Black & Decker BXFT50007GB User manual

BXFT50007GBwww.blackanddecker.co.uk

ENGLISH (Original instructions)
2
What’s in the box
Instruction Manual
46” Digital Tower Fan
with 12 Hour Timer
Base
Remote Control
4 x Wing Screws
Cable Hook
Features
1. Control Panel
2. Carry Handle
(Back of unit)
3. Display Panel
4. Air Outlet
5. Base
Control Panel
6. Timer Button
7. Speed Button
8. Oscillation Button
9. ON/OFF Button
10. Mode Button
LED Display Panel
11. Oscillation
12. Normal Mode
13. Natural Mode
14. Sleep Mode
15. Child Mode
16. Time H/Room
Temp °C
17. Fan Speed
1
2
3
4
5
86
16
17
11 12 13 14 15
9
107

ENGLISH
(Original instructions)
3
Intended Use
Your BLACK+DECKERBXFT50007GB 46” Digital
Tower Fan with 12 Hour Timer has been designed for
cooling small and medium spaces.
This appliance is intended for indoor household use
only.
Thank you for choosing BLACK+DECKER. We hope
that you will enjoy using this product for many years.
Safety Instructions
WARNING: Read all safety
warnings and all instructions. Failure
to follow the warnings and
instructions listed below may result in
electric shock, re and/or serious
injury.
♦ Read this manual carefully before
using the appliance.
♦ The intended use is described in
this manual.
♦ The use of any accessory or
attachment or the performance of
any operation with this appliance
other than those recommended in
this instruction manual may present
a risk of personal injury.
♦ Retain this manual for future
reference.
♦ WARNING: When using mains-
powered appliances, basic safety
precautions, including the following,
should always be followed to
reduce the risk of re, electric
shock, personal injury and material
damage.
Using Your Appliance
Please read the operating
instructions carefully before using
your tower fan for the rst time.
♦ Check that the voltage of the main
circuit corresponds with the rating
of the appliance before operating.
♦ Children shall not play with the
appliance.
♦ Do not let the cable hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
♦ The use of accessory attachments
is not recommended by the
appliance manufacturer, apart from
those supplied with this product.
♦ Do not pull the plug out by the
cable as this may damage the plug
and/or the cable.
♦ Do not use this product for anything
other than its intended use.
♦ This appliance is for household use
only.
♦ Do not carry the appliance by the
power cable.
♦ Do not use the appliance outdoors.
♦ Do not operate with wet hands.
♦ Use of an extension cable with this
appliance is not recommended.
However, if it is necessary to use
an extension lead, ensure that
the lead is suited to the power
consumption of the appliance to
avoid overheating of extension
cable, appliance or plug point. Do
not place the extension cable in a

ENGLISH (Original instructions)
4
position where it can be pulled on
by children or animals or tripped
over.
♦ Always unplug the unit when not in
use or before cleaning.
♦ The manufacturer does not accept
responsibility for any damage
or injury caused by improper or
incorrect use, or for repairs carried
out by unauthorised personnel.
Safety Of Others
♦ Close supervision is necessary
when any appliance is used by or
near children.
♦ Children should not play with the
appliance.
♦ This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
♦ Cleaning and user maintenance
should not be undertaken by
children without supervision.
♦ Take care when any appliance is
used near pets.
♦ Do not allow the cord to become
twisted.
After Use
♦ While cleaning, DO NOT use a wet
cloth or use water on any part of
the unit, as this may cause a short
circuit or electrical shock.
♦ Keep this unit clean. Do not allow
objects to enter the ventilation
opening as this may cause electric
shock, or damage to the unit.
Switch off the unit and then remove
the plug from the socket when not
in use or before cleaning.
♦ Check all inlets and outlets
regularly for accumulated dust.
♦ Disconnect the unit from mains
outlet when it is not in use, or
before relocating or cleaning it.
♦ Switch off and remove the plug
from the socket before leaving the
appliance unattended and before
changing, cleaning or inspecting
any parts of the appliance.
♦ When not in use, the appliance
should be stored in a dry place.
Children should not have access to
stored appliances.
Inspections And Repairs
♦ Do not attempt to dismantle, repair
or remould any part of the unit. This
should only be done by a qualied
service agent. Even the change of
power cable should be done by a
qualied person.

ENGLISH
(Original instructions)
5
♦ In the unlikely event the appliance
develops a fault, stop using it
immediately and seek advice from
the manufacturer.
♦ In case of technical problems,
switch off the product and do not
attempt to repair it yourself. Return
the appliance to an authorised
service facility for examination,
adjustment or repair. Always
insist on the use of original spare
parts. Failure to comply with the
above mentioned precautions and
instructions, could affect the safe
operation of this product.
Additional safety instructions for
Air Coolers and Fans
♦ Install the unit on at and hard oor
to diminish vibration or noise.
♦ Always operate the appliance on a
smooth, even, stable surface. Do
not place the unit on a hot surface.
♦ Ensure that the unit is switched off
after use.
♦ Do not immerse cables, plugs or
any part of the appliance in water
or any other liquid.
♦ Operate the unit only at the voltage
specied.
♦ Do not use the unit near open
windows, as contact with rain and
other natural elements could cause
an electrical hazard
♦ Do not put heavy objects on the
appliance.
♦ Do not tip the unit on its side.
♦ Never insert any other object into
the unit body to avoid any hazard
or unit failure.
♦ Do not put the unit close to
heat-generating devices or
near ammable and dangerous
materials.
♦ If the supply cable is damaged,
it must be replaced by the
manufacturer or its service agent or
a similarly qualied person in order
to avoid a hazard
♦ The appliance must be positioned
so that the plug is accessible.
♦ For optimal airow circulation,
leave a distance of at least 1 metre
around the appliance on every side.
Always direct the airow in order
to optimise cooling. Avoid corners,
small objects and other surfaces
or objects which may impede the
airow.
♦ Do not leave the unit unattended
when plugged in. Always unplug
the unit when not in use.
♦ Do not locate the unit where it may
fall in to a bathtub or other water
container.
WARNING: Do not place the unit
on or near a hot gas electric burner.

ENGLISH (Original instructions)
6
Electrical safety
WARNING: Before use, check that the mains
voltage corresponds to the voltage on the rating
plate.
Always check that the mains voltage
corresponds to the voltage on the rating
plate.
♦Appliance plugs must match the outlet. Never
modify the plug in any way.
♦Do not use any adapter plugs with this appliance.
Unmodied plugs and matching outlets will reduce
the risk of electric shock.
♦To avoid the risk of electric shock, do not immerse
the cord, plug or appliance in water or other liquid.
Extension cables
♦Up to 30m (100 ft) can be used without loss of
power.
♦If the supply cord is damaged, it must be
replaced by the manufacturer or an authorised
BLACK+DECKER Service Centre in order to avoid
a hazard.
WARNING: Before assembling, switch the
appliance off and remove the plug from the socket.
Mains plug replacement
If a new mains plug needs to be tted:
♦Safely dispose of the old plug.
♦Connect the brown lead to the live terminal in the
new plug.
♦Connect the blue lead to the neutral terminal.
♦If the product is class I (earthed), connect the
green/yellow lead to the earth terminal.
Note! If your product is class II double insulated
(only 2 wires in the cord set), no connection is to be
made to the earth terminal.
Follow the tting instructions supplied with good
quality plugs. Any replacement fuse must be of the
same rating as the original fuse supplied with the
product.
WARNING: The above section on mains plug
replacement is for authorized service centre
persons.
Features
1. Control Panel
2. Carry Handle (Back of unit)
3. Display Panel
4. Air Outlet
5. Base
Control Panel
6. Timer Button
7. Speed Button
8. Oscillation Button
9. ON/OFF Button
10.Mode Button
Use
About the Controls
♦ 4 Cooling Modes - Normal, Natural, Sleeping, Child
♦ 3 Fan Speed Settings
♦ 12 Hour Timer
♦ Oscillation Function
Remote Control
POWER
SPEED OSC
TIMER MODE
Installing the Battery
WARNING: Danger of explosion if battery is
incorrectly replaced.
WARNING: DO NOT INGEST BATTERY;
CHEMICAL BURN HAZARD. This product contains
a coin/button cell battery. If the coin/button cell
battery is swallowed, it can cause severe internal
burns in just 2 hours and can lead to death.
ON/OFF button
Oscillation button
Speed selection button
Timer button
Mode button

ENGLISH
(Original instructions)
7
♦ Keep new and used batteries away from children.
If the battery compartment does not close
securely, stop using the product and keep it away
from children.
♦ If you think batteries might have been swallowed
or placed inside any part of the body, seek
immediate medical attention.
♦ If the coin cell battery contents come into contact
with the skin, immediately wash area with mild
soap and water. If coin cell battery liquid gets
into the eye, rinse water over the open eye for
15 minutes or until irritation ceases. If medical
attention is needed, the battery electrolyte is
composed of an organic solvent and lithium salts.
♦ Do not incinerate or dispose of tool together with
household waste material! Tool that has reached
the end of its life must be collected separately
and returned to an environmentally compatible
recycling facility.
To Begin Using Your Fan
♦ Start by installing the battery.
♦ To install the battery, rst detach the battery cover
from the remote. To do this, place a thumb or
small object on the grooved area on the underside
of the battery cover and push it gently to the side,
while simultaneously pulling the compartment
away from the body of the remote.
♦ Insert 1 x CR2032 battery into the battery
compartment, taking care to ensure the positive
polarity is facing upwards.
♦ Once the battery is in place, slide the battery
cover back into the remote. It will automatically
lock into place and secure the battery inside.
Assembling Your Fan
WARNING: Before performing any assembly or
maintenance, switch the unit off and remove it from
the power supply.
♦ Install the cable hook at the back of the unit.
♦ Pass the cord through the base. Assemble the two
base halves together. Position the base half with
the alignment pin over the other base half with the
alignment sockets, as shown in the image below.
♦ Press the two halves together until ush.
Note! The base may be slightly different from that
illustrated. However the assembly is the same.
♦ Assemble the base to the bottom of the tower fan.
With the tower on its side, align the 4 base sockets
onto the tower bottom pins, as shown in the image
below. Tighten the thumb screws securely.
♦ Your fan is now ready for normal use.
Turning the Unit On or Off
♦ Press the Power On/Off button to turn the unit
on. Press this button again while the fan is in
operation to turn the unit off. There will be a sound
prompt to indicate the unit has been turned on or
off.
♦ The LED display will show the ambient room
temperature.

ENGLISH (Original instructions)
8
Cooling Mode Selection
♦ This fan is equipped with a choice of 4 cooling
modes. Repeatedly press the Mode button to
cycle through and select your desired cooling
mode. There will be a sound prompt and the
corresponding indicator will illuminate on the unit’s
LED display to show the mode selected.
♦ Normal: The fan operates at the fan speed
selected.
♦ Natural: The fan will operate in a continuous cycle
of High speed, Medium speed, Low speed for 5
seconds at each speed.
♦ Sleep: Once the High speed fan operation has
been selected, press the mode key until the
Sleep icon is displayed. The fan will operate
for 30 minutes at High speed, then 30 minutes
at Medium speed followed by Low speed and
will maintain this Low speed until it is manually
switched off.
♦ Child: The fan will run for a set operating time of
3 hours in auto mode, whereby the unit operates
at High speed for 15 mins, followed by Medium
speed for 15 mins and then low speed until the
unit switches off automatically after 3 hours.
Note! The oscillation function will start automatically
but can be turned off manually as desired by
pressing the oscillation key.
Speed Selection
♦ There is a choice of 3 fan speeds: Low, Medium
or High.
LOW MEDIUM HIGH
♦ Repeatedly press the Speed button to cycle
through the available speeds. There will be a
sound prompt and the corresponding indicator will
be displayed on the unit’s LED screen to show the
speed selected.
Timer
♦ This fan is equipped with a timer that allows you to
set an operating time of up to 12 hours before the
unit will automatically turn off.
♦ Repeatedly press the Timer button to select your
desired operating time. The time selected will
display on the unit’s LED screen.
The Oscillation Function
♦ Press the Oscillation button to turn the oscillation
function on. There will be a sound prompt and the
corresponding indicator will light up on the unit’s
LED screen to indicate this function has been
selected.
♦ Press the Oscillation button again while this
function is activated to turn it off. There will be a
sound prompt and the icon will go off.
Cleaning and maintenance
WARNING: Before cleaning and maintenance,
switch the appliance off and remove the plug from
the socket, to prevent electric shock.
♦ Do not immerse any part of the appliance, power
cord or plug in water or any other liquid.
♦ Use a soft damp cloth to wipe the surface. Avoid
using abrasives or strong detergent, spray or
chemicals as these may cause damage to the
appliance.
♦ Clean the inlet and outlet vents with a standard
household vacuum. Do not use water to clean
these parts of the fan. Do not allow water to enter
the appliance.
♦ Do not disassemble the fan for cleaning.
♦ Gently wipe the surface of the remote control with
a soft, dry cloth. If the appliance will not be used
for a long time, remove the batteries from the
remote control.
Storage
♦ Wrap the cable around the hook at the back of
the unit.
♦ Once the fan has been cleaned, it can be stored in
a plastic bag.
♦ Keep away from vibrations and electrical devices
with cooling / heating function.
♦ Do not expose it to direct sunlight, hot and humid
places.
♦ Keep out of the reach of children.

ENGLISH
(Original instructions)
9
Protecting the environment
Separate collection. Products and
batteries marked with this symbol must
not be disposed of with normal household
waste.
Products and batteries contain materials that can
be recovered or recycled, reducing demand for
raw materials. Please recycle electrical products
and batteries according to local provisions. Further
information is available at www.2helpU.com.
Technical data
BXFT50007GB
Input voltage V ~ 220-240
Frequency Hz 50-60
Power input W45
Weight KG 3.65
Product Guarantee
This product comes with a 2 Year guarantee from the
original date of purchase. If any defect arises due to
faulty materials or workmanship, the faulty products
must be returned to the place of purchase. Refund or
replacement is at the discretion of the retailer. This
guarantee is in addition to and in no way prejudices
your statutory rights.
The Following Conditions Apply:
♦ The product must be returned to the retailer
with proof of purchase or a receipt within the
1st year of purchase. For any product related
issues after 12 months please contact our
customer services team.
♦ The product must be installed and used in
accordance with the instructions contained in
this instruction guide.
♦ It must be used only for domestic purposes.
♦ It does not cover wear and tear, damage,
misuse or consumable parts.
♦ This guarantee is valid in the UK and Republic
of Ireland.
For all customer service enquires please contact
us below;
RKW,
Sutton House,
Berry Hill Road,
Stoke-on-Trent,
ST4 2NL
Email [e-mail]
Tel [phone]
Black & Decker® and BLACK+DECKER™ and the
Black & Decker® and BLACK+DECKER™ logos
are registered trademarks of The Black & Decker®
Corporation and are used under licence. All rights
reserved. Imported and Distributed by RKW LTD,
Sutton House, Berry Hill Industrial Estate, Berry Hill
Road, Stoke-on-Trent, ST4 2NL

ENGLISH (Original instructions)
10
Model Identier(s): BXFT50007GB
Item Symbol Value Unit
Maximum fan ow rate F36.86 m3/min
Fan Power input P 37.0 W
Service Value SV 1.00 (m3/min)/W
Standby power consumption PSB 0.630 W
Fan sound power level LWA 54.39 dB(A)
Maximum air velocity c2.96 m/sec
Seasonal electricity
consumption Q12.546 kWh/a
Contact Details: RKW LTD, Sutton House, Berry Hill Industrial Estate, Berry Hill Road,
Stoke-on-Trent, ST4 2NL

11

12/2020
