blackburn Delphi 5.0 User manual

TABLE OF CONTENTS
ENGLISH
Bike One/Bike Two Setting 29
Program Wheel Size, Units and Chronograph 30
Program Odometers 37
Program Time of Day 38
Program Heart Rate Zone Upper and Lower Limits 40
Operating the Heart Monitor 42
Program Altimeter 44
Operating the Ride Time and Total Time Chronographs 47
Starting Stopping and Clearing the Chronograph and Memory 48
Clearing Maximum Speed or Maximum Cadence Only 48
Operating the LAP Chronograph 49
Operating the Backlight System 51
Technical Data 52
Warranty and Repair 54
TABLE OF CONTENTS
ENGLISH
Introduction 1
Warnings and Cautions 2
Care and Maintainance 3
How This Product Works 4
Parts of your Blackburn Delphi Cycle Computer 7
Resetting the Computer to its Default Settings 8
Shipping and Sleep Modes 8
Changing the Battery in the Blackburn Delphi Cycle Computer 9
Changing the Battery in the Wireless Speed Transmitter 11
Changing the Battery in the Indepad™Transmitter Belt 12
Wearing the Blackburn Indepad™ Transmitter Belt 13
Installing the Computer on your Bike 14
Keys and their Functions 18
Sections of LCD Display 21
Basic Operation 25
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 2

Congratulations on your purchase of a new Blackburn Delphi Cycle Computer. Blackburn Delphi computers
are among the most advanced cycle computers available in the market today. Designed to meet the needs of
serious cyclists, Delphi cycle computers offer a wide range of advanced features including wireless operation,
ECG accurate wireless heart rate and ultra-accurate altimeter functionality. Blackburn has gone to great
expense to assure these are the finest cycle computers you can buy. We are so sure of this, each unit we
make is covered by a limited LIFETIME WARRANTY against any defects in materials or workmanship. See
Page 54 for a complete description of the Bell Sports Limited Warranty
This manual is an integral part of your Blackburn cycle computer. Please read it carefully and use it while
performing the initial programming and operating of the unit. After you are fully familiar with all of the
features and functions of your Blackburn cycle computer, put this manual in a safe location for future
reference.
WARNING—Blackburn cycle computers and heart rate monitors are training and fitness tools. Before
beginning any exercise program, consult your doctor to discuss your exercise plans.
WARNING—Blackburn cycle computers featuring an altimeter sensor are NOT designed to be used as a
PRIMARY altitude instrument for flying, skydiving, hang gliding or other sports where sudden major changes
in altitude may occur or when there is a need for industrial precision.
WARNING—Do Not divert your attention from the road ahead to operate yo\ur cycle computer at any time.
We also strongly suggest you wear a Bell or Giro helmet any time you ride your bike.
WARNING TO PEOPLE THAT WEAR PACEMAKERS—While your heart rate monitor should have no direct
effect on your pacemaker, we strongly recommend that you consult your physician or cardiologist before
using this product or embarking on an exercise program.
CAUTION—Blackburn cycle computers are sophisticated electronic instruments. Blackburn recommends this
unit only be installed by a qualified Blackburn retailer. Failure to read the instructions may result in
damaged caused by improper installation and may void the warranty. If you are unsure about how to properly
perform any aspect of the assembly, installation or operation of your Blackburn cycle computer, please
contact your local Blackburn retailer.
CAUTION—This unit is designed to be water resistant under normal riding conditions. It should not be
immersed in water. It should not be left attached to the bike if the bike is being transported on an
automobile.
INTRODUCTION WARNINGS AND CAUTIONS
ENGLISH
ENGLISH
12
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 4

HOW A WIRELESS CYCLE COMPUTER WORKS
Your new Blackburn Delphi cycle computer is equipped with a wireless radio system for the transmission of
speed and distance. Wheel rotation data is sent from the fork to the computer unit on the handlebars where
it is processed to display speed and distance traveled. To reduce the chances of cross communication with
other wireless cycle computers the system is designed to be both directional and short range. Because of
the short range of the radio system, it is best to install the fork transmitter on the top half of the fork blade.
Mounting the unit at the bottom of the fork or on the back of the fork blade may result in the computer
being unable to pick up the signal.
AUTO START/STOP—Unlike wired units, wireless computers are incapable of having a true automatic start/stop
system because there is no hard wired circuit to close and activate the computer. Because of this, wireless
cycle computers must, at some point, turn off their radio system in order to conserve battery life. Your
Blackburn wireless computer is programmed with the most sophisticated Start/Stop algorithm available in a
cycle computer. While in SLEEP mode, the Delphi unit looks for new speed or heart rate information every
two minutes for a period of two hours. Even if you stop riding and do not start again for 2 hours, the largest
segment of ride data you will lose will be 2-minutes.
HOW THIS PRODUCT WORKS
ENGLISH
4
CYCLE COMPUTER
Blackburn cycle computers contain many delicate electronic components which may be damaged by
excessive exposure to heat, shock or general abuse. Treated with care, your cycle computer is capable of
delivering many years of reliable service. Improper care and handling, or damage caused by abuse or
neglect, will void you Blackburn Warranty.
NEVER—Leave your computer in your car on hot days.
NEVER—Store your Blackburn cycle computer in a plastic or other non-breathable container.
CARE AND MAINTENANCE
ENGLISH
3
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 6

WIRELESS HEART RATE MONITORS
DELPHI 5.0 AND 6.0
Your new Blackburn cycle computer may be equipped with a wireless heart rate monitor. The heart monitor
system is a sophisticated athletic training tool which is capable of measuring your heart rate with the
accuracy of a hospital ECG system. Heart rate monitors use a chest strap to pick up the electrical signal
emitted by the contractions of the heart and transmit the information to the computer. Every time the heart
beats, a short radio signal is sent from the chest transmitter to the computer. The computer measures the
time between the incoming signals, filters and averages them and displays a heart rate number on screen.
To achieve the most accurate heart rate reading possible, it is important to be aware of circumstances that
can cause false signals to enter the system and cause your heart rate measurement to be inaccurate.
1. The chest strap should be worn as tightly as possible without being uncomfortable. If the chest strap
is not tight enough, movement between it and your body can cause false signals to be generated,
which may be seen as heart beats by the watch. This is especially true during high impact activities,
such as running.
2. Environmental factors such as high-tension power lines, home security systems and radio towers may
interfere with the ability of the watch to receive a signal from the transmitter. A loss of the heart rate
signal and the heart rate display showing zero, will usually indicate this. This problem is usually
transient in nature, and will stop once you have passed out of the area of interference.
3. Occasionally, when you are using your heart rate monitor watch in close proximity to other heart rate
monitors, it is possible for your watch unit to pick up the signal from the other transmitters. This is
called cross-talk. When you are experiencing cross-talk, you will see a very high heart rate or a heart
rate of zero. If this happens, simply allow a bit more space between you and the other users.
4. While riding, the flow of air over your body may cause your jersey or shirt to flutter and tap against the
heart rate transmitter. This tapping can result in false signals being generated causing inaccurate
readings. If you find this happening, try wearing the transmitter backward so that the transmitter and
electrodes are against your back with the elastic strap across the front of your chest.
HOW THIS PRODUCT WORKS HOW THIS PRODUCT WORKS
ENGLISH
ENGLISH
5
PRESSURE SENSING ALTIMETERS
DELPHI 6.0
Because the altimeter system in the Blackburn Delphi 6.0 relies on Barometric Pressure for its
measurements, it is critical that you regularly calibrate the unit to a known altitude. Generally, the small
pressure changes experienced during a day of use will have only a minor effect on the accuracy of the unit.
However, the arrival or departure of a weather front can change the current altitude display by several
hundred feet or more.
To simplify the calibration process the Blackburn Delphi 6.0 allows you to store your home altitude to
memory and calibrate the unit to this altitude at any time using a PRESS & HOLD of the OPTION key while in
the CURRENT ALTITUDE screen.
6
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 8

SHIPPING MODE—Your new Blackburn Delphi computer comes to the dealer in SHIPPING
MODE. In this mode the LCD display is totally blank. This is done to extend the battery
life. Press any key to wake the unit up and advance to the default display mode.
NOTE: It is possible the unit will not come to you in SHIPPING MODE if it has been
previously activated. This should not have an adverse impact on the life of the
battery.
SLEEP MODE—When the receiver circuit of the computer unit shuts down, the unit goes into
its SLEEP MODE. In SLEEP MODE the display will show the current Time of Day,
Chronograph (RT or TT) and Units (Miles or Kilometers) settings.
On the bottom of the computer unit, to the upper right of the battery door is a small
hidden RESET key. Pressing this key with a toothpick or other small pointed object will
reset all programmed values to their default values and resets the microprocessor. This
may also be accomplished by removing and reinstalling the units’battery.
CAUTION—Pressing the RESET key will automatically clear any information from the units’
memory.
PARTS OF YOUR BLACKBURN DELPHI
CYCLE COMPUTER RESETTING THE COMPUTER TO ITS DEFAULT SETTINGS
SHIPPING AND SLEEP MODES
ENGLISH
ENGLISH
7
FACE OF COMPUTER
WHEEL MAGNET
WIRELESS FORK TRANSMITTER
WIRELESS FORK TRANSMITTER
MOUNTING PAD
IP- TIES
BLACKBURN INDEPAD™
HEART RATE TRANSMITTER
HEART RATE TRANSMITTER
ELASTIC STRAP
WIRELESS BRACKET
WIRELESS BRACKET WITH
CADENCE SENSOR
BRACKET SLEEVE
1
2
2
3
3
4
5
6
7
8
9
10
1
45
6
7
8
9
10
8
CYCLE COMPUTER
RESET BUTTON
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 10

CHANGING THE BATTERY IN THE BLACKBURN
DELPHI CYCLE COMPUTER
ENGLISH
ENGLISH
9
CHANGING THE BATTERY IN THE BLACKBURN
DELPHI CYCLE COMPUTER
Blackburn Delphi computers are powered by a CR2032 3v Lithium Battery. Under normal conditions, this
battery should last approximately one year.
REPLACING THE COMPUTER BATTERY
1. Using a coin, turn the battery door counter clockwise until the door comes free.
2. Take care not to damage the O-ring seal for the battery compartment and carefully remove the old
battery.
3. Place a new battery in the battery compartment with the positive (+) side toward the battery door. Be
extremely careful not to bend the battery contact when inserting a new battery.
4. Place the battery door over the opening and tighten it down by using a coin and turning in a clockwise
direction.
5. If the O-ring has been damaged, replace it before reinstalling the battery door.
CAUTION—Extreme care should be taken when replacing the battery to ensure the unit remains fully water
resistant. Failure to properly replace the battery and correctly seal the unit may cause the unit to become
damaged and may void the warranty.
CAUTION—Use of the backlight system an average of more than twice per day may result in shortened battery
life.
ALWAYS—Check the batteries if you are experiencing problems with your computer. Most problems
experienced with the operation of this unit are the result of dead or dying batteries.
REPLACING THE COMPUTER BATTERY
10
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 12

CHANGING THE BATTERY IN THE WIRELESS
SPEED TRANSMITTER CHANGING THE BATTERY IN THE INDEPAD™ TRANSMITTER BELT
ENGLISH
ENGLISH
The Wireless Speed Transmitter uses a 23A 12v Alkaline battery. Under normal conditions, this battery
should last approximately one year.
1. Using a coin, turn the battery door counter clockwise until the door comes free.
2. Take care not to damage the O-ring seal for the battery compartment and carefully remove the old
battery.
3. Place a new battery in the transmitter positive (+) side toward the battery door.
4. Place the battery door over the opening and tighten it down by using a coin and turning in a clockwise
direction.
5. If the O-ring has been damaged, replace it before reinstalling the battery door.
NOTE: Extreme care should be taken when replacing the battery to ensure the unit remains fully water
resistant. Failure to properly replace the battery and correctly seal the unit may cause the unit to
become damaged and may void the warranty.
The Blackburn Delphi 5.0 and 6.0 units feature a wireless heart rate transmitter, powered by a CR2032 3v
Lithium battery. Under normal conditions you can expect to get approximately 700-800 hours of heart rate
transmitter use with a fresh battery.
1. Using a coin, turn the battery door counter clockwise until the door comes free of the watch.
2. Take care not to damage the O-ring seal for the battery compartment and carefully remove the old
battery.
3. Place a new battery in the battery compartment with the positive (+) side toward the battery door.
4. Place the battery door over the opening and tighten it down by using a coin and turning in a clockwise
direction.
5. If the O-ring has been damaged, replace it before reinstalling the battery door. Most jewelers and
watch shops should have replacement O-ring seals.
NOTE: Extreme care should be taken when replacing the battery to ensure the unit remains fully water
resistant. Failure to properly replace the battery and correctly seal the unit may cause the unit to
become damaged and may void the warranty.
12
CYCLE COMPUTER
11
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 14

WEARING THE BLACKBURN INDEPAD™
TRANSMITTER BELT INSTALLING THE COMPUTER ON YOUR BIKE
ENGLISH
ENGLISH
To ensure a proper heart rate display, the chest transmitter must be moistened and properly adjusted. Wet
the electrodes (located to the right and left of the main transmitter case) with saliva or ECG conductive gel.
Do not use water, moisturizing creams or suntan oil, as these are insulators and may interfere with the heart
rate signal. Snap the plastic tabs at the end of the elastic belt into the holes at the end of the transmitter,
and adjust the strap so that the transmitter fits tightly below the pectoral muscles, as shown in the drawing.
NOTE: Users with significant chest hair may have a problem obtaining contact between the transmitter
electrodes and their skin, resulting in poor performance. It may be necessary for these individuals to
shave the area of their chest beneath the transmitter.
NOTE: In dry and cold climates it may take a few minutes of use for the electrodes to soften, and a layer of
perspiration to form between the contact and the skin for good performance. Moistening the electrodes
with saliva or ECG conductive gel can speed up this process.
13
INSTALLING THE WIRELESS FORK TRANSMITTER
The Delphi 4.0, 5.0 and 6.0 receive speed and distance from a wireless transmitter
mounted to the front fork.
1. Attach the wireless front wheel sensor and rubber mounting pad to the front of
the left fork blade using the zip-ties provided so the battery cap is pointing
downward. Snug up the zip-ties but do not fully tighten them. The sensor
should be mounted as high on the fork blade as possible. The range of the
transmitter is approximately 18in (46cm). Mounting it high on the fork will
assure good signal reception. Other mounting locations may work, but we feel
this is the best location for most applications.
2. Attach the spoke magnet to a spoke on the same side of the wheel as the sensor.
Tighten the attachment screw just enough to hold the magnet in place but loose
enough so that it is still movable.
3. Adjust the position of the sensor and magnet so they are in proper alignment as
shown. The magnet should pass by the sensor adjacent to the molded plastic
line at a distance of 1-3mm.
4. Once everything is in alignment, fully tighten the spoke magnet in place and
tighten the zip-ties holding the sensor to the fork.
14
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 16

INSTALLING THE CADENCE TRANSMITTER AND BRACKET
INSTALLING THE COMPUTER ON YOUR BIKE INSTALLING THE COMPUTER ON YOUR BIKE
ENGLISH
ENGLISH
CYCLE COMPUTER 16
INSTALLING THE CADENCE TRANSMITTER AND BRACKET
Activation of the cadence functions of the Delphi 4.0, 5.0 and 6.0 units requires the installation of the
bracket with the wired cadence sensor.
1. Attach the cadence sensor to the LEFT chain stay near where the crank/pedal pass the stay using the
zip-ties provided. Snug up the zip-ties but do not fully tighten them. It is recommended the cadence
sensor be mounted on the top of the chainstay.
NOTE: The wire exiting the sensor should be pointing toward the front of the bike.
2. Attach the cadence magnet to the back side of the LEFT crank arm using the zip-tie provided. The
cadence magnet should be attached as closely to the pedal spindle as possible.
3. Adjust and position the sensor so the magnet passes within 1-3mm. Fully tighten the zip-ties once
you have everything properly aligned.
4. Route the sensor wire forward and under the bottom bracket and along the bottom of the down tube
securing it occasionally with tape. Once you are near the head tube, the sensor wire should be
wrapped around the front or rear derailleur cable housing and the front brake cable housing.
5. Attach the bracket to the handlebars and tighten the mounting screw.
CAUTION—Make sure you leave enough slack in the sensor wire so the handle bars can turn fully from side to
side without creating any stress.
15
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 18

ATTACHING THE COMPUTER HEAD TO THE HANDLEBAR
BRACKET AND TESTING
When the bracket and sensors are completely installed on the bike slide the Delphi
computer unit into the bracket. The computer should LOCK into the bracket with an
AUDIBLE "CLICK". If you do not hear a click or if the Delphi computer body is not
flush with the back edge of the bracket the computer is not locked in place and may
come out.
Once everything is assembled spin the wheel and turn the crank and make sure speed
and cadence are being displayed on the screen. If you are not receiving one or both
pieces of information, check the magnet and sensor alignment and make sure the
magnets are passing the proper point on the sensor and that they are within 1-3mm. If
they are closer to 3mm than to 1mm try reducing the gap and test the system again.
INSTALLING THE WIRELESS HANDLEBAR BRACKET
Attach the wireless handlebar bracket to the handlebars. It is best to place the computer on the left side of
the bars so it is located directly above the transmitter. However, this is not absolutely necessary and the unit
should work mounted on either side of the bars.
NOTE: There are two molded plastic shims supplied with the Delphi computer brackets. The THIN shim
allows the bracket to fit Oversized 31.8 mm handlebars. The THICK shim allows the bracket to fit
standard 26.0mm handlebars.
INSTALLING THE COMPUTER ON YOUR BIKE KEYS AND THEIR FUNCTIONS
ENGLISH
ENGLISH
17
QUICK PRESS VS. PRESS & HOLD
There are two key actions used to program and operate the Delphi computer.
QUICK PRESS—The key is pressed quickly and then immediately released. This is the most common key action
and is used for most operations. Throughout this manual, QUICK PRESS will be indicated in BLUE.
PRESS & HOLD—The key is pressed and held for a period of 2-seconds until the desired action takes place.
This key action is generally used to enter a programming sequence or to clear information from the display.
Throughout this manual, PRESS & HOLD will be indicated in RED.
18
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 20

KEYS AND THEIR FUNCTIONS
ENGLISH
20
CYCLE COMPUTER
KEYS AND THEIR FUNCTIONS
ENGLISH
19
UPPER DISPLAY/EL KEY
Primary Function
•PRESS & HOLD to Change the Upper Display Window view.
Secondary Function
•QUICK PRESS to Activate the display light.
OPTION KEY
Primary Function
•QUICK PRESS to change between OPTIONS.within MODES
Secondary Functions
•QUICK PRESS to Change a Variable in a Setting Sequence
Upward. HOLD for FAST ADVANCE
•PRESS & HOLD in Main Altimeter Display to calibrate to
stored home altitude.
START/STOP KEY
Primary Function
•QUICK PRESS to Start/Stop TT Chronograph.
•QUICK PRESS to Start and Stop LAP Chronograph.
•PRESS & HOLD to Clear ALL Ride Data.
Secondary Functions
•QUICK PRESS to Change a Variable in a Setting Sequence
Downward. HOLD for FAST ADVANCE
•PRESS & HOLD to Clear Maximum Speed or Maximum
Cadence when in those Screens.
MODE KEY
Primary Function
•QUICK PRESS to change between MODES.
Secondary Functions
•PRESS & HOLD to Enter Setting Sequences.
•QUICK PRESS to Select a Variable in a Setting Sequence.
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 22

SECTIONS OF LCD DISPLAY SECTIONS OF LCD DISPLAY
ENGLISH
ENGLISH
22
CYCLE COMPUTER
RT/TT
These icons indicate if the
primary chronograph is
programmed to display Ride
Time (RT) with the chronograph
starting and stopping with the
turning of the wheel. Or Total
Time (TT) with the chronograph
running continually.
CHRONOGRAPH WINDOW
The center line of the LCD
display shows the primary
chronograph for the unit. The
center line always shows the
primary chronograph with one
exception. When viewing Heart
Rate Dynamic Memory in the
Lower Data Window, time
accumulated in each heart rate
zone will be displayed in the
Chronograph Window.
HEART RATE SYMBOL
This icon indicates Heart Rate
is currently being shown in the
Upper Data Window.
COMPARISON ARROWS
These icons work in two ways.
If Heart Rate is being displayed
in the Upper Data Window, the
arrows will show if you are
above, below or in your
programmed heart rate training
zone. If the Upper Data
Window is blank or displaying
Cadence, the arrows will
indicate if your current speed
is above, below or equal to your
current average speed.
NOTE: Cadence displays only function if the Delphi unit is attached to a cadence bracket.
SPEED WINDOW
Current Speed is always visible
in the upper left corner of the
LCD display.
KM/H AND M/H
These icons indicate if the unit
is programmed to display
speed and distance in Miles or
Kilometers.
UPPER DATA WINDOW
The Upper Data Window
located at the top right corner
of the LCD Display is one of
the unique features of
Blackburn Delphi computers.
You can choose to display
Current Cadence, Current Heart
Rate (5.0 and 6.0) or leave
this window blank.
CAD
This icon indicates Cadence is
currently being shown in the
Upper Data Window.
21
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 24

SECTIONS OF LCD DISPLAY SECTIONS OF LCD DISPLAY
ENGLISH
ENGLISH
24
CYCLE COMPUTER
AM
This icon is located to the right
of the Lower Data Window and
indicates when the 12-hr clock
is showing AM time. PM and
24-hr clock time are indicated
by the lack of any icon.
BIKE 1/BIKE 2
To the left of the Lower Data
Window are the Bike 1 and
Bike 2 Icons. PRESS & HOLD
both the MODE and OPTION
key to change the Bike Settings
at any time.
FT / M
These icons indicate if altitude
is being shown in Feet (FT) or
Meters (M).
NOTE: The altimeter setting is
independent of the
Miles/Kilometers
settings. You may choose
to display speed in Miles
per Hour and Altitude in
Meters.
ALTIMETER
To the right of the Lower Data
Line there is a mountain icon
which is active when altimeter
functions are being displayed.
LOWER DATA WINDOW
The Lower Data Window shows a wide range of secondary
functions. This window is controlled by the MODE and
OPTION keys. Pressing the MODE key scrolls through the
following information:
Speed Information
Distance Information
LAP Chronograph Information
Cadence Information (If Active)
Heart Rate Information
Altitude Information
Time of Day (If Active)
Pressing the OPTION key scrolls through the sub
functions in each category.
23
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 26

BASIC OPERATION BASIC OPERATION
ENGLISH
ENGLISH
MODE AND OPTION FLOW SEQUENCES
This diagram shows the information which is displayed in the Lower Data Window in response to QUICK
PRESSES of the MODE and OPTION keys.
MODE AND OPTION FLOW SEQUENCES
25
AVERAGE
AVERAGE
SPEED
SPEED
MAXIMUM
MAXIMUM
SPEED
SPEED
ODOMETER
ODOMETER
BIKE 1
BIKE 1
ODOMETER
ODOMETER
BIKE 2
BIKE 2
ODOMETER
ODOMETER
BIKE 1 & 2
BIKE 1 & 2
AVERAGE
AVERAGE
CADENCE
CADENCE
MAXIMUM
MAXIMUM
CADENCE
CADENCE
LAP 20
LAP 20
CURRENT
CURRENT
DISTANCE
DISTANCE
CLIMBED
CLIMBED
CURRENT
CURRENT
% GRADE
% GRADE
TIME BELOW
TIME BELOW
TARGET ZONE
TARGET ZONE
LAP 19
LAP 19
LAP 18
LAP 18
THROUGH
THROUGH
LAP 1
LAP 1
CURRENT
CURRENT
ALTITUDE
ALTITUDE
TRIP
TRIP
DISTANCE
DISTANCE
CURRENT
CURRENT
CADENCE
CADENCE
If Upper Display
If Upper Display
Window Shows HR
Window Shows HR
or Blank
or Blank
AVERAGE
AVERAGE
HEART RATE
HEART RATE
MAXIMUM
MAXIMUM
HEART RATE
HEART RATE
TIME ABOVE
TIME ABOVE
TARGET ZONE
TARGET ZONE
TIME IN
TIME IN
TARGET ZONE
TARGET ZONE
CURRENT
CURRENT
HEART RATE
HEART RATE
If Upper Display
If Upper Display
Window Shows
Window Shows
Cadence or Blank
Cadence or Blank
Delphi 5.0/6.0 Delphi 6.0
26
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 28

BASIC OPERATION BASIC OPERATION
ENGLISH
ENGLISH
UPPER DATA WINDOW FLOW SEQUENCES
This diagram shows the information which is displayed in the Upper Data Window. You may choose to show
Blank, Cadence or Heart Rate in this line.
AVERAGE SPEED COMPARISON
If the Upper Data Window is BLANK or showing CADENCE, the Comparison Arrows function as a Speed
Comparator indicating if you current speed is above ( ), below ( ) or equal (no arrow) to your current
average speed.
If the Upper Data Window is showing HEART RATE, the Comparison Arrows indicate if you are above ( ) ,
below ( ) or within (no arrow) your Target Heart Rate Zone.
BLANK W/
BLANK W/
SPEED
SPEED
COMPARISON
COMPARISON
CADENCE W/
CADENCE W/
SPEED
SPEED
COMPARISON
COMPARISON
EL KEY
HEART RATE W/
HEART RATE W/
TARGET HEART
TARGET HEART
RATE ZONE
RATE ZONE
INDICATION
INDICATION
27
STEP BY STEP—CHANGING THE UPPER DATA WINDOW INFORMATION
1. By Default the Upper Data Window is Blank (no display data) when you install a new battery.
a. Any time a Delphi unit is attached to a cadence bracket, CADENCE can be displayed in the Upper
Data Window.
b. On the Delphi 5.0 and 6.0 units which are equipped with a wireless heart rate system. Heart rate
may be displayed in the Upper Data Window.
2. To change the Upper Data Window PRESS & HOLD the Upper Display/EL key for approximately
2-seconds until the value changes.
3. Release the key and repeat step #2 until the information you want is showing.
NOTE: If Heart Rate or Cadence is displayed in the Upper Data Window, it is not shown in the Heart Rate or
Cadence sequences of the Lower Data Window.
28
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 30

Blackburn Delphi Computers allow you to program two separate bike functions. Most functions are totally
independent. For example, you can program Bike One for Ride Time in Miles and Bike Two for Total Time in
Kilometers.
NOTE: Before you can program any computer settings, the primary chronograph must be cleared to zero
using a 2-second PRESS & HOLD of the S/S key while in the Ride Distance (DST) screen.
CHANGE BIKE 1/BIKE 2 SETTING
PRESS & HOLD both the MODE and OPTION keys at the same time. When Bike 1-2 icon changes, release
the keys.
BIKE ONE/BIKE TWO SETTING PROGRAM WHEEL SI E, UNITS AND CHRONOGRAPH
ENGLISH
ENGLISH
29
Blackburn Delphi Computers use the rolling circumference of your wheel and tire combination to determine
speed and distance. The more accurate this setting, the more accurate your ride information will be.
However, variations of less than 30mm from the actual circumference will have very little impact on the
overall accuracy of the unit.
PRESET WHEEL SI ES
For easy setup, Blackburn Delphi Computers come
with 11 of the most popular wheel/tire sizes
pre-programmed into the unit. Simply select the size
of your tire as you scroll through the list in the
programming sequence and you are done.
The following are the pre-set wheel sizes programmed
into the unit. Follow the steps on Page 33 to enter a
preset wheel size into the Delphi unit.
30
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 32

PROGRAM WHEEL SI E, UNITS AND CHRONOGRAPH
ENGLISH
PROGRAM WHEEL SI E, UNITS AND CHRONOGRAPH
ENGLISH
MEASURED WHEEL SI E
If your wheel/tire size is not one of the pre-programmed sizes, or if you desire absolute accuracy, you may
enter an exact wheel circumference into the system. Use one of the two following methods for measuring
the circumference of your wheel/tire combination.
MEASURING WHEEL SI E USING RADIUS METHOD
The wheel radius method is quick, easy and very accurate.
1. With your bike standing vertically on a flat surface, measure the distance in millimeters from the
center of the front axle or quick release to the floor. If your measurement is in inches, multiply by
25.4 to convert to millimeters.
2. Multiply the measurement in millimeters by 6.28 and enter the resulting number into your computer
using the steps on Page 35.
MEASURING WHEEL SI E USING ROLLOUT METHOD
The roll-out method is the most accurate method for determining the circumference of your wheel/tire
combination.
1. On a flat open surface make a mark on your tire and the floor exactly where they meet.
2. Roll your bike forward one full revolution of the front wheel and mark the point on the floor where the
revolution is complete. For maximum accuracy be sitting on the bike while someone rolls you and the
bike forward.
3. Measure the distance from the first mark to the second in millimeters and enter the resulting number
into your computer using the steps on Page 35.
32
CYCLE COMPUTER
31
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 34

PROGRAM WHEEL SI E, UNITS AND CHRONOGRAPH PROGRAM WHEEL SI E, UNITS AND CHRONOGRAPH
ENGLISH
ENGLISH
STEP BY STEP—ENTER A PRE-PROGRAMMED WHEEL SI E
1. Choose Bike 1 or Bike 2. (Page 29)
2. Starting in the Distance (DST) screen of the Lower Display Window.
3. PRESS & HOLD the MODE key for approximately 2- seconds.
4. QUICK PRESS the OPTION or START/STOP keys to scroll through the 11 pre-programmed wheel sizes.
"WHEEL" will be shown in the lower line of the display with the pre-programmed wheel size shown in
the center line of the display.
5. Select your choice using a QUICK PRESS of the MODE key and advance to the SET Speed and
Distance units display (Page 36).
STEPS 2 & 3 STEP 4 STEP 5
STEP BY STEP—ENTER AN EXACT WHEEL SI E
1. Choose Bike 1 or Bike 2. (Page 29)
2. Starting in the Distance (DST) screen of the Lower Display Window.
3. PRESS & HOLD the MODE key for approximately 2- seconds.
4. QUICK PRESS the OPTION or START/STOP keys until the display shows 2096 flashing in the center
line of the display.
5. QUICK PRESS the MODE key once. The ones digit will begin to flash.
6. Adjust the digit using QUICK PRESSES of the OPTION and START/STOP keys and enter your choice
into memory using a QUICK PRESS of the MODE key.
7. Repeat until all digits are entered
8. A final QUICK PRESS of the MODE key will exit the Wheel Size setting sequence and advance to the
SET Speed and Distance units Display (Page 36).
NOTE: Before you can program any computer settings, the primary chronograph must be cleared to zero
using a 2-second PRESS & HOLD of the S/S key while in the Ride Distance (DST) screen.
34
CYCLE COMPUTER
33
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 36

PROGRAM WHEEL SI E, UNITS AND CHRONOGRAPH
ENGLISH
PROGRAM WHEEL SI E, UNITS AND CHRONOGRAPH
ENGLISH
35
STEPS 2 & 3 STEP 4
STEP 5 STEP 6 STEPS 7 & 8
STEP BY STEP—ENTER AN EXACT WHEEL SI E STEP BY STEP—SET SPEED AND DISTANCE UNITS
1. Upon entering the SET Speed and Distance units display, M/H (Miles per
Hour) or KM/H (Kilometers per Hour) will flash in the upper right hand corner
of the display.
2. QUICK PRESS the OPTION key to cycle between M/H and KM/H settings.
3. Select your choice using a QUICK PRESS of the MODE key and advance to the
SET Chronograph function display.
STEP BY STEP—SET CHRONOGRAPH FUNCTION
1. Upon entering the SET Chronograph function display, RT (Ride Time) or TT
(Total Time) will flash in the upper right hand corner of the display.
2. QUICK PRESS the OPTION key to cycle between RT and TT (Total Time)
settings.
3. Select your choice using a QUICK PRESS of the MODE key and exit the setting
sequence.
RIDE TIME (RT)—When RT is selected the Delphi’s Chronograph will start and stop with
the motion of the wheel. This setting tracks the actual time you are riding your bike.
TOTAL TIME (TT)—When TT is selected the Delphi’s Chronograph will initially start with
the first rotation of the wheel. However, it will continue to run from that point, until
the timing is stopped, using a QUICK PRESS of the START/STOP key.
STEPS 1 & 2
(SPEED/DISTANCE)
STEPS 1 & 2
(CHRONOGRAPH)
36
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 38

PROGRAM ODOMETERS PROGRAM TIME OF DAY
ENGLISH
ENGLISH
Blackburn Delphi Computers are equipped with Separate Odometers for Bike 1 and
Bike 2 and a Combined Odometer showing the total for both bikes. Bike 1 and Bike
2 Odometers may be reprogrammed with an existing mileage following a battery
change.
NOTE: Make sure you write down your mileage for each Odometer prior to removing
the battery if you wish to reprogram the odometers.
NOTE: If Odometer 1 and Odometer 2 are set for different units (Miles or Kilometers)
as defined by the Speed and Distance Units settings for Bike 1 and Bike 2,
the Combined Odometer (ODO 1/2) will display in the units set for Bike 1.
NOTE: If the total capacity of any odometer is exceeded, the Lower Data Window will
display 5-dashes.
STEP BY STEP—SETTING THE PROGRAMMABLE
ODOMETERS
1. Starting in ANY Odometer screen (Odo 1, Odo 2 or Odo 1/2 ) in either Bike 1
or Bike 2.
2. PRESS & HOLD the MODE key for approximately 2-seconds.
3. ODO 1 will appear in the Lower Data Window with "00,000" in the Center
Display Line.
4. Adjust the Odometer 1 setting using QUICK PRESSES of the OPTION and
START/STOP keys. Fast advance using a PRESS & HOLD.
5. When Odo 1 is set to the desired value, QUICK PRESS the MODE key to enter
the value and Advance to setting Odo 2.
6. Repeat steps 3 and 4.
7. QUICK PRESS the MODE key to enter the Odo 2 value and exit the setting
sequence.
STEPS 3 & 4
STEPS 5 & 7
37
Blackburn Delphi Computers are equipped with a clock which shows time of day in either 12 or 24 hour
formats. There is also a programming option which allows you to turn the clock off so it does not show up in
the normal operation sequence, reducing the number of key strokes needed to move through the displays.
STEP BY STEP—SETTING THE TIME OF DAY
1. Starting in the Time of Day display in the Lower Data Window if Time of Day is Active; or Starting in
the Average or Maximum Speed displays if Time of Day is Inactive.
2. PRESS & HOLD the MODE key for approximately 2-seconds.
3. VIEW will appear in the Lower Data Window with ON or OFF in the Center Display Line.
4. Select ON or OFF using QUICK PRESSES of the OPTION key. QUICK PRESS the MODE key to enter the
value and advance to 12/24 Hour setting.
a. Select ON if you wish Time of Day to be part of the display sequence in the Lower Display Window.
b. Select OFF if you do not wish to view Time of Day on the display.
5. Repeat steps 3 and 4 to Set Hours and Minutes and QUICK PRESS the MODE key to exit the Time of
Day programming sequence.
NOTE: Before you can program any computer settings, the primary chronograph must be cleared to zero
using a 2-second PRESS & HOLD of the S/S key while in the Ride Distance (DST) screen.
38
CYCLE COMPUTER
Blackburn_4/5/6_Manual 8/3/05 9:58 AM Page 40
