Black Box LB522A-KIT User manual

LB522A-KIT
LB524A-KIT
LB528A-KIT
DeeSL.2 Ethernet Extender
Extend corporate LAN communications at higher speeds or at a
longer distance.

724-746-5500 | blackbox.com
Page 2
Black Box DeeSL.2 Ethernet Extender
TABLE OF CONTENTS
1. GENERAL INFORMATION .......................................................................10
1.1 Features ............................................................................................10
1.2 Description........................................................................................ 10
1.3 LB52xA-KIT front Panel.................................................................... 11
1.3.1 LED Descriptions ..................................................................11
1.4 LB52xA-KIT Rear Panel ................................................................... 12
1.4.1 Port Descriptions ..................................................................12
1.5 Reset Button..................................................................................... 13
1.6 Ground Terminal............................................................................... 14
2. Applications Overview ............................................................................... 14
2.1 Typical Application ............................................................................14
2.2 Distance Charts................................................................................ 16
2.2.1 Distance Chart LB52xA-KIT Series - Auto Mode...................16
2.2.2 Distance Chart LB52xA-KIT Series - Optimal Mode............. 16
2.2.3 Distance Chart LB52xA-KIT Series - TCPAM - 128 ............. 17
3. Hardware Installation................................................................................. 18
3.1 Planning the Installation ....................................................................18
3.1.1 Network Diagram ..................................................................19
3.1.2 IP Related Information.......................................................... 19
3.1.3 AC Power Mains................................................................... 20
3.1.4 Location and mounting requirements ................................... 20
3.1.5 Installing the LB52xA-KIT..................................................... 20
3.1.6 Connecting cables ................................................................ 21
3.1.7 Grounding the LB52xA-KIT and connecting power .............. 21
3.2 Configuring the LB52xA-KIT............................................................. 23
3.2.1 Web configuration requirements ...........................................23
3.3 Console configuration requirements................................................. 23
3.3.1 Telnet configuration requirements ........................................23
4. Web Configuration..................................................................................... 24
4.1 Setting Up the WMI ...........................................................................24
4.1.1 TCP/IP setup ........................................................................24
4.1.2 System Login........................................................................ 25
4.2 Basic Configuration Options............................................................. 26
4.2.1 Operation mode and Management port ................................26
4.2.2 DHCP server......................................................................... 28
4.2.3 LAN....................................................................................... 29
4.2.4 Review and save basic setup changes................................. 31
4.3 Advanced Configuration Options...................................................... 31
4.3.1 LINE ......................................................................................31
4.3.2 VLAN .................................................................................... 34

724-746-5500 | blackbox.com Page 3
Table of Contents
4.3.3 Configuring 802.1Q VLAN Tagging ......................................39
4.3.4 Quality of Service (QoS)....................................................... 41
4.3.5 Rate Limit ............................................................................. 54
4.3.6 Flow Control ......................................................................... 55
4.4 Status Options.................................................................................. 55
4.4.1 LINE Status ..........................................................................55
4.4.2 Management Status ............................................................. 56
4.4.3 LAN Status ........................................................................... 56
4.4.4 Performance Status.............................................................. 57
4.1 Administration Options .....................................................................58
4.1.1 Security Administration .........................................................58
4.1.2 SNMP Administration ........................................................... 61
4.1.3 Remote Syslog..................................................................... 64
4.2 Utility Options ................................................................................... 64
4.2.1 System Information ...............................................................65
4.2.2 Configuration Tool................................................................ 65
4.2.3 Upgrade................................................................................ 66
4.2.4 Logout................................................................................... 66
4.2.5 Restart.................................................................................. 67
5. Console and Telnet Configuration............................................................. 67
5.1 Login to the Console Interface ..........................................................67
5.2 Log in using Telnet........................................................................... 68
5.3 Interface commands......................................................................... 68
5.4 Window structure.............................................................................. 69
5.5 Main Menu Tree ............................................................................... 70
5.5.1 Menu tree for authorized users .............................................70
5.6 Menu tree for unauthorized users..................................................... 72
5.7 Enable Command Menu................................................................... 73
5.8 Setup Command Menu..................................................................... 75
5.8.1 Line .......................................................................................75
5.8.2 LAN....................................................................................... 77
5.8.3 VLAN.................................................................................... 78
5.8.4 QoS ...................................................................................... 82
5.8.5 Rate...................................................................................... 89
5.8.6 Management......................................................................... 90
5.8.7 DHCP ................................................................................... 90
5.8.8 DNS Proxy............................................................................ 92
5.8.9 Host Name............................................................................ 93
5.8.10 Factory Default................................................................... 93
5.9 Status Command Menu.................................................................... 94
5.9.1 LINE Status ..........................................................................94
5.9.2 Interface Status .................................................................... 95
5.10 Show Command Menu..................................................................... 95

724-746-5500 | blackbox.com
Page 4
Black Box DeeSL.2 Ethernet Extender
5.11 Write Command................................................................................ 96
5.12 Reboot Command............................................................................. 97
5.13 Ping Command................................................................................. 97
5.14 Administration Command Menu ....................................................... 98
5.14.1 User Profile .........................................................................98
5.14.2 Security............................................................................. 100
5.14.3 SNMP ............................................................................... 101
5.14.4 Supervisor Password and ID ............................................ 103
5.15 Utility Command Menu ................................................................... 104
5.15.1 Upgrade main software .....................................................105
5.15.2 Backup system configuration............................................ 105
5.15.3 Restore system configuration ........................................... 105
5.16 Exit Command................................................................................ 106
A. Specifications........................................................................................... 107
A.1 Line Connector ...............................................................................107
A.2 Line Modulation ..............................................................................107
A.3 Ethernet Connector .........................................................................107
A.4 LAN Protocols .................................................................................107
A.5 VLAN Support .................................................................................107
A.6 QoS Support ...................................................................................107
A.7 Management Connector .................................................................107
A.8 Management Interface ....................................................................107
A.9 Front Panel Indicators .....................................................................108
A.10 Power Supply ..................................................................................108
A.11 Operating Temperature ..................................................................108
A.12 Storage Temperature ......................................................................108
A.13 Dimensions .....................................................................................108
A.14 Weight .............................................................................................108
B. Port Pin-outs.............................................................................................109
B.1 Console Port ...................................................................................109
B.2 Ethernet ..........................................................................................110
B.3 Line (Black Box) ..............................................................................110

724-746-5500 | blackbox.com Page 5
RADIO FREQUENCY INTERFERENCE STATEMENTS
RADIO FREQUENCY INTERFERENCE STATEMENTS
FEDERAL COMMUNICATIONS COMMISSION AND INDUSTRY CANADA RADIO
FREQUENCY INTERFERENCE STATEMENTS
This equipment generates, uses, and can radiate radio-frequency energy, and if not
installed and used properly, that is, in strict accordance with the manufacturer’s
instructions, may cause interference to radio communication. It has been tested and
found to comply with the limits for a Class A computing device in accordance with the
specifications in Subpart B of Part 15 of FCC rules, which are designed to provide rea-
sonable protection against such interference when the equipment is operated in a
commercial environment. Operation of this equipment in a residential area is likely to
cause interference, in which case the user at his own expense will be required to take
whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compli-
ance could void the user’s authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from
digital apparatus set out in the Radio Interference Regulation of Industry Canada.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les
limites applicables aux appareils numériques de la classe A prescrites dans le Règle-
ment sur le brouillage radioélectrique publié par Industrie Canada.

724-746-5500 | blackbox.com
Page 6
Black Box DeeSL.2 Ethernet Extender
INSTRUCCIONES DE SEGURIDAD
(Normas Oficiales Mexicanas Electrical Safety Statement)
1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de
que el aparato eléctrico sea operado.
2. Las instrucciones de seguridad y operación deberán ser guardadas para referen-
cia futura.
3. Todas las advertencias en el aparato eléctrico y en sus instrucciones de oper-
ación deben ser respetadas.
4. Todas las instrucciones de operación y uso deben ser seguidas.
5. El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de
la tina de baño, lavabo, sótano mojado o cerca de una alberca, etc..
6. El aparato eléctrico debe ser usado únicamente con carritos o pedestales que
sean recomendados por el fabricante.
7. El aparato eléctrico debe ser montado a la pared o al techo sólo como sea
recomendado por el fabricante.
8. Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo
descrito en las instrucciones de operación. Todo otro servicio deberá ser referido
a personal de servicio calificado.
9. El aparato eléctrico debe ser situado de tal manera que su posición no interfiera
su uso. La colocación del aparato eléctrico sobre una cama, sofá, alfombra o
superficie similar puede bloquea la ventilación, no se debe colocar en libreros o
gabinetes que impidan el flujo de aire por los orificios de ventilación.
10.El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como
radiadores, registros de calor, estufas u otros aparatos (incluyendo amplificado-
res) que producen calor.
11.El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo
descrito en el instructivo de operación, o como se indique en el aparato.
12.Precaución debe ser tomada de tal manera que la tierra fisica y la polarización
del equipo no sea eliminada.
13.Los cables de la fuente de poder deben ser guiados de tal manera que no sean
pisados ni pellizcados por objetos colocados sobre o contra ellos, poniendo par-
ticular atención a los contactos y receptáculos donde salen del aparato.

724-746-5500 | blackbox.com Page 7
INSTRUCCIONES DE SEGURIDAD
14.El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomenda-
ciones del fabricante.
15.En caso de existir, una antena externa deberá ser localizada lejos de las lineas
de energia.
16.El cable de corriente deberá ser desconectado del cuando el equipo no sea
usado por un largo periodo de tiempo.
17.Cuidado debe ser tomado de tal manera que objectos liquidos no sean derrama-
dos sobre la cubierta u orificios de ventilación.
18.Servicio por personal calificado deberá ser provisto cuando:
A. El cable de poder o el contacto ha sido dañado; u
B. Objectos han caído o líquido ha sido derramado dentro del aparato; o
C. El aparato ha sido expuesto a la lluvia; o
D. El aparato parece no operar normalmente o muestra un cambio en su desem-
peño; o
E. El aparato ha sido tirado o su cubierta ha sido dañada.

724-746-5500 | blackbox.com
Page 8
Black Box DeeSL.2 Ethernet Extender
SAFETY WHEN WORKING WITH ELECTRICITY
• This device contains no user serviceable parts. This
device can only be repaired by qualified service personnel.
• Do not open the device when the power cord is connected.
For systems without a power switch and without an external
power adapter, line voltages are present within the device
when the power cord is connected.
• For devices with an external power adapter, the power
adapter shall be a listed Limited Power Source. The mains
outlet that is utilized to power the device shall be within 10
feet (3 meters) of the device, shall be easily accessible, and
protected by a circuit breaker in compliance with local regu-
latory requirements.
• For AC powered devices, ensure that the power cable
used meets all applicable standards for the country in
which it is to be installed.
• For AC powered devices which have 3 conductor power
plugs (L1, L2 & GND or Hot, Neutral & Safety/Protective
Ground), the wall outlet (or socket) must have an earth
ground.
• For DC powered devices, ensure that the interconnecting
cables are rated for proper voltage, current, anticipated
temperature, flammability, and mechanical serviceability.
• WAN, LAN & PSTN ports (connections) may have hazard-
ous voltages present regardless of whether the device is
powered ON or OFF. PSTN relates to interfaces such as
telephone lines, FXS, FXO, DSL, xDSL, T1, E1, ISDN, Voice,
etc. These are known as “hazardous network voltages” and
to avoid electric shock use caution when working near
these ports. When disconnecting cables for these ports,
detach the far end connection first.
• Do not work on the device or connect or disconnect
cables during periods of lightning activity.
WARNING

724-746-5500 | blackbox.com Page 9
In accordance with the requirements of council
directive 2002/96/EC on Waste of Electrical and
Electronic Equipment (WEEE), ensure that at
end-of-life you separate this product from other
waste and scrap and deliver to the WEEE col-
lection system in your country for recycling.
This device contains no user serviceable parts.
This device can only be repaired by qualified
service personnel.
This device is NOT intended nor approved for
connection to the PSTN. It is intended only for
connection to customer premise equipment.
Electrostatic Discharge (ESD) can damage
equipment and impair electrical circuitry. It
occurs when electronic printed circuit cardsare
improperly handled and can result in complete
or intermittent failures. Do the following to pre-
vent ESD:
• Always follow ESD prevention procedures
when removing and replacing cards.
• Wear an ESD-preventive wrist strap, ensuring
that it makes good skin contact. Connect the
clip to an unpainted surface of the chassis
frame to safely channel unwanted ESD voltages
to ground.
• To properly guard against ESD damage and
shocks, the wrist strap and cord must operate
effectively. If no wrist strap is available, ground
yourself by touching the metal part of the chas-
sis.
WARNING
WARNING
WARNING

724-746-5500 | blackbox.com
Page 10
Black Box DeeSL.2 Ethernet Extender
1. GENERAL INFORMATION
Thank you for your purchase of this Black Box ® product. This product has been thor-
oughly inspected and tested and is warranted for one year for parts and labor. If any
questions or problems arise during installation or use of this product, contact Black
Box Technical Support at 724-746-5500 or [e-mail].
1.1 FEATURES
• High speed extension with speeds up to 22.8 Mbps
• up to 8-wire (4 pair) Line connection via built-in RJ-45 ports
• 4 auto 10/100Base-Tx, full or half-duplex Ethernet ports for direct connection of
four Ethernet devices
• Extends Ethernet up to 1.8 miles (2.9 km) using 24 AWG/0.5mm wire (192 kbps
speed)
• CE marked
1.2 DESCRIPTION
The Black Box ® LB52xA-KIT simplifies and provides cost-effective network extension
by utilizing pre-existing twisted pair infrastructure, which enables service providers to
offer broadband or data backhaul services to businesses, governments and various
institutions over existing last-mile, copper infrastructure. Today, more than ever, opera-
tors are finding the business case for leveraging their existing copper networks to be
highly attractive from an ROI and initial investment perspective over fiber roll-outs.
Black Box’s LB52xA-KIT Ethernet Extender incorporates multi-pair bonding to offer an
unmatched rate, reach and reliable Ethernet connectivity, providing symmetrical 22.8
Mbps of bandwidth over 4-pair (8-wire) at distances up to 1.8 miles (2.9 km). The
LB52xA-KIT comes standard with a 4-port fast Ethernet switch with full QoS and CoS
features. VLAN (802.1q) capabilities include 4 levels of priorities, traffic flow control
and rate control. These traffic management and QoS features enable service providers
to provision for differentiated services and/or SLAs.
The following base models are available:
• LB522A-KIT: Ethernet Extender (2-wire), 5.7 Mbps
• LB524A-KIT: Ethernet Extender (4-wire), 11.4 Mbps
• LB528A-KIT: Ethernet Extender (8-wire), 22.8 Mbps

724-746-5500 | blackbox.com Page 11
Refer to Appendix A for a complete feature description of the LB52xA-KIT.
Figure 1. LB52xA-KIT
1.3 LB52XA-KIT FRONT PANEL
1.3.1 LED Descriptions
The front panel LEDs display the status of the power, system, Ethernet ports, and Line
port. Figure 2. shows the front panel LED indicators and Table 1 provides a description
of the LED indicators’ behavior.
Figure 2. LB52xA-KIT front panel LEDs

724-746-5500 | blackbox.com
Page 12
Black Box DeeSL.2 Ethernet Extender
1.4 LB52XA-KIT REAR PANEL
1.4.1 Port Descriptions
The Black Box LB52xA-KIT rear panel ports are shown in the figure below and
described in Table 2.
Figure 3. LB52xA-KIT rear panel
Table 1: Front panel LEDs
LED Condition Description
Power On Power is applied
Alarm On
Blink LINE connection dropped LINE self-test
Management On Management port is connected
WAN (1-4) LINK On
Blink LINE is connected LINE handshake/transmited/received data
LAN (1-4) LINK/ACT On
Blink Ethernet is connected Ethernet link transmitted/received data
LAN (1-4) 100M On
Off LAN port is on 100M mode LAN port is on 10M mode
Power Console
Reset
Management Line
LAN
9V,1A
PowerConsole
Reset
Management Line
L
A
N
9
V
,
1
A

724-746-5500 | blackbox.com Page 13
NOTE: For port pinout information, see Appendix B. on page 109.
1.5 RESET BUTTON
• To restart the unit with the current startup configuration—Press the Reset button
for less than 1 second and release. The LB52xA-KIT will restart with the current
startup configuration.
• To restart the unitwith factory default configuration—Press the Reset button for 5
seconds until the Power LED starts blinking. The unit will restart with factory
default configuration.
• To restart the unit in bootloader mode (to be used only by trained Black Box tech-
nicians)—Start with the unit powered off. Press and hold the Reset button while
applying power to the unit. Release the Reset button when the Power LED starts
blinking so the unit will enter bootloader mode.
Table 2: Port descriptions
Port Description
Power Power adaptor inlet: Input voltage 9VDC
Console
(RS-232 control port)
Used for service and maintenance, the Console
port, an RS-232 RJ-45 connector with EIA-561
pinout, connects the router to a serial terminal
such as a PC or ASCII terminal (also called a
dumb terminal). Asynchronous default data rate
9600 bps, hardware DSR and DTR signals for
external modems are wired directly together
internally.
Reset Reset button for rebooting or loading factory
default settings
LAN (LAN Ethernet
Ports 1-4)
10/100Base-Tx full-/half-duplex, RJ-45, auto
detection and fallback, connects the unit to an
Ethernet LAN.
Management RJ-45 for management port
Line Interface for WAN port (RJ-45)

724-746-5500 | blackbox.com
Page 14
Black Box DeeSL.2 Ethernet Extender
1.6 GROUND TERMINAL
The marked lug or terminal should be connected to the building protec-
tive earth bus. The function of protective earth does not serve the pur-
pose of providing protection against electrical shock, but instead
enhances surge suppression on the lines for installations where suitable
bonding facilities exist. The connector type is M3 machine screw.
2. APPLICATIONS OVERVIEW
The Black Box LB52xA-KIT simplifies and provides cost effective network extension by
utilizing pre-existing twisted pair infrastructure. This enables service providers to offer
broadband or data backhaul services to businesses, governments and various institu-
tions over existing last-mile, copper infrastructure. Today, more than ever, operators
are finding the business case for leveraging their existing copper networks to be highly
attractive from an ROI and initial investment perspective over fiber roll-outs.
2.1 TYPICAL APPLICATION
The Black Box Extenders are the perfect fit for simple, cost-effective high speed Ether-
net Extension. They allow customers to take advantage of the existing copper infra-
structure to connect remote LANs across distances and at speeds previously
unthought-of. The auto-rate feature ensures the highest speed is achieved on each
connection, and the plug and play operation ensures they are up and running in sec-
onds. Add in the 4 x auto-sensing full/half duplex 10/100Base-TX Ethernet ports with
the integrated crossover switch to make setup even easier. The value of these Ether-
net Extenders can’t be beat!
• Auto-Rate Feature—The advanced auto-rate algorithm automatically deter-
mines the best possible rate for each connection and sets up each extender
without any need for user interface.
• Plug and Play—Just unpack the extenders, plug them into each end of the
extension, power them up, and they are up and running. It doesn’t get any eas-
ier!
• High Speed/Long Reach—These Ethernet Extenders provide the best combi-
nation of speed and distance seen anywhere in the industry!

724-746-5500 | blackbox.com Page 15
Applications Overview
Figure 4. LB52xA-KIT application

724-746-5500 | blackbox.com
Page 16
Black Box DeeSL.2 Ethernet Extender
2.2 DISTANCE CHARTS
2.2.1 Distance Chart LB52xA-KIT Series - Auto Mode (TCPAM-32/16)
2.2.2 Distance Chart LB52xA-KIT Series - Optimal Mode (TCPAM - 128)
Table 4: Distance Chart LB52xA-KIT Series - Optimal Mode
Table 3: Distance Chart LB52xA-KIT
Line Rate Distance
Line
Speed 522A 2-Wire 524A 4-Wire 528A 8-Wire 26 AWG/
0.4mm 24 AWG/
0.5mm 22 AWG/ 0.65mm
N= kbps kbps kbps kft km kft km kft km
3192 384 768 17.0 5.2 21.5 6.6 27.5 8.4
4256 512 1024 17.0 5.2 20.5 6.2 27.0 8.2
8512 1024 2048 14.5 4.4 17.5 5.3 23.5 7.2
12 768 1536 3072 13.5 4.1 16.0 4.9 21.5 6.6
16 1024 2048 4096 12.5 3.8 15.0 4.6 20.0 6.1
20 1280 2560 5120 12.0 3.7 14.5 4.4 19.0 5.8
24 1536 3072 6144 11.5 3.5 14.0 4.3 18.5 5.6
32 2048 4096 8192 11.0 3.4 13.5 4.1 17.5 5.3
36 2304 4608 9216 11.0 3.4 13.0 4.0 17.0 5.2
60 3840 7680 15360 9.0 2.7 11.0 3.4 14.5 4.4
72 4608 9216 18432 8.5 2.6 10.0 3.0 13.5 4.1
89 5696 11392 22784 7.5 2.3 9.0 2.7 12.0 3.7
Line Rate Distance
Line
Speed 522A 2-Wire 524A 4-Wire 528A 8-Wire 26 AWG/
0.4mm 24 AWG/
0.5mm 22 AWG/ 0.65mm
N= kbps kbps kbps kft km kft km kft km
7448 896 1792 20.0 6.1 24.0 7.3 31.0 9.4
8512 1024 2048 19.0 5.8 23.0 7.0 30.0 9.1
10 640 1280 2560 18.0 5.5 20.5 6.2 28.0 8.5
11 704 1408 2816 17.0 5.2 19.0 5.8 26.5 8.1
16 1024 2048 4096 16.0 4.9 18.0 5.5 24.5 7.5
20 1280 2560 5120 15.0 4.6 17.0 5.2 23.0 7.0

724-746-5500 | blackbox.com Page 17
2.2.3 Distance Chart LB52xA-KIT Series - TCPAM - 128
Table 5: Distance Chart LB52xA-KIT Series - TCPAM-128
22 1408 2816 5632 14.0 4.3 15.5 4.7 21.0 6.4
27 1728 3456 6912 13.0 4.0 14.5 4.4 20.0 6.1
34 2176 4352 8704 12.0 3.7 14.5 4.4 18.5 5.6
39 2496 4995 9987 11.0 3.4 13.0 4.0 17.0 5.2
44 2816 5362 11264 10.0 3.0 12.0 3.7 15.5 4.7
53 3392 6784 13568 9.0 2.7 10.5 3.2 13.5 4.1
73 4681 9344 18688 8.0 2.4 9.5 2.9 12.5 3.8
89 5696 11392 22784 7.0 2.1 8.5 2.6 10.5 3.2
110 7040 14080 28160 6.0 1.8 7.0 2.1 9.0 2.7
125 8000 16000 32000 5.0 1.5 6.0 1.8 7.5 2.3
152 9728 19456 38912 4.0 1.2 4.5 1.4 6.0 1.8
164 10496 20992 41984 3.0 0.9 3.5 1.1 4.5 1.4
198 12792 25584 51168 2.0 0.6 2.5 0.8 3.0 0.9
Line Rate Distance
Line
Speed 522A 2-Wire 524A 4-Wire 528A 8-Wire 26 AWG/
0.4mm 24 AWG/
0.5mm 22 AWG/ 0.65mm
N= kbps kbps kbps kft km kft km kft km
5320 640 1280 22.0 6.7 26.5 8.1 34 10.4
6384 768 1536 21.0 6.4 25.5 7.8 32.5 9.9
8512 1024 2048 20.0 6.1 24.0 7.3 31.0 9.4
9576 1152 2304 19.0 5.8 23.0 7.0 29.5 9.0
9576 1152 2304 18.0 5.5 21.5 6.6 27.5 8.4
12 768 1536 3072 17.0 5.2 20.5 6.2 26.5 8.1
16 1024 2048 4096 16.0 4.9 19.5 5.9 24.5 7.5
20 1280 2560 5120 15.0 4.6 18.0 5.5 23.0 7.0
22 1408 2816 5632 14.0 4.3 16.5 5.0 21.5 6.6
27 1728 3456 6912 13.0 4.0 15.7 4.8 20.0 6.1
34 2176 4352 8704 12.0 3.7 14.5 4.4 18.5 5.6
Line Rate Distance
Line
Speed 522A 2-Wire 524A 4-Wire 528A 8-Wire 26 AWG/ 0.4mm 24 AWG/ 0.5mm 22 AWG/ 0.65mm
N= kbps kbps kbps kft km kft km kft km

724-746-5500 | blackbox.com
Page 18
Black Box DeeSL.2 Ethernet Extender
3. HARDWARE INSTALLATION
This chapter contains information for planning the installation of the LB52xA-KIT with
the following installation procedures:
• “Unpacking the LB52xA-KIT” on page 20 lists the contents of the shipping box
• “Connecting cables” on page 21 describes how to install the port cables
• “Grounding the LB52xA-KIT and connecting power” on page 21 describes how to
ground and connect the power source
3.1 PLANNING THE INSTALLATION
Before beginning the actual installation, we strongly recommend that you gather all the
information you will need to install and set up the device.
• Create a network diagram
• Gather IP related information
• Install the hardware and software needed to configure the LB52xA-KIT
• Verify power source reliability
39 2496 4992 9984 11.0 3.4 13.0 4.0 17.0 5.2
45 2880 5760 11520 10.0 6.0 12.0 3.7 15.5 4.7
53 3392 6784 13568 9.0 2.7 10.5 3.2 13.5 4.1
74 4736 9472 18944 8.0 2.4 9.5 2.9 12.5 3.8
90 5760 11520 23040 7.0 2.1 8.5 2..6 10.5 3.2
112 7168 14336 28672 6.0 1.8 7.0 2.1 9.0 2.7
126 8064 16128 32256 5.0 1.5 6.0 1.8 7.5 2.3
152 9728 19456 38912 4.0 1.2 4.5 1.4 6.0 1.8
167 10688 21376 42752 3.0 0.9 3.5 1.1 4.5 1.4
198 12672 25344 50688 2.0 0.6 2.5 0.8 3.0 0.9
220 14072 28144 56288 1.0 0.3 1.0 0.3 1.5 0.5
239 15288 30476 61152 0.5 0.2 0.5 0.2 1.0 0.3
Line Rate Distance
Line
Speed 522A 2-Wire 524A 4-Wire 528A 8-Wire 26 AWG/ 0.4mm 24 AWG/ 0.5mm 22 AWG/ 0.65mm
N= kbps kbps kbps kft km kft km kft km

724-746-5500 | blackbox.com Page 19
Hardware Installation
When you finish preparing for your installation, go to section “Installing the LB52xA-
KIT” on page 20 to install the device.
3.1.1 Network Diagram
Draw a network overview diagram that displays all neighboring IP nodes, connected
elements and telephony components. Figure 5. shows possible network connections
to the LB52xA-KIT.
Figure 5. LB52xA-KIT connection diagram
3.1.2 IP Related Information
Before you can set up the basic IP connectivity for your LB52xA-KIT series you should
have the following information:
• IP addresses used for Ethernet LAN and WAN ports
• Subnet mask used for Ethernet LAN and WAN ports
You will need a PC (or equivalent) with a VT-100 emulation program (e.g. HyperTermi-
nal) to configure the software on your LB52xA-KIT.
+-
DC 9V CONSOLE
RST
MGMT LINE
LAN
Desktop PC Laptop computer
LAN
Printer
Switch
Notebook
Notebook
Desktop PC
Desktop PC
ServerRAID Drive
WAP

724-746-5500 | blackbox.com
Page 20
Black Box DeeSL.2 Ethernet Extender
3.1.3 AC Power Mains
If you suspect that your AC power is not reliable, for example if room lights flicker often
or there is machinery with large motors nearby, have a qualified professional test the
power. Install a power conditioner if necessary. Refer to “Grounding the LB52xA-KIT
and connecting power” on page 21.
NOTE: When setting up your LB52xA-KIT, you must consider cable-length limitations
and potential electromagnetic interference (EMI) as defined by the applicable local and
international regulations. Ensure that your site is properly prepared before beginning
installation.
3.1.4 Location and mounting requirements
The LB52xA-KIT is intended to be placed on a desktop or a similar sturdy, flat surface
that offers easy access to the cables. Additionally, you should consider the need to
access the unit for future upgrades and maintenance.
This completes the planning phase for installation. The next section begins the installa-
tion procedures.
3.1.5 Installing the LB52xA-KIT
Unpacking the LB52xA-KIT
Inspect the shipping carton for external damage. Note any damage before removing
the container contents. Report any equipment damage to the shipping carrier immedi-
ately for claim purposes. Save all packing material in case you need to return an item
to the factory for servicing.
The LB52xA-KIT comes with the following items:
• LB52xA-KIT
• An RJ-45-to-RJ-45 cable for use with the console and Ethernet ports
• A DB-9-to-RJ-45 (EIA-561) adapter for connecting a PC’s serial port to the
LB52xA-KIT console port
The mains outlet that is utilized to power the equipment must be
within 1 foot (3 meters) of the device and shall be easily accessi-
ble.
WARNING
