Black Box LBG1000A-R2 User manual

Manageable Gigabit Switch
User’s Manual 1
February 2004
Managed Express Switch
LBG1000A-R2
CUSTOMER
SUPPORT
INFORMATION
Order toll-free in the U.S. 24 hours, 7 A.M. Monday to midnight Friday: 877-877-BBOX
FREE technical support, 24 hours a day, 7 days a week: Call 724-746-5500 or
fax [phone] Mail order: Black Box Corporation, 1000 Park Drive, Lawrence,
PA 15055-1018 Web site: www.blackbox.com • E-mail: [email protected]

Manageable Gigabit Switch
User’s Manual 2
FEDERAL COMMUNICATIONS COMMISSION AND
CANADIAN DEPARTMENT OF COMMUNICATIONS
RADIO FREQUENCY INTERFERENCE STATEMENT
This equipment generates, uses, and can radiate radio frequency energy and if not installed and used properly, that
is, in strict accordance with the manufacturer’s instructions, may cause interference to radio communication. It has
been tested and found to company with the limits for a Class A computing device in accordance with the
specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection against
such interference when the equipment in a residential area is likely to cause interference, in which case the user at
his own expense will be required to take whatever measures may be necessary to correct the interference.
Changes or modifications not expressly approved by the party responsible for compliance could void the user’s
authority to operate the equipment.
This digital apparatus does not exceed the Class A limits for radio noise emission from digital apparalus set out in
the Radio Interference Regulation of the Canadian Department of Communications.
Le présent appareil numérique n’émet pas de bruits radioélectriques dépassant les limites applicables aux appareils
numériques de la classe A prescrites dans le Règlement sur le brouillage radioélectrique publié par le ministère des
Communications du Canada.

Manageable Gigabit Switch
User’s Manual 3
Normas Oficiales Mexicanas (NOM)
INSTRUCCIONES DE SEGURIDAD
Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado.
Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura.
Todas las advertencias en el aparato eléctrico y en sus instrucciones de operación deben ser respetadas.
Todas las instrucciones de operación y uso deben ser seguidas.
El aparato eléctrico no deberá ser usado cerca del agua—por ejemplo, cerca de la tina de baño, lavabo, sótano
mojado o cerca de una alberca, etc.
El aparato eléctrico debe ser usado únicamente con carritos o pedestales que sean recomendados por el fabricante.
El aparato eléctrico debe ser montado a la pared o al techo sólo como sea recomendado por el fabricante.
Servicio—El usuario no debe intentar dar servicio al equipo eléctrico más allá a lo descrito en las instrucciones de
operación. Todo otro servicio deberá ser referido a personal de servicio calificado.
El aparato eléctrico debe ser situado de tal manera que su posición no interfiera su uso. La colocación del aparato
eléctrico sobre una cama, sofá, alfombra o superficie similar puede bloquea la ventilación, no se debe colocar en
libreros o gabinetes que impidan el flujo de aire por los orificios de ventilación.
El equipo eléctrico deber ser situado fuera del alcance de fuentes de calor como radiadores, registros de calor,
estufas u otros aparatos (incluyendo amplificadores) que producen calor.
El aparato eléctrico deberá ser connectado a una fuente de poder sólo del tipo descrito en el instructivo de
operación, o como se indique en el aparato.
Precaución debe ser tomada de tal manera que la tierra fisica y la polarización del equipo no sea eliminada.
Los cables de la fuente de poder deben ser guiados de tal manera que no sean pisados ni pellizcados por objetos
colocados sobre o contra ellos, poniendo particular atención a los contactos y receptáculos donde salen del aparato.
El equipo eléctrico debe ser limpiado únicamente de acuerdo a las recomendaciones del fabricante.
En caso de existir, una antena externa deberá ser localizada lejos de las lineas de energia.
El cable de corriente deberá ser desconectado del cuando el equipo no sea usado por un largo periodo de tiempo.
Cuidado debe ser tomado de tal manera que objectos liquidos no sean derramados sobre la cubierta u orificios de
ventilación.
Servicio por personal calificado deberá ser provisto cuando:
A: El cable de poder o el contacto ha sido dañado; u
B: Objectos han caído o líquido ha sido derramado dentro del aparato; o
C: El aparato ha sido expuesto a la lluvia; o
D: El aparato parece no operar normalmente o muestra un cambio en su desempeño; o su cubierta ha sido dañado.

Manageable Gigabit Switch
User’s Manual 4
Preface
This manual describes how to install and use the Manageable Gigabit Switch. This switch introduced here is
designed to deliver full scalability with SNMP/RMON web-based management functions by providing:
LBG1000A-R2: 24 x 10/100BaseTX fixed ports and optional 2 x 1000BaseT/SX/LX ports.
For the two Gigabit ports, it allows options of fiber type and wavelength at user’s discretion. This switch brings a
simple answer to today’s complicated networking environments.
To get the most out of this manual, you should have an understanding of Ethernet networking concepts.
In this manual, you will find:
Features on the switch
Illustrative LED functions
Installation instructions
Management Configuration
SNMP, DHCP, IGMP…
Specifications

Manageable Gigabit Switch
User’s Manual 5
Table of Contents
PREFACE 4
TABLE OF CONTENTS 5
PRODUCT OVERVIEW 8
LBG1000A-R2: Manageable 24 + 2 Gigabit Switch 8
Package Contents 8
Product Highlights 9
Basic Features 9
Management Support 9
Front Panel Display 10
Physical Ports 11
Switch Management 11
Administration console via RS-232 serial port 11
Web-based browser interface 11
External SNMP-based network management application 11
INSTALLATION 12
Selecting a Site for the Switch 12
Connecting to Power 12
Connecting to Your Network 13
Cable Type & Length 13
Cabling 13
SWITCH MANAGEMENT 14
Management Access Overview 14
Administration Console 14
Direct Access 14
SNMP-Based Network Management 15
Protocols 15
Management Architecture 15

Manageable Gigabit Switch
User’s Manual 6
MENU-DRIVEN CONSOLE MANAGEMENT 16
Logging on to the switch 16
At the screen prompt 16
Switch Management Screen 17
Navigating Through the Console Interface 17
Performing Basic Management Activities 18
Start with Selection Menu 18
General Management Configurations 18
LAN Port Configurations 19
Console Port Configurations 21
Performing Advanced Management Activities 22
Start with Selection Menu 22
L2 Switching DataBase 23
IP Networking 26
Bridging 30
Static Filtering 31
MAC Address In-Filters 32
Spanning Tree Functions 33
SNMP Functions 35
Other Protocols 36
Port Mirroring 37
QoS Setup 38
Sending and Receiving Files 41
Logout 42
Save Settings 42
Restore Default Settings 42
Reboot 42
WEB-BASED BROWSER MANAGEMENT 43
Logging on to the switch 43
Understanding the Browser Interface 43
Performing File Activities 44
Start with Selection Menu 44
Performing Basic Setup Activities 45
Start with Selection Menu 45
LAN Port Configuration 47
Console Port Configuration 49
Performing Advanced Setup Activities 50
Start with Selection Menu 50
MAC Address Management 50
IP Networking 52
Per Port Statistics 57

Manageable Gigabit Switch
User’s Manual 7
Bridging 57
Static MAC Filter 58
IP Multicast Group 59
VLAN Perspective 60
Spanning Tree Perspective 61
SNMP 63
Other Protocols 64
Port Mirroring 66
QoS 66
SNMP & RMON MANAGEMENT 71
Overview 71
SNMP Agent and MIB-2 (RFC 1213) 71
RMON MIB (RFC 1757) and Bridge MIB (RFC 1493) 72
RMON Groups Supported 72
Bridge Groups Supported 72
SPECIFICATIONS 73

Manageable Gigabit Switch
User’s Manual 8
Product Overview
LBG1000A-R2: Manageable 24 + 2 Gigabit Switch
Front View
Package Contents
When you unpack the product package, you shall find the items listed below. Please inspect the contents, and report
any apparent damage or missing items immediately to your authorized reseller.
3LBG1000A-R2: Manageable Switch
3User’s Manual
3AC power cord
3RS232 cable
3Rackmount brackets with screws

Product Highlights
Basic Features
LBG1000A-R2: 24 x 10/100BaseTX ports with RJ-45 connectors, plus options of 2 x 1000BaseT/SX/LX ports, auto-
MDIX on port 17 ~ port 24
Auto-negotiation for speed and duplexity on all 10/100BaseTX ports
Full wire-speed forwarding rate
Store-and-forward mechanism
Back-pressure and IEEE 802.3x compliant flow control
Supports 32K MAC addresses
Provides 2MBytes memory buffer
Front panel reset button
Front panel port status LEDs
♦Standard 19” rackmount size, one-unit-height
Management Support
VLAN
Port-based VLAN
802.1Q tagged VLAN
PORT-SECURITY
Limit number of MAC addresses learned per port
Static MAC addresses stay in the filtering table
PORT-MIRRORING
Port-mirroring provided through dedicated
COS (IEEE802.1p Classification of Service)
4-level transmission priorities: 4 queues per output port
Packet transmission scheduled using Weighted Round Robin (WRR)
User-defined weights
Classification of packet priority can be based on either a VLAN tag on packet or a user-definable port priority
INTERNETWORKING PROTOCOLS
Bridging:
802.1D Spanning Tree
802.1p/Q – GARP/GVRP
Routing:
RIP
RIP-2
DHCP-Relay
ICMP Router Discovery Message
IP Multicast:
IGMP Snooping
Maximum of 128 VLANs and IP multicast sessions
Bandwidth Control

Manageable Gigabit Switch
User’s Manual 10
NETWORK MANAGEMENT METHODS
Console port access via RS-232 cable
Telnet remote access
SNMP agent:
MIB-2 (RFC1213)
Bridge MIB (RFC1493)
RMON MIB (RFC1757) – statistics, history, alarm and events
VLAN MIB (802.1Q/RFC2674)
Private MIB
Java applet-based MIB browser
Web browser support based on HTTP server and CGI parser
Kermit/TFTP software-upgrade capability
Front Panel Display
cPOWER
This LED comes on when the switch is properly connected to power and turned on.
dPort Status LEDs
The LEDs are located at the left side of each section, displaying status for each respective port. Please refer to the following table
for more details.
LED State Indication
On
A valid network connection
established.
LNK stands for LINK.
LNK/AC
T Flashin
g
Transmitting or receiving data.
ACT stands for ACTIVITY.
On Connection in full duplex mode.
FDX stands for FULL-DUPLEX.
Flashin
g
Collision occurred.
COL stands for COLLISION.
FDX/CO
L
Off Connection in half-duplex mode.

Manageable Gigabit Switch
User’s Manual 11
eGigabit Port Status LEDs
The LEDs are located at the left side of each Gigabit module, displaying status for each respective port. Please refer to the
following table for more details.
LED State Indication
Flashing Transmitting or receiving data.
ACT stands for ACTIVITY.
ACT
Off No activity.
On
A valid network connection
established.
LNK stands for LINK.
LNK
Off No connection.
Physical Ports
The Manageable Gigabit Switch provides:
24 x 10/100TX fixed ports and options of 2 x 1000T/SX/LX ports.
16 x 10/100TX fixed ports and options of 1 x 8-Port 10/100TX/100FX module, 2 x 1000T/SX/LX ports.
CONNECTIVITY
SC connectors on Gigabit ports
ST, SC, VF-45, MT-RJ connectors on 100FX ports
RJ-45 connectors on TX ports
MODE SELECTION
• 10BaseT full-duplex mode
• 10BaseT half-duplex mode
• 100BaseTX/FX full-duplex mode
• 100BaseTX/FX half-duplex mode
• 1000BaseT/SX/LX full-duplex mode
• Auto-negotiating mode
Switch Management
Administration console via RS-232 serial port
The switch provides an onboard serial port, which allows the switch to be configured via a directly connected terminal or a
Telnet session.
Web-based browser interface
The switch also boasts a point-and-click browser-based interface that lets users access full switch configuration and
functionality from a Netscape or Internet Explorer browser.
External SNMP-based network management application
The switch can also be configured via SNMP.

Manageable Gigabit Switch
User’s Manual 12
Installation
This chapter gives step-by-step instructions about how to install the switch:
Selecting a Site for the Switch
As with any electric device, you should place the switch where it will not be subjected to extreme temperatures,
humidity, or electromagnetic interference. Specifically, the site you select should meet the following requirements:
-The ambient temperature should be between 32 and 104 degrees Fahrenheit (0 to 40 degrees Celsius).
-The relative humidity should be less than 90 percent, non-condensing.
-Surrounding electrical devices should not exceed the electromagnetic field (RFC) standards for IEC 801-3, Level 2
(3V/M) field strength.
-Make sure that the switch receives adequate ventilation. Do not block the ventilation holes on each side of the
switch or the fan exhaust port on the rear of the switch.
-The power outlet should be within 1.8 meters of the switch.
Connecting to Power
Step 1: Connect the supplied AC power cord to the receptacle on the back of the switch, and then plug it into a
standard AC outlet with a voltage range from 100 to 240 Vac.
Step 2: Disconnect the power cord if you want to shut down the switch.
Rear view

Manageable Gigabit Switch
User’s Manual 13
Connecting to Your Network
Cable Type & Length
It is necessary to follow the cable specifications below when connecting the switch to your network. Use appropriate cables
that meet your speed and cabling requirements.
Cable Specifications
Speed Connector
Port
Speed
Half/Full
Duplex
Cable Max.
Distance
10BaseT RJ-45 10/20
Mbps
2-pair
UTP/STP
Cat. 3, 4, 5
100 m
100BaseTX RJ-45 100/200
Mbps
2-pair
UTP/STP
Cat. 5
100 m
100BaseFX
(*Wavelength
of 850nm)
ST, SC, VF-
45, MT-RJ
100/200
Mbps
62.5/125µ
m multi-
mode fiber
2 km
100BaseFX
(*Wavelength
of 1300nm)
SC 100/200
Mbps
10/125µm
single-
mode fiber
75 km
1000BaseT RJ-45 1000/2000
Mbps
4-pair
UTP/STP
Cat. 5
100 m
SC 1000/2000
Mbps
62.5/125µ
m multi-
mode fiber
220 m1000BaseSX
(*Wavelength of
850nm)
SC 1000/2000
Mbps
50/125µm
multi-mode
fiber
550 m
SC 1000/2000
Mbps
62.5/125µ
m multi-
mode fiber
550 m1000BaseLX
(*Wavelength
of 1300nm)
SC 1000/2000
Mbps
10/125µm
single-
mode fiber
20 km
Cabling
Step 1: First, ensure the power of the switch and end devices is turned off.
<Note> Always ensure that the power is off before any installation.
Step 2: Prepare cable with corresponding connectors for each type of port in use.
<Note> To connect two regular RJ-45 ports between switches or hubs, you need a cross-over cable.
Step 3: Consult Cable Specifications Table on previous page for cabling requirements based on connectors and
speed.
Step 4: Connect one end of the cable to the switch and the other end to a desired device.
Step 5: Once the connections between two end devices are made successfully, turn on the power and the switch is
operational.

Manageable Gigabit Switch
User’s Manual 14
Switch Management
This chapter explains the methods that you can use to configure management access to the switch. It describes the
types of management applications and the communication and management protocols that deliver data between
your management device (workstation or personal computer) and the system. It also contains information about port
connection options.
This chapter covers the following topics:
• Management Access Overview
• Key Concepts
• Key Guidelines for Implementation
• Administration Console Access
• Web Management Access
• SNMP Access
• Standards, Protocols, and Related Reading
Management Access Overview
The switch gives you the flexibility to access and manage the switch using any or all of the following methods.
The administration console and web browser interface support are embedded in the switch software and are
available for immediate use.
Administration Console
The administration console is an internal, character-oriented, menu-driven user interface for performing system
administration such as displaying statistics or changing option settings.
Using this method, you can view the administration console from a terminal, personal computer, Apple Macintosh,
or workstation connected to the switch’s console port.
There are two ways to use this management method: direct access or modem access. The following sections
describe these methods.
Direct Access
Direct access to the administration console is achieved by directly connecting a terminal or a PC equipped with a terminal-
emulation program (such as HyperTerminal) to the switch console port.
When using the management method, configure the terminal-emulation program to use the following parameters (you can
change these settings after login):
[DEFAULT PARAMETERS]
♦115,200bps
♦8 data bits
♦No parity
♦1 stop bit

Manageable Gigabit Switch
User’s Manual 15
This management method is often preferred because you can remain connected and monitor the system during system
reboots. Also, certain error messages are sent to the serial port, regardless of the interface through which the associated
action was initiated. A Macintosh or PC attachment can use any terminal-emulation program for connecting to the terminal
serial port. A workstation attachment under UNIX can use an emulator such as TIP.
Modem Access
You can access the switch’s administration console from a PC or Macintosh using an external modem attached to the
console port. The switch management program provides Console Port screen, accessible from the Basic Management
screen, that lets you configure parameters for modem access.
When you have configured the external modem from the administration console, the switch transmits characters that you
have entered as output on the modem port. The switch echoes characters that it receives as input on the modem port to the
current administration console session. The console appears to be directly connected to the external modem.
Web Management
The switch provides a browser interface that lets you configure and manage the switch remotely.
After you set up your IP address for the switch, you can access the switch’s web interface applications directly in
your web browser by entering the IP address of the switch. You can then use your web browser to list and manage
switch configuration parameters from one central location, just as if you were directly connected to the switch’s
console port.
Web Management requires either Microsoft Internet Explorer 4.01 or later or Netscape Navigator 4.03 or later.
SNMP-Based Network Management
You can use an external SNMP-based application to configure and manage the switch. This management method
requires the SNMP agent on the switch and the SNMP Network Management Station to use the same community
string. This management method, in fact, uses two community strings: the get community string and the set
community string. If the SNMP Network management station only knows the set community string, it can read and
write to the MIBs. However, if it only knows the get community string, it can only read MIBs. The default get and
set community strings for the switch are public.
Protocols
The switch supports the following protocols:
VIRTUAL TERMINAL PROTOCOLS, SUCH AS TELNET
A virtual terminal protocol is a software program, such as Telnet, that allows you to establish a management session from a
Macintosh, a PC, or a UNIX workstation. Because Telnet runs over TCP/IP, you must have at least one IP address configured on
the switch before you can establish access to it with a virtual terminal protocol.
<Note> Terminal emulation is different from a virtual terminal protocol in that you must connect a terminal directly to the console port.
SIMPLE NETWORK MANAGEMENT PROTOCOL (SNMP)
SNMP is the standard management protocol for multivendor IP networks. SNMP supports transaction-based queries that allow the
protocol to format messages and to transmit information between reporting devices and data-collection programs. SNMP runs on
top of the User Datagram Protocol (UDP), offering a connectionless-mode service.
Management Architecture
All of the management application modules use the same Messaging Application Programming Interface (MAPI).
By unifying management methods with a single MAPI, configuration parameters set using one method (e.g. console
port) are immediately displayed the other management methods (e.g. SNMP agent of web browser).
The management architecture of the switch adheres to the IEEE open standard. This compliance assures customers
that the switch is compatible with, and will interoperate with other solutions that adhere to the same open standard.

Menu-Driven Console Management
The switch provides a menu-driven console interface for configuration purposes. The switch can be configured
either locally through its RS-232 port or remotely via a Telnet session. For the later, you must specify an IP address
for the switch first.
This chapter describes how to configure the switch using its menu-driven console.
Logging on to the switch
At the screen prompt
Login:
Password:
LOGIN NAME
Enter the console interface factory default console name admin.
PASSWORD
Enter the factory default password (no password, press <Enter> directly). Or enter a user-defined password if you followed the
instructions later and changed the factory default password.
Factory Default Password: no password, press <Enter> directly.
<Note> Only one console and three telnet users can log on to the switch concurrently. However, it is not recommended that multiple
users modify the configuration at the same time.
* For initial IP settings, you must configure the switch through its
RS232 port.

Switch Management Screen
BASIC MANAGEMENT
Basic management activities.
ADVANCED MANAGEMENT
Advanced management activities.
LOGOUT
Highlight this option and press Enter to log out.
SAVE SETTINGS
Highlight this option and press Enter to save the current settings and remain in the configuration program.
RESTORE DEFAULT SETTINGS
Highlight this option and press Enter to restore the factory default settings.
REBOOT
Highlight this option and press Enter to reboot.
Navigating Through the Console Interface
The console interface consists of a series of menu boxes. Each menu box has several options, which are listed
vertically. Move the highlight to select an option as you wish; press the Enter key to activate that option.
Press this key… To
Up Arrow or K* Move the highlight one line up in a menu box
Down Arrow or J* Move the highlight one line down in a menu
box
Tab Move the highlight between screens
Enter Select the highlighted option
Esc Move to a previous menu
<Note> * Remember to release the <Caps Lock> key if you press <K> or <J> and cannot move the highlight on the screen.

Performing Basic Management Activities
Basic management activities consist of General, LAN Port, and Console Port tasks.
Start with Selection Menu
Step 1: Highlight [Basic Management] from [Switch Management] screen and press <Enter>. The [Basic
Management] screen appears:
Step 2: Highlight a desired option and press <Enter>. Or press <Esc> to exit.
General Management Configurations
Step 1: Highlight [General] from [Basic Management] screen and press <Enter>.
System Name
Step 2: System Name is highlighted. Press <Enter> if you want to change it.
Location
Step 3: Move to highlight Location and press <Enter> if you want to change it.
admin Password
Step 4: Move to highlight admin Password and press <Enter> if you want to change it.

Manageable Gigabit Switch
User’s Manual 19
Guest Password
Step 5:Move to highlight guest Password and press <Enter> if you want to change it.
Statistics Collection
Step 6: Move to highlight Statistics Collection and press <Enter> if you want to change it, Disabled or Enabled.
Reboot-On-Error
Step 7: Move to highlight Reboot-On-Error and press <Enter> if you want to change it, Disabled or Enabled.
Remote Telnet Login
Step 8:Move to highlight Remote Telnet Login and press <Enter> if you want to change it, Disabled or Enabled.
Return to Basic Management
Step 9: Press <Esc> to return to [Basic Management] screen when completed.
LAN Port Configurations
Step 1: Highlight [LAN Port] from [Basic Management] screen and press <Enter>.
SPEED & FLOW CONTROL
Step 2: Speed & Flow Control is highlighted. Press <Enter> if you want to set speed or flow control on port.
Step 3: Highlight All (10/100M or 1000M) Ports and press <Enter> to configure at one time. Otherwise, move to
highlight each port and press <Enter> to configure individually.

Manageable Gigabit Switch
User’s Manual 20
Step 4: Port Setting Options screen appears. Highlight Speed & Flow Control and press <Enter>.
Line Speed
Step 5: For Line Speed, move to highlight a desired setting from Speed Options and press <Enter>.
<Note> In the Speed Options, Auto denotes auto negotiation on speed and duplex mode, HDdenotes half-duplex, and FD denotes
full-duplex.
Step 6: Press <Esc> to previous screen. Highlight Flow Control and press <Enter>
Flow Control
Step 7: For Flow Control, move to highlight a desired setting from the Flow Cntl Options and press <Enter>.
Step 8:Press <Esc> to a previous screen as shown in Step 3.
PHYSICAL PORT ADDRESS
Step 9: Press <Esc> to a previous screen as shown in Step 1.
Step 10: Move to highlight Physical Address to view physical port address.
Step 11: Press <Esc> to return to [Basic Management] screen when completed.
