Black Box LBH120A-H SERIES User manual

24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM
INDUSTRIAL
SWITCH/
CONVERTER
LBH120A-H SERIES AND LMC270A-XX-XX SERIES
USER MANUAL
100
5
1
2
3
4
100
LINK/
ACT
PWR
LINK/
ACT
1
2
3
4
X
100
LINK/
ACT
100
LINK/
ACT
PWR
LINK/
ACT
1
PWR
LINK/
ACT

2
TABLE OF CONTENTS
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
1. SPECIFICATIONS........................................................................................................................................................................... 3
2. OVERVIEW...................................................................................................................................................................................... 5
2.1 Introduction...............................................................................................................................................................................................5
2.2 Available Models......................................................................................................................................................................................5
2.2.1 Industrial Switches............................................................................................................................................................................................. 5
2.2.2 Industrial Media Converters ............................................................................................................................................................................5
2.3 Features ....................................................................................................................................................................................................5
2.4 What’s Included........................................................................................................................................................................................6
2.5 Hardware Description..............................................................................................................................................................................6
3. INSTALL ATION .............................................................................................................................................................................. 8
3.1 Preparing the Installation Site.................................................................................................................................................................8
3.2 Installation Steps .....................................................................................................................................................................................8
4. OPERATION.................................................................................................................................................................................. 11
APPENDIX A. REGULATORY INFORMATION ................................................................................................................................ 12
A.1 FCC Statement .......................................................................................................................................................................................12
A.2 NOM Statement .....................................................................................................................................................................................13
APPENDIX B. TRADEMARKS/DISCLAIMER.................................................................................................................................. 14
B.1 Trademarks Used in this Manual ..........................................................................................................................................................14
B.2 Disclaimer...............................................................................................................................................................................................14

3
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 1: SPECIFICATIONS
SPECIFICATIONS
Approvals
ISO Manufactured in an ISO 9001 facility
Safety UL 62368
EMI FCC Part 15B, Class A ,
VCCI Class A ,
EN 61000-6-4,
EN 61000-3-2,
EN 61000-3-3
EMS EN 61000-6-2 ,
EN 61000-4-2 (ESD Standards) ,
EN 61000-4-3 (Radiated RFI Standards) ,
EN 61000-4-4 (Burst Standards) ,
EN 61000-4-5 (Surge Standards),
Signal ports: ±4kV line-to-ground,
EN 61000-4-6 (Induced RFI Standards),
EN 61000-4-8 (Magnetic Field Standards)
Environmental Test Compliance IEC 60068-2-6 Fc (Vibration),
IEC 60068-2-27 Ea (Shock),
FED STD 101C Method 5007.1 (Free fall w/ package)
Technology
Standards IEEE 802.3u 100BASE-TX/FX,
IEEE 802.3x full-duplex flow control,
IEEE 802.3az Energy Efficient Ethernet,
IEEE 802.1p Quality of Service (QoS)
Forwarding and Filtering Rate 10 Mbps: 14,880 pps,
100 Mbps: 148,810 pps
Packet Buffer Memory 448 KB
Processing Type Store-and-Forward,
Half-duplex back-pressure and IEEE802.3x full-duplex flow control,
Auto Negotiation,
Auto MDI/MDIX
Address Table Size 1K MAC addresses
Power
Power Input 12–48 VDC
Power Consumption 1.82 W Max. 0.14A @ 12 VDC,
0.07A @ 24 VDC, 0.038A @ 48 VDC

41. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 1: SPECIFICATIONS
SPECIFICATIONS (CONTINUED)
Mechanical
Connectors LBH120A-H: (4) RJ-45 device ports, (1) RJ-45 uplink port;
LBH120A-H-SC, LBH120A-H-20K-SC, LBH120A-H-40K-SC, LBH120A-H-75K-SC:
(4) RJ-45 device ports, (1) pair of SC fiber ports for uplink;
LBH120A-H-ST: (4) RJ-45 device ports, (1) pair of ST fiber ports for uplink;
LMC270A-MM-SC, LMC270A-SM-20K-SC, LMC270A-SM-40K-SC, LMC270A-SM-75K-SC:
(1) RJ-45 port, (1) pair of SC fiber ports;
LMC270A-MM-ST, LMC270A-SM-ST: (1) RJ-45 port, (1) pair of ST fiber ports
Indicators Per RJ-45 port: (1) Link/Activity LED, (1) Speed LED;
Per SC or ST fiber port: (1) Link/Activity LED, (1) Speed LED
Enclosure Plastic IP30
Mounting DIN rail, top hat type 35-mm
Dimensions Each unit: 4.33"H x 1.02"W x 2.76"D (11 x 2.6 x 7 cm)
Weight 0.44 lb. (0.2 kg)
Environment
Operating Temperature 14 to 140° F (10 to 60° C);
Tested at -4 to +158° F (-20 to +70° C)
Storage Temperature -40 to +185° F (-40 to +85° C)
Ambient Relative Humidity 5 to 95%, noncondensing

5
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
2.1 OVERVIEW
The Industrial Switches and Industrial Media Converters operate at temperature extremes of 14 to 140° F (-10 to +60* C). These units are
ideal for harsh environments constrained by space.
The switches provide four twisted-pair device ports and one twisted-pair or fiber uplink port. The media converters link twisted-pair
segments or devices to fiber segments or devices.
2.2 AVAILABLE MODELS
The models listed below are available.
2.2.1 INDUSTRIAL SWITCHES
LBH120A-H (four RJ-45 twisted-pair device connectors, and one RJ-45 twisted-pair uplink connector)
LBH120A-H-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors)
LBH120AH-ST (four RJ-45 twisted-pair device connectors, and one pair of ST fiber uplink connectors)
LBH120A-H-20K-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors, 20 km distance)
LBH120A-H-40K-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors, 40 km distance)
LBH120A-H-75K-SC (four RJ-45 twisted-pair device connectors, and one pair of SC fiber uplink connectors, 75 km distance)
2.2.2 INDUSTRIAL MEDIA CONVERTERS
LMC270A-MM-SC (one RJ-45 twisted-pair connector and one pair of SC multimode fiber connectors)
LMC270A-MM-ST(one RJ-45 twisted-pair connector and one pair of ST multimode fiber connectors)
LMC270A-SM-20K-SC (one RJ-45 twisted-pair connector and one pair of SC single-mode fiber connectors, 20 km distance)
LMC270A-SM-40K-SC (one RJ-45 twisted-pair connector and one pair of SC single-mode fiber connectors, 40 km distance)
LMC270A-SM-75K-SC (one RJ-45 twisted-pair connector and one pair of SC single-mode fiber connectors, 75 km distance)
LMC270A-SM-20K-ST (one RJ-45 twisted-pair connector and one pair of ST single-mode fiber connectors, 20 km distance)
2.3 FEATURES
Complies with EN61000-6-2 & EN61000-6-4 EMC Generic standard immunity for industrial environment.
Supports IEEE 802.3az 10BASE-TE only. 10BASE-T is not supported. 10BASE-TE is fully interoperable with 10BASE-T over 328 feet
(100 meters) of class D (Category 5) or better cabling as specified in ISO/IEC 11801:1995.
Supports 802.3az/802.3u/802.3x. Auto-negotiation: 10/100Mbps, Full/Half-duplex. Auto MDI/MDIX.
100BASE-FX: Multi mode SC or ST type, Single mode SC or ST type.
100BASE-BX: WDM Multi mode or Single mode SC type.
Supports 1024 MAC addresses, 448K bits buffer memory.
IEEE802.3x Flow control for Full-duplex, Back pressure for Half-duplex.
Non-blocking architecture and full wire-speed forwarding rate.

61. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
Supports IEEE802.1p QoS with two priority queues.
Supports IEEE802.3az Energy Efficient Ethernet (EEE).
Supports Max. length of frame up to 1552 Bytes.
Power Consumption: 1.82 W Max. 0.14 A @ 12 VDC, 0.07 A @ 24 VDC, 0.038 A @ 48 VDC.
Power Supply: DC Terminal Block power input, 12-48 VDC.
Operating temperature ranges from 14 to 140° F (-10 to +60° C).
2.4 WHAT’S INCLUDED
Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support
at 877-877-2269 or [e-mail].
(1) Industrial Ethernet Switch or (1) Industrial Ethernet Media Converter
(1) Quick Start Guide
2.5 HARDWARE DESCRIPTION
Figure 2-1 shows three available models. Table 2-1 describes their components. Models not pictured have the same components as
shown in the diagram, but have different fiber optic port speeds. For a complete list of available models and their port descriptions, see
Table 2-2.
1
2
3
4
5, 6
7
LBH120A-H LBH120A-H-SC LMC270A-MM-SC
FIGURE 2-1. LBH120A-H, LBH120A-H-SC AND LMC270A-MM-SC MODELS

7
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTER 2: OVERVIEW
TABLE 2-1. LBH120A-H, LBH120A-H-SC AND LMC270A-MM-SC COMPONENTS
NUMBER IN FIGURE 2-1 COMPONENT DESCRIPTION
1(4) RJ-45 connectors Links to RJ-45 devices
2(1) RJ-45 connector Links twisted-pair uplink
3 (1) Link/Activity LED Lights when there is activity on the link
4 (1) Speed LED on RJ-45 connector Lights when data is being transmitted at 100 Mbps
5 (1) Link/Activity LED on RJ-45 connector Lights when there is activity on the link
6 (1) Speed LED on SFP port Lights when data is being transmitted at 100 Mbps
7 (1) pair of SC or ST connectors Links to fiber optic cable, uplink port on the LBH120A-H-SC
and device port on the LMC270A-MM-SC
TABLE 2-2. PORTS ON THE SWITCHES AND MEDIA CONVERTERS
PRODUCT CODE NUMBER OF RJ-45 PORTS NUMBER OF FIBER PORTS
SWITCHES
LBH120A-H 5 (4 device, 1 uplink) None
LBH120A-H-SC 4(1) SC
LBH120A-H-ST 4(1) ST
LBH120A-H-20K-SC 4 (1) SC, 20 km distance
LBH120A-H-40K-SC 4 (1) SC, 40 km distance
LBH120A-H-75K-SC 4 (1) SC, 75 km distance
MEDIA CONVERTERS
LMC270A-MM-SC 1(1) SC
LMC270A-MM-ST 1(1) ST
LMC270A-SM-20K-SC 1 (1) SC, 20 km distance
LMC270A-SM-40K-SC 1 (1) SC, 40 km distance
LMC270A-SM-75K-SC 1 (1) SC, 75 km distance
LMC270A-SM-20K-ST 1 (1) ST, 20 km distance

81. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTE R 3: INSTALL ATION
3.1 PREPARING THE INSTALLATION SITE
Before you install the device, be sure your operating environment meets the operating environment requirements listed below.
Power source:
Provide a power source within 6 feet (1.8 meters) of the installation location. Power specifications for the Hardened Unmanaged
Switch are shown in Chapter 1, Specifications.
Environment:
Install the Hardened Unmanaged Switch in a dry area, with ambient temperature between -14 and +140º F (-10 and +60° C).
The installation location should have a maximum relative humidity of 95%, non-condensing.
Do not restrict airflow by covering or obstructing the top and side panels of the Hardened Unmanaged Switch. Keep at least 2 inches
(5.08 centimeters) free on all sides for cooling.
3.2 INSTALLATION STEPS
STEP 1: Install the unit on the DIN rail. Place the switch on the DIN rail from above using the slot. Push the front of the switch
toward the mounting surface until it audibly snaps into place.
FIGURE 3-1. INSTALLING THE UNIT ON A DIN RAIL

9
1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTE R 3: INSTALL ATION
STEP 2: Connect 10/100BASE-TX.
The table below lists the pinouts of the 10/100BASE-TX ports.The picture shows the connector pinout.
TABLE 3-1. 10/100BASE-TX PINOUTS
PIN REGULAR PORTS UPLINK PORT
1 Input Receive Data + Output Transmit Data +
2 Input Receive Data - Output Transmit Data -
3 Output Transmit Data + Input Receive Data +
4 Not connected Not connected
5 Not connected Not connected
6 Output Transmit Data - Input Receive Data -
7 Not connected Not connected
8 Not connected Not connected
PIN 8
PIN 7
PIN 6
PIN 5
PIN 4
PIN 3
PIN 2
PIN 1
STEP 3: Connect 100BASE-FX
The Tx (transmit) port of device 1 is connected to the Rx (receive) port of device 2, and the Rx (receive) port of device 1 to the Tx
(transmit) port of device 2. The fiber connector is shown below.
FIGURE 3-3. FIBER CONNECTOR
STEP 4: Connect the switch to your network.
Cable Type and Length
Follow the cable specifications below when connecting the switch to your network. Use the appropriate cables that meet your speed
and cabling requirements.
TABLE 3-2. CABLE SPECIFICATIONS
SPEED CONNECTOR PORT SPEED HALF/FULL DUPLEX CABLE MAX
10BASE-TE RJ-45 10/20 Mbps 2-pair UTP/STP CAT5 328 ft. (100 m)
100BASE-TX RJ-45 100/200 Mbps 2-pair UTP/STP CAT5 328 ft. (100 m)
100BASE-FX SC, ST 200 Mbps MMF (50 or 62.5 µm) 1.2 mi. (2 km)
100BASE-FX SC, ST 200 Mbps SMF (9 or 10 µm) 12.4 or 24.8 mi. (20 or 40 km)
100BASE-BX SC 200 Mbps MMF (50 or 62.5 µm) 1.2 or 3.1 mi. (2 or 5 km)
100BASE-BX SC 200 Mbps SMF (9 or 10 µm) 12.4 or 24.8 mi. (20 or 40 km)
FIGURE 3-2. RJ-45 CONNECTOR

10 1. 8 7 7. 8 7 7. 2 2 6 9 BLACKBOX.COM
NEED HELP?
LE AVE THE TECH TO US
LIVE 24/7
TECHNICAL
SUPPORT
1. 8 7 7. 87 7. 2 2 6 9
CHAPTE R 3: INSTALL ATION
STEP 5: Grounding the Unit
CAUTION: This equipment is designed to permit the connection of the grounded conductor of the DC supply circuit to the grounding
conductor at the equipment.
For power connection, the following conditions must be met:
• This equipment must be connected directly to the DC supply system grounding electrode conductor or to a bonding jumper from a
grounding terminal bar or bus to which the DC supply system grounding electrode conductor is connected.
• This equipment must be located in the same immediate area (such as, adjacent cabinets) as any other equipment that has a
connection between the grounded conductor of the same DC supply circuit and the grounding conductor, and also the point of
grounding of the DC system. The DC system should not be
grounded elsewhere.
• The DC supply source must be located within
the same premises as the equipment.
• Switching or disconnecting devices will not be in the grounded circuit conductor between the DC source and the point of
connection of the grounding electrode conductor.
GND
PWR
POWER GROUND
12–4 8 V D C
POWER INPUT
GROUND
FIGURE 3-4. GROUNDING THE UNIT
Before you apply power:
1. Inspect the equipment thoroughly.
2. Verify that all cables are installed correctly.
3. Check cable routing to make sure cables are not damaged or create a safety hazard.
4. Be sure that all equipment is mounted properly and securely.
STEP 5: Apply power.
Connect the 12–48 VDC power supply voltage to start up the switch via the terminal block.
