Birlea CONRAD CON1BSSLOK User manual

Vendor: S000369
Page 1 of 9
ASSEMBLY INSTRUCTIONS
CONRAD 1 DRAWER BEDSIDE SILVER OAK
IMPORTANT: READ THESE INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR USING YOUR CONRAD
1 DRAWER BEDSIDE SILVER OAK.
PLEASE KEEP THESE INSTRUCTIONS FOR FUTURE REFERENCE.
HEALTH & SAFETY:
DO NOT use this Bedside if any parts are missing , damaged or worn.
DO NOT use this Bedside unless all fixings are secured.
Always use on a level, even surface.
WARNING: If this item is placed on a non-carpeted floor you must place some protection under all legs to stop
CARE & MAINTENANCE:
DO NOT push the bedside as this will damage the legs.
Always lift the bedside with two people to reposition.
Keep any sharp objects away from the bedside.
www.birlea.com
the bedside from moving. If this is not adhered to there is no guarantee if the bedside collapses.
Periodically check all screws & fixings to ensure they are secure.

Vendor: S000369
Page 2 of 9
1 x H
Inner Drawer
Runners
1 x M
Inner Drawer
Runners
1 x N
Outer Drawer
Runners
1 x O
Outer Drawer
Runners
1 x P
Wall Plug
1 x Q
Bracket
1 x R
Screw
4x12mm
8 x I
Wooden
Dowel
4 x J
Screw
4x40mm
4 x K
Screw
3x14mm
6 x L
Bolt
6x35mm
12 x A
Cam Lock
12 x B
Quickfit Screw
5 x C
Screw
4x30mm
12 x G
Screw
3x12mm
1 x E
Handle
2 x F
Bolt
6x30mm
4 x D
Wedge
1 - 1pc 2 - 1pc 5 - 1pc 6 - 1pc3 - 1pc 4 - 1pc
7 - 1pc 8 - 1pc 11 - 1pc 12 - 3pcs9 - 1pc 10 - 1pc 13 - 2pc
Hardware
Parts
s

Vendor: S000369
Page 3 of 9
C x 4
A x 4
B x 4
F x 2
E x 1
H x 1
M x 1
G x 6
C
C
C
C
7
8
9
78
7
10
A
A
B
B
E
F
F
B
B
A
A
G
G G
M
GG
H
G
G
H
M
G
G
G
G
G
9
711
9
Step 1
DRAWERS
Fix panels 7, 8and 9
together using screws C.
Fit quickfit screws B
to front panel 10.
Fix handle Eto front of
drawer using bolts F.
Turn drawer over and fix
inner drawer runners H
and Mto underside of
drawer using screws G.
Insert cam locks Ato
panels 7and 9.
Fit panel 10 to front of
drawer and turn cam locks
clockwise to tighten.
Fit base panel 11 into grooves
between panels 7and 9.

Vendor: S000369
Page 4 of 9
G x 6
G
G
G
N
G
N
2
G
G
G
O
G
O
3
A
A
B
I
I
B
2
3
A
A
B
B
I
I
5
2
4
N x 1
O x 1
I x 2
A x 2
B x 2
I x 2
A x 2
B x 2
5
4
Step 2
Fix outer drawer runners Nand Oto
panels 2and 3using screws G.
Step 3
Insert quickfit screws Band
wooden dowels Ito panel 2.
Insert cam locks to panels 4and 5.
Fit panels together and turn cam
locks clockwise to tighten.
Step 4
Insert quickfit screws Band
wooden dowels Ito panel 3.
Insert cam locks to panels 4and 5.
Fit panels together and turn cam
locks clockwise to tighten.

Vendor: S000369
Page 5 of 9
B x 4
Q x 1
R x 1
6
2
3
B
B
B
B1
Q
R
Step 5
Slide back panel 6into slots in between panels 2and 3.
Step 6
Fit quickfit screws Bto panel 1.
Fix bracket Qto underside of
panel 1using screw R.

Vendor: S000369
Page 6 of 9
A x 4
K x 4
D x 4
I x 4
A
A
A
I
I
II
K
D
D
D
K
K
K
D
K
D
1
2
3
6
3
Step 7
Insert wooden dowels Ipanels 2and 3.
Insert cam locks Ato panels 2and 3.
Step 8
Fit wedges Dto back of unit
to secure back panels.
Secure with screws K.
Lower panel 1into place and
turn cam locks to tighten.

Vendor: S000369
Page 7 of 9
J x 4
L x 6
L
L
L
L
L
L
13
13
12
2
12
12
J
J
J
J
13
Step 9
Fix parts 12 and 13 together using bolts L, as shown.
Step 10
Fix joined leg parts (Step 9) to
base of assembled unit using
screws J, as shown.

Vendor: S000369
Page 8 of 9
P
C
P x 1
C x 1
Step 11
For extra stability, it is recommended that you fix your bedside table
to the wall using the additional hardware C and P, as shown. Screw C is
fixed from inside the unit, through the bracket and into the wall plug P.
Should you choose not to affix the product to the wall,
serious injury may be caused if the product tips over.

Vendor: S000369
Page 9 of 9
10kg
4kg
Step 12
Once the unit is in its final location fit the drawer onto runners in unit as shown.
Additional Information:
• For complete product information, images and dimension diagrams please visit the
website www.birlea.com
•If you have any issues with your item please contact the retailer directly you
purchased it from who will be able to resolve any issues with Birlea.
shared in our #birleahome feature on Instagram.
•Why don’t you send us photos of your assembled furniture to [email protected] to be
