Black & Decker BXAC40005GB User manual

BXAC40005GBwww.blackanddecker.co.uk

ENGLISH (Original instructions)
2
What’s in the box
Instruction Manual
Portable 7,000 BTU 3-in-1
Air Conditioner
Remote Control
Features
1. Carrying Handle
2. Control Panel
3. Air Outlet
4. Air Inlet
5. Cord Storage
6. Air Inlet
7. Air Filter
8. Window Air Outlet
9. Air Filter
10.Water Stopper/Drainage Point
11. Window Hose
12.Adaptor
13.Adaptor Cover
14.Drain Tube
15.Active Carbon Filter
16.Remote Control
2
1
3 4
12
13
5
6
7
8
9
10
11
14
15
16

ENGLISH
(Original instructions)
3
Control Panel
1. On/Off (Power) Button
2. Mode (Function) Option Button
3. Speed (Ventilation) Button
4. Timer Button
5. Temperature Down Button
6. Temperature Up Button
7. Sleep Button
a. Display Window
b. Receiver For Remote Control
c. High Ventilation Indicator
d. Low Ventilation Indicator
e. Automatic Mode Indicator
f. Cooling Mode Indicator
g. Fan Mode Indicator
h. Dehumidify (Dry) Mode Indicator
i. Full Water Indicator
j. Indicator For Compressor Operation

ENGLISH (Original instructions)
4
Intended Use
Your BLACK+DECKER BXAC40005GB Portable
7,000 BTU 3-in-1 Air Conditioner has been designed
for cooling small and medium spaces.
This appliance is intended for indoor household use
only.
Thank you for choosing BLACK+DECKER. We hope
that you will enjoy using this product for many years.
Safety Instructions
WARNING: Read all safety
warnings and all instructions. Failure
to follow the warnings and
instructions listed below may result in
electric shock, re and/or serious
injury.
♦ Read this manual carefully before
using the appliance.
♦ The intended use is described in
this manual.
♦ The use of any accessory or
attachment or the performance of
any operation with this appliance
other than those recommended in
this instruction manual may present
a risk of personal injury.
♦ Retain this manual for future
reference.
♦ WARNING: When using mains-
powered appliances, basic safety
precautions, including the following,
should always be followed to
reduce the risk of re, electric
shock, personal injury and material
damage.
Using Your Appliance
Please read the operating
instructions carefully before using
your air conditioner for the rst time.
♦ Check that the voltage of the main
circuit corresponds with the rating
of the appliance before operating.
♦ Children shall not play with the
appliance.
♦ Do not let the cable hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
♦ The use of accessory attachments
is not recommended by the
appliance manufacturer, apart from
those supplied with this product.
♦ Do not pull the plug out by the
cable as this may damage the plug
and/or the cable.
♦ Do not use this product for anything
other than its intended use.
♦ This appliance is for household use
only.
♦ Do not carry the appliance by the
power cable.
♦ Do not use the appliance outdoors.
♦ Do not operate with wet hands.
♦ Use of an extension cable with this
appliance is not recommended.
However, if it is necessary to use
an extension lead, ensure that
the lead is suited to the power
consumption of the appliance to
avoid overheating of extension
cable, appliance or plug point. Do
not place the extension cable in a

ENGLISH
(Original instructions)
5
position where it can be pulled on
by children or animals or tripped
over.
♦ Always unplug the unit when not in
use or before cleaning.
♦ The manufacturer does not accept
responsibility for any damage
or injury caused by improper or
incorrect use, or for repairs carried
out by unauthorised personnel.
Safety Of Others
♦ Close supervision is necessary
when any appliance is used by or
near children.
♦ Children should not play with the
appliance.
♦ This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
♦ Cleaning and user maintenance
should not be undertaken by
children without supervision.
♦ Take care when any appliance is
used near pets.
♦ Do not allow the cord to become
twisted.
After Use
♦ While cleaning, DO NOT use a wet
cloth or use water on any part of
the unit, as this may cause a short
circuit or electrical shock.
♦ Keep this unit clean. Do not allow
objects to enter the ventilation
opening as this may cause electric
shock, or damage to the unit.
Switch off at the wall socket then
remove the plug from the socket
when not in use or before cleaning.
♦ Check all inlets and outlets from
time to time for accumulated dust.
♦ Disconnect the unit from mains
outlet when it is not in use, or
before relocating or cleaning it.
♦ Switch off and remove the plug
from the socket before leaving the
appliance unattended and before
changing, cleaning or inspecting
any parts of the appliance.
♦ When not in use, the appliance
should be stored in a dry place.
Children should not have access to
stored appliances.
Inspections And Repairs
♦ Do not attempt to dismantle, repair
or remould any part of the unit. This
should only be done by a qualied
service agent. Even the change of
power cable should be done by a
qualied person.

ENGLISH (Original instructions)
6
♦ In the unlikely event the appliance
develops a fault, stop using it
immediately and seek advice from
the manufacturer.
♦ In case of technical problems,
switch off the product and do not
attempt to repair it yourself. Return
the appliance to an authorised
service facility for examination,
adjustment or repair. Always
insist on the use of original spare
parts. Failure to comply with the
above mentioned precautions and
instructions, could affect the safe
operation of this product.
Additional safety instructions for
Air conditioners and Fans
♦ Install the unit on at and hard oor
to diminish vibration or noise.
♦ Always operate the appliance on a
smooth, even, stable surface. Do
not place the unit on a hot surface.
♦ Ensure that the unit is switched off
after use.
♦ Do not immerse cables, plugs or
any part of the appliance in water
or any other liquid.
♦ Operate the unit only at the voltage
specied.
♦ Do not use the unit near open
windows, as contact with rain and
other natural elements could cause
an electrical hazard
♦ Do not put heavy objects on the
appliance.
♦ Do not tip the unit on its side.
♦ Never insert any other object into
the unit body to avoid any hazard
or unit failure.
♦ Do not put the unit close to
heat-generating devices or
near ammable and dangerous
materials.
♦ If the supply cable is damaged,
it must be replaced by the
manufacturer or its service agent or
a similarly qualied person in order
to avoid a hazard
♦ The appliance must be positioned
so that the plug is accessible.
WARNING: Do not place the unit
on or near a hot gas electric burner.
Safety relating to refrigerant R290:
♦ These symbols on your device
mean:
♦ This appliance is lled with
Propane gas R290. ALWAYS follow
the manufacturer’s instruction
concerning use and repairs.
♦ Read the entire instruction manual
carefully before attempting to use
the appliance.
♦ Do not install, operate or store
the device in a room smaller than
11m2.
♦ Read these warnings carefully.

ENGLISH
(Original instructions)
7
♦ This appliance contains the
refrigerant R290. R290 is a
refrigerant that complies with the
relevant European Directives.
Never perforate the refrigerant
circuit.
CAUTION: R290 is flammable
(GWP3)!
♦ DO NOT use any processes to
clean the unit or accelerate the
defrosting process, other than
those recommended by the
manufacturer.
♦ DO NOT store the appliance in a
room containing other continuously
operating ignition sources (for
example: open ames, an operating
gas appliance or an operating
electric heater).
♦ DO NOT pierce or burn any of the
components of the cooling circuit
of the unit. DO NOT set the unit on
re.
♦ Take care to store the appliance
in such a way as to prevent
mechanical faults or damage from
occurring.
♦ DO NOT install, operate or store
the appliance in a room with a oor
area of less than 11m2.
♦ Be aware that the refrigerant may
be odourless, and that leaks may
not be detectable by smell.
♦ ALWAYS take care to comply with
national gas regulations.
♦ Keep ventilation openings clear of
obstruction.
♦ Store the appliance in a well-
ventilated area where the room
size corresponds to the room area
specied for operation.
♦ Any person who is involved with
working on or breaking into a
refrigerant circuit should hold a
current valid certicate from an
industry-accredited assessment
authority, which authorises their
competence to handle refrigerants
safely in accordance with an
industry recognised assessment
specication.
♦ Servicing shall only be performed
on the grounds recommended
by the equipment manufacturer.
Maintenance and repair requiring
the assistance of other skilled
personnel shall be carried out
under the supervision of the person
competent in the use of ammable
refrigerants.
WARNING: Do not place the unit
on or near a hot gas electric burner.

ENGLISH (Original instructions)
8
Electrical safety
Before use, check that the mains voltage
corresponds to the voltage on the rating plate.
This product must be earthed. Always
check that the mains voltage
corresponds to the voltage on the rating
plate.
♦ Appliance plugs must match the outlet. Never
modify the plug in any way.
♦ Do not use any adapter plugs with earthed (Class
1) appliances. Unmodied plugs and matching
outlets will reduce the risk of electric shock.
♦ To avoid the risk of electric shock, do not immerse
the cord, plug or appliance in water or other liquid.
Extension cables & class 1 product
♦ A 3 core cable must be used as your tool is
earthed and of class 1 construction.
♦ Up to 30m (100 ft) can be used without loss of
power.
♦ If the supply cord is damaged, it must be
replaced by the manufacturer or an authorised
BLACK+DECKER Service Centre in order to avoid
a hazard.
Warning! Before assembling, switch the appliance
off and remove the plug from the socket.
Features
1. Carrying Handle
2. Control Panel
3. Air Outlet
4. Air Inlet
5. Cord Storage
6. Air Inlet
7. Air Filter
8. Window Air Outlet
9. Air Filter
10.Water Stopper/Drainage Point
11. Window Hose
12.Adaptor
13.Adaptor Cover
14.Drain Tube
15.Active Carbon Filter
16.Remote Control
Use
About the Controls
♦ 2 speed selection
♦ 24 hour timer
♦ 3 cooling modes and dehumidifying mode
♦ Sleep mode
♦ LED display
Remote Control
ON/OFF button
Speed button
Up button
Timer button
Down button
Sleep button
Mode selection button

ENGLISH
(Original instructions)
9
Moving the Unit
♦ This unit is equipped with castor wheels and a
carry handle, for easy movement.
♦ To move the unit, grip it rmly by the carry handle
and pull it along the oor as required. Alternatively,
position yourself behind the unit, grip it rmly on
both sides, and push it along the oor as required.
Installing the Batteries
♦ To begin using this air conditioning unit, start by
installing the batteries in the remote control.
♦ To install the batteries, rst detach the battery
cover from the remote. To do this, place your
nger on the grooved area at the centre of the
battery cover and push down and away from the
body of the remote.
♦ Insert 2 x AAA batteries into the battery
compartment, taking care to ensure the polarities
are correct.
♦ Once the batteries have been correctly inserted,
replace the battery cover by aligning each of the
locking tabs with the corresponding notch on the
remote control body and pushing it upwards until it
clicks into place.
♦ The remote control is now ready for normal use.
Assembling Your 3-in-1 Air Conditioner
WARNING: Before performing any assembly or
maintenance, switch the unit off and remove it from
the power supply.
Installing the Window Hose
♦ Before using your air conditioning unit, you will
need to install the window hose so that hot air
from the appliance are released onto an outside,
open-air area. The sections below illustrate the
correct way to attach and install the window hose.
♦ Before using your air conditioner, you will need
to install the window hose so that fumes from the
appliance are released onto an outside, open-air
area.
♦ To install the window hose, feed the end of the
tube through any available window and secure it
into place using the included adapter. Ensure the
distance between the unit and the window is at
least 50cm.
Note! When not using the air conditioner, plug the
hole with the cover provided.
Mounting the Window Hose

ENGLISH (Original instructions)
10
♦ To attach the window hose, clip it to the back of
the air cooling unit. Take care to avoid any bends
or kinks as this could cause the pipe to clog,
resulting in overheating and potential malfunction.
The illustrations above show the correct position
for the window hose.
Note! Although the hose may be extended up to
a total length of 30cm, we recommend its length
be kept as short as possible to ensure optimal
performance.
Note! Use ONLY the hose provided with your air
cooling unit. Attempting to attach other hoses
to it to extend the length could result in the unit
malfunctioning.
Installing the Carbon Filter
This unit comes complete with an included carbon
lter. You will need to install this lter before
attempting to use your air conditioner. The image
above illustrates the correct way to place this lter
into the unit.
Turning Your Appliance On or Off
♦ Press the Power On/Off button on the remote
control or on the appliance’s control panel to turn
it on. The LED indicators and LED display on the
unit’s control panel will come on and air will start
emitting from the vents to show the unit has been
turned on.
♦ Press the button again to turn the appliance off.
The LED indicators and LED display on the unit’s
control panel will go out and air will stop emitting
from the vents to show the unit has been turned
off.
Speed Selection
♦ Press the Speed button on the remote control
or on the appliance’s control panel to choose
between High and Low speed settings. The
corresponding indicator will light up on the unit’s
body to show which speed has been selected.
Controlling the Air Flow
♦ This unit allows for manual control of the air ow
through the positioning of the inner and outer
louvers at the front of the unit.
♦ To position the outer louvers, gently hold them by
the lip and push them upwards or downwards as
required. Push the louvers upwards to open them,
or downwards to close them.
♦ To position the inner louvers, gently hold them
by the lip and push them sideways to the left or
right as required. The air ow will be re-directed
accordingly.

ENGLISH
(Original instructions)
11
Temperature Selection
♦ While the unit automatically adjusts its selected
mode to reect room temperature, temperature
outputs can also be manually controlled if
required.
♦ Press the Up and Down buttons on the remote
control or the + and – buttons on the unit’s control
panel to manually adjust temperature levels. Press
the Up or + buttons to increase the temperature,
or press the Down or – buttons to decrease it.
Note! The unit’s temperature will increase or
decrease by increments of 1, from 18 to 32 degrees.
Selecting Functions
♦ Press the Mode button on the remote control or
on the appliance’s control panel to switch between
the Auto, Cooling, Fan and Dehumidifying modes.
To select a different function, press the button
again as many times as required until you have
reached your preferred function.
♦ Automatic Mode - Automatic mode is the unit’s
default working mode. In this mode, the unit will
automatically detect ambient temperature in the
room and select the appropriate function. If the
ambient temperature is above 23 degrees, the
unit will automatically start in cooling mode; if
the temperature is 23 degrees or below, it will
automatically start in ventilation mode.
The corresponding indicators will light up to show
which mode the unit is operating in. For cooling
mode, the Auto and Cooling indicators will light up;
for ventilation mode, the Auto and Fan indicator
will light up.
Note! When the unit is in Automatic mode,
temperature levels cannot be manually controlled or
changed.
Note! When rst turned on, the unit will automatically
start on Automatic mode.
♦ Cooling Mode - In cooling mode, the unit will blow
out cold air to decrease the ambient temperature.
To select cooling mode, press the ‘Mode’ button
repeatedly until the corresponding indicator lights
up.
♦ Fan Mode - In fan mode, the unit will blow out
natural air to cool the ambient temperature.
To select fan mode, press the ‘Mode’ button
repeatedly until the corresponding indicator lights
up.
Note! When the unit is in Fan mode, temperature
levels cannot be manually controlled or changed.
♦ Dehumidifying Mode - This unit is equipped with a
dehumidifying function, which removes moisture
from the air to purify it.
To select dehumidifying mode, press the ‘Mode’
button repeatedly until the corresponding indicator
lights up.
Note! When the dehumidifying function is selected,
the unit will vibrate briey as the compressor kicks
in. This is normal and not indicative of malfunction.
♦ Sleep Mode - You can set the unit to operate
overnight by pressing the Sleep button when the
unit is in operation.
In sleep mode, the unit will operate at low speed,
and its temperature will increase or decrease by
1 degree for the rst two hours. The unit will then
keep a constant temperature until turned off.
In cooling mode, the temperature will increase; in
fan mode, it will decrease.
Press the Sleep button again while the unit is in
sleep mode to turn this function off. The fan will
resume operation and default to the latest pre-set
mode and speed settings.
Note! In sleep mode, the unit will automatically turn
itself off after 12 hours of continuous operation.
The Timer Function
This unit is equipped with a 24-hour programmable
timer.
Setting the Timer
♦ Press the Timer button on the remote control or
on the appliance’s control panel to activate the
timer. The number ‘0’ will appear on the unit’s LCD
display to indicate the timer function has been
selected.
♦ Once this function has been activated,
continuously press the Timer button again to
select your desired operation time, from 1 to 24
hours.

ENGLISH (Original instructions)
12
Pre-Setting the Timer
♦ The unit’s timer can also be pre-set and used as
a delay timer, so that the unit will begin operation
after a set period of time.
♦ To pre-set a delay time, press the Timer button
while the unit is plugged into the mains, but not in
operation. The number ‘0’ will appear on the unit’s
LCD display to indicate the pre-set delay timer
function has been selected.
♦ Once this function has been activated,
continuously press the Timer button again to
select your desired delay time, from 1 to 24 hours.
Note! To cancel a pre-set delay timer, press the
Power On/Off button to turn the unit on, then press
the button again to turn it off if necessary. This will
cancel any previously set delay timers.
Draining the Unit
Draining
Knob
Rubber PlugWater Hole
While the unit is operating, water will be extracted
from the air into the built-in water tank.
When the reservoir is full, both the compressor and
motor will stop, the unit will emit a buzzing sound and
the ‘Water’ and ‘Comp’ indicator on the unit’s control
panel will begin to ash.
When this occurs, we recommend you drain or
empty the water tank, to ensure the unit continues to
operate correctly.
To empty the water tank, follow the steps
below:
♦ Turn off the unit and avoid moving it.
♦ Place a container, such as a water tray,
underneath the drain hole.
♦ Remove the drain plug and plug cap, to allow the
water to drain out.
♦ When the container is almost full, place the drain
plug back into the plug hole and empty the water
tray.
♦ Repeat this procedure until the unit is empty.
♦ Once you have emptied the unit, put the rubber
plug and plug cap back into place and tighten the
cap rmly.
♦ When you have completed the drainage process,
turn the unit back on and ensure the ‘Water’ and
’Comp’ indicators are no longer ashing. This
signals the process has been carried out correctly
and the unit has been drained.
Note! To stop the buzzing sound, press any button
on the unit’s remote control.
Note! Always wait at least 3 minutes after switching
off the unit before turning it back on. This will help
prolong the life of the compressor.
Draining Without the Tank
♦ You can also drain the unit without needing to
empty the water tank. To do so, simply remove
the drain plug and plug cap, insert the drain tube
into the water outlet, and connect the other end of
this tube into a drain, as shown in the illustrations
below.
Note! The drain must be at or below the outlet level.
Note! Please note that when using this method of
drainage, the ‘Water’ indicator on the unit’s control
panel will not ash.
Drain Tube

ENGLISH
(Original instructions)
13
Extending the Drainage Tube
♦ The drainage tube can also be extended using
a tube of a similar diameter (18mm) and an
appropriate connector, as shown in the illustration
below.
Self-Diagnosis
♦ This unit is equipped with a self-diagnose feature,
which warns you of any errors or malfunctions
it nds in the course of its normal operation.
Any errors the unit nds when running its self-
diagnose will be represented by the words ‘E1’ or
‘E2’ appearing on the display panel.
♦ Should any malfunction occur, please seek out
a specialised technician or contact our customer
support team.
Cleaning and maintenance
WARNING: Before cleaning and maintenance,
switch the appliance off and remove the plug from
the socket, to prevent electric shock.
Note! Always unplug the unit from the mains before
cleaning.
Note! Clean the unit regularly to ensure optimal
performance.
Cleaning the Housing
♦ To clean the unit’s housing, wipe it down with a
soft, damp cloth.
♦ Never use aggressive chemicals, gasoline,
detergents, chemically treated cloths or other
cleaning solutions to clean the unit, as this may
cause damage to its components.
Cleaning the Filter
♦ To clean the lter, tap it lightly or use a vacuum
cleaner to remove loose dust and dirt from its
surface.
♦ Once it is dust and dirt-free, rinse the lter
thoroughly under running water, at a temperature
of no more than 40 degrees centigrade.
♦ Dry the lter thoroughly before placing it back into
the unit.
Note! NEVER attempt to operate the unit without the
lters.
Before storing the unit:
♦ Drain any water inside the tank.
♦ Operate the unit in ventilation only mode for a few
hours to thoroughly dry the interior.
♦ Clean or change the lter.
♦ Unplug and store the power cord.
♦ Place the unit back into its original box.
♦ You can now safely store the unit.
Mains plug replacement
If a new mains plug needs to be tted:
♦ Safely dispose of the old plug.
♦ Connect the brown lead to the live terminal in the
new plug.
♦ Connect the blue lead to the neutral terminal.
♦ If the product is class I (earthed), connect the
green/yellow lead to the earth terminal.
Note! If your product is class II double insulated
(only 2 wires in the cord set), no connection is to be
made to the earth terminal.
Follow the tting instructions supplied with good
quality plugs. Any replacement fuse must be of the
same rating as the original fuse supplied with the
product.
WARNING: The above section on mains plug
replacement is for authorized service centre
persons.
Extension Tube
Original Tube

ENGLISH (Original instructions)
14
Protecting the environment
Separate collection. Products and
batteries marked with this symbol must
not be disposed of with normal household
waste.
Products and batteries contain materials that can
be recovered or recycled, reducing demand for
raw materials. Please recycle electrical products
and batteries according to local provisions. Further
information is available at www.2helpU.com.
Technical data
BXAC40005GB
Input voltage V AC 220-240V
Frequency Hz 50
Power input W810
Weight KG 22
Product Guarantee
This product comes with a 2 Year guarantee from the
original date or purchase. If any defect arises due to
faulty materials or workmanship, the faulty products
must be returned to the place of purchase. Refund or
replacement is at the discretion of the retailer. This
guarantee is in addition to and in no way prejudices
your statutory rights.
The Following Conditions Apply:
♦ The product must be returned to the retailer
with proof of purchase or a receipt within the
1st year of purchase. For any product related
issues after 12 months please contact our
customer services team.
♦ The product must be installed and used in
accordance with the instructions contained in
this instruction guide.
♦ It must be used only for domestic purposes.
♦ It does not cover wear and tear, damage,
misuse or consumable parts.
♦ This guarantee is valid in the UK and Republic
of Ireland.
For all customer service enquires please contact
us below;
RKW,
Sutton House,
Berry Hill Road,
Stoke-on-Trent,
ST4 2NL
Email [e-mail]
Tel [phone]

ENGLISH
(Original instructions)
15
Model Identier(s): BXAC40005GB
Item Symbol Value Unit
Rated output power for cooling P rated for cooling 2.1 KW
Rated output power for heating P rated for heating N/A KW
Rated input power for cooling P EER 0.81 KW
Rated input power for heating P COP N/A KW
Rated energy efciency ratio EER rated 2.6 -
Rated coefcient of performance COP rated N/A -
Thermostat OFF mode power
consumption P TO 137 W
Standby mode power consumption P SB 0.48 W
OFF mode power consumption P OFF N/A W
Seasonal electricity consumption for
single ducts (SD) hourly electricity
consumption
Q SD 0.81 kWh/60min
Sound power level (indoor only) LwA 65 dB(A)
Global Warming potential refrigerant GWP 3kgCO2 eq
Contact Details: Imported by Black & Decker, 210 Bath Road,
Slough, Berkshire SL1 3YD

United Kingdom & Black & Decker Tel. [phone]
Republic Of Ireland 210 Bath Road Fax [phone]
www.blackanddecker.co.uk Slough, Berkshire SL1 3YD
emeaser[email protected]m
09/2019
