Black Box TL555A User manual

1
Run two or four
remote controllers
from one host.
Run sync or async,
local or remote.
Share lines in
broadcast or select
mode.
Transparent to data.
Speeds up to 64 kbps
or 2.048 bps.
TD
RD RTS CTS DSR RLSD
1234
V.35 Data Sharer
High-speed V.35 line-sharing.
KeyFeatures
V.35DATASHARERS
Black Box Corporation • 1000 Park Drive • Lawrence, PA 15055-1018 • Tech Support: 72 -7 6-5500 • www.blackbox.com • e-mail: [email protected]
© 2005. All rights reserved.
Black Box Corporation.
6/13/2005 #12276
Ordering Information
ITEM CODE
V.35 Data Sharers
2-Channel ...................................................................TL555A
-Channel ...................................................................TL570A
You may also need…
V.35 Interface Cable, Male/Male ...................EYN 50-MM
Contention Type: RTS/CTS
Operation: Synchronous or
asynchronous; half- or full duplex
Speed: TL555A: Up to 6 kbps;
TL570A: Up to 2.0 8 Mbps
Interface: Master port is DTE, slave
port is DCE
Connectors: TL555A: (3) M/3 F;
TL570A: (5) M/3 F
Indicators: TL555A: (6) LEDs:
Power, RTS A, RTS B, and
Master Port: CD, CTS, RXD;
TL570A: (6) LEDs: TD, RD, RTS,
CTS, DSR, RLSD
ower: TL555A: 115 VAC, 60 Hz;
TL570A: 115/230 VAC, 60/50 Hz,
25 watts, wallmount
transformer
Size: TL555A: 2.5"H x 8.1"W x
11.3"D (6. x 20.6 x 28.7 cm);
TL570A: 1.8"H x 12"W x 8"D ( .6 x
30.5 x 20.3 cm)
Specifications
U
se these bidirectional port-
sharing devices in local or
remote applications for
synchronous or asynchronous
operation.
V.35 Data Sharers enable two
or four synchronous controllers to
share one host (via CSU/DSUs) in
a polled environment.
In a local asynchronous setup,
two or four terminals can share
one mainframe, controller, or
front-end processor.
In broadcast mode, the host
sends a polling message to all
remote controllers. In select
mode, only the device you select
receives the host’s transmissions
until the host polls again.
