Wireless Video Presentation System III Quick Installation Guide
1. What’s Included
Your package should include the following items. If anything is missing
or damaged, contact Black Box Technical Support at 724-746-5500
or [e-mail].
• (1) Wireless Video Presentation System III unit
• (1) 5-VDC, 2.5-A wallmount power supply with U.S. adapter, UK adapter,
EU adapter, and Australia adapter
• (2) antennas
• (1) mounting bracket for a wall
• (2) small mounting screws to mount the AC1132A to a bracket
• (4) large screws to mount the bracket to the wall
• This quick installation guide
• (1) USB flash drive/token containing software and a user’s manual
2. USB Token Contents
The USB token consists of the following software:
Client Folder:
• Software for Windows®, Mac®OS, and App for Windows Mobile 5/6
Applications Folder:
• VAC (for audio projection)
• VDD (for virtual extended screen)
• IB Maker (for changing startup screen)
• PtG Converter (for MobiShow PtG function)
• SNMP Manager (for Wireless Presentation System device management)

Page 3
724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
3. Hardware Description
Figures 3-1 and 3-2 illustrate the front and back panels of the unit. Table 3-1
describes its components.
1 2
Figure 3-1. Front panel.
3 4 5 6 7 8 3
Figure 3-2. Back panel.
Table 3-1. Wireless Presentation System III components.
Number Component Description
1USB connector Connects to mouse and/or keyboard
2Power LED Lights when power to the unit is on
3Antenna port Connects to antenna
45-VDC power connector Links to power
5VGA connector Connects to projector input
6Audio connector Attaches to audio
7RJ-45 port Links to LAN
8Reset button Press to reset the unit

Page 4 724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
4. Installation
1. Connect the projector VGA cable to the AC1132A unit’s VGA connector and
turn on the projector power.
Figure 4-1. Connect the AC1132A to the projector.
2. Power on the AC1132A unit.
The unit is ready when the projector shows the default menu in Figure 4-2.
Figure 4-2. Default menu.

Page 5
724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
4.1 Windows
1. Make sure your PC WLAN is already enabled, and connect your PC to the
AC1132A unit using your wireless Ethernet interface.
Figure 4-3. Choose a wireless network screen.
2. Open the Web browser, and it will redirect you to the AC1132A home page
automatically, or you can enter the IP address to access the AC1132A home
page. The default IP address of the AC1132A is 192.168.100.10. The IP address
shown on the left corner of the projector screen is the default IP address.
Figure 4-4. Home page.

Page 6 724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
3. Download the client software (Figure 4-5). Select the “Windows 7/Vista/XP”
and execute the installation program (Figure 4-6).
After you install the program, the Wireless Presentation System III shortcut will
appear on the PC desktop.
Figure 4-5. Main page.
Figure 4-6. Run or Save dialog box and WPS shortcut icon.
4. Make sure your personal firewall allows AC1132A software to pass through.
If not, you will need to configure the firewall to accept this connection.
5. Enter the LOGIN CODE as it appears on the projector screen (Figure 4-7).

Page 7
724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
Figure 4-7. Login.
6. Click the “Play” button to start projection, or choose one of the
numbers (1 to 4) to project to the split screen (Figure 4-8).
Figure 4-8. Start projection.

Page 8 724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
4.2 Windows Mobile 5/6
1. Make sure your WLAN in the Smartphone or PDA is already enabled, and
connect your smartphone or PDA to the AC1132A unit.
2. Open your browser and redirect to the AC1132A home page to download the
MobiShow client software, and execute the installation program.
3. Open “Programs” on your phone and find the “MobiShow” application.
4. Select the “MobiShow” icon to launch the client software.
5. MobiShow will turn on Wi-Fi on your phone and list available access points for
you to choose (Figure 4-9).
Figure 4-9. Selecting an access point screen.
6. Select a MobiShow wireless network (SSID with prefix WPS) to connect to.
7. MobiShow client will connect to that access point and search for MobiShow
devices automatically. When a MobiShow device is found, it will automatically
log in and the main menu in Figure 4-10 will be shown on your phone.

Page 9
724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
Figure 4-10. Main menu.
8. Select which feature to use. To project your phone’s screen, click on the “Screen”
icon. To do a PC-less presentation with Presentation-to-Go (PtG), select the “PtG”
icon. To project photos from your phone, select the “Photo” icon.
NOTE: Not all phones support screen projection.
4.3 Mac
1. Enable your Wi-Fi and connect to the AC1132A (WPS) device.
Figure 4-11. Select WPS.
2. Execute the AC1132A client software for Mac. (You can find it on the Wireless
Presentation System III USB token or download it from the AC1132A web page.)

Page 10 724-746-5500 | blackbox.com
Wireless Video Presentation System III Quick Installation Guide
3. Launch WPS software and enter the login code (Figure 4-12).
Figure 4-12. Enter login code screen.
4. Click the “Play” button to start projection (Figure 4-13).
Figure 4-13. Start projection.

Page 11
