INSTRUCTION MANUAL
48"TOWER FAN
Thank you for choosing BLACK+DECKER!
PLEASE READ BEFORE RETURNING THIS PRODUCT FOR
ANY REASON.
If you have a question or experience a problem with your BLACK+DECKER
purchase, go to www.blackanddecker.com/instantanswers
If you can’t find the answer or do not have access to the Internet, call
844-299-0879 from 10:30 a.m. to 6:30 p.m. EST Mon. - Fri. to speak with an
agent. Please have the catalog number available when you call.
SAVE THIS MANUAL FOR FUTURE REFERENCE.
CATALOG NUMBER
BFTR48W
POWER SPEED
TIMER OSCILLATE
M1 M2
POWER SPEED
TIMER OSCILLATE
M1 M2

Page 2

Thank you for purchasing our
BLACK+DECKER product. This
easy-to-use manual will guide you
in getting the best use of your fan.
Remember to record the model and
serial numbers. They are on a label
on the rear.
Staple your receipt to your manual.
You will need it to obtain warranty service.
Model number
Serial number
Date of purchase
PRODUCT REGISTRATION
CONTENTS
SAFETY INFORMATION
Important Safety Instructions......................................................................................................................................... 4-6
Electrical Requirements....................................................................................................................................................... 5
SET UP & USE
Parts & Features........................................................................................................................................................................ 7
Operation & Use ..................................................................................................................................................8-11
Replacing the Fuse................................................................................................................................................12
CLEANING & CARE...............................................................................................................................................12
TROUBLE SHOOTING & WARRANTY
Before You Call For Service ...............................................................................................................................13
Customer Service...................................................................................................................................................13
Troubleshooting......................................................................................................................................................13
Limited Warranty ................................................................................................................................................................... 14
Page 3

Page 4
SAFETY INFORMATION
IMPORTANT SAFETY INSTRUCTIONS
1. READ ALL INSTRUCTIONS BEFORE USE
2. Never insert fingers, pencils, or any other object through the grill
when fan is running
3. Disconnect fan when moving from one location to another.
4. Disconnect fan when not in use and before cleaning.
5. To protect against risk of electrical shock, do not immerse fan in
water or any other liquid.
6. Do not let cord hang over edge of table or counter.
7. Be sure fan is on a stable surface when operating to avoid
overturning.
8. Do not use fan in window. Rain may create electrical hazard.
9. Close supervision is necessary when any appliance is used by or near
children.
10. This product employs overload protection (fuse). A blown fuse
indicates an overload or short-circuit situation. If the fuse blows,
unplug the product from the outlet. Replace the fuse as per the user
manual (follow product marking for proper fuse rating) and check
the product. If the replacement fuse blows, a short-circuit may be
present and the product should be discarded or returned to an
authorized service facility for examination and/or repair.
11. Do not operate any fan with a damaged cord or plug. Discard fan or
return to an authorized service facility for examination and/or repair.
12. Do not run cord under carpeting. Do not cover cord with throw rugs,
runners, or similar coverings. Do not route cord under furniture or
appliances. Arrange cord away from trac area and where it will not
be tripped over.
WARNING
WARNING - Hazards or unsafe
practices which COULD result in
severe personal injury or death
DANGER
DANGER - Immediate hazards
which WILL result in severe
personal injury or death
CAUTION
CAUTION - Hazards or unsafe
practices which COULD result in
minor personal injury
WARNING
When using electrical appliances, basic safety precautions
should be followed, including the following

Page 5
SAFETY INFORMATION
13. To reduce the risk of fire or electric shock, DO NOT use this fan with
any solid state speed control devices.
14. Do not use outdoors.
SAVE THESE INSTRUCTIONS
HOUSEHOLD USE ONLY
ELECTRICAL REQUIREMENTS
This appliance has a polarized plug (one blade is wider than the other). To reduce the
risk of electric shock, this plug is intended to fit into a polarized outlet only one way.
If the plug does not fit into the outlet, reverse the plug. If it still does not fit, contact a
qualified electrician. Do not attempt to modify the plug in any way.
POWER SUPPLY CORD
1. If the power supply cord is too short, do not use an extension cord. Have a qualified
electrician or serviceman to install an outlet near the appliance.
2. If it is absolutely necessary to use longer cord sets or an extension cord, extreme
care must be exercised.
a) The marked electrical rating of the cord set or extension cord must equal to or
be greater than the electrical rating of the appliance. The longer cord should be
arranged so that it will not drape over the counter top or table top where it can be
pulled on by children or tripped over unintentionally.
NOTE: Neither BLACK+DECKER nor the dealer can accept any liability for damage
to the product or personal injury resulting from failure to observe the
electrical connection procedures.

Page 6
SAFETY INFORMATION
HANDLING ALKALINE BATTERIES
1. Should fluid from the battery accidentally get into your eyes, there is a threat
of loss of eyesight, do not rub them. Immediately rinse your eyes with clean tap
water and then consult a physician immediately.
2. Do not put the battery in a fire, expose it to heat, dismantle or modify it. If the
insulation or safety valve is damaged, the battery may leak fluid, overheat or
explode.
3. Do not insert the battery with the poles reversed. Doing so may cause some
abnormality or a short and the battery may leak fluid, overheat or explode.
4. Keep the battery out of the reach of children. If the battery is swallowed, contact a
physician immediately.
5. If the alkali fluid gets in your mouth, rinse your mouth with water and contact a
physician immediately.
6. If the alkali fluid gets on your skin or clothes, it may burn your skin, thoroughly
rinse the aected area with tap water.
7. Do not mix new and old batteries or other makes of batteries. The dierent
attributes may cause the battery to leak fluid, overheat or explode.
8. This battery was not made to be recharged. Recharging this battery may damage
the insulation or internal structure and may cause the battery to leak fluid,
overheat or explode.
9. Do not damage or remove the label on the exterior of the battery. Doing so may
cause the battery to short, leak fluid, overheat or explode.
10. Do not drop, throw or expose the battery to extreme impact. Doing so may cause
the battery to leak fluid, overheat or explode.
11. Do not alter the shape of the battery. If the insulation or safety valve is damaged,
the battery may leak fluid, overheat or explode.
12. Immediately remove batteries when they have lost all power. Leaving the batteries
in the unit for a long time may cause the batteries to leak fluid, overheat or
explode due to gas that is generated by the batteries.
13. Cleaning should be limited to external parts only.
Contact your local government for disposal practices in your area.
WARNING
When handling alkaline batteries, basic safety precautions
should be followed, including the following

POWER SPEED
TIMER OSCILLATE
M1 M2
POWER SPEED
TIMER OSCILLATE
M1 M2
Page 7
PARTS & FEATURES
SET UP & USE
Control Display
Fan Body
Pillars
Base
88:88
TIMER
POWER SPEED SLEEP SWING
GENERAL NATURAL
LMH
Remote Control
Round Head Screws for
attaching the fan body to
the pillar x6
Thumb Screws for
attaching base to
pillars x 4
Remote control holder
(on back of unit, not visible)
L Shaped Tool
Round Head Screws for
attaching the front and
rear pillar x6
Rear panel
of main unit

Page 8
SET UP & USE
ASSEMBLY INSTRUCTIONS
1. Pass the power cord through the channel of pillar and firmly clasp pillar sections
together.
2. Attach the pillars to the fan body, tightening the 6 round head screws provided
with the L shaped tool.
3. Pass the power cord through the central gate and snap wire casing of the base
together.
4. Firmly clamp the front and rear base section together.
5. Align the front of the fan with front base and secure using the 4 thumbscrews.
6. Using the L shaped tool, insert six screws on back side of unit (see illustration in
parts and features section) to secure the front and rear pillars to one another.
7. Make sure the power cord is going through the arch shaped cut out at both the
center of the base and the outer rim of the base. The cord should also be behind
the black plastic barriers located near the rim of the base. (see fig. 3)
NOTE: For additional cord maintenance, remove the two silver screws from the
cord clamp (see fig. 3). Completely lift o the black bar that the screws are
threaded into. In the area of the cord clamp, take the cord and push it in
toward the fan base, making sure it is laying perfectly flat. Place the black bar
back in place over the cord and thread the two silver screws into the holes
molded in the base.
Fig. 1 Fig. 2

Page 9
SET UP & USE
BATTERY INSTRUCTIONS
1. Press down on the battery compartment cover and slide it out. (fig. 4)
2. Insert 2 “AAA” batteries (not included), making sure that the positive terminals are
facing the proper way. (fig. 5)
3. Replace the cover.
BATTERY WARNINGS
1. Do not dispose of batteries in fire, batteries may explode or leak.
2. Do not mix old and new batteries.
3. Do not mix alkaline, standard (carbon-zinc) or rechargeable (nickel-cadmium)
batteries.
NOTE: Use size “AAA” alkaline batteries. Do not use rechargeable batteries.
Remote Control
Battery Battery Compartment Cover
Fig. 4 Fig. 5
x x
Fig. 3
BOTTOM OF UNIT
Arch Shaped Cutout
Arch Shaped
Cutout
Cord Clamp
Black Plastic
Barriers
Black bar

SET UP & USE
Page 10
OPERATION INSTRUCTIONS
BACKLIT DISPLAY
This product has a backlit display to improve visibility. The backlit display will go on
automatically when you first plug in the fan and remain on for about five seconds
before automatically shutting o. The same thing will happen if you touch any button
on the unit or remote control.
SETTING THE CLOCK
When you first plug in your fan, the digital clock will read “12:00”. To set to correct
time, push SPEED button on unit or remote to set the correct hour. Push TIMER
button on unit or remote to set the correct minute. If power is interrupted for any
reason, you will need to manually reset the clock to the correct time.
NOTE: This is a 24 hour time display. For example, if you want to set the clock to 8pm
you need to set the display to read “20:00”.
REMOTE AND CONTROL PANEL
Power Button: Press to start or stop the fan.
Speed Button: Press to select from three speeds: LOW, MEDIUM and HIGH.
Timer Button: Press to set auto shuto timer in 30 minute increments ranging from
30 minutes to 12 hours.
Oscillation Button: Press to start oscillation function. Press again to stop oscillation
function.
M1 Button : Press to activate “NATURAL” wind mode. In Natural wind mode, fan
airflow pattern (determined by fan speed) will change randomly to
emulate a natural breeze.
M2 Button : Press to activate “SLEEP” wind mode. In Sleep wind mode, fan airflow
pattern will change cyclically every 30 minutes.
If fan is on HIGH fan speed when SLEEP wind is activated, unit will operate in HIGH
rhythm airflow pattern for 30 minutes, switch to MEDIUM rhythm airflow pattern for
30 minutes and to LOW rhythm airflow pattern where it will remain.
If fan is on MEDIUM fan speed when SLEEP wind is activated, unit will operate in
MEDIUM rhythm airflow pattern for 30 minutes then switch to LOW rhythm airflow
pattern where it will remain.
If fan is on LOW fan speed when SLEEP wind is activated, unit will operate in LOW
rhythm airflow pattern where it will remain.
NOTES: All three fan speeds will be reached regardless of whether you are in HIGH,
LOW or MEDIUM rhythm airflow patterns. In addition to the NATURAL and
SLEEP wind modes, there is also a GENERAL wind mode which is the
default when you turn on your fan. In the GENERAL wind mode, there will be
constant output airflow at the speed you selected.
