BIXOLON SRP-S3000 User manual

User’s Manual
LINERLESS PRITNER
Ver. 1.00
SRP-S3000
http://www.bixolon.com

Ver. 1.00
- 2-
SRP-S3000
Introduction
SRP-S3000 printers have been designed to be connected to various types of electronic
devices such as POS (Point Of Sales), and computer peripheral devices.
※
The main features of the printer are as follows
1. LINERLESS PRINTER
2. Low-noise thermal transfer method printing
3. Maximum 200mm/s printing speed
4. 142 x 210 x 157 (W X D X H)
5. Interface: Serial, USB, Ethernet, WLAN(2.4GHz/5GHz), Bluetooth 5.0
6. Equipped with data buffer (receives print data even while printing)
7. Can print a range of barcodes
8. Range of printing density selectable
(controlled with virtual memory switch management)
It is advisable to read the contents of this manual carefully before using the printer for
the first time.
※
Use only authorized supplies that can be trusted!
- We are not responsible for quality and service for damage caused by the use of
unauthorized products (or recycled ones).

Ver. 1.00
- 3-
SRP-S3000
Safety Information
Warning: Warnings must be heeded carefully in order to prevent serious physical
harm.
Caution: Cautions must be heeded in order to prevent minor injuries, equipment
damage, or data loss.
Symbol Information
DC (Direct current)
Error, Warning
Paper Feeding
Stand-By
USB
Ethernet

Ver. 1.00
- 4-
SRP-S3000
Table of Contents
1. Installing Printer and Getting Started ......................................................................... 5
1-1 Unpacking.............................................................................................................................5
1-2 Interface................................................................................................................................6
1-2-1 USB Interface (Device Function USB B Type Connector)....................................6
1-2-2 USB Interface (HOST Function, USB A Type Connector).....................................7
1-2-3 Ethernet Interface ...................................................................................................8
1-2-4 Serial Interface(RS-232C)........................................................................................9
1-2-5 Wireless LAN Interface (Option)..........................................................................10
1-2-5 Bluetooth Interface (Option) ...............................................................................10
1-3 Cash drawer Port ...............................................................................................................11
1-4 Connecting Power Supply.................................................................................................13
1-5 Reconfiguration of Printer................................................................................................15
1-6 Installing & Replacing Paper ............................................................................................16
1-7 Recommended Papers......................................................................................................19
1-8 Removing Paper Jam .........................................................................................................20
1-9 Using Printer Functions ....................................................................................................21
1-10 Mounting Partition(40,58mm)........................................................................................22
2. Self-Test ......................................................................................................................... 23
3. LCD Menu ...................................................................................................................... 25
4. Cleaning Printer............................................................................................................ 28
5. Specifications ................................................................................................................ 30

Ver. 1.00
- 5-
SRP-S3000
1. Installing Printer and Getting Started
1-1 Unpacking
• Check the following contents list, and contact your dealer for assistance if any item is
missing or incorrect.
- Product
SRP-S3000
- Standard Components
Power Cord
Installation Guide
USB A-B Cable
Partition 2ea
- Optional Components
Serial Cable
(9pin - 9pin)

Ver. 1.00
- 6-
SRP-S3000
1-2 Interface
• Connect the printer to the host computer using the right interface cable that complies
with the specifications of the interface
1-2-1 USB Interface (Device Function USB B Type Connector)
Pin No.
Signal Name
Designation (Color)
Function
Shell
Shield
Drain Cable
Frame Ground
1
VBUS
RED
Host Power
2
D-
WHITE
Data Line (D-)
3
D+
GREEN
Data Line (D+)
4
GND
BLACK
Signal Ground
Caution After turning off the power switch of printer, connect and disconnect
the communication cable.
USB B Port (Device Function)

Ver. 1.00
- 7-
SRP-S3000
1-2-2 USB Interface (HOST Function, USB A Type Connector)
Pin No.
Signal Name
Designation (Color)
Function
Shell
Shield
Drain Cable
Frame Ground
1
VBUS
RED
Host Power
2
D-
WHITE
Data Line (D-)
3
D+
GREEN
Data Line (D+)
4
GND
BLACK
Signal Ground
USB Interface can connect to the peripheral devices.
(ie. the barcode reader, customer display and WLAN Dongle that is supported by the
printer.)
Caution
Do not connect the USB A-A type cable with the Printer and H
OST(ex. PC)
After turning off the power switch of printer, connect and disco
nnect the communication cable.
USB A Port(HOST Function)

Ver. 1.00
- 8-
SRP-S3000
1-2-3 Ethernet Interface
Pin No.
Signal Name
Designation (Color)
Function
1
TD+
WHITE ORANGE
Transmit +
2
TD-
ORANGE
Transmit -
3
CT
WHITE GREEN
Center tap
4
NC
BLUE
-
5
NC
WHITE BLUE
-
6
NC
GREEN
-
7
RD+
WHITE BROWN
Receive +
8
RD-
BROWN
Receive -
Note
Refer to the utility and network connection manual for
Interface connection information.
Caution After turning off the power switch of printer, connect and disconnect
the communication cable.
Ethernet Cable Port

Ver. 1.00
- 9-
SRP-S3000
1-2-4 Serial Interface(RS-232C)
Pin No.
Signal Name
Direction
Function
1
NC
-
-
2
TxD
Output
Transmit Data
3
RxD
Input
Receive Data
6,8
RTS
Output
Ready To Send
4,7
CTS
Input
Clear To Send
5
SG
-
Signal Ground
9
NC
-
-
Caution After turning off the power switch of printer, connect and disco
nnect the communication cable.
Serial Cable Port

Ver. 1.00
- 10 -
SRP-S3000
1-2-5 Wireless LAN Interface (Option)
1) Wireless LAN Communication Specifications
Item
Specifications
Frequency
2.4GHz / 5GHz
Protocol
802.11 a/b/g/n
2) Connecting Wireless LAN
Printer can be connected to terminal devices with Bluetooth communication
Capability. (PDA, PC, smartphone, tablet PC, etc.)
Note
Refer to the Wireless Wireless LAN Connection Manual for more
detailed instructions about how to establish the connection.
1-2-5 Bluetooth Interface (Option)
1) Bluetooth Communication Specifications
Item
Specifications
Frequency
2.402~2.480 GHz
Version
5.0
2) Bluetooth Connection
Printer can be connected to terminal devices with Bluetooth communication
Capability. (PDA, PC, smartphone, tablet PC, etc.)
Note Refer to the Bluetooth Connection Manual for more detailed
instructions about how to establish the connection.

Ver. 1.00
- 11 -
SRP-S3000
1-3 Cash drawer Port
• Connect the cash drawer cable to the drawer kick-out port on the rear side of the
printer.
Pin No.
Signal Name
Direction
1
Frame Ground
-
2
Drawer Kick-out Drive Signal 1
Output
3
Drawer Open/Close Signal
Input
4
+24V
-
5
Drawer Kick-out Drive Signal 2
Output
6
Signal Ground
-
Caution
- Use a cash drawer that meets the printer specifications.
Using a cash drawer that is inappropriate to the specs or us
Ing it as a power supply for a separate device may result in
damage to the product.
- Do not connect a telephone line to the drawer kick-out port.
Otherwise, the telephone line and the computer may be
damaged.
- Do not allow a foreign object such as a conductor to touch
the drawer kick-out port.
This may result in damage to the product
- Make sure to use a cash drawer with an internal coil resistance of
24 Ωor higher. (The maximum current is 1A.)
Drawer Kick-out Port

Ver. 1.00
- 12 -
SRP-S3000
- The open signal time for the cash drawer should not exceed 0.8
seconds. After opening the cash drawer, make sure to idle for at
least 3.2 seconds (at least 4 times that of the open signal time)
before operating it.

Ver. 1.00
- 13 -
SRP-S3000
1-4 Connecting Power Supply
1) Make sure the product is turned off before connecting the power supply.
2) Connect the power cable with the flat side pointing to the outside of the printer, as
shown in the diagram below.
Power Port
Power Cord

Ver. 1.00
- 14 -
SRP-S3000
Caution
- Only use a power supply provided by Bixolon. Bixolon shall
bear no responsibility for damage caused by using a third-party
power supply.
- Check the power supply’s label to check its electronic specs.
- When removing the power supply, make sure you have a firm
grasp of the plug terminal of the power cable and the printer
and pull horizontally.
- When connecting or disconnecting power, make sure to remove
the power supply from the power outlet before removing.
- Pay attention to the direction in which you insert the power
cable.
Warning Do not connect a voltage out of the specifications of the power
supply. It can cause damage to the product or a fire.
O
X

Ver. 1.00
- 15 -
SRP-S3000
1-5 Reconfiguration of Printer
• This product supports virtual memory switch change the use the virtual memory
switch utility. Use virtual memory switch management function for self-diagnosis.
Note
- Use the Unified Utility or LCD to change the virtual memory switch
settings.
- For more information, refer to the utility and 3. LCD Menu.
Caution Turn the power ON/OFF after changing the settings using the virtual
memory switch utility and LCD.

Ver. 1.00
- 16 -
SRP-S3000
1-6 Installing & Replacing Paper
1) Open the paper roll cover by Pulling the Cover-Open Lever.
Caution Do not open the print cover while the printer is operating,
otherwise the printer may be damaged.

Ver. 1.00
- 17 -
SRP-S3000
2) Remove the empty paper roll and replace with a new one as shown in the image.
Caution
Check the orientation of the roll paper when inserting it into
the printer.
O
X

Ver. 1.00
- 18 -
SRP-S3000
3) Pull out a small amount of paper as shown in the picture, and close the cover.
Caution
-
When closing the cover, hold down the center of printer cover
firmly so that paper roll is loaded correctly.
- Make sure to use the specified paper only.

Ver. 1.00
- 19 -
SRP-S3000
1-7 Recommended Papers
- Iconex
Classic: 9023-1253, 9023-1232(80mm), 9023-1823, 9023-1397(58mm),
9023-1233, 9023-1818(40mm)
Classic High Tack: 9023-1254(80mm), 9023-1500(58mm), 9023-1258(40mm)
Classic High Temp: 9023-1267, 9023-1463 (80mm), 9023-1269(40mm)
Ultralite: 9023-1866(80mm), 9023-1410(58mm), 9023-1865(40mm)
Classic High Tack Plus: 9023-1846(80mm)
Linerless Extreme(Snag Resistant): 9023-1873, 9023-1708(40mm)
Linerless Extreme(Freshness Labeling): 9016-3227, 9016-3777, 9016-3257(40mm)
- MAXStick
2GO: MS2142402GO3S(58mm), MS3182402GO4S(80mm)
PLUSD: MS1732290PLUSD HVHR(40mm), MS214170PLUSD(58mm),
MS318170PLUSD(80mm), MS3183752GOPLUSD(80mm)
X2: MS11732270X2HRHT(40mm), MS214150X2(58mm)
- StickyPOS
40MMRL90-9000(40mm), 2CR-11 58X350(58mm) 2CR-11 80X350(80mm)
- Sato
Restick: 585006411(80mm)
Linerless Extreme: 585006451(80mm)
- Blumberg
Linerless Extreme: A11649(58mm), A12978(80mm)
Caution
- Use of papers other than those recommended above may
damage TPH or degrade the printing quality and our
company Is not responsible for the damage caused by
non-recommended papers.
- If you have to use other products, we recommend that you
Use papers with a similar level of quality to the recommended
ones.

Ver. 1.00
- 20 -
SRP-S3000
1-8 Removing Paper Jam
1) When a paper jam occurs, turn the printer OFF and then back ON, open the cover,
and remove the jammed paper.
※
In case of a minor jam, it may be possible that the operating blade returns to
the original position and cover can be opened simply by turning the printer OFF
and then back ON.
Follow the steps shown below if the cover does not open after power cycling.
2) Turn the printer OFF.
3) Lift the paper rollout part of the COVER-CUTTER to remove it.
4) Turn the knob and insert the blade that sticks out using a cross-head screwdriver as
shown below.
5) Lift the cover-open lever and remove the jammed paper. Put the COVER-CUTTER back
in place.
6) Turn the printer ON and use it.
Note
- Placing your hand above the printer outlet may cause a paper jam.
- In case of a minor jam, it may be possible that the operating
blade returns to the original position by turning the printer
OFF and then back ON.
COVER-CUTTER
