1. General Information
Thank you for your purchase of this Black Box product. If any questions arise
during installation or use of the unit, contact Black Box Tech Support at
[phone].
1.1 Features
•
Easy-to-install T1/E1 Extenders— no configuration required
•
Data rates up to 2.048 Mbps in 64-kbps intervals
•
Plug ‘n’ Play for easy installations
•
LED indicators for Power, Ethernet Link, and Frame
• CE marked
1.2 Description
The Black Box T1/E1 Extenders provide high speed 2-wire T1/E1 extension con-
nectivity to ISPs, PTTs, and enterprise environments using binder group friendly
TC-PAM modulation.
Line connection is made with an RJ-45 jack. Models MT196A-E1 and MT195A-
T1 are powered by an 100/230 VAC (Universal) supply. The NTU features exter-
nally-accessible DIP switches, loopback diagnostics, and Plug ‘n’ Play.

T1/E1 LINK EXTENDERS
9
2. Installation
Because the T1/E1 Extenders require no configuration, they can be installed
quickly. Installation consists of the following:
•
Connect the power plug (refer to section 2.1, “Connecting Power” on page 10).
•
Connect the line port (refer to section 2.3, “Connecting the Line Port” on
page 11)
Note See Figure 1 and Figure 2 for the rear-panel connectors locations.
•
Connect the T1/E1 port (refer to section 2.4, “Connecting the Circuit Interface”
on page 11).
Figure 1. Model MT196A-E1 rear panel
Figure 2. Model MT195A-T1 rear panel
Made in the USA
Power
Power Line
Line
TX
Interface
RX
RX (75 Ohm)
(Data from
G.703/G.704
network)
TX (75 Ohm)
(Data to
G.703/G.704
network)
E1 interface
(120 Ohm)
Made in the USA
Power
Power Line
Line
Interface
T1 interface
(RJ-48C)

T1/E1 LINK EXTENDERS
10
2.1 Connecting Power
Your T1/E1 Extender comes with an external AC adaptor with a detachable
power cord.
To connect power to the T1/E1 Extender:
1. Connect the female plug of the AC power cord to the AC adaptor provided.
2. Connect the barrel-type connector of the AC adaptor to the Power connec-
tor on the T1/E1 Extender.
3. Insert the male plug of the AC power cord into the AC power outlet (100-
240 VAC).
4. Verify that the Power LED on the front panel illuminates and remains lit.
2.2 Power Input Connector
The T1/E1 Extender comes with an AC power supply.
• The supplies connection to the T1/E1 Extender is a 2.5 mm barrel receptacle
with the center conductor positive (see Figure 3).
Figure 3. Power connection barrel receptacle diagram
•
T1/E1 Extender’s rated voltage: 5.0 VDC
•
T1/E1 Extender’s rated current: 1 A DC
2.2.1 E
XTERNAL
AC
UNIVERSAL POWER SUPPLY
•
Output from power supply: 5 VDC, 2A
• Input to power supply: universal input 100–240 VAC 50/60 Hz 0.3A
The external AC adaptor shall be a listed limited power
source that incorporates a disconnect device and shall
be positioned within easy reach of the operator. Ensure
that the AC power cable meets all applicable standards
for the country in which it is to be installed, and that it
is connected to a wall outlet which has earth ground.
CAUTION

T1/E1 LINK EXTENDERS
11
2.3 Connecting the Line Port
Follow the steps below to connect the line port:
1. Obtain a single-twisted pair cable with an RJ-45 plug connector at each
end.
2. Plug one end of the cable into the RJ-45 socket (labeled Line) on the T1/E1
Extender .
3. When the remote and local extender units synchronize, the front-panel Link
LED will turn on.
2.4 Connecting the Circuit Interface
Your T1/E1 Extender comes with either an RJ-48C or an RJ-48C and dual BNC
for connection to a T1 or E1:
•
Model MT196A-E1 - E1: 120-Ohm RJ-48C and dual 75-Ohm BNC connec-
tors
•
Model MT195A-T1 - T1: RJ-48C
To connect the twisted pair cable to the T1/E1 port:
1. Attach the male connector of the twisted pair cable to the female RJ-48
connector on the T1/E1 Extender.
2. Attach the other end of the cable to the RJ-48 connector on the local T1 or
E1.
Note When attaching the T1/E1 Extender directly to a T1/E1 circuit, a straight
through twisted pair cable can be used. When attaching the MT196A-
E1/R or MT195A-T1/R to a device, please use the enclosed T1/E1 cross
over cable for proper operation.
Note The unit marked as MT196A-E1/L or MT195A-T1/L is configured by
default to accept timing from the T1/E1 circuit. The MT196A-E1/R or
MT195A-T1/R unit then recovers this timing from the line in order to
ensure synchronization of the T1/E1 circuit over the extenders.
The interconnecting cables shall be acceptable for
external use and shall be rated for the proper applica-
tion with respect to voltage, current, anticipated tem-
perature, flammability, and mechanical serviceability.
CAUTION

T1/E1 LINK EXTENDERS
12
3. Operation
Once the T1/E1 Extenders are properly installed, they should operate transpar-
ently. No user settings required. This section describes reading the LED status
monitors.
3.1 Front Panel LED Status Monitors
Models MT196A-E1 and MT195A-T1 feature three front-panel LEDs that moni-
tor power, Ethernet signals, and the CopperLink connection. Figure 4 shows the
front panel location of each LED. Table 1 describes the LED functions.
Figure 4. T1/E1 Extender front panel
Table 1: Front panel LED description
LED Description
Power When lit, indicates the unit is powered on
Link On solid—link is connected
Off—No signal detected
Flashing — Data is being transmitted/received
Frame On solid—T1/E1 frame is connected
Off — No signal detected
Flashing — Error detected
Power
LED
Link
LED
Frame
LED
Link
Frame
Power
T1/E1 Link Extender

T1/E1 LINK EXTENDERS
13
3.2 Configuration and Dip Switches
The T1/E1 Extenders are Plug ‘n’Play enabled and do not require any configura-
tion by the user.
Note The user should NOT change any of the dip switches except for S1-7 (if
necessary). If the user changes the position of any of the dip switches
(except for S1-7), it will affect the operation of the unit. Refer to
Appendix B. on page 16 for the factory default dip switch configuration.
3.2.1 S
WITCH
S1-7: L
INE
B
UILD
O
UT
Switch S1-7 defines the shape of the waveform on the T1 or E1 line.
Table 2: S1-7 Default Position
Switch MT196A-
E1/L/EUI MT196A- E1/R/EUI MT195A- T1/L/EUI MT195A- T1/R/EUI
S1-7 OFF (120) OFF (120) ON (0.0dB) ON (0.0dB)

T1/E1 LINK EXTENDERS
14
A. Specifications
A.1 Circuit Rates
• Model MT196A-E1 - 2.048 Mbps
•
Model MT195A-T1 - 1.544 Mbps
A.2 Circuit Interface
•
E1 (Model MT196A-E1) presents G.703/G.704 interface. Either 75 Ohms
(unbalanced) or 120 Ohms (balanced). Pins 1 & 2 are Receive. Pins 4 & 5 are
transmit.
•
T1 (Model MT195A-T1) present T1 interface. Pins 1 & 2 are Receive. Pins 4
& 5 are Transmit.
A.3 Circuit Defaults
•
E1 Line Coding = HDB3.
•
T1 Line Coding = B8ZS; Line Build Out Rx =Automatic; Line Build Out Tx =
0.
A.4 Circuit Connector
•
Dual BNC and RJ48C (Model MT196A-E1), strap selectable
• RJ48C connector (Model MT195A-T1)
A.5 LED Indicators
• Three LED indicators: Power, Link, Frame
A.6 Power and Power Supply Specifications
• AC power supply
•
Connection to the T1/E1 Extender requires +5VDC ±5% DC power (1.0A
minimum). Center pin is +5V. The barrel type plug has a 2.5/5.5/10mm
I.D./O.D./shaft length dimensions
•
T1/E1 Extender’s rated voltage: 5.0 VDC
• T1/E1 Extender’s rated current: 1A DC

T1/E1 LINK EXTENDERS
15
A.7 Environmental
•
Temperature: 32–122°F (0–50°C)
•
Relative Humidity: 5–95%, non-condensing
•
Altitude: 0–15,000 ft (0–4,572 m)
A.8 Transmission Line
•
Single Twisted Pair
A.9 Line Coding
•
TC-PAM (Trellis Coded Pulse Amplitude Modulation)
A.10 Line Interface
•
Transformer coupled, 2500 VRMS isolation
A.11 Line Physical Connection
• RJ-45, 2-wire polarity insensitive pins 4 and 5

T1/E1 LINK EXTENDERS
16
B. Factory Default Dip Switch Configuration
Note This information is provided for informational purposes only. These set-
tings should not be changed other than by instructions from Black Box
Support, lest the unit be rendered inoperable.
B.1 Switch S1 - Factory Default configuration
B.2 Switch S2 - Factory Default Configuration
Table 3: S1 Factory Default Dip Switch Configuration
Switch MT196A-
E1/L/EUI MT196A- E1/R/EUI MT195A- T1/L/EUI MT195A- T1/R/EUI
Switch 1-1 ON ON ON ON
Switch 1-2 ON ON ON ON
Switch 1-3 ON ON ON ON
Switch 1-4 ON ON OFF OFF
Switch 1-5 ON ON OFF OFF
Switch 1-6 OFF OFF ON ON
Switch 1-7 OFF OFF ON ON
Switch 1-8 ON ON ON ON
Table 4: S2 Factory Default Dip Switch Configuration
Switch MT196A-
E1/L/EUI MT196A- E1/R/EUI MT195A- T1/L/EUI MT195A- T1/R/EUI
Switch 2-1 OFF OFF OFF OFF
Switch 2-2 OFF OFF OFF OFF
Switch 2-3 OFF OFF OFF OFF
Switch 2-4 OFF ON OFF ON
Switch 2-5 ON OFF ON OFF
Switch 2-6 OFF OFF ON ON
Switch 2-7 OFF OFF ON ON
Switch 2-8 ON ON ON ON

T1/E1 LINK EXTENDERS
17
Notes
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________

T1/E1 LINK EXTENDERS
18
Notes
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________

T1/E1 LINK EXTENDERS
19
Notes
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________
________________________________________________________________

© Copyright 2007. Black Box Corporation. All rights reserved.
1000 Park Drive • Lawrence, PA 15055-1018 • 724-746-5500 • Fax [phone]
BLACK BOX®®
NETWORK SERVICES
