Black & Decker BFF16B User manual

Page 1
INSTRUCTION MANUAL
16 IN. FLOOR FAN
CATALOG NUMBER
BFF16B
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR ANY
REASON.
If you have a question or experience a problem with your BLACK+DECKER purchase, go
to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 9:00 a.m. to 7:00 p.m. EST Mon. - Fri. to speak with an agent. Please
have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.

Page 3
CONTENTS
SAFETY INFORMATION
Important Safety Instructions..........................................................................................................................................4-5
Electrical Requirements....................................................................................................................................................... 5
SET UP & USE
Parts & Features .......................................................................................................................................................................6
Operation Of Your Fan ........................................................................................................................................ 7
Replacing the Fuse................................................................................................................................................. 8
CLEANING & CARE...............................................................................................................................................8
TROUBLESHOOTING & WARRANTY
Before You Call For Service................................................................................................................................ 9
Customer Service.................................................................................................................................................... 9
Troubleshooting .................................................................................................................................................... 10
Limited Warranty.....................................................................................................................................................................11
Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your fan.
Remember to record the model and
serial numbers. They are on a label
on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION

Page 4
1. READ ALL INSTRUCTIONS BEFORE USE
2. Never insert ngers, pencils, or any other object through the grill
when fan is running
3. Disconnect fan when moving from one location to another.
4. Disconnect fan when not in use and before cleaning and servicing.
5. To protect against risk of electrical shock, do not immerse fan in
water or any other liquid.
6. Do not let cord hang over edge of table or counter.
7. Be sure fan is on a stable surface when operating to avoid
overturning.
8. Do not use fan in window. Rain may create electrical hazard.
9. Close supervision is necessary when any appliance is used by or near
children.
10. This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the user
manual (follow product marking for proper fuse rating) and check
the product. If the replacement fuse blows, a short-circuit may be
present and the product should be discarded or returned to an
authorized service facility for examination and/or repair.
11. Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
12. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trafc area and where it will not
be tripped over.
13. To Reduce The Risk Of Fire Or Electric Shock, Do Not Use This Fan
With Any Solid-State Speed Control Device.
14. Do not use outdoors.
IMPORTANT SAFETY INSTRUCTIONS
SAFETY INFORMATION
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following

Page 5
SAFETY INFORMATION
READ AND SAVE THESE
INSTRUCTIONS
HOUSEHOLD USE ONLY
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to t into a polarized outlet only one way.
If the plug does not t into the outlet, reverse the plug. If it still does not t, contact a
qualied electrician. Do not attempt to modify the plug in any way.
DOUBLE INSULATION
Double insulated appliances are constrcuted througout with two separate layers
of electrical insulation or one single layer of reinforced insulation between the user
and the appliance’s electrical system. Products built with this insulation system are
not intended to be grounded. As a result, this appliance is equipped with a two-
prong plug which permits it to be used without concern for maintaining a ground
connection.
NOTE: Double insulation does not take the place of normal safety precautions when
operating this appliance. The secondary insulation system is for protection
against injury resulting from a possible failure of the primary insulation within
the product.
CAUTION: WHEN SERVICING USE ONLY IDENTICAL REPLACEMENT PARTS.
POWER SUPPLY CORD
1. If the power supply cord is too short, do not use an extension cord. Have a qualified
electrician or service person install an outlet near the appliance.

Page 6
SET UP & USE
PARTS & FEATURES
FRONT
BACK
Base
Front Guard
Tilt Adjustment Knob
Speed Control

Page 7
SET UP & USE
OPERATION OF YOUR FAN
SPEED CONTROL
The speed control is located on the rear side of the fan in the center of the grill. Turn
the knob to move from OFF to either HIGH MEDIUM or LOW speed.
Turn the knob to the OFF position at any time to power off the unit.
WARNING: To avoid injury when directing airow, do not rest hands on base while
pushing on guards.

Page 8
SET UP & USE
REPLACING THE FUSE
CAUTION: Turn off fan and disconnect plug from power source before replacing
fuse.
• Open fuse cover located on the side of the power cord plug by sliding it toward
the plug blades
• Remove fuse carefully by taking a small tool and slowly prying out one end. Once
you have one end out, slowly pry out the other end.
• To avoid the risk of re, replace only with 2.5 Amp, 125V fuse.
• Close fuse cover by sliding cover toward the top of the plug.
CAUTION: Risk of re. Do not replace attachment plug. Contains a safety device
(fuse) that should not be removed. Discard product if the attachment
plug is damaged.
CLEANING AND MAINTENANCE
WARNING: Be sure to turn off fan and unplug from the electrical supply source
before cleaning.
Be sure not to get water or any other liquid inside the motor.
Do not disassemble the fan for cleaning.
• To ensure adequate air circulation to the motor, keep vents at the rear of the
motor housing free of dust, debris, etc. Unplug fan before using a vacuum cleaner
to clean these vents. Do not disassemble the fan motor to clean.
• Plastic parts of the fan should be cleaned with mild soap and a damp cloth or
sponge. Rinse with clean water to remove any soapy lm residue.
• Be sure not to get water or any other liquid inside the motor.
Fuse
Fuse cover

Page 9
TROUBLESHOOTING & WARRANTY
BEFORE YOU CALL FOR SERVICE
IF THE APPLIANCE FAILS TO OPERATE:
A) Check to make sure that the appliance is plugged in securely. If it is not, remove
the plug from the outlet, wait 10 seconds and plug it in again securely.
B) Check for a blown circuit fuse or a tripped main circuit breaker. If these seem to
be operating properly, test the outlet with another appliance.
IF NONE OF THE ABOVE SOLVES THE PROBLEM, CONTACT A QUALIFIED
TECHNICIAN. DO NOT TRY TO ADJUST OR REPAIR THE APPLIANCE YOURSELF.
IMPORTANT
DO NOT RETURN THIS PRODUCT TO THE STORE
If you have a problem with this product, please contact the
BLACK+DECKER Customer Satisfaction Center at
844-299-0879 or [email protected].
DATED PROOF OF PURCHASE, MODEL # AND SERIAL #
REQUIRED FOR WARRANTY SERVICE

Page 10
TROUBLE POSSIBLE CAUSE POSSIBLE REMEDY
Appliance does not turn on
Appliance is not plugged in Check that appliance is
plugged into a working outlet
The fuse cover may be open Disconnect the plug from
outlet and close the cover of
the fuse.
Troubleshoot your problem by using the chart below. If the appliance still does not
work properly, contact W Appliance Co. customer service center or the nearest
authorized service center. Customers must never troubleshoot internal components.
SPECIFICATIONS
BFF16B
• Unit Dimensions (W x D x H): 20.55” x 6.38” x 19.17”
• Net Weight: Approx. 5.5 lb
TROUBLESHOOTING & WARRANTY
