT TOUCH BED”
”ADD/REMOVE EQUIP.”
Add or remove equipment.
Press ”RELEASE TO FIN.”
Release ”DO NOT TOUCH BED”
”XXX.X LB”
To convert the patient’s weight:
To convert the patient’s weight ”WEIGHT NOW KGS”
to kilograms, press and release ”XXX.X KG”
”LBS./KG.”
Repeat the procedure to return to
pounds.
SCALE
ON
ZERO
LBS.
KG.

Weigh System Control Panel Guide
19
SYMBOL ACTION DISPLAY
To change the numerical value
of displayed weight:
Press and hold to scroll to ”HOLD TO DEC. WT.”
desired weight. ”XXX.X LB”
Press and hold to scroll to ”HOLD TO INC. WT.”
desired weight. ”XXX.X LB”
