ASSEMBLY INSTRUCTIONS
NEW HAMPSHIRE 3 DOOR 2 DRAWER WARDROBE
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR NEW HAMPSHIRE
3 DOOR 2 DRAWER WARDROBE.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this wardrobe if any parts are missing, damaged or worn.
DO NOT use this wardrobe unless all fixings are secured.
Always use on a level, even surface.
WARNING: If thi item i placed on a non-carpeted floor you mu t place ome protection under all leg to top
the wardrobe from moving. If thi i not adhered to there i no guarantee if the wardrobe collap e .
CARE & MAINTENANCE:
Periodically chec all screws & fixings to ensure they are secure.
DO NOT push the wardrobe as this will damage the legs.
Always lift the wardrobe with two people to reposition.
Keep any sharp objects away from the wardrobe.
www.birlea.com

Vendor: S000299
Page 2 of 5
Parts List
1 – Top Panel (Box 1) 2 – Drawer Cabinet (Box 2) 3 – Front Panel (Box 1)
4 – Left Panel (Box 1) 5 – Ri ht Panel (Box 1) 6 – Centre Panel (Box 1)
7 – Back Panel (Box 1) 8 – Han in Rail x 2 (Box 1) 9 – Shelf x 2 (Box 1)
Hardware Li t (found in box 1)
Part De cription Qty
A M6 x 35 mm Bolt 24
B M6 x 40 mm Bolt 12
C
6 x 19 mm Washer
36
D 8 x 25 mm Wooden Dowel 6
E
Brac et
6
F
Connector
2
G 3 x 15 mm Screw 28
H
Handle
3
K Allen Key 1
L Brac et
6
**You will need a crewdriver (not provided).

Vendor: S000299
Page 3 of 5
Step 1: Attach the left panel (4), right panel (5) and centre panel (6) to the front panel (3) using hardware
parts A, C and K.
DO NOT u e any power tool a thi may damage the frame and will invalidate any claim.
Step 2: Attach the bac panel (6) using hardware parts A, C and K.
DO NOT u e any power tool a thi may damage the frame and will invalidate any claim.

Vendor: S000299
Page 4 of 5
Step 3: Insert the hanging rails (8). Attach the top panel (1) using hardware parts B, C and D.
DO NOT u e any power tool a thi may damage the frame and will invalidate any claim.
Step 4: Join the two sections together using hardware part D and F.
DO NOT u e any power tool a thi may damage the frame and will invalidate any claim.

Vendor: S000299
Page 5 of 5
Step 5: Secure the two sections together using hardware parts F and G.
DO NOT u e any power tool a thi may damage the frame and will invalidate any claim.
Step 6: Insert the shelves (9) and secure using hardware parts G and L. Attach hardware part H. Secure the
two sections together using hardware part E and G.
DO NOT u e any power tool a thi may damage the frame and will invalidate any claim.
Additional Information:
• For complete product information, images and dimension diagrams please visit the
website www.birlea.com
• If you have any issues with your item please contact the retailer directly you
purchased it from who will be able to resolve any issues with Birlea.
• Why don’t you send us photos of your assembled furniture to [email protected] to be
shared in our #birleahome feature on Instagram.
