Black & Decker BXFD52003GB User manual

BXFD52003GBwww.blackanddecker.co.uk

ENGLISH (Original instructions)
2
What’s in the box
Instruction Manual
9” Desk Fan
Guard fastening screw
Features
1. Guard securing clip
2. Guards
3. Oscillation knob
4. Blade
5. Shaft
6. Speed control buttons
7. Base
1
2
3
4
5
6
7

ENGLISH
(Original instructions)
3
Intended Use
Your BLACK+DECKER BXFD52003GB 9’’ Desk Fan
has been designed for cooling small and medium
spaces.
This appliance is intended for indoor household use
only.
Thank you for choosing BLACK+DECKER. We hope
that you will enjoy using this product for many years.
Safety Instructions
WARNING: Read all safety
warnings and all instructions. Failure
to follow the warnings and
instructions listed below may result in
electric shock, re and/or serious
injury.
♦ Read this manual carefully before
using the appliance.
♦ The intended use is described in
this manual.
♦ The use of any accessory or
attachment or the performance of
any operation with this appliance
other than those recommended in
this instruction manual may present
a risk of personal injury.
♦ Retain this manual for future
reference.
♦ WARNING: When using mains-
powered appliances, basic safety
precautions, including the following,
should always be followed to
reduce the risk of re, electric
shock, personal injury and material
damage.
Using Your Appliance
Please read the operating
instructions carefully before using
your portable fan for the rst time.
♦ Check that the voltage of the main
circuit corresponds with the rating
of the appliance before operating.
♦ Children shall not play with the
appliance.
♦ Do not let the cable hang over the
edge of a table or counter or let
it come into contact with any hot
surfaces.
♦ The use of accessory attachments
is not recommended by the
appliance manufacturer, apart from
those supplied with this product.
♦ Do not pull the plug out by the
cable as this may damage the plug
and/or the cable.
♦ Do not use this product for anything
other than its intended use.
♦ This appliance is for household use
only.
♦ Do not carry the appliance by the
power cable.
♦ Do not use the appliance outdoors.
♦ Do not operate with wet hands.
♦ Use of an extension cable with this
appliance is not recommended.
However, if it is necessary to use
an extension lead, ensure that
the lead is suited to the power
consumption of the appliance to
avoid overheating of extension
cable, appliance or plug point. Do
not place the extension cable in a

ENGLISH (Original instructions)
4
position where it can be pulled on
by children or animals or tripped
over.
♦ Always unplug the unit when not in
use or before cleaning.
♦ The manufacturer does not accept
responsibility for any damage
or injury caused by improper or
incorrect use, or for repairs carried
out by unauthorised personnel.
Safety Of Others
♦ Close supervision is necessary
when any appliance is used by or
near children.
♦ Children should not play with the
appliance.
♦ This appliance can be used by
children aged from 8 years and
above and persons with reduced
physical, sensory or mental
capabilities or lack of experience
and knowledge if they have been
given supervision or instruction
concerning use of the appliance
in a safe way and understand the
hazards involved.
♦ Cleaning and user maintenance
should not be undertaken by
children without supervision.
♦ Take care when any appliance is
used near pets.
♦ Do not allow the cord to become
twisted.
After Use
♦ While cleaning, DO NOT use a wet
cloth or use water on any part of
the unit, as this may cause a short
circuit or electrical shock.
♦ Keep this unit clean. Do not allow
objects to enter the ventilation
opening as this may cause electric
shock, or damage to the unit.
Switch off the unit and then remove
the plug from the socket when not
in use or before cleaning.
♦ Check all inlets and outlets
regularly for accumulated dust.
♦ Disconnect the unit from mains
outlet when it is not in use, or
before relocating or cleaning it.
♦ Switch off and remove the plug
from the socket before leaving the
appliance unattended and before
changing, cleaning or inspecting
any parts of the appliance.
♦ When not in use, the appliance
should be stored in a dry place.
Children should not have access to
stored appliances.
Inspections And Repairs
♦ Do not attempt to dismantle, repair
or remould any part of the unit. This
should only be done by a qualied
service agent. Even the change of
power cable should be done by a
qualied person.

ENGLISH
(Original instructions)
5
♦ In the unlikely event the appliance
develops a fault, stop using it
immediately and seek advice from
the manufacturer.
♦ In case of technical problems,
switch off the product and do not
attempt to repair it yourself. Return
the appliance to an authorised
service facility for examination,
adjustment or repair. Always
insist on the use of original spare
parts. Failure to comply with the
above mentioned precautions and
instructions, could affect the safe
operation of this product.
Additional safety instructions for
Air Coolers and Fans
♦ Install the unit on at and hard oor
to diminish vibration or noise.
♦ Always operate the appliance on a
smooth, even, stable surface. Do
not place the unit on a hot surface.
♦ Ensure that the unit is switched off
after use.
♦ Do not immerse cables, plugs or
any part of the appliance in water
or any other liquid.
♦ Operate the unit only at the voltage
specied.
♦ Do not use the unit near open
windows, as contact with rain and
other natural elements could cause
an electrical hazard
♦ Do not put heavy objects on the
appliance.
♦ Do not tip the unit on its side.
♦ Never insert any other object into
the unit body to avoid any hazard
or unit failure.
♦ Do not put the unit close to
heat-generating devices or
near ammable and dangerous
materials.
♦ If the supply cable is damaged,
it must be replaced by the
manufacturer or its service agent or
a similarly qualied person in order
to avoid a hazard
♦ The appliance must be positioned
so that the plug is accessible.
♦ For optimal airow circulation,
leave a distance of at least 1 metre
around the appliance on every side.
Always direct the airow in order
to optimise cooling. Avoid corners,
small objects and other surfaces
or objects which may impede the
airow.
WARNING: Do not place the unit
on or near a hot gas electric burner.

ENGLISH (Original instructions)
6
Electrical safety
Before use, check that the mains voltage
corresponds to the voltage on the rating plate.
Always check that the mains voltage
corresponds to the voltage on the rating
plate.
♦ Appliance plugs must match the outlet. Never
modify the plug in any way.
♦ Do not use any adapter plugs with this appliance.
Unmodied plugs and matching outlets will reduce
the risk of electric shock.
♦ To avoid the risk of electric shock, do not immerse
the cord, plug or appliance in water or other liquid.
Extension cables & class 2 product
♦ A 2 core cable must be used as your tool is not
earthed.
♦ Up to 30m (100 ft) can be used without loss of
power.
♦ If the supply cord is damaged, it must be
replaced by the manufacturer or an authorised
BLACK+DECKER Service Centre in order to avoid
a hazard.
Warning! Before assembling, switch the appliance
off and remove the plug from the socket.
Features (Refer to diagram on page 2)
1. Guard securing clip
2. Guards
3. Oscillation knob
4. Blade
5. Shaft
6. Speed control buttons
7. Base
Use
About the Controls
♦ 2 Speed settings
♦ Oscillation Function
Assembling Your Fan - Affixing the Base to
the Motor Housing
WARNING: Before performing any assembly or
maintenance, switch off and remove from the power
supply.
♦ To assemble your fan, start by threading the
power cord through the hole in the fan base.
♦ When the power cord has been passed through
this hole, locate the small notches on the inside
of the hole. These align with the grooves at
the bottom of the motor housing. Observing
this alignment, slot the motor housing into the
base until both parts sit ush. Once both parts
are slotted into place, twist the motor housing
clockwise to tighten it and secure it to the fan
base.

ENGLISH
(Original instructions)
7
Installing the Back Guard
♦ Remove the nut at the back of the motor housing
and put it to one side.
♦ Once this part has been removed, afx the back
guard to the motor housing. To do this, align
the two pins at the top and bottom of the motor
housing with the two corresponding notches on
the back guard, so that the handle on the guard is
at the top of the fan, above the blades.
♦ With the back guard in position, replace the nut
onto its slot at the base of the blade shaft, and
turn it clockwise to tighten.
Note! Take care to secure the back guard into place
when re-tightening the nut, to prevent it from slipping
out of position.
♦ The back guard should now be secured into place.
Installing the Fan Blades
♦ Once the back guard has been installed,slot the
fan blades into it and push them into place.
Note! Ensure the blades rotate unimpeded and do
not graze against the back guard. If the fan blades
become stuck or graze against the guard mesh,
they will need to be re-installed. Repeat the steps
above as necessary until the blades move freely and
naturally inside the guard mesh.
Installing the Front Guard
WARNING do not operate the fan without all
guards in place.
♦ When the blades have been installed, connect
the front guard to the back guard to complete fan
assembly. To do this, align the edges of the two
guards, ensuring the xing bracket on the front
guard is at the top of the fan, directly above the
blades.
♦ When the front guard is in place, locate the
locking clips around the rim of the front guard and
push each of these down to secure the front guard
into place.
♦ Once the front guard has been secured into place,
use the screwdriver to x the screw and lock nut
through the bottom of the grids.
♦ Your fan is now ready for normal use.
Turning the Unit On or Off
♦ Press any of the 2 speed buttons on the fan’s
control panel to turn the unit on. The fan will
automatically start operating at the desired speed.
♦ Press the 0 button on the fan’s control panel while
the fan is in operation to turn the unit off.
Speed Selection
♦ This fan is equipped with a choice of 2
speed settings: Low (1) or High (2). Press the
corresponding button on the unit’s control panel to
select the desired speed.
WARNING Press only one of the speed control
buttons at a time. Permanent damage to the switch
housing may result if two or more of the buttons are
pressed simultaneously.
♦ Press the other speed button while the unit is
in operation to change wind speed. The fan will
automatically adjust to the new setting within a
few seconds.
♦ Press the 0 button on the fan’s control panel while
it is in operation to turn the unit off. Wind will stop
emitting from the fan grille and the fan blades will
stop rotating after a few seconds to show the unit
has been turned off.
The Oscillation Function
♦ This fan is equipped with an oscillation function,
for more even air ow distribution across a room
or area.
♦ Push the oscillation knob at the back of the motor
housing down to turn the oscillation function on.
The fan will automatically begin turning from side
to side in a xed pattern.
♦ Pull the oscillation knob up while the fan is
oscillating to turn this function off. The fan will
automatically remain locked at its current angle,
and the wind ow will be directed that way. To
select a different angle or direction for the wind,
turn the oscillation function back on, as described
above, wait until the fan is facing in the required
direction, then pull the oscillation knob up to stop
the oscillation function and lock the fan into place.

ENGLISH (Original instructions)
8
Adjusting the Air Flow
♦ This unit is equipped with a vertical tilt function,
which can be manually adjusted to better direct
the air ow.
♦ To adjust the vertical tilt angle of the fan, rmly
grip the top half of the motor housing and push it
gently upwards or downwards as required. The
fan will give off a clicking noise to indicate the tilt
mechanism is working.
♦ Once the fan has been tilted, it will automatically
remain at the selected angle until manually
adjusted again.
Note! The fan’s horizontal angle cannot be manually
adjusted. To change the horizontal angle of the fan,
activate the oscillation function as detailed above,
wait until the fan is at the desired angle, then pull the
oscillation knob up to stop the oscillation function
and lock the fan into place.
Cleaning and maintenance
WARNING: Before cleaning and maintenance,
switch the appliance off and remove the plug from
the socket, to prevent electric shock.
♦ Do not immerse any part of the appliance, power
cord or plug in liquids.
♦ Use a soft damp cloth to wipe the surface. Avoid
using detergent, spray or chemicals as these may
cause damage to the appliance.
WARNING: DO NOT allow water or steam to
enter any part of the appliance, as this could cause it
to malfunction.
♦ Store the appliance in a cool, dry place, ideally in
its original packaging.
Mains plug replacement
WARNING: The following section on mains plug
replacement is for authorised service centre persons
only.
If a new mains plug needs to be tted:
♦ Safely dispose of the old plug.
♦ Connect the brown lead to the live terminal in the
new plug.
♦ Connect the blue lead to the neutral terminal.
♦ If the product is class I (earthed), connect the
green/yellow lead to the earth terminal.
Note! If your product is class II double insulated
(only 2 wires in the cord set), no connection is to be
made to the earth terminal.
Follow the tting instructions supplied with good
quality plugs. Any replacement fuse must be of the
same rating as the original fuse supplied with the
product.
Protecting the environment
Separate collection. Products and
batteries marked with this symbol must
not be disposed of with normal household
waste.
Products and batteries contain materials that can
be recovered or recycled, reducing demand for
raw materials. Please recycle electrical products
and batteries according to local provisions. Further
information is available at www.2helpU.com.
Technical data
BXFD52003GB
Input voltage V AC 220-240V
Frequency Hz 50
Power input W20
Weight KG 1.29

ENGLISH
(Original instructions)
9
Product Guarantee
This product comes with a 2 Year guarantee from the
original date of purchase. If any defect arises due to
faulty materials or workmanship, the faulty products
must be returned to the place of purchase. Refund or
replacement is at the discretion of the retailer. This
guarantee is in addition to and in no way prejudices
your statutory rights.
The Following Conditions Apply:
♦ The product must be returned to the retailer
with proof of purchase or a receipt within the
1st year of purchase. For any product related
issues after 12 months please contact our
customer services team.
♦ The product must be installed and used in
accordance with the instructions contained in
this instruction guide.
♦ It must be used only for domestic purposes.
♦ It does not cover wear and tear, damage,
misuse or consumable parts.
♦ This guarantee is valid in the UK and Republic
of Ireland.
For all customer service enquires please contact
us below;
RKW,
Sutton House,
Berry Hill Road,
Stoke-on-Trent,
ST4 2NL
Email [e-mail]
Tel [phone]
Black & Decker® and BLACK+DECKER™ and the
Black & Decker® and BLACK+DECKER™ logos
are registered trademarks of The Black & Decker®
Corporation and are used under licence. All rights
reserved. Imported and Distributed by RKW LTD,
Sutton House, Berry Hill Industrial Estate, Berry Hill
Road, Stoke-on-Trent, ST4 2NL

ENGLISH (Original instructions)
10
Model Identier(s): BXFD52003GB
Item Symbol Value Unit
Maximum fan ow rate F10.58 m3/min
Fan Power input P 18.23 W
Service Value SV 0.58 (m3/min)/W
Standby power consumption PSB 0.00 W
Seasonal electricity
consumption Q5.83 kWh/a
Fan sound power level LWA 51.20 dB(A)
Maximum air velocity c2.25 m/sec
Contact Details: RKW LTD, Sutton House, Berry Hill Industrial Estate, Berry Hill Road,
Stoke-on-Trent, ST4 2NL

11

11/2020
