Birlea COROB4HPINV2 User manual

IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR
USING YOUR 4'0 CORONA HIGH END BED.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT jump on this bed frame.
DO NOT use this bed frame if any parts are missing, damaged or worn.
DO NOT use this bed frame unless all fixings are secured.
Always use on a level, even surface.
WARNING: If this bed is placed on a non-carpeted floor you must place some protection under all legs to stop
the bed frame from moving. If this is not adhered to there is no guarantee if the bed frame collapses.
CARE & MAINTENANCE:
Periodically check all screws & fixings to ensure they are secure.
DO NOT push the bed frame as this will damage the legs.
Always lift the bed with two people to reposition.
Keep any sharp objects away from the frame.
4 m
4m
ASSEMBLY INSTRUCTIONS
4'0 CORONA HIGH END BED
Page 1 of 7
!
f
You
Tube
www.birlea.com
Vendor: S000238

HARDWARE LIST - Box 2
Part Item Qty
30mm dowel
16mm Screw
30mm Screw
Nut
50mm Bolt
120mm Bolt
Half moon nut
A
D
G
L
B
E
J
M
C
F
K
10
4
52
8
2
2
10
8
8
40mm dowel 130mm Bolt
Recycle
2m
01 2 345 6 7891 0
mm 1 1 1 2 1 3 1 4 1 5 1 6
Part Item Qty
32mm Bolt 2
H
N
Metal bracket
O
2
You will need a screwdriver, small mallet
and M11 spanner (not provided).
2
Spacer
1
Allen key
8
Round metal stud
1Headboard panel (117 x 49cm) - Box 1
2Headboard rail (117 x 9.2cm) - Box 1
3Footboard panel (117 x 41.9cm) - Box 1
Left headboard post (110 x 8.2cm) - Box 2
4
Right headboard post (110 x 8.2cm) - Box 2
5
Left footboard post (88 x 8.2cm) - Box 2
6
Right footboard post (88 x 8.2cm) - Box 2
7
Side rail x 2 (190 x 11.2cm) - Box 2
8
Centre rail (195.5 x 6.5cm) - Box 2
9
10 Slat x 26 (61 x 6.5cm) - Box 1 11 Support leg x 2 (28.3 x 6.5cm) - Box 1
Page 2 of 7
Vendor: S000238
12 Hardware Kit x 1 - Box 2

2x
G
B
B
A
A
A
A
A
A
11
11
9
8
N
1
2
Page 3 of 7
Step 2: Insert hardware part A to the headend panel (1), footboard panel (3) and Headboard rail (2) using a small mallet
(not provided).
3
Vendor: S000238
Step 1: Join the support legs (11) to the centre rail (9) using hardware N and G.
Insert hardware part B to the side rails (8) using a small mallet (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.

H
H
H
H
H
H
H
H
N
1
4
5
5
4
2
N
67
Page 4 of 7
Step 4: Attach the left footend post (6) and right footend post (7) to the footend panel (3) using hardware
parts N and H.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
H
H
H
H
7
3
6
Vendor: S000238
Step 3: Attach the left headboard post (4) and right headboard post (5) to the headend panel (1)
.and headend rail (2) using hardware parts N and H
DO NOT use any power tools as this may damage the frame and will invalidate any claim.

1
C
J
E
F
K
3
L
L
1
8
89
N
8
9
Page 5 of 7
Step 6: Attach the side rails (8) to the posts using hardware parts N, J and K. Fix the centre rail (9)headboard
using hardware parts E and F with an M11 spanner (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
L
1
Vendor: S000238
Step 5: Fix hardware parts L to the headboard rail (2) and footboard panel (3) using hardware part C
.and a screwdriver (not provided)
DO NOT use any power tools as this may damage the frame and will invalidate any claim.

b:
a:
J
K
E
F
D
D
N
8
9
3
10
10 10
10
10
10
O
O
10
10
Page 6 of 7
Step 7: Attach the footend using hardware parts N, J and K and fix the centre rail (9) in place using
hardware parts E and F with an M11 spanner (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
3
Vendor: S000238
Step 8: Fix slats (10) to the side rails (8) and centre rail (9) using hardware parts O and D with a screwdriver (not provided).
Make sure to start from the ends and work towards the middle.
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
9
8
8

160mm
50mm
Step 9: Insert hardware part M using a small mallet (not provided).
DO NOT use any power tools as this may damage the frame and will invalidate any claim.
M
M
MM40mm
40mm
Page 7 of 7
M
M
Vendor: S000238
Additional Information:
• For complete product information, images and dimension diagrams please visit the
website www.birlea.com
• If you have any issues with your item please contact the retailer directly you
purchased it from who will be able to resolve any issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [email protected] to be
shared in our #birleahome feature on Instagram.
