BJ Live SHX INTERACTIVE PANEL User manual

c.Mare de Déu del Coll, 70,Local|08023|Barcelona|Spain|t.+34 93 285 04 37|fax + 34 93 553 56 34| [e-mail] | www.bjliveat.com
BJ EP2 SHX INTERACTIVE PANEL
Installation Guide

BJ-EP2 SHX INTERACTIVE PANEL
Installation Guide
BJ_EP2 SHX Interactive Panel
Page 2
1_Components
PC and touchscreen monitor Wireless keyboard/ mouse
Microphone Wall bracket
2_Attaching the padding
Remove the protective foil from the double-sided tape to attach the padding to the monitor
frame. The ON/OFF button must be situated at the top of the monitor. Once the padding
has been attached, locate and connect the female connector in the panel to the male
connector in the padding.

BJ-EP2 SHX INTERACTIVE PANEL
Installation Guide
BJ_EP2 SHX Interactive Panel
Page 3
3_Mounting the panel on a wall

BJ-EP2 SHX INTERACTIVE PANEL
Installation Guide
BJ_EP2 SHX Interactive Panel
Page 4
The following must be taken into account in order to ensure the panel is correctly installed:
- Ensure the wall can bear a total weight of 4 times that of the equipment being
installed.
- Type 1 wall: false or timber frame walls.
Requires two crossbeams set 144 mm apart.
- Type II wall: Brick or concrete walls.
Requires a minimum thickness of 102 mm. If the wall has been plastered, the
maximum render thickness should not exceed 16 mm.
- In all cases, even when the wall type is neither of those above, the installer is
always responsible for ensuring that the wall structure and the brackets are capable
of supporting up to 4 times the total weight of the equipment being installed.
4_ Connections
−Switching the panel ON and OFF.
The panel is switched ON and OFF with the push-button situated in the padding. It will
have been connected to the female connector in Step 2.
−Connecting the microphone to the interactive panel.
The microphone is connected to the panel with a 6.22 mm jack in the lower part of the
back of the panel.
−USB port.
A USB port is located in the lower part of the connection panel at the back of the
monitor. This port is used to connect a USB hub that includes the antenna for the
wireless keyboard and allows other USB devices (including pen drives and external
hard drives) to be connected.

BJ-EP2 SHX INTERACTIVE PANEL
Installation Guide
BJ_EP2 SHX Interactive Panel
Page 5
5_Pre-loaded content
Senswitcher: very simple
activities that are controlled by
touching any part of the
screen.
Whitecap: converts any sound
into light signals.
Look to Learn: various simple
programs that allow
interaction with the
touchscreen.
VUMeter: a bar of light that
varies in size according to the
volume of the sounds captured
by the microphone.

BJ-EP2 SHX INTERACTIVE PANEL
Installation Guide
BJ_EP2 SHX Interactive Panel
Page 6
6_Technical specifications
